Docker Orchestration: Beyond the Basics

Transcript

1. Docker Orchestration: Beyond the Basics Aaron Lehmann Software Engineer, Docker
2. 2 About me • Software engineer at Docker • Maintainer on SwarmKit and Docker Engine open source projects • Focusing on distributed state, task scheduling, and rolling updates
3. Swarm mode
4. 4 Swarm mode is Docker’s built in orchestration • Docker can orchestrate containers over multiple machines without extra software • Example: running a instances of a web service on several machines
5. 5 Getting started with swarm mode • Initialize a new swarm: mgr-1$ docker swarm init • Join an existing swarm: worker-1$ docker swarm join --token <token>
 192.168.65.2:2377
6. 6 Swarm mode: Services • Swarm mode deals with services, not individual containers • Each service creates one or more replica tasks, which are run as containers • On manager, create a new service for a search microservice application: mgr-1$ docker service create -p 8080:8080 --name search \ --replicas 4 searchsvc:v1.0 mgr-1$ docker service ls ID NAME REPLICAS IMAGE COMMAND 2xtw9qipmbe9 search 4/4 searchsvc:v1.0
7. 7 Swarm mode: Nodes • Worker nodes just run service tasks • Manager nodes manage the swarm mgr-1$ docker node ls ID HOSTNAME STATUS AVAILABILITY MANAGER STATUS drwxwi4h2fb0tcrwgmpmma2x0 * mgr-1 Ready Active Leader 1mhtdwhvsgr3c26xxbnzdc3yp mgr-2 Ready Active Reachable 516pacagkqp2xc3fk9t1dhjor mgr-3 Ready Active Reachable 9j68exjopxe7wfl6yuxml7a7j worker-1 Ready Active 03g1y59jwfg7cf99w4lt0f662 worker-2 Ready Active dxn1zf6l61qsb1josjja83ngz worker-3 Ready Active
8. 8 Swarm mode topology Manager Manager Manager Worker Worker Worker Worker Worker Worker Search service container Billing service container Search service container Search service container Billing service container Search service container
9. 9 Swarm mode topology Worker Worker Worker Worker Worker Worker Search service container Billing service container Search service container Search service container Billing service container Search service container Manager Manager Manager
10. 10 Swarm mode topology Worker Worker Worker Worker Worker Search service container Billing service container Search service container Search service container Search service container Billing service container Manager Manager Manager
11. High availability
12. 12 High availability • Survive failures of some portion of workers and managers • If a worker fails, its assigned tasks are rescheduled elsewhere • What about manager failures?
13. 13 Raft • Raft is a protocol for maintaining a strongly consistent distributed log • Way to avoid a single point of failure
14. 14 Raft concepts • Quorum: A majority of managers • Leader: Randomly chosen manager that can add information to the distributed log • Election: The process of choosing a new leader
15. 15 High availability • The leader is the manager that: • Makes the scheduling decisions • Keeps track of node health • Handles API calls
16. 16 High availability • If the leader fails, another manager is elected in its place • For Raft to function, more than half the managers (a quorum) must be reachable
17. 17 How many managers for a swarm? • A single manager is fine in some scenarios • Any swarm meant to survive a manager failure should have 3 or 5 managers • No scaling benefit to adding additional managers • Each one replicates a full copy of the swarm's state
18. 18 Manager fault tolerance Number of managers Majority Tolerated Failures 1 1 0 2 2 0
19. 19 Manager fault tolerance Number of managers Majority Tolerated Failures 1 1 0 2 2 0
20. 20 Manager fault tolerance Number of managers Majority Tolerated Failures 1 1 0 2 2 0 3 2 1 4 3 1
21. 21 Manager fault tolerance Number of managers Majority Tolerated Failures 1 1 0 2 2 0 3 2 1 4 3 1
22. 22 Manager fault tolerance Number of managers Majority Tolerated Failures 1 1 0 2 2 0 3 2 1 4 3 1 5 3 2 6 4 2
23. 23 Manager fault tolerance Number of managers Majority Tolerated Failures 1 1 0 2 2 0 3 2 1 4 3 1 5 3 2 6 4 2
24. 24 Manager fault tolerance Number of managers Majority Tolerated Failures 1 1 0 2 2 0 3 2 1 4 3 1 5 3 2 6 4 2 7 4 3 8 5 3 9 5 4
25. 25 Where to deploy the managers • Managers must have static IP addresses • Managers should have very reliable connectivity to each other • Swarms that span a big geographic area aren't recommended • Looking at federation as an eventual solution for multi- region • Spreading managers across a cloud provider's "availability zones" in one region may make sense
26. 26 What to do if quorum is lost • Suppose two out of three managers fail • The swarm won't be able to schedule tasks or perform administrative functions • You will see timeouts from commands like
 docker node ls if this happens
27. 27 What to do if quorum is lost • What if these managers are gone forever? • docker swarm init --force-new-cluster on the surviving manager recovers from this state • This modifies the swarm so that it only has a single manager • From that point, new managers can be added
28. 28 Protecting managers from accidental overloading • By default, managers will be assigned tasks just like workers • This makes sense on small deployments • Best practice for serious deployments: avoid running container workloads on managers
29. 29 Protecting managers from accidental overloading • Drain the managers to prevent them from running service tasks: mgr-1$ docker node update --availability=drain <manager id> • Alternatively, set the node.role == worker constraint on all services
30. 30 Rolling updates • Important to avoid downtime during updates • docker service update is a rolling update by default • Parameters: • Update delay (--update-delay) • Update failure action: pause or continue
 (--update-failure-action) • Parallelism (--update-parallelism)
31. 31 Rolling updates Prepare new Stop old Start new Health checks Update delay Prepare new Stop old Start new Health checks Update delay Prepare new Stop old Prepare new Stop old Time Update parallelism {
32. Security
33. 33 Security model • All swarm connections are encrypted and authenticated with mutual TLS • Each node is identified by its certificate (CN = node ID) • The certificate authorizes the node to act as either a worker or manager (OU = swarm-manager or OU = swarm-worker) • By default, each manager operates as a certificate authority with the same CA key
34. 34 Security around adding nodes • How does a new node authenticate itself before having a certificate? • It presents a join token which is provided to
 docker swarm join
35. 35 Security around adding nodes • The join token contains a secret that authorizes the new node to receive either a worker or manager certificate • It also contains a digest of the root CA certificate, for protection against man-in-the-middle attacks • The node does not use or store the join token after joining
36. 36 Node joining example: adding a new worker • On a manager, retrieve the join token: mgr-1$ docker swarm join-token worker To add a worker to this swarm, run the following command: docker swarm join \
 --token SWMTKN-1-5f7umqonkff6je2l1kqpxdsok3bwipn73hlr5dxtvx4lusy809 -5yn6jy5zqqq3tnummvq365y7m \
 172.17.0.2:2377
37. 37 Node joining example: adding a new worker • Run the command on the new worker: worker-1$ docker swarm join --token \ SWMTKN-1-5f7umqonkff6je2l1kqpxdsok3bwipn73hlr5dxtvx4lusy809 -5yn6jy5zqqq3tnummvq365y7m \
 172.17.0.2:2377 This node joined a swarm as a worker.
38. 38 Node joining flow Joining node Manager Join token, certificate request Signed certificate Node registration Task assignments = TLS with no client certificate = Mutually authenticated TLS
39. 39 Rotating join tokens • The join tokens remain valid until they are rotated • It is good practice to periodically rotate them • docker swarm join-token --rotate worker generates a new worker token to replace the old one • docker swarm join-token --rotate manager generates a new manager token to replace the old one
40. 40 Rotating join tokens mgr-1$ docker swarm join-token --rotate worker Succesfully rotated worker join token. To add a worker to this swarm, run the following command: docker swarm join \
 --token SWMTKN-1-5f7umqonkff6je2l1kqpxdsok3bwipn73hlr5dxtvx4l usy809-6cq1skbwkkrp2xgv4ak0cgn01 \
 172.17.0.2:2377
41. 41 Certificate renewal • By default, certificates issued to nodes by the Swarm manager are valid for 90 days • Before they expire, nodes automatically renew their certificates • Jitter is added to the renewal time
42. 42 Certificate renewal • Renewal does not involve join tokens • A manager will issue a renewed certificate to any node that can prove its identity with mutual TLS • The certificate validity period can be changed with mgr-1$ docker swarm update --cert-expiry=1000h • A shorter expiration time limits the time window where a leaked certificate is useful to an attacker
43. 43 External certificate authorities • Some may prefer to use a hardened external CA • Swarm mode can be set up to call out to an external CA $ docker swarm init --external-ca \
 protocol=cfssl,url=https://myca.domain.com
44. 44 Node joining flow (external CA) Joining node Manager Join token, cert request Signed certificate Node registration Task assignments = TLS with no client certificate = Mutually authenticated TLS External CA Cert request Signed cert
45. 45 External certificate authorities • Initially supported protocol is cfssl's JSON API • Swarm manager authenticates with the external CA using mutual TLS with its manager certificate • External CA becomes a single point of failure for granting and renewing certificates
46. 46 Registry credentials • Some images are private, meaning a password or token is needed to pull them • If I just run:

