  1. C0mput3r 5ecur!7y
    Windows ReversingDarkArt
    [email protected]
    !1

    View Slide

  2. • Master degree at CSIE, NTUST
    • Security Researcher - chrO.ot, TDOHacker
    • Speaker
    - BlackHat, DEFCON, beVX, VXCON, HITCON
    >_cat ./Bio
    !2

    View Slide

  3. • General Compiler
    • Recap: Intel x86 Basic
    • x86 Instruction Set
    • x86 Calling Convention
    • Let's Mess Up IDA Pro ;)
    • Obfuscation Tricks
    • Junk Instructions
    • Control Flow Obfuscation
    • Structured Exception Handling (SEH)
    • Virtual Machine (Packer Style)
    >_cat ./lab
    !3

    View Slide

  4. [email protected]
    General Compiler
    !4

    View Slide

  5. General Compiler
    !5
    Source.cpp Object Files Main.exe
    Compiler
    Assembly Codes
    Assembler
    Linker

    View Slide

  6. >_cat msgbox.c
    !6
    #include
    int main()
    {
    MessageBoxA(
    0, "hi there.", "info", 0
    );
    return 0;
    }

    View Slide

  7. based on
    x86 Calling Convention
    !7
    #include
    int main(void) {
    MessageBoxA(
    0,
    "hi there.",
    "info",
    0
    );
    return 0;
    }
    push 0
    push "info"
    push "hi there."
    push 0
    call MessageBoxA
    xor eax, eax
    ret
    en.wikipedia.org/wiki/X86_calling_conventions

    View Slide

  8. >_Compiler
    8
    xor eax, eax
    ret
    push 0
    push "info"
    push "hi there."
    push 0
    call MessageBoxA
    0xdead: "info"
    0xbeef: "hi there."
    .rdata section
    0xcafe: 0x7630EA99
    .idata section
    (Import Address Table)

    View Slide

  9. >_Compiler
    !9
    xor eax, eax
    ret
    push 0
    push offset "info"
    push offset "hi there."
    push 0
    call MessageBoxA
    0xdead: "info"
    0xbeef: "hi there."
    .rdata section
    0xcafe: 0x7630EA99
    .idata section
    (Import Address Table)

    View Slide

  10. >_Compiler
    !10
    xor eax, eax
    ret
    push 0
    push 0x40dead
    push 0x40beef
    push 0
    call ds:0x40cafe
    0xdead: "info"
    0xbeef: "hi there."
    .rdata section
    0xcafe: 0x7630EA99
    .idata section
    (Import Address Table)

    View Slide

  11. [email protected]
    >_Periodic Table?
    !11
    sparksandflames.com/files/x86InstructionChart.html

    View Slide

  12. >_Assembler
    push 0 ; 6A 00
    push 0x40dead ; 68 AD DE 40 00
    push 0x40beef ; 68 EF BE 40 00
    push 0 ; 6A 00
    call ds:0x40cafe ; FF 15 FE CA 00 00
    xor eax, eax ; 33 C0
    ret ; C3
    !12

    View Slide

  13. !13
    Main.exe
    .text Section
    6A 00
    68 AD DE 00 00
    68 EF BE 00 00
    6A 00
    FF 15 FE CA 00 00
    33 C0
    C3
    0xdead: "info"
    0xbeef: "hi there."
    0xcafe: 0x7630EA99
    .rdata Section
    .idata Section

    View Slide

  14. [email protected]
    Address Space
    Layout Randomization
    !14

    View Slide

  15. >_Memory Process
    iexplorer.exe
    ntdll.dll
    kernel32.dll
    ...
    Low Address
    custom.dll
    xxxxxx.dll
    module.dll
    High Address
    Thread Stack

    View Slide

  16. >_Memory Process
    iexplorer.exe
    ntdll.dll
    kernel32.dll
    ...
    Low Address
    custom.dll
    xxxxxx.dll
    module.dll
    High Address
    *.exe file should be loaded at 0x400000 by default
    third-party *.dll file
    System Modules
    Thread Stack

    View Slide

  17. >_ASLR
    Process
    iexplorer.exe
    ntdll.dll
    kernel32.dll
    ...
    custom.dll
    xxxxxx.dll
    module.dll
    Process
    iexplorer.exe
    ntdll.dll
    kernel32.dll
    ...
    custom.dll
    xxxxxx.dll
    module.dll
    Process
    iexplorer.exe
    ntdll.dll
    kernel32.dll
    ...
    custom.dll
    xxxxxx.dll
    module.dll
    third-party *.exe &
    *.dll files are loaded
    at different addresses
    when create process.
    System Modules are
    only randomized after
    reboot.

