droidconfr2013-discover-embedded-linux-with-android

Talk given at droidcon fr 2013
http://fr.droidcon.com/2013/sessions/genymobile/

Code sample are available:
https://github.com/CedricCabessa/droidconfr2013

Video:
http://www.youtube.com/watch?v=BgP-QjjWCfA

slide 1 to 37 have speaker notes
slide 38 to the end are the same without speaker notes (download pdf to have correct ratio, speakerdeck do not support slide rotation)

Transcript

1. Discover embedded Linux
   with Android
   Cédric Cabessa
   ccabessa@genymobile.com


   View Slide

2. Introduction
   Android is for mass market. Ecosystem is oriented toward multimedia content and
   consumer.
   Money is made selling games, music and so on.


   View Slide

3. Introduction
   On the other hand, embedded linux is used to create everykind of project, you have
   drivers for everything, you can plug any devices you want.
   The "hdtv blueray microwave washing machine" come from the Yocto-project


   View Slide

4. Introduction
   Can we keep Android with it's UI, its fully integrated API and yet use it to build our
   own embedded system ?


   View Slide

5. Introduction
   Android IS Linux


   View Slide

6. The Question
   ● How to modify Android to support a new hardware /
   new features without asking Google.
   ● Android Style
   You have a dev board (like a pandaboard) with Android. You want to plug a new
   device (gpio, i2c, rs232, ...).
   How to use it with an Android like API


   View Slide

7. Case study
   ●
   http://source.android.com
   ●
   Nexus
   ●
   Pandaboard
   ●
   Manufacturer support
   Android is opensource (AOSP), it is fairly easy to grab the source and build your own
   ROM (if you have hardware support: nexus or dev board with manufacturer support).


   View Slide

8. Case study
   ● Let's play with hardware !


   View Slide

9. Case study
   ● Character device: /dev/droidcon
   ● Convert upper case to lower case, in kernel land!
   In linux, most of the drivers are exposed through the "/dev" fiilesystem.
   To send data to the driver, you simply open the file and write to it.
   In real life, we assume you already have a driver for your device


   View Slide

10. Case study
    We assume we have a support for linux (driver) for our new hardware, we want to
    create applications that use it.
    We have to patch every layer from kernel to framework


    View Slide

11. Kernel / Driver
    ●
    Not part of AOSP
    ●
    Driver can be built with the kernel
    ●
    Or as a seperate module (.ko)
    ●
    GPLv2
    Driver is provided by your board manufacturer (kernel) or as a module from your
    device provider.
    Of course you can write your own if you have a custom device.


    View Slide

12. Kernel / Driver
    ●
    init.rc
    on boot
    insmod /system/lib/modules/droidcon.ko
    chown system system /dev/droidcon
    chmod 0600 /dev/droidcon
    ●
    device///device.mk
    PRODUCT_COPY_FILES := \
    device///droidcon.ko:system/lib/modules/droidcon.ko


    View Slide

13. Kernel / Driver
    ●
    Try it (connect as root)
    adb shell
    # ls -l /dev/droidcon
    crw------- system system 249, 0 droidcon
    # echo Hello > /dev/droidcon
    # cat /dev/droidcon
    hELLO
    #
    with real world devices, it is hard to check everything works just after loading the
    module


    View Slide

14. Kernel / Driver
    ●
    Our device is only usable by 'system'
    ●
    Run our app as system? => NO
    ●
    system_server use the device
    ●
    App communicate with system_server
    We will have to create permissions


    View Slide

15. HAL
    We simply load the driver and check permission. It's time to use it.
    Hardware Abstraction Layer


    View Slide

16. HAL
    ●
    C library
    ●
    Talk to driver
    ●
    Expose hardware feature
    ●
    Often closed source :-(
    expose hardware feature:
    driver can only support read / write, HAL should expose more advanced semantics
    that are implemented using read/write/...
    ex: usb missile launcher:
    HAL: missile_launch()
    Driver: write(/dev/foo, 42)


    View Slide

17. HAL
    ●
    hardware/droidcon/lib
    ●
    libdroidcon.h
    ssize_t droidcon_getdata(void *buf, size_t count);
    ssize_t droidcon_putdata(const void *buf, size_t count);
    void droidcon_clear(void);
    ●
    Do complicated thing here!
    And only here
    The driver only support open / read / write / close.
    We create a "droidcon_clear" function, this semantic make sense from a driver user
    point of view. In fact it is implemented as write(fd, 0, 0)
    ==> intelligent stuff go here


    View Slide

18. JNI
    Hal is C, System Service is java
    => jni


    View Slide

19. JNI
    ●
    frameworks/base/core/java/android/droidcon/
    LibDroidcon.java
    package android.droidcon;
    public class LibDroidcon {
    public native static void clear();
    public native static String getData() throws DroidconException;
    public native static void putData(String in) throws DroidconException;
    static {
    System.loadLibrary("droidcon_jni");
    }
    }
    Rem: we hack framework! May be we could separate our change from the standard
    android, but we will have to modify SystemServer so can't stay really separated.


