Typical Vulnerabilities in Nginx Configurations and Mitigation Methods

Focused exploration of prevalent vulnerabilities within Nginx configurations and the effective methods to mitigate them. This talk will guide you through identifying and addressing typical security flaws found in Nginx setups, from misconfigurations to overlooked security controls. Learn practical mitigation strategies to fortify your Nginx servers against potential threats.

Transcript

1. Typical Vulnerabilities in Nginx Configurations Egor Karbutov, Information Security Engineer, Yandex Core Security Team
2. Into
3. Agenda 3 › Nginx? › Client-Side Vulnerabilities › Server-Side Vulnerabilities › Gixy tool
4. Nginx? 4 ▎ Web-server! › Reverse proxy › Load balancer › HTTP cache › …
5. Usage scheme 5 App Servers Datacenter
6. More about Yandex load balance https://youtu.be/xcGa-q5MA0s Usage scheme 6 App Servers Datacenter L3 Balancer Service 1 Service 2 Service 3 / /api /admin /img / Load Balancer
7. 7 Typical vulnerable configuration
8. Client-Side Vulnerabilities
9. Regular expression for Referer and Origin 9 ▎ Some developers use regular expressions to validate security headers. Handling Referer: › to get rid of ‘bad’ requests › To withstand CSRF and Clickjacking vulnerabilities CORS: › Legal SOP Bypass
10. CORS Misconfiguration 10 example.com HTTP/1.1 200 OK Access-Control-Allow-Origin: https://evil.com Access-Control-Allow-Credentials: true evil.com 1 2 GET /secrets_files HTTP/1.1 Host: example.com Origin: https://evil.com Cookie: sessionid=1ccdb0041193c7115b3f7ecd991bc7efc82212d4 3 6 Preflight request 4 5 Response with data JS data extraction
11. 11 ▎ Why? Because PCRE! › Regular expression for python: Typical vulnerable configuration ▎ The result of checking the regular expression in Nginx
12. 12 How to fix? › First way › Second way
13. 13 Other examples › Insert a value from the Origin header › Insert a value from the Referer header › Insert a wildcard value (browser won’t send request with users cookie) › Insert null
14. How to fix? 14 ▎ Вe careful with regular expressions in Nginx You have to: › check regular expressions in the PCRE environment or refuse using regular expressions › check third-party domains › check wildcard domains and subdomains › check that user input does not fall into the add_header directive
15. http://nginx.org/en/docs/http/ngx_http_headers_module.html#add_header Redefining of response headers 15 ▎ «There could be several “add_header” directives. These directives are inherited from the previous level if and only if there are no ” add_header” directives defined on the current level.» Nginx have a non-standard inheritance mechanism.
16. 16 Typical vulnerable configuration
17. 17 ▎ Root headers ▎ /new-headers ▎ /new-headers with Origin header
18. https://github.com/openresty/headers-more-nginx-module#readme How to fix? 18 You may: › duplicate important headers › set important headers in one section › use headers-more-nginx-module
19. None in valid_referrers directive 19 ▎ The ngx_http_referer_module module is used to block access to a site for requests with invalid values in the “Referer” header field. You can call the module by using a valid_referrers directive This module is not intended for: - building security - point blocking of clients
20. 20 Typical vulnerable configuration
21. 21 ▎ Request with valid referer ▎ Request without referer ▎ Request with evil referer
22. https://developer.mozilla.org/en-US/docs/Web/HTTP/Headers/Referer https://developer.mozilla.org/en-US/docs/Web/HTTP/Headers/Referrer-Policy https://html.spec.whatwg.org/multipage/origin.html 22 Some ways to send a request without referer ▎ Request with opaque origin ▎ Request from frame ▎ Request from https to http ▎ HTML meta tags ▎ Referrer Policy Headers
23. How to fix? 23 › Don’t use “none” in the directive › Don’t use ngx_http_referer_module for security
24. CLRF Injection 24 ▎ CRLF refers to the Carriage Return and Line Feed sequence of special characters Example symbols: › \r or \n › %0d%0a › 0x0D0x0A › %E5%98%8A%E5%98%8
25. http://nginx.org/ru/docs/http/ngx_http_core_module.html#location CLRF Injection 25 The injection can take place through the $uri/$document_uri variable ▎ The $uri variable goes through normalization – URL Decode Can be used to attack: - a user - on a server behind Nginx