    View Slide

  18. !18
    Main.exe
    .text Section
    6A 00
    68 AD DE 40 00
    68 EF BE 40 00
    6A 00
    FF 15 FE CA 40 00
    33 C0
    C3
    0xdead: "info"
    0xbeef: "hi there."
    0xcafe: 0x7630EA99
    .rdata Section
    .idata Section
    >_Issue
    I don't know how to
    randomize *.exe
    module address :(

    View Slide

  19. !19
    Main.exe
    .text Section
    6A 00
    68 AD DE 40 00
    68 EF BE 40 00
    6A 00
    FF 15 FE CA 40 00
    33 C0
    C3
    0xdead: "info"
    0xbeef: "hi there."
    0xcafe: 0x7630EA99
    .rdata Section
    .idata Section
    Relocation Table
    (aka PIE)

    View Slide

  20. >_Relocation
    • Process loader won't implement ASLR on *.exe module
    without relocation table, even if you enable the ASLR
    option on the *.exe file.
    • There're serval relocation blocks stored the offset of
    assembly codes which includes resource, global
    variable, data from the other section.
    • In the .text section, every 0x1000 bytes of assembly
    code are grouped into a relocation block. All the
    relocation blocks are grouped into a relocation table.
    !20

    View Slide

  21. >_PE Bear
    !21

    View Slide

  22. >_PE Bear
    !22

    View Slide

  23. [email protected]
    Recap:
    x86 Assembly
    !23

    View Slide

  24. [email protected]
    >_Periodic Table?
    !24
    sparksandflames.com/files/x86InstructionChart.html

    View Slide

  25. 雅量量
    x86 指令集是⼀一種很有雅量量的語⾔言
    !25
    ⼈人總會去尋求⾃自⼰己喜歡的事物,每個⼈人的看法或觀點不同,
    並沒有什什麼關係,重要的是──⼈人與⼈人之間,應該有彼此容忍
    和尊重對⽅方的看法與觀點的雅量量。

    View Slide

  26. >_CISC
    !26
    Bytecodes on .text section
    35 FF 15 FE CA 40 00
    0: 35 ff 15 fe ca - xor eax,0xcafe15ff
    5: 40 - inc eax

    View Slide

  27. 0: ff 15 fe ca 40 00 - call DWORD PTR ds:0x40cafe
    !27
    Bytecodes on .text section
    35 FF 15 FE CA 40 00
    0: 35 ff 15 fe ca - xor eax,0xcafe15ff
    5: 40 - inc eax
    >_CISC

    View Slide

  28. 0: ff 15 fe ca 40 00 - call DWORD PTR ds:0x40cafe
    !28
    Bytecodes on .text section
    35 FF 15 FE CA 40 00
    0: 35 ff 15 fe ca - xor eax,0xcafe15ff
    5: 40 - inc eax
    0: 15 fe ca 40 00 adc eax,0x40cafe
    >_CISC

    View Slide

  29. 0: ff 15 fe ca 40 00 - call DWORD PTR ds:0x40cafe
    !29
    Bytecodes on .text section
    35 FF 15 FE CA 40 00
    0: 35 ff 15 fe ca - xor eax,0xcafe15ff
    5: 40 - inc eax
    0: 15 fe ca 40 00 adc eax,0x40cafe
    >_CISC
    ROP-Chain

    View Slide

  30. >_Thread
    !30
    addr @ 401000:
    6A 00
    68 AD DE 40 00
    68 EF BE 40 00
    6A 00
    FF 15 FE CA 40 00
    33 C0
    C3
    push 0
    push 0x40dead
    push 0x40beef
    push 0
    call ds:0x40cafe
    xor eax, eax
    ret
    via
    x86 Instruction Set
    Registers
    eax 41414141
    ebx 42424242
    ecx 43434343
    edx 44444444
    ... ...
    esp 7ffffffc
    ebp 7ffffffc
    eip 401000

