  1. E V E N T U A L LY B U I L D A R E A C T I V E

    E L A S T I C S E A R C H C L I E N T
    S I M P LY R E A C T I V E
    C H R I S T O P H S T R O B L , P I V O TA L S O F T WA R E I N C .

    @ S T R O B L C H R I S T O P H
    Technologieplauscherl
    2019-04-24

    View Slide

  2. „Non blocking all the way“

    View Slide

  3. I D I O M AT I C
    C L O S E T O E X I S T I N G
    N O F L U F F
    E V O LVA B L E
    D E S I G N G O A L S

    View Slide

  4. R E S T - B U T…
    R E S P O N S E F O R M AT S
    J S O N PA R S I N G
    R O U T I N G / R E S O U R C E M G M T
    O B S TA C L E S

    View Slide

  5. T E C H N O L O G Y S TA C K
    Spring Web Client
    Web Request Handling
    Project Reactor
    Reactive Composition
    Reactor Netty
    Transportation
    Elasticsearch
    You know, for search…

    View Slide

  6. Why not…?
    public Mono search(SearchRequest request) {
    return Mono.create(sink !->
    restHighLevelClient.searchAsync(request, RequestOptions.DEFAULT, new ActionListener() {
    @Override
    public void onResponse(SearchResponse searchResponse) {
    sink.success(searchResponse);
    }
    @Override
    public void onFailure(Exception e) {
    sink.error(e);
    }
    }));
    }

    View Slide

  7. „Start at the beginning“

    View Slide

  8. public interface ReactiveElasticsearchClient {
    /**
    * Execute a {@link SearchRequest} against the {@literal search} API.
    *
    * @param consumer never {@literal null}.
    * @see Search API on
    * elastic.co!
    * @return the {@link Flux} emitting {@link SearchHit hits} one by one.
    !*/
    default Flux search(Consumer consumer) {
    SearchRequest request = new SearchRequest();
    consumer.accept(request);
    return search(request);
    }
    /**
    * Execute the given {@link SearchRequest} against the {@literal search} API.
    *
    * @param searchRequest must not be {@literal null}.
    * @see Search API on
    * elastic.co!
    * @return the {@link Flux} emitting {@link SearchHit hits} one by one.
    !*/
    default Flux search(SearchRequest searchRequest) {
    return search(HttpHeaders.EMPTY, searchRequest);
    }
    /**
    * Execute the given {@link SearchRequest} against the {@literal search} API.
    *
    * @param headers Use {@link HttpHeaders} to provide eg. authentication data. Must not be {@literal null}.
    * @param searchRequest must not be {@literal null}.
    * @see Search API on
    * elastic.co!
    * @return the {@link Flux} emitting {@link SearchHit hits} one by one.
    !*/
    Flux search(HttpHeaders headers, SearchRequest searchRequest);
    !// !!...
    }
    Evolvable
    Idiomatic
    No Fluff
    Close To Existing

    View Slide

  9. „Then dive into details“

    View Slide

  10. REST Interface
    Reactive Communication via WebClient
    client.search(request !->
    request
    .indices("twitter")
    .types("users")
    .source(new SearchSourceBuilder().query(QueryBuilders.matchAllQuery()))
    ).subscribe();

    View Slide

  11. REST Interface
    Reactive Communication via WebClient
    private Mono sendRequest(WebClient webClient, String logId, Request request, HttpHeaders headers) {
    RequestBodySpec requestBodySpec = webClient.method(HttpMethod.valueOf(request.getMethod().toUpperCase())) !//
    .uri(builder !-> {
    builder = builder.path(request.getEndpoint());
    if (!ObjectUtils.isEmpty(request.getParameters())) {
    for (Entry entry : request.getParameters().entrySet()) {
    builder = builder.queryParam(entry.getKey(), entry.getValue());
    }
    }
    return builder.build();
    })
    .attribute(ClientRequest.LOG_ID_ATTRIBUTE, logId) !//
    .headers(theHeaders !-> {
    theHeaders.addAll(headers);
    if (request.getOptions() !!= null) {
    if (!ObjectUtils.isEmpty(request.getOptions().getHeaders())) {
    request.getOptions().getHeaders().forEach(it !-> theHeaders.add(it.getName(), it.getValue()));
    }
    }
    });
    if (request.getEntity() !!= null) {
    Lazy body = bodyExtractor(request);
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters(),
    body!::get);
    requestBodySpec.contentType(MediaType.valueOf(request.getEntity().getContentType().getValue()));
    requestBodySpec.body(Mono.fromSupplier(body!::get), String.class);
    } else {
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters());
    }
    return requestBodySpec !//
    .exchange() !//
    .onErrorReturn(ConnectException.class, ClientResponse.create(HttpStatus.SERVICE_UNAVAILABLE).build());
    }
    client.search(request !->
    request
    .indices("twitter")
    .types("users")
    .source(new SearchSourceBuilder().query(QueryBuilders.matchAllQuery()))
    ).subscribe();