26. 26 Typical vulnerable configuration ▎ As well as directive for proxy › proxy_set_header › proxy_pass
27. 27 ▎ Request with valid referer ▎ Request without referer
28. https://hackerone.com/reports/15492 https://hackerone.com/reports/15492 https://habr.com/ru/company/pt/blog/247709/ 28 ▎ BugBounty
29. How to fix? 29 › Don’t use $uri variables, use $request_uri › Be careful with “add header” directives › Be careful in regular expressions, do not forget to exclude line breaks in them
30. Open Redirect 30 ▎ Incorrect configuration allows redirecting a user to an arbitrary domain Vulnerable directive is rewrite If the specified regular expression matches the request URI, the URI is changed according to the replacement string. The vulnerability occurs when there is an incorrect concatenation/regular expression of the domain path inside rewrite
31. 31 Typical vulnerable configuration
32. How to fix? 32 › Be careful when using rewrite › Carefully use user input in rewrite regex rules
33. Server-Side Vulnerabilities
34. Alias traversal 34 ▎ The alias directive is used to change the path in location › Directive is commonly used to static files: on request “/i/top.gif ” the file will be taken from /data/w3/images/ top.gif
35. 35 Typical vulnerable configuration
36. https://hackerone.com/reports/455858 https://hackerone.com/reports/446330 https://www.acunetix.com/vulnerabilities/web/path-traversal-via-misconfigured-nginx-alias/ 36 ▎ The following tests were performed to confirm this vulnerability ▎ BugBounty
37. How to fix? 37 ▎ It’s quite easy! You have to use ‘/’ at the end of the parent prefixed location
38. http://nginx.org/ru/docs/http/ngx_http_core_module.html#var_host Spoofing the Host request header 38 ▎ Incorrect configuration allows you to replace the Host header from the proxy to the backend side Where you can shoot yourself in the foot: › Generating links based on the Host header, redirects, uploading resources, etc. The difference is $http_host instead of $host: › $host - host in order of priority: the host name from the request string, or the host name from the Host header of the request header, or the name of the server corresponding to the request › $http_host - is directly taken from the request’s header "Host"
39. 39 Typical vulnerable configuration
40. How to fix? 40 › List the correct server names in the server_name directive › Always use the $host variable instead of $http_host › Always use the server default section
41. SSRF 41 ▎ Incorrect configuration allows sending requests on behalf of Nginx Vulnerable directive is proxy_pass Vulnerability occurs when: › proxy_pass can be completely controlled › Lack of an internal directive in the proxying location › Unsafe redirection to the internal location
42. 42 Typical vulnerable configuration ▎ Lack of the internal directive and fully controlled proxy_pass
43. http://nginx.org/ru/docs/http/ngx_http_core_module.html#internal Unsafe redirect 43 Internal requests are: › requests redirected by the error_page, index, random_index and try_files directives › requests redirected using the "X-Accel-Redirect” field of the upstream server response › subqueries generated by the ”include virtual" command of the ngx_http_ssi_module module, directives of the ngx_http_addition_module module, as well as the auth_request and mirror directives › requests modified by the rewrite directive
44. 44 Typical vulnerable configuration ▎ Insecure redirect ▎ Concatenation without a leading slash
45. How to fix? 45 › For proxying location, use the internal directive › Uniquely identify the addresses of the proxied servers (for example, via mapping) › Check the correct concatenation of user input to the proxied host and handle the input
46. Gixy 46 ▎ Tool for analyzing Nginx configuration files › Written in Python › Developed by community and Yandex engineers › We use it inside Yandex › Fast, easy, free We are looking for contributors!
47. Полезные ссылки 47 › Gixy - https://github.com/yandex/gixy › Nginx docs - http://nginx.org/ru/docs/ › Scalable configuration nginx – https://youtu.be/jf3wIN-FwW4 › Load balancing in Yandex - https://youtu.be/xcGa-q5MA0s
48. Egor Karbutov Information Security Engineer, Yandex Core Security Team Thanks! shikari@yandex-team.ru @ ShikariSenpai