    View Slide

20. JNI
    ●
    hardware/droidcon/jni/
    android_droidcon_LibDroidcon.c
    JNIEXPORT void JNICALL Java_android_droidcon_LibDroidcon_putData
    (JNIEnv *env,
    jclass cls, jstring string)
    {
    int ret;
    const char *buff = (*env)->GetStringUTFChars(env, string, NULL);
    int length = (*env)->GetStringLength(env, string);
    ret = droidcon_putdata(buff, length);
    if (ret < 0) {
    ThrowDroidconException(env, "fail to put data");
    }
    (*env)->ReleaseStringUTFChars(env, string, buff);
    }


    View Slide

21. JNI
    ●
    Tip for testing:
    ○
    Add a Main.java in android.droidcon
    public class Main {
    public static void main (String[] args) {
    try {
    LibDroidcon.putData("Hello");
    String out = LibDroidcon.getData();
    System.out.println(out);
    LibDroidcon.clear();
    } catch (DroidconException e) {
    Log.d("droidcon", e.toString());
    }
    }
    }
    ○
    Run it with the shell
    # dalvikvm android.droidcon.Main
    hELLO


    View Slide

22. System Service
    Now we can use our HAL from java.
    SystemService run as system.
    When you use context.getSystemService(...) you only get a proxy that send command
    through binder IPC to the SystemService.
    System Service do the real work and check permission.


    View Slide

23. System Service
    ●
    Must implement a Binder interface
    ●
    framework/base/droidcon/java/android/droidcon/
    IDroidconManager.aidl
    package android.droidcon;
    /** {@hide} */
    interface IDroidconManager
    {
    void clear();
    String getData();
    void putData(String data);
    }
    Declare every methods the client (framework) can call on the server (System Service)
    Can't throw exception here. Use return code or something else.


    View Slide

24. System Service
    ●
    frameworks/base/services/java/com/android/server/
    DroidconService.java


    View Slide

25. System Service
    package com.android.server;
    /** @hide */
    class DroidconService extends IDroidconManager.Stub {
    public String getData() {
    enforceAccessPermission();
    try {
    return LibDroidcon.getData();
    } catch(DroidconException e) {
    Slog.d(TAG, "cannot getdata");
    }
    return null;
    }
    private void enforceAccessPermission() {
    mContext.enforceCallingOrSelfPermission(
    android.Manifest.permission.DROIDCON_ACCESS,
    "DroidconService");
    }
    IDroidconManager.Stub is automatically generated from IDroidconManager.aidl
    Check for exception here and return
    Enforce permission (framework/base/core/res/AndroidManifest.xml)


    View Slide

26. System Service
    ●
    Hack SystemServer.java
    public void run() {
    [...]
    try {
    Slog.i(TAG, "Droidcon Service");
    droidconService = new DroidconService(context);
    ServiceManager.addService(Context.DROIDCON_SERVICE,
    droidconService);
    } catch (Throwable e) {
    reportWtf("starting Droidcon Service", e);
    }


    View Slide

27. Framework
    DroidconService is launched at startup. It listen to a Binder interface.
    We have to write the client side: Framework


    View Slide

28. Framework
    ●
    framework/base/droidcon/java/android/droidcon
    DroidconManager.java
    public class DroidconManager {
    IDroidconManager mService;
    /** @hide */
    public DroidconManager(IDroidconManager service) {
    mService = service;
    }
    public String getData() {
    try {
    return mService.getData();
    } catch (RemoteException e) {
    e.printStackTrace();
    }
    return null;
    }
    Do nothing but calling methods through the binder interface (and checking return
    value)


    View Slide

29. Framework
    ●
    Hack ContextImpl.java
    class ContextImpl extends Context {
    static {
    [...]
    registerService(DROIDCON_SERVICE, new ServiceFetcher() {
    public Object createService(ContextImpl ctx) {
    IBinder b = ServiceManager.getService(DROIDCON_SERVICE);
    IDroidconManager service = IDroidconManager.Stub.asInterface
    (b);
    return new DroidconManager(service);
    }});


    View Slide

30. Framework
    ●
    Create a new SDK
    ○
    make update-api
    ○
    make sdk
    ●
    Configure eclipse


    View Slide

31. Framework

    package="com.example.droidcon"
    android:versionCode="1"
    android:versionName="1.0" >

    ● AndroidManifest.xml


    View Slide

32. Framework


    View Slide

33. Framework


    View Slide

34. Framework


    View Slide

35. Conclusion
    ●
    Hardware support is not an excuse to not choose
    Android
    ●
    Kernel Driver and HAL should be re-usable
    ●
    Upper layers are mostly "glue code"
    ●
    Fragmentation?


    View Slide

36. References
    ● Remixing Android
    http://marakana.com/s/post/1044/remixing_android
    ● Adding System Service
    http://processors.wiki.ti.com/index.php/Android-
    Adding_SystemService


    View Slide

37. Q&A
    Genymobile SAS - 41, rue Meslay 75003 PARIS - 01 83 64 25 40
    www.genymobile.com
    QUESTIONS ?
    Cédric Cabessa
    ccabessa@genymobile.com
    https://speakerdeck.com/cedriccabessa/
    droidconfr2013-discover-embedded-linux-with-android
    https://github.com/CedricCabessa/droidconfr2013


    View Slide