    View Slide

  12. REST Interface
    Reactive Communication via WebClient
    private Mono sendRequest(WebClient webClient, String logId, Request request, HttpHeaders headers) {
    RequestBodySpec requestBodySpec = webClient.method(HttpMethod.valueOf(request.getMethod().toUpperCase())) !//
    .uri(builder !-> {
    builder = builder.path(request.getEndpoint());
    if (!ObjectUtils.isEmpty(request.getParameters())) {
    for (Entry entry : request.getParameters().entrySet()) {
    builder = builder.queryParam(entry.getKey(), entry.getValue());
    }
    }
    return builder.build();
    })
    .attribute(ClientRequest.LOG_ID_ATTRIBUTE, logId) !//
    .headers(theHeaders !-> {
    theHeaders.addAll(headers);
    if (request.getOptions() !!= null) {
    if (!ObjectUtils.isEmpty(request.getOptions().getHeaders())) {
    request.getOptions().getHeaders().forEach(it !-> theHeaders.add(it.getName(), it.getValue()));
    }
    }
    });
    if (request.getEntity() !!= null) {
    Lazy body = bodyExtractor(request);
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters(),
    body!::get);
    requestBodySpec.contentType(MediaType.valueOf(request.getEntity().getContentType().getValue()));
    requestBodySpec.body(Mono.fromSupplier(body!::get), String.class);
    } else {
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters());
    }
    return requestBodySpec !//
    .exchange() !//
    .onErrorReturn(ConnectException.class, ClientResponse.create(HttpStatus.SERVICE_UNAVAILABLE).build());
    }
    POST
    client.search(request !->
    request
    .indices("twitter")
    .types("users")
    .source(new SearchSourceBuilder().query(QueryBuilders.matchAllQuery()))
    ).subscribe();

    View Slide

  13. REST Interface
    Reactive Communication via WebClient
    private Mono sendRequest(WebClient webClient, String logId, Request request, HttpHeaders headers) {
    RequestBodySpec requestBodySpec = webClient.method(HttpMethod.valueOf(request.getMethod().toUpperCase())) !//
    .uri(builder !-> {
    builder = builder.path(request.getEndpoint());
    if (!ObjectUtils.isEmpty(request.getParameters())) {
    for (Entry entry : request.getParameters().entrySet()) {
    builder = builder.queryParam(entry.getKey(), entry.getValue());
    }
    }
    return builder.build();
    })
    .attribute(ClientRequest.LOG_ID_ATTRIBUTE, logId) !//
    .headers(theHeaders !-> {
    theHeaders.addAll(headers);
    if (request.getOptions() !!= null) {
    if (!ObjectUtils.isEmpty(request.getOptions().getHeaders())) {
    request.getOptions().getHeaders().forEach(it !-> theHeaders.add(it.getName(), it.getValue()));
    }
    }
    });
    if (request.getEntity() !!= null) {
    Lazy body = bodyExtractor(request);
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters(),
    body!::get);
    requestBodySpec.contentType(MediaType.valueOf(request.getEntity().getContentType().getValue()));
    requestBodySpec.body(Mono.fromSupplier(body!::get), String.class);
    } else {
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters());
    }
    return requestBodySpec !//
    .exchange() !//
    .onErrorReturn(ConnectException.class, ClientResponse.create(HttpStatus.SERVICE_UNAVAILABLE).build());
    }
    POST
    twitter/users/_search
    client.search(request !->
    request
    .indices("twitter")
    .types("users")
    .source(new SearchSourceBuilder().query(QueryBuilders.matchAllQuery()))
    ).subscribe();

