Using Riak for events storage and analysis at Booking.com

At Booking.com, we have a constant flow of events coming from various applications and internal subsystems. This critical data needs to be stored for real-time, medium and long term analysis. Events are schema-less, making it difficult to use standard analysis tools.This presentation will explain how we built a real time storage and analysis solution based on Riak. The talk will cover: data aggregation and serialization, Riak configuration, solutions for lowering the network usage, and finally, how Riak's advanced features are used to perform real-time data crunching on the cluster nodes

Transcript

1. Using Riak for Events storage and analysis at
   Booking.com
   Damien Krotkine


   View Slide

2. Damien Krotkine
   • Software Engineer at Booking.com
   • github.com/dams
   • @damsieboy
   • dkrotkine


   View Slide

3. View Slide

4. KEY FIGURES
   • 600,000 hotels
   • 212 countries
   • 800,000 room nights every 24 hours
   • 43 million+ guest reviews
   • 155+ offices worldwide
   • 8,600 people
   • not a small website…


   View Slide

5. INTRODUCTION


   View Slide

6. View Slide

7. View Slide

8. View Slide

9. View Slide

10. www API
    mobi


    View Slide

11. www API
    mobi
    frontend


    View Slide

12. www API
    frontend
    backend
    mobi
    events storage
    events: info about
    subsystems status


    View Slide

13. backend
    web mobi api
    databases
    caches
    load
    balancers
    availability
    cluster
    email
    etc…


    View Slide

14. WHAT IS AN EVENT ?


    View Slide

15. EVENT STRUCTURE
    • Provides info about subsystems
    • Data
    • Deep HashMap
    • Timestamp
    • Type + Subtype
    • The rest: specific data
    • Schema-less


    View Slide

16. { timestamp => 12345,
    type => 'WEB',
    subtype => 'app',
    dc => 1,
    action => { is_normal_user => 1,
    pageview_id => '188a362744c301c2',
    # ...
    },
    tuning => { the_request => 'GET /display/...'
    bytes_body => 35,
    wallclock => 111,
    nr_warnings => 0,
    # ...
    },
    # ...
    }


    View Slide

17. { type => 'FAV',
    subtype => 'fav',
    timestamp => 1401262979,
    dc => 1,
    tuning => {
    flatav => {
    cluster => '205',
    sum_latencies => 21,
    role => 'fav',
    num_queries => 7
    }
    }
    }


    View Slide

18. EVENTS FLOW PROPERTIES
    • Read-only
    • Schema-less
    • Continuous, sequential, timed
    • 15 K events per sec
    • 1.25 Billion events per day
    • peak at 70 MB/s, min 25MB/s
    • 100 GB per hour


    View Slide

19. USAGE


    View Slide

20. USAGE
    1. GRAPHS
    2. DECISION MAKING
    3. SHORT TERM ANALYSIS
    4. A/B TESTING


    View Slide

21. GRAPHS
    • Graph in real-time ( few seconds lag )
    • Graph as many systems as possible
    • General platform health check


    View Slide

22. GRAPHS


    View Slide

23. GRAPHS


    View Slide

24. DASHBOARDS


    View Slide

25. META GRAPHS


    View Slide

26. USAGE
    1. GRAPHS
    2. DECISION MAKING
    3. SHORT TERM ANALYSIS
    4. A/B TESTING


    View Slide

27. DECISION MAKING
    • Strategic decision ( use facts )
    • Long term or short term
    • Technical / Non technical Reporting


    View Slide

28. USAGE
    1. GRAPHS
    2. DECISION MAKING
    3. SHORT TERM ANALYSIS
    4. A/B TESTING


    View Slide

29. SHORT TERM ANALYSIS
    • From 10 sec ago -> few hours ago
    • Code deployment checks and rollback
    • Anomaly Detector


    View Slide

30. USAGE
    1. GRAPHS
    2. DECISION MAKING
    3. SHORT TERM ANALYSIS
    4. A/B TESTING


    View Slide

31. A/B TESTING
    • Our core philosophy: use facts
    • It means: do A/B testing
    • Concept of Experiments
    • Events provide data to compare
    • We need data from the last few days