    View Slide

  31. >_Thread
    !31
    addr @ 401000:
    6A 00
    68 AD DE 40 00
    68 EF BE 40 00
    6A 00
    FF 15 FE CA 40 00
    33 C0
    C3
    push 0
    push 0x40dead
    push 0x40beef
    push 0
    call ds:0x40cafe
    xor eax, eax
    ret
    via
    x86 Instruction Set
    Registers
    eax 41414141
    ebx 42424242
    ecx 43434343
    edx 44444444
    ... ...
    esp 7ffffffc
    ebp 7ffffffc
    eip 401000
    Process
    aaaaaaaaa.exe
    ntdll.dll
    kernel32.dll
    ...
    Low Address
    custom.dll
    xxxxxx.dll
    module.dll
    High Address
    Thread Stack

    View Slide

  32. >_Heap
    uint32_t buf[3] = { 1, 2, 3 };
    buf[1] = 0xAAAAAAAA;
    buf[2] = 0x12345678;
    !32
    Low Address = 0x100
    (buf)
    High Address
    &(buf[0]) = 0x100
    buf[0] = 1
    00 00 00 01
    &(buf[1]) = 0x104
    buf[1] = 0xAAAAAAAA
    AA AA AA AA
    &(buf[2]) = 0x108
    buf[2] = 0x12345678
    78 56 34 12

    View Slide

  33. >_Stack
    uint32_t stack[100];
    uint32_t index = 99;
    void x86_push(uint32_t in) { stack[--index] = in; }
    void x86_pop(&out) { x = stack[index++]; }
    !33
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x100 + sizeof(uint32_t) * 99
    Allocate Local Memory
    Release Local Memory

    View Slide

  34. >_Stack
    push eax
    push ebx
    pop edx
    !34
    Low Address = 0x100
    (stack)
    High Address
    eax 1
    ebx 2
    edx 3
    esp = 0x28c
    index = 99

    View Slide

  35. >_Stack
    push eax
    push ebx
    pop edx
    !35
    Low Address = 0x100
    (stack)
    High Address
    eax 1
    ebx 2
    edx 3
    00 00 00 01
    esp = 0x288
    index = 98
    esp = 0x28c
    index = 99

    View Slide

  36. >_Stack
    push eax
    push ebx
    pop edx
    !36
    Low Address = 0x100
    (stack)
    High Address
    eax 1
    ebx 2
    edx 3
    00 00 00 01
    esp = 0x288
    index = 98
    esp = 0x28c
    index = 99
    00 00 00 02
    esp = 0x284
    index = 97

    View Slide

  37. >_Stack
    push eax
    push ebx
    pop edx
    !37
    Low Address = 0x100
    (stack)
    High Address
    eax 1
    ebx 2
    edx 2
    00 00 00 01
    esp = 0x288
    index = 98
    esp = 0x28c
    index = 99
    00 00 00 02
    esp = 0x284
    index = 97

    View Slide

  38. [email protected]
    x86 Calling Convention
    !38

    View Slide

  39. >_Calling Convention
    !39 en.wikipedia.org/wiki/X86_calling_conventions
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret

    View Slide

  40. >_Calling Convention
    !40 en.wikipedia.org/wiki/X86_calling_conventions
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    The Begin of function
    The end of function

    View Slide

  41. >_Function
    !41
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)

    View Slide

  42. !42
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    00 00 00 03
    esp = 0x288
    index = 98

    View Slide

  43. !43
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    00 00 00 03
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97

    View Slide

  44. !44
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    00 00 00 03
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96

    View Slide

  45. !45
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96
    ret addr
    esp = 0x27c
    index = 95
    00 00 00 03

    View Slide

  46. !46
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96
    ret addr
    esp = 0x27c
    index = 95
    old ebp
    esp = 0x278
    index = 94
    00 00 00 03

    View Slide

  47. !47
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96
    ret addr
    esp = 0x27c
    index = 95
    old ebp
    esp = 0x278
    index = 94
    ebp = 0x278 (the base pointer for the current stack frame)
    00 00 00 03

    View Slide

  48. !48
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96
    ret addr
    esp = 0x27c
    index = 95
    old ebp
    esp = 0x278
    index = 94
    ebp = 0x278 (the base pointer for the current stack frame)
    local
    buf
    esp = 0x274
    index = 93
    00 00 00 03