    View Slide

  14. REST Interface
    Reactive Communication via WebClient
    private Mono sendRequest(WebClient webClient, String logId, Request request, HttpHeaders headers) {
    RequestBodySpec requestBodySpec = webClient.method(HttpMethod.valueOf(request.getMethod().toUpperCase())) !//
    .uri(builder !-> {
    builder = builder.path(request.getEndpoint());
    if (!ObjectUtils.isEmpty(request.getParameters())) {
    for (Entry entry : request.getParameters().entrySet()) {
    builder = builder.queryParam(entry.getKey(), entry.getValue());
    }
    }
    return builder.build();
    })
    .attribute(ClientRequest.LOG_ID_ATTRIBUTE, logId) !//
    .headers(theHeaders !-> {
    theHeaders.addAll(headers);
    if (request.getOptions() !!= null) {
    if (!ObjectUtils.isEmpty(request.getOptions().getHeaders())) {
    request.getOptions().getHeaders().forEach(it !-> theHeaders.add(it.getName(), it.getValue()));
    }
    }
    });
    if (request.getEntity() !!= null) {
    Lazy body = bodyExtractor(request);
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters(),
    body!::get);
    requestBodySpec.contentType(MediaType.valueOf(request.getEntity().getContentType().getValue()));
    requestBodySpec.body(Mono.fromSupplier(body!::get), String.class);
    } else {
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters());
    }
    return requestBodySpec !//
    .exchange() !//
    .onErrorReturn(ConnectException.class, ClientResponse.create(HttpStatus.SERVICE_UNAVAILABLE).build());
    }
    POST
    twitter/users/_search
    {
    typed_keys=true,
    ignore_unavailable=false,

    }
    client.search(request !->
    request
    .indices("twitter")
    .types("users")
    .source(new SearchSourceBuilder().query(QueryBuilders.matchAllQuery()))
    ).subscribe();

    View Slide

  15. REST Interface
    Reactive Communication via WebClient
    private Mono sendRequest(WebClient webClient, String logId, Request request, HttpHeaders headers) {
    RequestBodySpec requestBodySpec = webClient.method(HttpMethod.valueOf(request.getMethod().toUpperCase())) !//
    .uri(builder !-> {
    builder = builder.path(request.getEndpoint());
    if (!ObjectUtils.isEmpty(request.getParameters())) {
    for (Entry entry : request.getParameters().entrySet()) {
    builder = builder.queryParam(entry.getKey(), entry.getValue());
    }
    }
    return builder.build();
    })
    .attribute(ClientRequest.LOG_ID_ATTRIBUTE, logId) !//
    .headers(theHeaders !-> {
    theHeaders.addAll(headers);
    if (request.getOptions() !!= null) {
    if (!ObjectUtils.isEmpty(request.getOptions().getHeaders())) {
    request.getOptions().getHeaders().forEach(it !-> theHeaders.add(it.getName(), it.getValue()));
    }
    }
    });
    if (request.getEntity() !!= null) {
    Lazy body = bodyExtractor(request);
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters(),
    body!::get);
    requestBodySpec.contentType(MediaType.valueOf(request.getEntity().getContentType().getValue()));
    requestBodySpec.body(Mono.fromSupplier(body!::get), String.class);
    } else {
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters());
    }
    return requestBodySpec !//
    .exchange() !//
    .onErrorReturn(ConnectException.class, ClientResponse.create(HttpStatus.SERVICE_UNAVAILABLE).build());
    }
    POST
    twitter/users/_search
    {
    typed_keys=true,
    ignore_unavailable=false,

    }
    {
    query : {
    match_all: { boost :1.0 }
    }
    }
    client.search(request !->
    request
    .indices("twitter")
    .types("users")
    .source(new SearchSourceBuilder().query(QueryBuilders.matchAllQuery()))
    ).subscribe();

