0 GTFSのデータを Streamlitで可視化してみた 2024-04-19 第87回NearMe技術勉強会 Kenji Hosoda
1 GTFSとは • GTFS (General Transit Feed Specification) は、交通システムに関する関連情報を利⽤者に配 信するために使⽤される”オープン標準”
• 路線、時刻表、運賃、地理的な乗り換えを表現する「GTFS Schedule」とトリップの更新、⾞ 両位置、サービスアラートなどのリアルタイム情報を提供する「GTFS Realtime」という⼆つ の主要な仕様がある • それに加えて、様々なニーズに対応するために拡張されたフォーマットが存在
2 GTFS-JPについて • GTFSの国際標準をベースにしつつ、⽇本独特の交通システムや⾔語、運賃体系に対応 するためにカスタマイズされている • 以下のサイトからデータを取得可能 https://tshimada291.sakura.ne.jp/transport/gtfs-list.html
3 今回は都営バスのデータを可視化してみる • GTFS-JP • https://ckan.odpt.org/dataset/b_bus_gtfs_jp-toei • GTFS Realtime •
https://ckan.odpt.org/dataset/b_bus_gtfs_rt-toei
4 セットアップ • こちらのコードをダウンロード • https://gist.github.com/kenji4569/ea42817d05980d2508963e66b297d03b • 以下を実⾏ • pip
install streamlit streamlit-folium folium pydeck pandas requests geopy gtfs-realtime-bindings • streamlit run gtfs-viewer-app.py • (オプション)公共交通オープンデータセンターにて開発者登録してアクセストークンを取得 (2営 業⽇かかる) • https://developer.odpt.org/ • 実⾏時にアクセストークンをセット • ACCESS_TOKEN=<your_access_token> streamlit run gtfs-viewer-app.py
5 実⾏結果 GTFS-JPのダウンロード バス停の表示 リアルタイムバス位置の表示 更新頻度 表示対象の絞り込み マップの種類
6 (表⽰対象の絞り込みとマップの切り替えについて) • データ数が多いのでfoliumだと動きが遅い → pydeckに変更 • (ただし、現状pydeckの⽅がリアルタイムの更新は苦⼿?)
7 コード解説1 GTFS-JPのダウンロード def download_gtfs_jp (): ... url = (
f"https://api.odpt.org/api/v4/files/Toei/data/ToeiBus-GTFS.zip?acl:consumerKey= {ACCESS_TOKEN}" if ACCESS_TOKEN else "https://api-public.odpt.org/api/v4/files/Toei/data/ToeiBus-GTFS.zip" ) with ( requests.get(url) as res, io.BytesIO(res.content) as bytes_io, zipfile.ZipFile(bytes_io) as zip, ): zip.extractall(GTFS_JP_DATA_DIR ) • ToeiBus-GTFS.zipファイルをダウンロード • ファイルを展開して./data以下に保存 ダウンロードしたデータ
8 コード解説2 GTFS Realtime のダウンロード from google.transit import gtfs_realtime_pb2 def
download_gtfs_realtime (time_steps): ... feed = gtfs_realtime_pb2.FeedMessage() records = [] with urllib.request.urlopen(url) as res: feed.ParseFromString( res.read()) for entity in feed.entity: record = [ entity.id, entity.vehicle.trip.trip_id, entity.vehicle.trip.route_id, entity.vehicle.trip.direction_id, entity.vehicle.position.latitude, entity.vehicle.position.longitude, entity.vehicle.current_stop_sequence, entity.vehicle.timestamp, entity.vehicle.stop_id, ] records.append(record) • ToeiBusのリアルタイムフィード (Protocol Buffers形式)をライブラリ を介して取得 参考:https://nttdocomo-developers.jp/entry/20231218_1
9 今後の展望 https://www.linkedin.com/posts/mobilitydata_gtfs-demandrespo nsivetransportation-drt-activity-7175942816848588800-JX9v • 「GTFS-Flex」来るか? • オンデマンド交通などフレキシブルなルートを扱うことが可能になる • NearMeの配⾞もルート検索アプリに表⽰できるようになる?
10 Thank you