    View Slide

32. EVENT AGGREGATION


    View Slide

33. EVENT AGGREGATION
    • Group events
    • Granularity we need: second


    View Slide

34. SERIALIZATION
    • JSON didn’t work for us (slow, big, lack features)
    • Created Sereal in 2012
    • « Sereal, a new, binary data serialization format that
    provides high-performance, schema-less serialization »
    • https://github.com/Sereal/Sereal


    View Slide

35. event
    event
    events storage
    event
    event
    event
    event
    event
    event
    event
    event
    event
    event
    event


    View Slide

36. e e
    e e
    e
    e
    e e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    LOGGER
    e
    e


    View Slide

37. web api
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e e
    e e
    e
    e
    e e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e


    View Slide

38. web api dbs
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e e
    e e
    e
    e
    e e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e


    View Slide

39. web api dbs
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e e
    e e
    e
    e
    e e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    1 sec
    e
    e


    View Slide

40. web api dbs
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e e
    e e
    e
    e
    e e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    1 sec
    e
    e


    View Slide

41. web api dbs
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    e
    1 sec
    events storage


    View Slide

42. web api dbs
    e
    e
    e
    e
    e
    e
    e
    e
    e
    1 sec
    events storage
    e
    e e reserialize
    + compress


    View Slide

43. events storage
    LOGGER …
    LOGGER LOGGER


    View Slide

44. STORAGE


    View Slide

45. WHAT WE WANT
    • Storage security
    • Mass write performance
    • Mass read performance
    • Easy administration
    • Very scalable
    • => We reviewed a bunch of contenders


    View Slide

46. WE CHOSE RIAK
    • Security: cluster, distributed, very robust
    • Good and predictable read / write performance
    • The easiest to setup and administrate
    • Advanced features (MapReduce, triggers, 2i, CRDTs …)
    • Riak Search
    • Multi Datacenter Replication


    View Slide

47. View Slide

48. CLUSTER
    • Commodity hardware
    • All nodes serve data
    • Data replication
    • Gossip between nodes
    • No master
    • distributed system
    Ring of servers


    View Slide

49. hash(key)


    View Slide

50. View Slide

51. KEY VALUE STORE
    • Namespaces: bucket
    • Values: opaque or CRDTs


    View Slide

52. RIAK: ADVANCED FEATURES
    • MapReduce
    • Secondary indexes (2i)
    • Riak Search
    • Multi DataCenter Replication


    View Slide

53. MULTI-BACKEND FOR STORAGE
    • Bitcask
    • Eleveldb
    • Memory


    View Slide

54. BACKEND: BITCASK
    • Log-based storage backend
    • Append-only files (AOF files)
    • Advanced expiration
    • Predictable performance (1 disk-seek max)
    • Perfect for sequential data
    • SSD or spinning disks ?


    View Slide

55. CLUSTER CONFIGURATION


    View Slide

56. DISK SPACE NEEDED
    • 8 days
    • 100 GB per hour
    • Replication 3
    • 100 * 24 * 8 * 3
    • Need 60 T


    View Slide

57. HARDWARE
    • 2 clusters
    • 12 nodes, then 16, then 27
    • 12 CPU cores ( Xeon 2.5Ghz)
    • 192 GB RAM
    • network 1 Gbit/s
    • 8 TB (raid 6)
    • Cluster total space: 128 TB


    View Slide

58. DATA DESIGN


    View Slide

59. web api dbs
    e
    e
    e
    e
    e
    e
    e
    e
    e
    1 sec
    events storage
    1 blob per EPOCH / DC / CELL / TYPE / SUBTYPE
    500 KB max chunks


    View Slide

60. DATA
    • Bucket name: “data“
    • Key: “12345:1:cell0:WEB:app:chunk0“
    • Value: List of events (Hashmaps), serialized & compressed
    • 200 keys per seconds


    View Slide

61. METADATA
    • Bucket name: “metadata“
    • Key: - “1428415043-2“
    • Value: list of data keys:



    [ “1428415043:1:cell0:WEB:app:chunk0“,

    “1428415043:1:cell0:WEB:app:chunk1“

    …

    “1428415043:4:cell0:EMK::chunk3“ ]
    • As pipe separated value (PSV)


    View Slide

62. WRITE DATA


    View Slide

63. PUSH DATA IN
    • Every seconds:
    • Push data values to Riak, in parallel
    • Wait for success
    • Push metadata


