Real Cross-Platform: Can the ASP.NET Ecosystem Do It for Servers?
Christian Weyer PRO
October 15, 2015
Transcript
34 slides
-
Real Cross-‐Platform Can the ASP.NET Ecosystem Do It for Servers?
Christian Weyer Thinktecture AG [email protected] -
Christian Weyer • Co-founder, co-owner and principal consultant at Thinktecture
AG • Focus on – Mobile & web-based application architectures – Interoperability, cross-device – Pragmatic end-to-end solutions • Microsoft MVP for ASP.NET (Architecture) ASP.NET Web API / vNext Advisory Board Member ASPInsider, AzureInsider • Google GDE for AngularJS • http://blogs.thinktecture.com/cweyer [email protected] @christianweyer 2 -
Talking Points • Modern Business Applications • Target Architecture •
ASP.NET Web API & SignalR on Mono • ASP.NET 5 • Cross-Platform Database 3 -
Cross-Platform • Windows is a proven server operating system •
Linux strong in server landscape/hosting – Licenses & costs – Lower system footprint – Microsoft Azure offers Linux out-of-the-box • Virtualization environments are going to rule – VMs – Docker • Developing applications on Windows, Linux or MacOSX 5 -
Building Server Solutions • JVM: Java, Scala etc. • Full
Stack: JavaScript in Browser, node.js in Backend • .NET – Stable, mature – especially on the server – No fragmentation like on the client-side • .NET vNext & ASP.NET vNext enable the next step 6 -
Target Architecture Needed • Necessity for a modern applications landscape
is a service-based architecture – Services != SOA J • Often deployed as a distributed application architecture – Online vs. Offline – Light-weight communication 11 -
13 Target Architecture for SPAs Web/Application Server Browser Engine HTML
CSS JS Assets index.html Client Logic (JS) Server Logic SPA Stock Push Service Products Web API Orders Web API HTTPS HTTPS HTTPS WebSockets HTTPS Config Other Services/ Web APIs View (HTML, CSS) View (HTML, CSS) View (HTML, CSS) JSON JSON JSON -
ASP.NET Web API • Implementing light-weight architectures with HTTP-basedAPIs •
Separate technology stack, no dependency on ASP.NET – Has similarities to ASP.NET MVC, but completely different code base • Based on OWIN 15 -
Implementing a Web API • Define routes • Derive from
ApiController • Implement actions – Actions map to HTTP methods – Prefix method name with desired HTTP method – e.g. PostComment – Or use [HttpGet/Post/Put/Delete] • Several hosting options, e.g. – ASP.NET Web Application (IIS) – Self-host server (console application, Windows service, etc.) 16 -
Push Services Pattern • ‘Push Services’ are really not an
official pattern – Observer pattern, anyone? • Model a service that – accepts incoming connections from callers – is able to push data down to callers – abstracts from communication nitty-gritty details • Realize Publish-Subscribe semantics – Based on standard web technologies with reach in mind – With maximum reach into any device, platform Push Service Consumer Send data External event (Database) External event (Message queue) External event (Other actor) Notify [data] 17 -
ASP.NET SignalR • SignalR – Server-side framework to write push
services – Set of client libraries to make push service communication easy to use on any platform – Optimized for asynchronous processing • Abstracts from the different techniques to implement pushing data – Mental model is a persistent connection – Volatile, non-durable • Negotiation of transport: WebSockets, SSE, Forever Frame, Long Polling 18 -
ASP.NET SignalR Development • Extensible framework & pipeline – Based
on interfaces & DI • Two programming models – Persistent connections – Hubs • Hubs offer a pre-defined application-level protocol in an RPC-ish style – Easy-to-get-going way for 80/20 situations 19 -
ASP.NET Web API & SignalR – with Mono • Web
API 2 & SignalR 2 run on Mono – Windows, MacOSX & Linux – Tested with 3.12;; issues in 4.0.x;; works in 4.2 Alpha • Self-Hosted – Web-Hosted has issues • Limitations in 3.12 – OWIN & IPrincipal behavior – CORS 20 -
.NET 2015 RyuJIT + SIMD Garbage Collector Runtime components Compilers
.NET Compiler Platform (Roslyn) Languages innovation .NET Framework 4.6 .NET Core 5 Fully-featured and integrated .NET libraries and runtime for Windows Modular and optimized .NET libraries and runtimes Base class libraries NuGet packages Libraries -
ASP.NET 5 (aka vNext) • Next version of ASP.NET has
version 5 • Runs on .NET 4.6, Mono or CoreCLR • MVC‘s next release is named ‚6‘ • Web API is gone (no longer a framework on its own) – Integrated with MVC – Common routing, controllers etc. • SignalR still a separate thing 23 -
Web APIs in MVC 6 • Entirely integrated into MVC
Services – One view onto the world of HTTP • Entirely new pipeline implementation – Based on the ideas of OWIN • Deriving from base controller no longer necessary – Useful helpers can be reached via base class • Quite straight forward to port over from Web API 2 25 -
ASP.NET 5 is fast • … and will be even
faster in future 26 https://github.com/aspnet/benchmarks -
ASP.NET 5 Release Schedule Milestone Release week Beta6 27 Jul
2015 Beta7 2 Sep 2015 Beta8 15 Oct 2015 RC1 Nov 2015 1.0.0 Q1* 2016 27 -
Cross-Plattform Database • SQL for classic relational data, schema-based •
SQL Server does not run on non-Windows OSes • NoSQL for schema-free data • SQL Server has no NoSQL features (not yet) 29 -
PostgreSql • Open Source, established since 1996 • Runs on
Windows, Linux, MacOS X • Strong in classic SQL tasks • Supports document-based NoSQL since version 9.3 – JSON and JSONB • npgsql driver for .NET – With ADO.NET API – Support for Entity Framework 30 -
Summary • Cross-Platform on the server is often a
deployment/licensing decision • ASP.NET Web API & SignalR work reliably (enough) on Mono & Linux today • Mono may converge with .NET Core as its underpinnings • Maybe you do not need to move to ASP.NET 5 (yet) – At least not migrate or port existing applications 31 -
Resources • ASP.NET Web API – http://www.asp.net/web-api • ASP.NET SignalR
– http://www.asp.net/signalr • ASP.NET 5 – http://www.asp.net/vnext • .NET Core – http://dotnet.github.io/core/ – http://dotnet.readthedocs.org/en/latest/ • Mono – http://www.mono-project.com/ • Npgsql - .Net Data Provider for Postgresql – http://npgsql.projects.pgfoundry.org/ 32