    View Slide

  16. JSON, NDJSON, YAML, CBOR and Smile
    The XContentParser private Publisher extends T> readResponseBody(String logId, Request request, ClientResponse response,
    Class responseType) {
    if (RawActionResponse.class.equals(responseType)) {
    ClientLogger.logRawResponse(logId, response.statusCode());
    return Mono.just(responseType.cast(RawActionResponse.create(response)));
    }
    if (response.statusCode().is5xxServerError()) {
    ClientLogger.logRawResponse(logId, response.statusCode());
    return handleServerError(request, response);
    }
    return response.body(BodyExtractors.toMono(byte[].class)) !//
    .map(it !-> new String(it, StandardCharsets.UTF_8)) !//
    .doOnNext(it !-> ClientLogger.logResponse(logId, response.statusCode(), it)) !//
    .flatMap(content !-> doDecode(response, responseType, content));
    }
    private static Mono doDecode(ClientResponse response, Class responseType, String content) {
    String mediaType = response.headers().contentType().map(MediaType!::toString).orElse(XContentType.JSON.mediaType());
    try {
    Method fromXContent = ReflectionUtils.findMethod(responseType, "fromXContent", XContentParser.class);
    return Mono.justOrEmpty(responseType
    .cast(ReflectionUtils.invokeMethod(fromXContent, responseType, createParser(mediaType, content))));
    } catch (Throwable errorParseFailure) { !// cause elasticsearch also uses AssertionError
    try {
    return Mono.error(BytesRestResponse.errorFromXContent(createParser(mediaType, content)));
    } catch (Exception e) {
    return Mono
    .error(new ElasticsearchStatusException(content, RestStatus.fromCode(response.statusCode().value())));
    }
    }
    }
    {
    "took": 57,
    "timed_out": false,
    "_shards": {
    "total": 5,
    "successful": 5,
    "skipped": 0,
    "failed": 0
    },
    "hits": {
    "total": 2,
    "max_score": 1,
    "hits": [
    {
    "_index": "twitter",
    "_type": "users",
    "_id": "3b6689bb-4a6a-4225-88a5-44712a6b0272",
    "_score": 1,
    "_source": {
    "name": "spiderman"
    }
    },
    {
    "_index": "twitter",
    "_type": "users",
    "_id": "ca0a8e08-86bf-40e8-b5e5-90deef1c9e2f",
    "_score": 1,
    "_source": {
    "name": "batman"
    }
    }
    ]
    }
    }

    View Slide

  17. private Publisher extends T> readResponseBody(String logId, Request request, ClientResponse response,
    Class responseType) {
    if (RawActionResponse.class.equals(responseType)) {
    ClientLogger.logRawResponse(logId, response.statusCode());
    return Mono.just(responseType.cast(RawActionResponse.create(response)));
    }
    if (response.statusCode().is5xxServerError()) {
    ClientLogger.logRawResponse(logId, response.statusCode());
    return handleServerError(request, response);
    }
    return response.body(BodyExtractors.toMono(byte[].class)) !//
    .map(it !-> new String(it, StandardCharsets.UTF_8)) !//
    .doOnNext(it !-> ClientLogger.logResponse(logId, response.statusCode(), it)) !//
    .flatMap(content !-> doDecode(response, responseType, content));
    }
    JSON, NDJSON, YAML, CBOR and Smile
    …but…
    {
    "took": 57,
    "timed_out": false,
    "_shards": {
    "total": 5,
    "successful": 5,
    "skipped": 0,
    "failed": 0
    },
    "hits": {
    "total": 2,
    "max_score": 1,
    "hits": [
    {
    "_index": "twitter",
    "_type": "users",
    "_id": "3b6689bb-4a6a-4225-88a5-44712a6b0272",
    "_score": 1,
    "_source": {
    "name": "spiderman"
    }
    },
    {
    "_index": "twitter",
    "_type": "users",
    "_id": "ca0a8e08-86bf-40e8-b5e5-90deef1c9e2f",
    "_score": 1,
    "_source": {
    "name": "batman"
    }
    }
    ]
    }
    }
    J S O N S T R E A M I N G
    Maybe in 8.0? Please!

    View Slide

  18. Resources
    Routing and Management
    ClientConfiguration config = ClientConfiguration.builder()
    .connectedTo("localhost:9200", "localhost:9201")
    .build();
    ReactiveElasticsearchClient client = ReactiveRestClients.create(config);
    client.search(request !->
    request
    .indices("twitter")
    .types("users")
    .source(new SearchSourceBuilder().query(QueryBuilders.matchAllQuery()))
    ).subscribe();
    public interface HostProvider {
    /**
    * Get the {@link WebClient} connecting to an active host utilizing cached
    * {@link ElasticsearchHost}.
    *
    * @return the {@link Mono} emitting the client for an active host or
    *. {@link Mono#error(Throwable) an error} if none
    * found.
    !*/
    default Mono getActive() {
    return getActive(Verification.LAZY);
    }
    /**
    * Get the {@link WebClient} connecting to an active host.
    *
    * @param verification must not be {@literal null}.
    * @return the {@link Mono} emitting the client for an active host or
    * {@link Mono#error(Throwable) an error} if none
    * found.
    !*/
    default Mono getActive(Verification verification) {
    return lookupActiveHost(verification).map(this!::createWebClient);
    }
    !// …
    }
    public Mono execute(ReactiveElasticsearchClientCallback callback) {
    return this.hostProvider.getActive()
    .flatMap(callback!::doWithClient)
    .onErrorResume(throwable !-> {
    if (throwable instanceof ConnectException) {
    return hostProvider.getActive(Verification.ACTIVE)
    .flatMap(callback!::doWithClient);
    }
    return Mono.error(throwable);
    });
    }

