Kotlin Coroutines for Android

A walkthrough of Kotlin Coroutines and how to use it in Android Development

Transcript

1. Kotlin Coroutines


   View Slide

2. The Async Problem
   class AsyncExampleActivity : AppCompatActivity() {
   override fun onCreate(savedInstanceState: Bundle?) {
   super.onCreate(savedInstanceState)
   setContentView(R.layout.activity_async_example)
   }
   }


   View Slide

3. The Async Problem
   class AsyncExampleActivity : AppCompatActivity() {
   companion object {
   const val URL = "http://server.com/image.jpg"
   }
   override fun onCreate(savedInstanceState: Bundle?) {
   super.onCreate(savedInstanceState)
   setContentView(R.layout.activity_async_example)
   val image = ImageFetcher.fetchImage(URL)
   imageView.setImageBitmap(image)
   }
   }


   View Slide

4. The Async Problem
   class AsyncExampleActivity : AppCompatActivity() {
   companion object {
   const val URL = "http://server.com/image.jpg"
   }
   override fun onCreate(savedInstanceState: Bundle?) {
   super.onCreate(savedInstanceState)
   setContentView(R.layout.activity_async_example)
   thread {
   val image = ImageFetcher.fetchImage(URL)
   imageView.setImageBitmap(image)
   }
   }
   }


   View Slide

5. The Async Problem
   class AsyncExampleActivity : AppCompatActivity() {
   companion object {
   const val URL = "http://server.com/image.jpg"
   }
   override fun onCreate(savedInstanceState: Bundle?) {
   super.onCreate(savedInstanceState)
   setContentView(R.layout.activity_async_example)
   thread {
   val image = ImageFetcher.fetchImage(URL)
   runOnUiThread {
   imageView.setImageBitmap(image)
   }
   }
   }
   }


   View Slide

6. The Async Problem
   class AsyncExampleActivity : AppCompatActivity() {
   companion object {
   const val URL = "http://server.com/image.jpg"
   }
   override fun onCreate(savedInstanceState: Bundle?) {
   super.onCreate(savedInstanceState)
   setContentView(R.layout.activity_async_example)
   thread {
   val image = ImageFetcher.fetchImage(URL)
   runOnUiThread {
   if(!isDestroyed) imageView.setImageBitmap(image)
   }
   }
   }
   }


   View Slide

7. Callback Hell
   fun callbackHell(): Unit {
   loadA {
   loadB {
   loadC {
   loadD {
   loadE { displayResult(it) }
   }
   }
   }
   }
   }


   View Slide

8. AsyncTask
   class ImageLoader(val imageView: ImageView) : AsyncTask() {
   override fun doInBackground(vararg params: String?): Bitmap {
   return ImageFetcher.fetchImage(params[0]!!)
   }
   override fun onPostExecute(result: Bitmap?) {
   imageView.setImageBitmap(result)
   }
   }


   View Slide

9. RxJava
   Observable.just(URL)
   .map { ImageFetcher.fetchImage(it) }
   .subscribe { imageView.setImageBitmap(it) }


   View Slide

10. RxJava
    Observable.just(URL)
    .map { ImageFetcher.fetchImage(it) }
    .subscribeOn(Schedulers.io())
    .observeOn(AndroidSchedulers.mainThread())
    .subscribe { imageView.setImageBitmap(it) }


    View Slide

11. RxJava
    RxView.clicks(button)
    .map { URL }
    .observeOn(Schedulers.io())
    .map { ImageFetcher.fetchImage(it) }
    .observeOn(AndroidSchedulers.mainThread())
    .subscribe { imageView.setImageBitmap(it) }


    View Slide

12. RxJava
    RxView.clicks(button)
    .map { URL }
    .observeOn(Schedulers.io())
    .map { ImageFetcher.fetchImage(it) }
    .observeOn(AndroidSchedulers.mainThread())
    .subscribe({ imageView.setImageBitmap(it) },
    { Log.e(TAG, "Couldn't fetch image!", e) })


    View Slide

13. Coroutines


    View Slide

14. Coroutines are cheap
    fun main(args: Array) {
    (0 until 100000)
    .forEach {
    thread {
    sleep(5000L) // Fake our long running call
    print(".")
    }
    }
    }


    View Slide

15. Coroutines are cheap
    fun main(args: Array) = runBlocking {
    val jobs = (0 until 100000)
    .map {
    launch {
    delay(5000L) // Fake our long running call
    print(".")
    }
    }
    // Wait for them to finish...
    jobs.forEach { it.join() }
    }


