Managing Secrets at Scale with Spring Claud Vault

Share and manage secrets (certificates, passwords, keys) for your applications using Vault and Spring Vault.

Transcript

1. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Managing Secrets at Scale
   with Vault
   Christoph Strobl
   Pivotal Software, Inc.
   @stroblchristoph
   #devone


   View Slide

2. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 2


   View Slide

3. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Apache TomEE
   Encryption to the Rescue
   3

   JdbcDriver com.mysql.jdbc.Driver
   JdbcUrl jdbc:mysql:!//localhost/test
   UserName test
   Password Passw0rd
   !


   View Slide

4. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Apache TomEE
   Encryption to the Rescue
   4

   JdbcDriver com.mysql.jdbc.Driver
   JdbcUrl jdbc:mysql:!//localhost/test
   UserName test
   Password xMH5uM1V9vQzVUv5LG7YLA!==
   PasswordCipher Static3DES
   !


   View Slide

5. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Symmetric vs. Asymmetric
   5


   View Slide

6. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 6
   https://www.flickr.com/photos/dahlstroms/4188244058


   View Slide

7. 7
   Say,
   change that Password once again!


   View Slide

8. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 8


   View Slide

9. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 9


   View Slide

10. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    •  Secure secret storage
    •  Sealing
    •  Revocation
    •  Leasing and renewal
    •  Multiple secret backends
    •  Access control policies
    •  HTTP endpoint
    10


    View Slide

11. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 11
    •  Secret Storage
    •  Tokens & ACL
    •  Dynamic Secrets
    •  Leasing and renewal
    •  Key Rolling
    •  Audit Logs
    •  Hardware Security Modules
    •  24x7 Support
    Community Enterprise


    View Slide

12. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Getting Started – Init Vault
    12
    $ vault init -key-shares=1 -key-threshold=1
    Key 1: a9cbc3e47e4635ff2e8239bf43397fad3d659500cc7a0d42deea0ffd4d307244
    Initial Root Token: eb5229d6-9858-d494-a1d7-820cae1ea31e
    $
    Sealed: true
    Key Shares: 1
    Key Threshold: 1
    Unseal Progress: 0
    $
    vault status


    View Slide

13. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Getting Started – Unseal Vault & Auth Client
    13
    $ vault unseal a9cbc3e47e4635ff2e8239bf43397fad3d65950…
    vault auth eb5229d6-9858-d494-a1d7-820cae1ea31e
    Sealed: false
    Key Shares: 1
    Key Threshold: 1
    Unseal Progress: 0
    $
    Successfully authenticated!
    token: eb5229d6-9858-d494-a1d7-820cae1ea31e
    token_duration: 0
    token_policies: [root]
    $


    View Slide

14. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Getting Started – Write & Read Secrets
    14
    $ vault write secret/devone value=awesome
    vault read secret/devone
    Success! Data written to: secret/devone
    $
    Key Value
    lease_duration 2592000
    value awesome
    $


    View Slide

15. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Getting Started - HTTP API
    15
    $ curl –H”X-Vault-Token eb5229d6-9858-d494 :49222/v1/secret/devone
    {
    lease_id : null,
    renewable : false,
    lease_duration : 2592000,
    data : {
    value : awesome
    },
    wrap_info : null,
    …
    }
    $


    View Slide

16. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Getting Started – Seal Vault
    16
    $ vault seal
    vault read secret/devone
    Vault is now sealed.
    $
    Error reading secret/devone: Error making
    API request.
    URL: GET :49222/v1/secret/devone
    Code: 503. Errors:
    * Vault is sealed
    $


    View Slide

17. 17
    How is this any better?
    What if someone’s got your token?


    View Slide

18. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Use APP ID Auth maybe?
    18
    18
    $ vault auth-enable app-id
    Successfully enabled 'app-id' at 'app-id'!
    $ vault write auth/app-id/map/app-id/devone value=admin
    $ vault write auth/app-id/map/user-id/awesome value=devone&
    cidr_block=10.0.0.0/16
    $


    View Slide

19. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Spring Cloud In General
    19
    Service Discovery Circuit Breakers Routing & Messaging
    Ci Pipelines
    Tracing
    API Gateway
    Configuration


    View Slide

20. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Spring Cloud
    20
    Configuration
    Config Server


    View Slide

21. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Spring Cloud
    21
    Service Discovery
    Service Reg.
    Consumer
    Producer
    Connect


    View Slide

22. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Spring Cloud...
    •  Circuit Breakers withNetflix Hystrix.
    •  Messaging using RabbitMQ or Apache Kafka.
    •  Tracing with Spring Cloud Sleuth & Zipkin.
    •  Spring Cloud Bus
    •  Spring Cloud Stream (pre. Dataflow)
    •  Spring Cloud Task
    •  Spring Cloud AWS
    •  … and many more!
    22


    View Slide

23. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Spring Cloud Vault
    23
    Token / Auth


    View Slide

24. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 24

    org.springframework.cloud!
    spring-cloud-starter-vault-config!
    !
    src/main/resources/bootstrap.properties
    spring.application.name=spring-devone-app
    spring.cloud.vault.token=eb5229d6-9858-d494-a1d7-820!!...
    Project Setup – Dependencies & Properties


    View Slide

25. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Resolved environment properties
    $ curl :8080/env | jq
    {
    vault:secret/spring-devone-app : {
    secret-key : “!!***!!***”
    },
    vault:secret/applicaton : {
    message: “Hello #devone!”
    },
    …
    }
    $


    View Slide

26. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Spring Profile support built in
    $ curl :8080/env | jq
    {
    profiles : [test, dev],
    vault:secret/spring-devone-app/dev : {
    local : “!!***!!***”
    },
    vault:secret/spring-devone-app/test : {
    secret-key : “!!***!!***”
    },
    vault:secret/spring-devone-app : {
    secret-key : “!!***!!***”
    },
    vault:secret/applicaton : {
    message: “Hello #devone!”
    },
    $ mvn -Dspring.profiles.active=test,dev
    …


    View Slide

27. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Secret Backends
    27


    View Slide

28. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Different Backends
    28
    1. Configure
    2. Setup
    3. Auth
    4. Credentials
    5. Auth


    View Slide

29. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Vault with different Backends
    29
    29
    $ vault mount mysql
    $ vault write &
    mysql/config/connection&
    connection_url=spring:vault@tcp(localhost:3306)
    $ vault read mysql/creds/readonly
    Lease_id mysql/creds/eb5229d6-9858
    Lease_duration 2592000
    Password: a9cbc3e47e4635ff2e8239b
    Username: token-eb5229d6-9858


    View Slide

30. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Spring Cloud Vault with different Backends.
    30
    src/main/resources/bootstrap.properties
    spring.application.name=spring-devone-app
    spring.cloud.vault.token=eb5229d6-9858-d494-a1d7-820!!...
    spring.cloud.vault.mysql.enabled=true
    spring.cloud.vault.mysql.role=readonly
    spring.datasource.url=jdbc:mysql:!//localhost:3306


    View Slide

31. Unless otherwise indicated, these slides are © 2013-2017 Pivotal Software, Inc. and licensed under a
    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 31
    Spring Framework 5 RC1
    Spring Boot 2 M1
    Check out the latest releases!


    View Slide