    View Slide

  19. Logging
    Reactive Communication via WebClient
    private Mono sendRequest(WebClient webClient, String logId, Request request, HttpHeaders headers) {
    RequestBodySpec requestBodySpec = webClient.method(HttpMethod.valueOf(request.getMethod().toUpperCase())) !//
    .uri(builder !-> {
    builder = builder.path(request.getEndpoint());
    if (!ObjectUtils.isEmpty(request.getParameters())) {
    for (Entry entry : request.getParameters().entrySet()) {
    builder = builder.queryParam(entry.getKey(), entry.getValue());
    }
    }
    return builder.build();
    })
    .attribute(ClientRequest.LOG_ID_ATTRIBUTE, logId) !//
    .headers(theHeaders !-> {
    theHeaders.addAll(headers);
    if (request.getOptions() !!= null) {
    if (!ObjectUtils.isEmpty(request.getOptions().getHeaders())) {
    request.getOptions().getHeaders().forEach(it !-> theHeaders.add(it.getName(), it.getValue()));
    }
    }
    });
    if (request.getEntity() !!= null) {
    Lazy body = bodyExtractor(request);
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters(),
    body!::get);
    requestBodySpec.contentType(MediaType.valueOf(request.getEntity().getContentType().getValue()));
    requestBodySpec.body(Mono.fromSupplier(body!::get), String.class);
    } else {
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters());
    }
    return requestBodySpec !//
    .exchange() !//
    .onErrorReturn(ConnectException.class, ClientResponse.create(HttpStatus.SERVICE_UNAVAILABLE).build());
    }
    client.search(request !->
    request
    .indices("twitter")
    .types("users")
    .source(new SearchSourceBuilder().query(QueryBuilders.matchAllQuery()))
    ).subscribe();

    View Slide

  20. Logging
    Reactive Communication via WebClient
    private Mono sendRequest(WebClient webClient, String logId, Request request, HttpHeaders headers) {
    RequestBodySpec requestBodySpec = webClient.method(HttpMethod.valueOf(request.getMethod().toUpperCase())) !//
    .uri(builder !-> {
    builder = builder.path(request.getEndpoint());
    if (!ObjectUtils.isEmpty(request.getParameters())) {
    for (Entry entry : request.getParameters().entrySet()) {
    builder = builder.queryParam(entry.getKey(), entry.getValue());
    }
    }
    return builder.build();
    })
    .attribute(ClientRequest.LOG_ID_ATTRIBUTE, logId) !//
    .headers(theHeaders !-> {
    theHeaders.addAll(headers);
    if (request.getOptions() !!= null) {
    if (!ObjectUtils.isEmpty(request.getOptions().getHeaders())) {
    request.getOptions().getHeaders().forEach(it !-> theHeaders.add(it.getName(), it.getValue()));
    }
    }
    });
    if (request.getEntity() !!= null) {
    Lazy body = bodyExtractor(request);
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters(),
    body!::get);
    requestBodySpec.contentType(MediaType.valueOf(request.getEntity().getContentType().getValue()));
    requestBodySpec.body(Mono.fromSupplier(body!::get), String.class);
    } else {
    ClientLogger.logRequest(logId, request.getMethod().toUpperCase(), request.getEndpoint(), request.getParameters());
    }
    return requestBodySpec !//
    .exchange() !//
    .onErrorReturn(ConnectException.class, ClientResponse.create(HttpStatus.SERVICE_UNAVAILABLE).build());
    }
    client.search(request !->
    request
    .indices("twitter")
    .types("users")
    .source(new SearchSourceBuilder().query(QueryBuilders.matchAllQuery()))
    ).subscribe();
    TRACE o.s.d.e.client.WIRE: 82 - [667a467f] Sending request POST /twitter/users/_search with parameters: {typed_keys=true, …}
    Request body: {„query":{"match_all":{"boost":1.0}}}
    TRACE o.s.d.e.client.WIRE: 110 - [667a467f] Received response: 200 OK
    Response body: {„took“:57,"timed_out":false,"_shards":{"total":5,"successful":5,"skipped":0,"failed":0},"hits":{"total":2, …..

    View Slide

  21. V E R S I O N : :

    3 . 2 . 0 . M 3
    G I T H U B : :

    s p r i n g - d a t a - e l a s t i c s e a rc h
    M A I N : :

    R e a c t i v e R e s t C l i e n t s
    C O N TA C T: :

    @ s t ro b l c h r i s t o p h

    View Slide