    View Slide

  49. !49
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96
    ret addr
    esp = 0x27c
    index = 95
    old ebp
    esp = 0x278
    index = 94
    ebp = 0x278 (the base pointer for the current stack frame)
    local
    buf
    esp = 0x274
    index = 93
    ebp ebp+4
    arg1:
    ebp+8
    arg2:
    ebp+0x0c
    arg3:
    ebp+0x10
    00 00 00 03

    View Slide

  50. !50
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96
    ret addr
    esp = 0x27c
    index = 95
    old ebp
    esp = 0x278
    index = 94
    ebp = 0x278 (the base pointer for the current stack frame)
    local
    buf
    esp = 0x274
    index = 93
    ebp ebp+4
    arg1:
    ebp+8
    arg2:
    ebp+0x0c
    arg3:
    ebp+0x10
    00 00 00 03

    View Slide

  51. !51
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96
    ret addr
    esp = 0x27c
    index = 95
    old ebp
    esp = 0x278
    index = 94
    ebp = 0x278 (the base pointer for the current stack frame)
    6
    esp = 0x274
    index = 93
    ebp ebp+4
    arg1:
    ebp+8
    arg2:
    ebp+0x0c
    arg3:
    ebp+0x10
    00 00 00 03

    View Slide

  52. !52
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96
    ret addr
    esp = 0x27c
    index = 95
    old ebp
    esp = 0x278
    index = 94
    ebp = 0x278 (the base pointer for the current stack frame)
    6
    ebp ebp+4
    arg1:
    ebp+8
    arg2:
    ebp+0x0c
    arg3:
    ebp+0x10
    00 00 00 03

    View Slide

  53. !53
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96
    ret addr
    esp = 0x27c
    index = 95
    old ebp
    6
    ebp ebp+4
    arg1:
    ebp+8
    arg2:
    ebp+0x0c
    arg3:
    ebp+0x10
    00 00 00 03

    View Slide

  54. !54
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    esp = 0x288
    index = 98
    00 00 00 02
    esp = 0x284
    index = 97
    00 00 00 01
    esp = 0x280
    index = 96
    ret addr
    old ebp
    6
    ebp ebp+4
    arg1:
    ebp+8
    arg2:
    ebp+0x0c
    arg3:
    ebp+0x10
    00 00 00 03

    View Slide

  55. !55
    Low Address = 0x100
    (stack)
    High Address
    esp = 0x28c
    index = 99
    add:
    push ebp
    mov ebp, esp
    sub esp, 0x04
    mov eax, [ebp+0x08]
    add eax, [ebp+0x0C]
    add eax, [ebp+0x10]
    mov [ebp-0x04], eax
    mov eax, [ebp-0x04]
    mov esp, ebp
    pop ebp
    ret
    push 3
    push 2
    push 1
    call add
    add esp,0x0c
    // add(1, 2, 3)
    00 00 00 03
    00 00 00 02
    00 00 00 01
    ret addr
    old ebp
    6
    ebp ebp+4
    arg1:
    ebp+8
    arg2:
    ebp+0x0c
    arg3:
    ebp+0x10

    View Slide

  56. [email protected]
    Structured
    Exception Handling (SEH)
    !56

    View Slide

  57. Structured exception handling enables you to have complete
    control over the handling of exceptions, provides support for
    debuggers, and is usable across all programming languages and
    machines. Vectored exception handling is an extension to
    structured exception handling.
    >_SEH
    docs.microsoft.com/en-us/windows/desktop/debug/structured-exception-handling

    View Slide

  58. >_Visual C++
    !58
    Actually SEH is a feature to
    support try {} catch (...) {}
    and...

    View Slide

  59. !59

    View Slide

  60. >_Visual C++
    !60

    View Slide

  61. [email protected]
    Thread Information Block
    —— Break into how Win32 API works
    !61

    View Slide

  62. >_TIB
    In computing, the Win32 Thread Information Block (TIB) is a data structure
    in Win32 on x86 that stores information about the currently running thread.
    This structure is also known as the Thread Environment Block (TEB).
    The TIB can be used to get a lot of information on the process without
    calling Win32 API. Examples include emulating GetLastError(), GetVersion().
    Through the pointer to the PEB one can obtain access to the import tables
    (IAT), process startup arguments, image name, etc. It is accessed from the
    FS segment register when operating on 32 bits, and from GS in 64 bits.
    !62
    en.wikipedia.org/wiki/Win32_Thread_Information_Block

