HashiCorp Vault
Heraud Kevin
July 06, 2017
Transcript
30 slides
A Tool for Managing Secrets
Provision, secure, and run any infrastructure for any application.
DB Credentials (MySQL, Hazelcast) Keystore password (P12, JKS) Keystore (private
key) Acces Keys (Tokenizer, OAuth2) Encryption Keys (AES) …
None
None
Secret Backends Storage Backends Auth Backends Audit Backends Telemetery
Les secrets dans une application • Où sont-ils stockés ?
– Fichiers « properties » – BDD – … • Comment gérer leurs cycles de vie ? – Renouvellement – Bail – Révocation – … • Qui doit les gérer ? • Comment mon application y accède ?
Les enjeux liés à Vault • Unseal/seal • Authentification (token,
login/passwd, github, …) • Génération des « unseal keys » – Shamir's Secret Sharing – PGP / Keybase.io – ? • Gestion des « Policy » • Génération des « tokens » utilisateurs • Wrap/unwrap • HSM (premium) • … Shamir's Secret Sharing
Comment accéder à Vault ? • CLI • HTTP API
• envconsul/consul-template • Ansible, Chef, … • docker-volume-libsecret • Client – Java, Spring Cloud, Scala – Go – Python – …
mount generic
$ vault write secret/app/key iauth.key_iauth=a8Y3IHgVCoj7AmUA Success! Data written to: secret/app/key
--- $ vault read secret/app/key iauth.key_iauth a8Y3IHgVCoj7AmUA --- $ vault read -wrap-ttl=10m secret/app/key wrapping_token: 19f11fee-c184-b218-6595-f58e87cad175 --- $ vault unwrap 19f11fee-c184-b218-6595-f58e87cad175 iauth.key_iauth a8Y3IHgVCoj7AmUA
None
mount mysql deprecated mount database beta Dynamic secrets or secrets
on-demand
Combien de fois change-t-on le mot de passe d’une base
de données dans la vie d’une application ?
None
mount pki
ITA Root CA ITA Intermediate CA vault.ita.rocks PKI = Ensemble
de composants physiques, de procédures et d’application en vue de gérer le cycle de vie des certificats
None
#MAUVAISEFOI
None
OpenSSL> openssl req -new -config etc/root-ca.conf -out ca/root- ca.csr -keyout
ca/root-ca/private/root-ca.key openssl ca -selfsign -config etc/root-ca.conf -in ca/root- ca.csr -out ca/root-ca.crt -extensions root_ca_ext openssl req -new -config etc/signing-ca.conf -out ca/signing-ca.csr -keyout ca/signing-ca/private/signing- ca.key openssl ca -config etc/root-ca.conf -in ca/signing-ca.csr - out ca/signing-ca.crt -extensions signing_ca_ext openssl req -new -config etc/server.conf -out certs/simple.org.csr -keyout certs/simple.org.key openssl ca -config etc/signing-ca.conf -in certs/simple.org.csr -out certs/simple.org.crt -extensions server_ext
KeyStore Explorer google/easypki keytool
None
HTTP API • Gestion des AC • Gestion des rôles
: – DN – TTL – Ext / Key usage (server auth, client auth, code signing, email protection, digital signature, data encipherment, …) – … • Gestion du cycle de vie des certificats • Gestion de la CRL
None
mount transit CaaS : Cryptography as a service
Gestion des clés (aes, ecdsa, eddsa) Chiffrement / Déchiffrement Génération
d’aléas Génération de hash (SHA256, SHA512, …) Génération de HMAC Signature / Validation
$ vault write -f transit/keys/foo Success! Data written to: transit/keys/foo
--- echo -n "LTDJ #70 : Vault" | base64 | vault write transit/encrypt/foo plaintext=- ciphertext vault:v1:N2BO36PLZ3…Beyt/LEj2MLo= --- vault write transit/decrypt/foo ciphertext=vault:v1:N2BO36PLZ3…Beyt/LEj2MLo= plaintext TFRESiAjNzAgOiBWYXVsdA== --- echo "TFRESiAjNzAgOiBWYXVsdA==" | base64 -d LTDJ #70 : Vault
Alternatives • Keywhiz (square) • Conjur • Docker secrets (swarm)
• Kubernetes secrets • AWS Key Management Service • Cloud Key Management (Google Cloud Plateform) • Azure Key Vault • …
AVANT JE STOCKAIS MES MOTS DE PASSE EN CLAIR