    View Slide

64. JAVA
    Bucket DataBucket = riakClient.fetchBucket("data").execute();
    DataBucket.store("12345:1:cell0:WEB:app:chunk0", Data1).execute();
    DataBucket.store("12345:1:cell0:WEB:app:chunk1", Data2).execute();
    DataBucket.store("12345:1:cell0:WEB:app:chunk2", Data3).execute();
    Bucket MetaDataBucket = riakClient.fetchBucket("metadata").execute();
    MetaDataBucket.store("12345-1", metaData).execute();
    riakClient.shutdown();


    View Slide

65. Perl
    my $client = Riak::Client->new(…);
    $client->put(data => '12345:1:cell0:WEB:app:chunk0', $data1);
    $client->put(data => '12345:1:cell0:WEB:app:chunk1', $data2);
    $client->put(data => '12345:1:cell0:WEB:app:chunk2', $data3);
    $client->put(metadata => '12345-1', $metadata, 'text/plain' );


    View Slide

66. READ DATA


    View Slide

67. READ ONE SECOND
    • For one second (a given epoch)
    • Request metadata for -DC
    • Parse value
    • Filter out unwanted types / subtypes
    • Fetch the keys from the “data” bucket


    View Slide

68. Perl
    my $client = Riak::Client->new(…);
    my @array = split '\|', $client->get(metadata => '1428415043-1');
    @filtered_array = grep { /WEB/ } @array;
    $client->get(data => $_) foreach @filtered_array;


    View Slide

69. READ AN INTERVAL
    • For an interval epoch1 -> epoch2
    • Generate the list of epochs
    • Fetch in parallel
    • Riak excels at handling huge number of req/sec


    View Slide

70. RIAK CLUSTER HEALTH


    View Slide

71. CPU USAGE


    View Slide

72. DISK IOPS


    View Slide

73. DISK IO UTILIZATION %


    View Slide

74. DISK SPACE RECLAIMED
    one day


    View Slide

75. REAL TIME PROCESSING OUTSIDE OF RIAK


    View Slide

76. EXAMPLES
    • Streaming => Graphite ( every sec )
    • Streaming => Anomaly Detector ( last 2 min )
    • Streaming => Experiment analysis ( last day )
    • Every minute => Hadoop
    • Manual request => test, debug, investigate
    • Batch fetch => ad hoc analysis
    • => Huge numbers of read requests


    View Slide

77. events storage
    graphite
    cluster
    Anomaly
    detector
    experiment

    cluster
    hadoop
    cluster
    mysql
    analysis
    manual
    requests
    50 MB/s
    50 MB/s
    50
    M
    B/s
    50
    M
    B/s
    50 MB/s
    50 MB/s


    View Slide

78. THIS IS REALTIME
    • 1 second of data
    • Stored in < 1 sec
    • Available after < 1 sec
    • Issue : network saturation


    View Slide

79. REAL TIME PROCESSING INSIDE RIAK


    View Slide

80. THE IDEA
    • Instead of
    • Fetch data,
    • Crunch data (ex: average),
    • Produce a small result
    • Do
    • Bring code to data
    • Crunch data on Riak
    • Fetch the result


    View Slide

81. WHAT TAKES TIME
    • Takes a lot of time
    • Fetching data out: network issue
    • Decompressing: CPU time issue
    • Takes almost no time
    • Crunching data


    View Slide

82. MAPREDUCE
    • Input: epoch-dc
    • Map1: metadata keys => data keys
    • Map2: data crunching
    • Reduce: aggregate
    • Realtime: OK
    • network usage: OK
    • CPU time: NOT OK


    View Slide

83. HOOKS
    • Every time metadata is written
    • Post-Commit hook triggered
    • Riak executes a callback we provided
    • Crunch data on the nodes


    View Slide

84. View Slide

85. Riak post-commit hook
    REST service
    RIAK service
    key key
    socket
    result sent for storage
    decompress

    process all tasks
    NODE HOST


    View Slide

86. HOOK CODE
    metadata_stored_hook(RiakObject) ->
    Key = riak_object:key(RiakObject),
    Bucket = riak_object:bucket(RiakObject),
    [ Epoch, DC ] = binary:split(Key, <<"-">>),
    MetaData = riak_object:get_value(RiakObject),
    DataKeys = binary:split(MetaData, <<"|">>, [ global ]),
    send_to_REST(Epoch, Hostname, DataKeys),
    ok.


