Talk I gave at December's 15 Chela.js. It's about how I use Web Audio API + Web MIDI API + a Novation Launchpad to be a Web Madeon.

Transcript

1. Web
   Launchpad


   View Slide

2. View Slide

3. eatcodetravel.com
   orlando @ github
   @eatcodetravel


   View Slide

4. Web
   Launchpad


   View Slide

5. Web MIDI
   Web Audio
   Launchpad


   View Slide

6. Web MIDI
   Web Audio
   Launchpad


   View Slide

7. View Slide

8. 80 buttons
   3 leds
   4 channels


   View Slide

9. Web MIDI
   Web Audio
   Launchpad


   View Slide

10. Web MIDI
    Web Audio
    Launchpad


    View Slide

11. Midi
    SamplePlayer
    SamplePackStore
    UIMapper
    PubSub


    View Slide

12. SamplePlayer
    SamplePackStore
    UIMapper
    PubSub
    Midi


    View Slide

13. Web Audio
    Launchpad
    Web MIDI


    View Slide

14. and Opera


    View Slide

15. Inputs / Outputs


    View Slide

16. How do we use it?


    View Slide

17. 20 _initMidi: function () {
    21 navigator.requestMIDIAccess({
    22 sysex: false
    23 }).then(this._onMidiSuccessHandler);
    24 },
    25
    26 _onMidiMessageHandler: function _onMidiMessageHandler(message) {
    27 console.log(message.data);
    28 PubSub.emitEvent('onMidiMessage', [message]);
    29 },
    30
    31 _onMidiSuccessHandler: function _onMidiSuccessHandler(midi) {
    32 var inputs = midi.inputs.values();
    33 // loop over all available inputs and listen for any MIDI input
    34 for (var input = inputs.next(); input && !input.done; input =
    inputs.next()) {
    35 // each time there is a midi message call the onMIDIMessage
    function
    36 input.value.onmidimessage = this._onMidiMessageHandler;
    37 }


    View Slide

18. 20 _initMidi: function () {
    21 navigator.requestMIDIAccess({
    22 sysex: false
    23 }).then(this._onMidiSuccessHandler);
    24 },
    25
    26 _onMidiMessageHandler:
    27
    28 PubSub.emitEvent(
    29 },
    30
    31 _onMidiSuccessHandler:
    32
    33 // loop over all available inputs and listen for any MIDI input
    34
    inputs.next()) {
    35 // each time there is a midi message call the onMIDIMessage
    function
    36 input.value.onmidimessage
    37 }


    View Slide

19. 31 _onMidiSuccessHandler: function _onMidiSuccessHandler(midi) {
    32 var inputs = midi.inputs.values();
    33 // loop over all available inputs and listen for any MIDI input
    34 for (var input = inputs.next(); input && !input.done; input =
    inputs.next()) {
    35 // each time there is a midi message call the onMIDIMessage
    function
    36 input.value.onmidimessage = this._onMidiMessageHandler;
    37 }
    20 _initMidi:
    21 navigator.requestMIDIAccess({
    22
    23 }).then(
    24 },
    25
    26 _onMidiMessageHandler:
    27
    28 PubSub.emitEvent(
    29 },
    30


    View Slide

20. 20 _initMidi:
    21 navigator.requestMIDIAccess({
    22
    23 }).then(
    24 },
    25
    30
    31 _onMidiSuccessHandler:
    32
    33 // loop over all available inputs and listen for any MIDI input
    34
    inputs.next()) {
    35 // each time there is a midi message call the onMIDIMessage
    function
    36 input.value.onmidimessage
    37 }
    26 _onMidiMessageHandler: function _onMidiMessageHandler(message) {
    27 console.log(message.data);
    28 PubSub.emitEvent('onMidiMessage', [message]);
    29 },


    View Slide

21. [144, 48, 127]


    View Slide

22. [144, 48, 127]
    Command
    or
    Channel
    Note Velocity


    View Slide

23. [144, 48, 127]
    127


    View Slide

24. [144, 48, ]
    0


    View Slide

25. Web MIDI
    Launchpad
    Web Audio


    View Slide

26. View Slide

27. Web Audio


    View Slide

28. How do we use it?


    View Slide

29. Midi
    SamplePackStore
    UIMapper
    PubSub
    SamplePlayer


    View Slide

30. 1 (function () {
    2 var SamplePlayer = function SamplePlayer(config) {
    3 this.init(config);
    4 };
    5
    6 SamplePlayer.prototype = Object.create(Base);
    7
    8 Object.assign(SamplePlayer.prototype, {
    9 events: {
    10 'onMidiMessage': '_onMidiMessageHandler',
    11 'samplePackChange': '_loadSamples'
    12 },
    13 samplePackName: null,
    14 samples: null,
    15 buffers: null,
    16
    17 init: function init(config) {
    18 this._bindAll();
    19 this.samples = {};
    20 this.buffers = {};
    21 this.audioContext = new AudioContext();
    22 this._loadSamples(SamplePackStore.activeSamplePack);
    23 this._listenEvents();
    24 },
    25


    View Slide

31. 1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    21 this.audioContext = new AudioContext();


