Data Science in the Cloud Using Python

Transcript

1. Data science in the
 cloud using Python Graham Dumpleton @GrahamDumpleton Graham.Dumpleton@gmail.com
2. Who am I? Author of mod_wsgi, the Apache module for hosting of Python web applications using the WSGI interface. Have a keen interest in Docker and Platform as a Service (PaaS) technologies. Currently a developer advocate for OpenShift at Red Hat.
3. Topics for today • What is Jupyter & who is using it? • How to provide Jupyter notebooks to many users. • Deploying a single Jupyter notebook to OpenShift. • Deploying JupyterHub to OpenShift. • Deploying a data processing cluster using Dask.
4. What is Jupyter? http://jupyter.org/
5. Who is using Jupyter? Individuals Collaborators Teachers Data-driven organisations use Jupyter to analyse their data, share their insights, and create dynamic, reproducible data science.
6. https://blog.data.gov.sg/how-we-caught-the-circle-line-rogue-train-with-data-79405c86ab6a
8. https://jupyterhub.readthedocs.io/
9. Running a single
 Jupyter notebook
10. Running on your local system pip3 install jupyter jupyter notebook
11. Local installation (Pros) • Save notebooks/data locally. • Python virtual environments. • Select Python version. • Select package versions.
12. Local installation (Cons) • Operating system differences. • Python distribution differences. • Python version differences. • Package index differences. • PyPi (pip) vs Anaconda (conda) • Effort to setup and maintain.
13. Running in a container docker run -it --rm -p 8888:8888 \ jupyter/minimal-notebook https://github.com/jupyter/docker-stacks
14. Container images (Pros) • Pre-created images. • Bundled operating system packages. • Known Python distribution/vendor. • Bundled Python packages. • Docker images are read only. • Run in an isolated environment. • Don’t need to maintain the image.
15. Container images (Cons #1) • More effort to customise experience. • Build a custom Docker image to extend. • Install extra packages each time you run it. • Images can be very large. • Multiple Python versions. • Packages that you do not need.
16. Container images (Cons #2) • Access to and saving your notebooks/data. • Need to mount persistent storage volumes. • Configure a contents manager for external storage. • Ensuring access is done securely.
18. Jupyter notebooks on OpenShift https://github.com/jupyter/docker-stacks/tree/master/examples/openshift
20. Source-to-Image enabled https://github.com/jupyter/docker-stacks/tree/master/examples/source-to-image
22. https://github.com/jakevdp/PythonDataScienceHandbook
23. Images built for OpenShift https://github.com/jupyter-on-openshift/jupyter-notebooks
24. Hosting multiple
 Jupyter notebooks
26. JupyterHub on OpenShift https://github.com/jupyter-on-openshift/jupyterhub-quickstart
27. POC - JupyterHub with KeyCloak https://github.com/jupyter-on-openshift/poc-hub-keycloak-auth
28. POC - JupyterHub with Dask https://github.com/jupyter-on-openshift/poc-hub-dask-cluster
29. What is Dask? http://dask.pydata.org/
32. Deployments
33. User access managed by KeyCloak
34. Persistent workspace for notebooks
35. Access to Dask cluster
36. Created at login
37. Control panel
38. JupyterHub
39. Hub + Proxy
40. Managed services Idle Notebook Culler Dask Cluster Manager
41. Builds
42. KeyCloak image Docker Hub
 jboss/keycloak-openshift:4.0.0.Final GitHub
 jupyter-on-openshift/poc-hub-dask-cluster
 keycloak OpenShift Image Registry
 keycloak-img S2I
43. JupyterHub images OpenShift Image Registry
 openshift/python GitHub
 jupyter-on-openshift/jupyterhub-quickstart OpenShift Image Registry
 jupyterhub-s2i S2I S2I GitHub
 jupyter-on-openshift/poc-hub-dask-cluster jupyterhub OpenShift Image Registry
 jupyterhub-img Base JupyterHub
 Image JupyterHub
44. Notebook images OpenShift Image Registry
 openshift/python GitHub
 jupyter-on-openshift/jupyter-notebooks minimal-notebook OpenShift Image Registry
 jupyterhub-notebook-s2i S2I S2I GitHub
 jupyter-on-openshift/poc-hub-dask-cluster notebook OpenShift Image Registry
 jupyterhub-notebook-img Base
 Notebook
 Image Notebook
 Image Dask Scheduler/Worker Image
45. Deployments JupyterHub Route Service KeyCloak Service Notebook Dask Scheduler Dask Worker Service Dask Worker Dask Worker PostgreSQL
 (KeyCloak) PostgreSQL
 (JupyterHub) Service Service Common Per User Route Service
46. Jupyter on OpenShift • Provides simplified deployment using a template. • JupyterHub customisable through use of Source-to-Image. • Can pre-build images with notebooks and required Python packages. • Can attach storage to notebooks for persistence. • Integrate with KeyCloak for user authentication. • Connect to backend cluster for distributed data analytics.
47. My other side projects • Using JupyterHub for teaching in university. • Using remote kernel gateway with Jupyter notebooks. • Working with Spark as backend data analytics cluster. • Utilising GPUs for high performance AI/ML tasks.
48. Resources • https://github.com/jupyter-on-openshift • https://www.jupyteronopenshift.org/ • https://github.com/jupyter/docker-stacks • examples/openshift & examples/source-to-image
49. Community • https://commons.openshift.org/ • https://commons.openshift.org/sig/OpenshiftMachineLearning.html • https://commons.openshift.org/sig/OpenshiftBigData.html • https://commons.openshift.org/sig/OpenshiftEDU.html
50. Try it • https://www.openshift.org/minishift/ • https://www.openshift.com/products/online/
51. Contact me Graham Dumpleton @GrahamDumpleton Graham.Dumpleton@gmail.com