    View Slide

87. send_to_REST(Epoch, Hostname, DataKeys) ->
    Method = post,
    URL = "http://" ++ binary_to_list(Hostname)
    ++ ":5000?epoch=" ++ binary_to_list(Epoch),
    HTTPOptions = [ { timeout, 4000 } ],
    Options = [ { body_format, string },
    { sync, false },
    { receiver, fun(ReplyInfo) -> ok end }
    ],
    Body = iolist_to_binary(mochijson2:encode( DataKeys )),
    httpc:request(Method, {URL, [], "application/json", Body},
    HTTPOptions, Options),
    ok.


    View Slide

88. REST SERVICE
    • In Perl, using PSGI (WSGI-like), Starman, preforks
    • Allow to write data cruncher in Perl
    • Also supports loading code on demand
    • list of operational companions Monitored


    View Slide

89. REST SERVICE: SCALABLE
    • Scalable
    • 1 second = 200 keys
    • 16 nodes, 10 CPUs ( 2 for Riak )
    • 1 key must be crunched in 16*10/200 sec = 0.8 sec
    • => we have time


    View Slide

90. OPTIMIZATION
    R C
    R C
    R C
    key
    primary node
    for that key
    R
    C
    : Riak
    : Companion
    PUT


    View Slide

91. ADVANTAGES
    • CPU usage and execution time can be capped
    • Data is local to processing
    • Data is decompressed only once
    • Data crunching done all at once
    • Two systems are loosely coupled
    • can be written in any language


    View Slide

92. DISADVANTAGES
    • Only for incoming data (streaming), not old data
    • Can’t easily use cross-second data


    View Slide

93. THE BANDWIDTH PROBLEM


    View Slide

94. • PUT - bad case
    • n_val = 3
    • inside usage =

    3 x outside usage


    View Slide

95. • PUT - good case
    • n_val = 3
    • inside usage =

    2 x outside usage


    View Slide

96. • GET - bad case
    • inside usage =

    3 x outside usage


    View Slide

97. • GET - good case
    • inside usage =

    2 x outside usage


    View Slide

98. • network usage ( PUT and GET ):
    • 3 x 13/16+ 2 x 3/16= 2.81
    • plus gossip
    • inside network > 3 x outside network


    View Slide

99. • Usually it’s not a problem
    • But in our case:
    • big values, constant PUTs, lots of GETs
    • sadly, only 1 Gbit/s
    • => network bandwidth issue


    View Slide

100. THE BANDWIDTH SOLUTIONS


     View Slide

101. THE BANDWIDTH SOLUTIONS
     1. Optimize GET for network usage, not speed
     2. Don’t choose a node at random


     View Slide

102. • GET - bad case
     • n_val = 1
     • inside usage =

     1 x outside


     View Slide

103. • GET - good case
     • n_val = 1
     • inside usage =

     0 x outside


     View Slide

104. WARNING
     • Possible only because data is read-only
     • Data has internal checksum
     • No conflict possible
     • Corruption detected


     View Slide

105. RESULT
     • practical network usage reduced by 2 !


     View Slide

106. THE BANDWIDTH SOLUTIONS
     1. Optimize GET for network usage, not speed
     2. Don’t choose a node at random


     View Slide

107. • bucket = “metadata”
     • key = “12345”


     View Slide

108. • bucket = “metadata”
     • key = “12345”
     Hash = hashFunction(bucket + key)
     RingStatus = getRingStatus
     PrimaryNodes = Fun(Hash, RingStatus)


     View Slide

109. hashFunction()
     getRingStatus()


     View Slide

110. hashFunction()
     getRingStatus()


     View Slide

111. WARNING
     • Possible only if
     • Nodes list is monitored
     • In case of failed node, default to random
     • Data is requested in an uniform way


     View Slide

112. RESULT
     • Network usage even more reduced !
     • Especially for GETs


     View Slide

113. NETWORK USAGE


     View Slide

114. CONCLUSION


     View Slide

115. CONCLUSION
     • We used only Riak Open Source
     • No training, self-taught, small team
     • Riak is a great solution
     • Robust, fast, scalable, easy
     • Very flexible and hackable
     • Helps us continue scaling


     View Slide

116. Q&A
     @damsieboy


     View Slide