    View Slide

  63. >_TIB
    !63

    View Slide

  64. [email protected]
    >_TIB (undocumented)
    !64
    struct TEB {
    //NT_TIB structure portion
    EXCEPTION_REGISTRATION* ExceptionList; //0x0000 / Current Structured Exception Handling frame
    void* StackBase; //0x0004 / Bottom of stack (high address)
    void* StackLimit; //0x0008 / Ceiling of stack (low address)
    void* SubSystemTib; //0x000C
    union {
    void* FiberData; //0x0010
    DWORD Version; //0x0010
    } dword10;
    void* ArbitraryUserPointer; //0x0014
    TEB* Self; //0x0018
    //NT_TIB ends (NT subsystem independent part)
    void* EnvironmentPointer; //0x001C
    CLIENT_ID ClientId; //0x0020
    // ClientId.ProcessId //0x0020 / value retrieved by GetCurrentProcessId()
    // ClientId.ThreadId //0x0024 / value retrieved by GetCurrentThreadId()
    void* ActiveRpcHandle; //0x0028
    void* ThreadLocalStoragePointer; //0x002C
    PEB* ProcessEnvironmentBlock; //0x0030
    ...
    bytepointer.com/resources/tebpeb32.htm

    View Slide

  65. [email protected]
    >_TIB (undocumented)
    !65
    struct TEB {
    //NT_TIB structure portion
    EXCEPTION_REGISTRATION* ExceptionList; //0x0000 / Current Structured Exception Handling frame
    void* StackBase; //0x0004 / Bottom of stack (high address)
    void* StackLimit; //0x0008 / Ceiling of stack (low address)
    void* SubSystemTib; //0x000C
    union {
    void* FiberData; //0x0010
    DWORD Version; //0x0010
    } dword10;
    void* ArbitraryUserPointer; //0x0014
    TEB* Self; //0x0018
    //NT_TIB ends (NT subsystem independent part)
    void* EnvironmentPointer; //0x001C
    CLIENT_ID ClientId; //0x0020
    // ClientId.ProcessId //0x0020 / value retrieved by GetCurrentProcessId()
    // ClientId.ThreadId //0x0024 / value retrieved by GetCurrentThreadId()
    void* ActiveRpcHandle; //0x0028
    void* ThreadLocalStoragePointer; //0x002C
    PEB* ProcessEnvironmentBlock; //0x0030
    ...
    bytepointer.com/resources/tebpeb32.htm
    EXCEPTION_REGISTRATION* ExceptionList; //0x0000

    View Slide

  66. >_x64dbg
    !66
    We can use the
    command "teb()" to
    fetch the current
    TEB table address.

    View Slide

  67. >_x64dbg
    !67
    We can use the
    command "teb()" to
    fetch the current
    TEB table address.
    Point to handler-chain

    View Slide

  68. >_x64dbg
    !68
    teb() = 0x5b0000

    View Slide

  69. >_SEH Record
    !69
    Thread Exception
    TEB
    fs:[0] SEH Chain
    fs:[4] StackBase
    fs:[8] StackLimt
    fs:[c] SubSystem
    Handler 3
    Callback
    Handler Ptr
    Prev Handler
    Handler 2
    Callback
    Handler Ptr
    Prev Handler
    Handler 1
    Callback
    Handler Ptr
    -1 (end)

    View Slide

  70. >_SEH
    !70

    View Slide

  71. >_SEH
    !71
    push ebp
    mov ebp, esp
    push offset __ehhandler$_main
    push fs:[0]
    mov fs:[0], esp
    mov [0], 1
    xor eax, eax
    mov ecx, [esp]
    mov large fs:0, ecx
    mov esp, ebp
    pop ebp
    retn
    Return value
    Function codes
    Register a handler
    Unregister a handler
    The begin of function
    The end of function

    View Slide

  72. >_Stack Frame
    !72
    Low Address
    (stack)
    High Address
    ret addr
    old ebp
    ebp (current stack frame)
    SEH
    record
    esp
    ebp ebp+4
    arg3
    arg2
    arg1
    ebp+8 ebp+0x0c ebp+0x10
    canery
    SEH record
    Previous
    SEH Record addr Current Handler
    buffer

    View Slide

  73. >_Buffer Overflow
    !73
    Low Address
    (stack)
    High Address
    ret addr
    old ebp
    ebp (current stack frame)
    SEH
    record
    esp
    ebp ebp+4
    arg3
    arg2
    arg1
    ebp+8 ebp+0x0c ebp+0x10
    canery
    SEH record
    Previous
    SEH Record addr Current Handler
    buffer