 mgr-1$ docker service create myprivateimage
 ...workers won't be able to pull the image
47. 47 Registry credentials • docker login credentials are forwarded to nodes executing containers from the service if
 --with-registry-auth is specified: mgr-1$ docker service create \ --with-registry-auth myprivateimage
 • Note that the password or token is exposed to workers where the tasks are scheduled
48. 48 Registry credentials • Alternative to --with-registry-auth: pre-pull private images on all nodes • Consider using constraints to limit private images to hardened nodes
49. Upcoming improvements
50. 50 Upcoming improvements: Secrets management • Include secrets such as crypto keys with services • The associated secrets are sent to the nodes where the service's tasks are assigned • They are made available inside a RAM filesystem mounted inside the container • Secrets are not written to disk as part of task execution
51. 51 Upcoming improvements: Visibility into container logs • Currently no swarm-level support for container logs • It will be possible to access logs from any task through a manager, regardless of where the task is running
52. 52 Upcoming improvements: High availability scheduling • Improves scheduling algorithm to spread out replicas over as many nodes as possible • This avoids concentrating the service's tasks on one node or a few nodes • Then it's harder for hardware/network failures to take out all replicas
53. 53 Upcoming improvements: High availability scheduling Scale up search service to 3 replicas, old scheduling algorithm: Node 2 Billing
 service Billing
 service Billing
 service Node 1 Search
 service Search
 service Search
 service Node 1 has fewest tasks, so it receives the new task Search
 service
54. 54 Upcoming improvements: High availability scheduling Scale up search service to 3 replicas, new scheduling algorithm: Node 2 Billing
 service Billing
 service Billing
 service Node 1 Search
 service Search
 service Search
 service Node 2 has fewest replicas of the search service, so it receives the new task Search
 service
55. 55 Upcoming improvements: Roll back service updates • If you accidentally roll out a bad update to a service, it will be possible to roll it back with a simple command: mgr-1$ docker service update --rollback <servicename>
56. 56 Other resources • Swarm mode documentation:
 https://docs.docker.com/engine/swarm/ • Overviews of Raft: • http://thesecretlivesofdata.com/raft/ • https://raft.github.io • SwarmKit project GitHub repository:
 https://github.com/docker/swarmkit
57. Thanks!
