CRI-O Introduction

CRI-O, an OCI-based implementation of Kubernetes Container Runtime Interface, used in SUSE and openSUSE projects. CRI-O is meant to provide an integration path between OCI conformant runtimes and the kubelet. Specifically, it implements the Kubelet Container Runtime Interface (CRI) using OCI conformant runtimes. In this session, we will explore the CRI-O arhitecture to undersand how it leverages OCI projects to work with kubelet via CRI.

Transcript

1. CRI-O Introduction David Ko Engineering Manager 2019/8/17 COSCUP 2019
2. 2 Outline What is OCI (Open Containers Initiative) ? What is OCI Compatible Runtime? What is K8s CRI (Container Runtime Interface)? What is CRI-O? How K8s CRI + CRi-O work?
3. 3 What is OCI (Open Containers Initiative) ? The Open Container Initiative (OCI) is a lightweight, open governance structure (project), for the express purpose of creating open industry standards around container formats and runtime. The OCI currently contains two specifications: • Runtime Specification (runtime-spec) • Image Specification (image-spec). OCI Image (OCI image spec) OCI Runtime FS Bundle (OCI runtime spec: how to run) OCI Runtime Instance (OCI runtime)
4. 4 What is OCI Compatible Runtime? A runtime for running containers according to the OCI specification. • runc ◦ https://github.com/opencontainers/runc • runsc ◦ https://github.com/google/gvisor • runv ◦ Hypervisor-based Runtime for OCI ◦ https://github.com/hyperhq/runv • runhcs ◦ Use the Windows Host Compute Service (HCS) to launch and manage Windows Containers. ◦ https://github.com/microsoft/hcsshim/tree/master/cmd/runhcs • kata-runtime ◦ Run secure container runtime with lightweight virtual machines ◦ https://github.com/kata-containers/runtime
5. 5 What is K8s CRI (Container Runtime Interface)? Container Runtime Interface (CRI) is a plugin interface which enables kubelet to use a wide variety of container runtimes without the need to recompile. CRI consists of a protocol buffers and gRPC API. https://github.com/kubernetes/cri-api // Runtime service defines the public APIs for remote container runtimes service RuntimeService { ... } // ImageService defines the public APIs for managing images. service ImageService { ... }
6. 6 CRI: RuntimeService & ImageService k8s.io/cri-api/pkg/apis/runtime/v1alpha2
7. 7 What is CRI-O? CRI-O is an implementation of the Kubernetes CRI (Container Runtime Interface) to enable using OCI (Open Container Initiative) compatible runtimes. It is a lightweight alternative to using Docker as the runtime for kubernetes. It allows Kubernetes to use any OCI-compliant runtime as the container runtime for running pods. Today it supports runc and Kata container runtimes but any OCI-conformant runtime can be plugged in principle.
8. 8 CRI-O Architecture
9. 9 K8s Container Runtime Engine/Manager kubelet OCI Runtime frakti hyperd • runc • runsc • runv • runhcs • kata-runtime Container Runtime Engine/Manager Container Runtime dockershim
10. 10 How K8s CRI + CRI-O work?
11. 11 Kublet: Step 1: start kubelet with container runtime k8s.io/kubernetes/pkg/kubelet::NewMainKubelet()
12. 12 Kublet: Step 2.1: get gRPC runtime & image services k8s.io/kubernetes/pkg/kubelet/remote or dockershim
13. 13 Kublet: Step 2.2: create gRPC runtime & image services k8s.io/kubernetes/pkg/kubelet/remote
14. 14 CRI-O: Step 1: create gRPC server exposing runtime & image services
15. 15 CRI-O: Step 2: use containers/storage & image lib for OCI image and runtime operation Major dependent libraries for OCI runtime & image: • github.com/containers/storage • github.com/containers/image • github.com/containers/conmon cri-o/internal/pkg/storage/runtime.go cri-o/internal/pkg/storage/image.go