    View Slide

  74. >_Buffer Overflow
    !74
    Low Address
    (stack)
    High Address
    ret addr
    old ebp
    ebp (current stack frame)
    SEH
    record
    esp
    ebp ebp+4
    arg3
    arg2
    arg1
    ebp+8 ebp+0x0c ebp+0x10
    canery
    SEH record
    Previous
    SEH Record addr Current Handler
    buffer
    Buffer Overflow from low addr to high addr

    View Slide

  75. >_Buffer Overflow
    !75
    Low Address
    (stack)
    High Address
    ret addr
    old ebp
    ebp (current stack frame)
    SEH
    record
    esp
    ebp ebp+4
    arg3
    arg2
    arg1
    ebp+8 ebp+0x0c ebp+0x10
    canery
    SEH record
    Previous
    SEH Record addr Current Handler
    buffer
    Buffer Overflow from low addr to high addr
    buffer
    memory out of bounds

    View Slide

  76. [email protected]
    Lab 1:
    Knock down the handler
    !76

    View Slide

  77. [email protected]
    Th3 D4Rk Art:
    Anti-analysis Techniques
    D4Rk
    !77

    View Slide

  78. >_Anti-analysis
    • Most static analysis tools (e.g. IDA Pro, Snowman,
    Hopper, etc.) transform machine code to Control-Flow
    Graph or C-like pseudocode based on the x86 Calling
    Convention.
    !78

    View Slide

  79. >_Anti-analysis
    • Issues
    • Break Stack Frame
    • Junk Instructions
    • Relace Orignal Instructions
    • VM-like Protection
    • Abusing SEH
    !79

    View Slide

  80. [email protected]
    Obfuscation Tricks
    !80

    View Slide

  81. >_Junk Instructions
    • nop
    • xchg eax, ebx; xchg ebx, eax
    • inc eax, dec eax;
    • lodsb, lodsw, lodsd
    • stosb, stosw, stosd
    • scasb
    • std, stc, sti
    • rdtsc
    • Just do nothing
    !81

    View Slide

  82. >_Junk Instructions
    !82
    IDA Pseudocode

    View Slide

  83. >_Junk Instructions
    !83 IDA Pseudocode

    View Slide

  84. >_Replacing Codes
    • jmp xxx = push xxx; ret
    • call xxx = push retAddr; jmp xxx

    = push retAddr; push xxx; ret
    • mov eax, ebx = push ebx; pop eax
    • sub esp, 0x04 = lea esp, [esp-0x04]
    • push xxx = sub esp, 0x04; mov [esp], xxx

    = lea esp, [esp-0x04]; mov [esp], xxx
    ...etc
    !84

    View Slide

  85. Black Hat Asia 2018:
    BREAKING STATE-OF-THE-ART BINARY CODE OBFUSCATION
    VIA PROGRAM SYNTHESIS
    • https://www.blackhat.com/docs/asia-18/asia-18-Blazytko-
    Breaking-State-Of-The-Art-Binary-Code-Obfuscation-Via-
    Program-Synthesis.pdf
    • https://www.blackhat.com/docs/asia-18/asia-18-Blazytko-
    Breaking-State-Of-The-Art-Binary-Code-Obfuscation-Via-
    Program-Synthesis-wp.pdf
    >_Virtual Machines
    !85

    View Slide

  86. !86
    >_Virtual Machines

    View Slide

  87. >_Virtual Machines
    !87

    View Slide

  88. !88
    >_Virtual Machines

    View Slide

  89. !89
    >_Virtual Machines

    View Slide

  90. • Call $+5; pop eax
    • push xx; push xx; call entry

    entry: add esp, 0x0c
    • push next; push xxxx; call [esp+0x04]; add esp, 0x08

    next: add esp, 0x0c
    • ret 0xff
    !90
    >_Control Flow

    View Slide

  91. !91
    >_Control Flow

    View Slide

  92. !92
    >_Abusing SEH

    View Slide

  93. !93
    >_Abusing SEH
    The SEH handler is always a lonely region.

    View Slide

  94. [email protected]
    Lab 2:
    Obfuscation Challenge
    !94

    View Slide

  95. Thanks.
    [email protected]
    Slide
    Github @aaaddress1
    Facebook
    !95

    View Slide