    View Slide

32. AudioContext


    View Slide

33. .createBuffer()
    .createBufferSource()
    .decodeAudioData()
    .createStereoPanner()
    .createAnalyser()
    .createBiquadFilter()


    View Slide

34. .createStereoPanner()
    .createAnalyser()
    .createBiquadFilter()
    .createBuffer()
    .createBufferSource()
    .decodeAudioData()


    View Slide

35. 1 (function () {
    2 var SamplePackStore = window.SamplePackStore = Object.create({});
    3
    4 Object.assign(SamplePackStore, {
    5 samplePacks: {},
    6 samplePacksData: {},
    7 activeSamplePack: null,
    8 set: function set(key) {
    9 if (this.samplePacks[key]) {
    10 this.activeSamplePack = this.samplePacks[key];
    11 PubSub.emitEvent('samplePackChange', [{name: key, data:
    this.activeSamplePack}]);
    12 }
    13 }
    14 });
    15
    16 SamplePackStore.samplePacks.firstOfTheYear = {
    17 48: '/samples/firstyear/kick1.wav',
    18 49: '/samples/firstyear/freeze1.wav',
    19 50: '/samples/firstyear/freeze2.wav',
    20 51: '/samples/firstyear/freeze3.wav',
    21 33: '/samples/firstyear/freeze4.wav',
    22 34: '/samples/firstyear/freeze5.wav',
    23 35: '/samples/firstyear/freeze6.wav',
    24 17: '/samples/firstyear/freeze7.wav',
    25 18: '/samples/firstyear/freeze8.wav',
    26 19: '/samples/firstyear/freeze9.wav',
    27 2: '/samples/firstyear/freeze10.wav',


    View Slide

36. 1 (function () {
    2 var SamplePlayer = function SamplePlayer(config) {
    3 this.init(config);
    4 };
    5
    6 SamplePlayer.prototype = Object.create(Base);
    7
    8 Object.assign(SamplePlayer.prototype, {
    9 events: {
    10 'onMidiMessage': '_onMidiMessageHandler',
    11 'samplePackChange': '_loadSamples'
    12 },
    13 samplePackName: null,
    14 samples: null,
    15 buffers: null,
    16
    17 init: function init(config) {
    18 this._bindAll();
    19 this.samples = {};
    20 this.buffers = {};
    21 this.audioContext = new AudioContext();
    22 this._loadSamples(SamplePackStore.activeSamplePack);
    23 this._listenEvents();
    24 },
    25
    26 _loadSamples: function _loadSamples(samplePack) {
    27 var samplePlayer = this;
    28 var name = this.samplePackName = samplePack.name;
    29 var data = samplePack.data;


    View Slide

37. 1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    23
    24
    25
    26
    27
    28
    29
    22 this._loadSamples(SamplePackStore.activeSamplePack);


    View Slide

38. 26 _loadSamples: function _loadSamples(samplePack) {
    27 var samplePlayer = this;
    28 var name = this.samplePackName = samplePack.name;
    29 var data = samplePack.data;
    30 var urls = [];
    31
    32 if (this.samples[name]) {
    33 return this.samples[name];
    34 }
    35
    36 this.samples[name] = {};
    37 this.buffers[name] = {};
    38
    39 Object.keys(data).forEach(function (key) {
    40 var url = data[key];
    41 urls.push(url);
    42 });
    43
    44 new BufferLoader(this.audioContext, urls, function (bufferList) {
    45 var keys = Object.keys(data);
    46
    47 keys.forEach(function (key, index) {
    48 var buffer = bufferList[index];
    49
    50 // Store the buffer to use it later
    51 samplePlayer.buffers[name][key] = buffer;
    52 });
    53 }).load();
    54 },


    View Slide

39. 1 _onMidiMessageHandler: function _onMidiMessageHandler(message) {
    2 var data = message.data;
    3
    4 var key = data[1];
    5 var command = data[2];
    6
    7 var samplePackName = this.samplePackName;
    8
    9 if (command === 127) {
    10 var buffer = this.buffers[samplePackName][key];
    11
    12 if (buffer) {
    13 var sample = this._createNode(buffer, this.loop);
    14 this.samples[samplePackName][key] = sample;
    15
    16 sample.start(0);
    17 }
    18
    19 this._ledOn(key, 'green', true);
    20 } else {
    21 var sample = this.samples[samplePackName][key];
    22
    23 sample && sample.stop(0);
    24
    25 this._ledOff(key);
    26 }
    27 },


    View Slide

40. 81
    82 _createNode: function (buffer) {
    83 var node = this.audioContext.createBufferSource();
    84 node.buffer = buffer;
    85 node.connect(this.audioContext.destination);
    86
    87 return node;
    88 },
    89
    90 _ledOn: function _ledOn(key, color, full) {
    91 PubSub.emitEvent('ledOn', [key, color, full]);
    92 },
    93
    94 _ledOff: function _ledOff(key) {
    95 PubSub.emitEvent('ledOff', [key]);
    96 }
    97 });
    98
    99 window.SamplePlayer = SamplePlayer;
    100 }());


    View Slide

41. Demo


    View Slide

42. Resources


    View Slide

43. orlando/web-launchpad
    html5rocks.com
    developer.mozilla.org
    splice.com


    View Slide