    View Slide

16. Kotlin Coroutines are easy!
    kotlin {
    experimental {
    coroutines 'enable'
    }
    }
    dependencies {
    implementation "org.jetbrains.kotlin:kotlin-stdlib-jre8:$kotlin_version"
    implementation “org.jetbrains.kotlinx:kotlinx-coroutines-core:0.20"
    implementation "org.jetbrains.kotlinx:kotlinx-coroutines-android:0.20"
    }


    View Slide

17. Kotlin Coroutines are easy!
    // Three suspending functions
    suspend fun doFirstThing(input: Int): String { ... }
    suspend fun doSecondThing(input: String): Int { ... }
    suspend fun doThirdThing(input: Int): String { ... }


    View Slide

18. Kotlin Coroutines are easy!
    launch {
    val resultOne = doFirstThing(args[0].toInt())
    val resultTwo = doSecondThing(resultOne)
    val resultThree = doThirdThing(resultTwo)
    println("Result: $resultThree")
    }


    View Slide

19. Cancellation
    fun main(args: Array) = runBlocking {
    val job = launch {
    while(true) {
    println("I'm sleeping...")
    delay(500L)
    }
    }
    delay(1300L) // delay a bit
    println("main: I'm tired of waiting!")
    job.cancel() // cancels the job
    job.join() // waits for job's completion
    println("main: Now I can quit.")
    }


    View Slide

20. Sequences
    fun fibonacci() = buildSequence {
    var terms = Pair(0, 1)
    // this sequence is infinite
    while(true) {
    yield(terms.first)
    terms = Pair(terms.second, terms.first + terms.second)
    }
    }
    println(fibonacci().take(10).toList()) // [0, 1, 1, 2, 3, 5, 8, 13, 21, 34]


    View Slide

21. Behind the scenes


    View Slide

22. Continuations
    // The following functions...
    suspend fun CompletableFuture.await(): T
    // ...is transformed at compile time to...
    fun CompletableFuture.await(continuation: Continuation): Any?


    View Slide

23. Continuations
    public interface Continuation {
    public val context: CoroutineContext
    public fun resume(value: T)
    public fun resumeWithException(exception: Throwable)
    }


    View Slide

24. State machine
    val a = a()
    val y = foo(a).await() // suspension point #1
    b()
    val z = bar(a, y).await() // suspension point #2
    c(z)


    View Slide

25. State machine
    class extends CoroutineImpl<...> implements Continuation {
    // The current state of the state machine
    int label = 0
    // local variables of the coroutine
    A a = null
    Y y = null
    void resume(Object data) {
    if (label == 0) goto L0
    if (label == 1) goto L1
    if (label == 2) goto L2
    else throw IllegalStateException()


    View Slide

26. State machine
    L0:
    // data is expected to be `null` at this invocation
    a = a()
    label = 1
    data = foo(a).await(this) // 'this' is passed as a continuation
    if (data == COROUTINE_SUSPENDED) return // return if await had suspended execution
    L1:
    // external code has resumed this coroutine passing the result of .await() as data
    y = (Y) data
    b()
    label = 2
    data = bar(a, y).await(this) // 'this' is passed as a continuation
    if (data == COROUTINE_SUSPENDED) return // return if await had suspended execution
    L2:
    // external code has resumed this coroutine passing the result of .await() as data
    Z z = (Z) data
    c(z)
    label = -1 // No more steps are allowed
    return
    }
    }


    View Slide

27. Looks familiar?


    View Slide

28. View Slide

29. Kotlin Coroutines,
    Anko and Android


    View Slide

30. Anko
    dependencies {
    implementation "org.jetbrains.anko:anko-coroutines:0.10.3"
    }


    View Slide

31. Background jobs
    jobButton.setOnClickListener {
    async(UI) {
    val data: Deferred = bg {
    loadData()
    }
    jobText.append(data.await())
    }
    }


    View Slide

32. Make it cancelable
    job = async(UI) {
    val data: Deferred = bg {
    loadData()
    }
    // Waits until return, or throw CancellationException
    jobText.append(data.await())
    }
    // in onDestroy()
    job?.cancel()


    View Slide

33. Using ref()
    val ref: Ref = this.asReference()
    jobButton.setOnClickListener {
    async(UI) {
    val data: Deferred = bg {
    loadData()
    }
    // Will throw CancellationException if null
    ref().jobText.append(data.await())
    }
    }


    View Slide

34. Click throttling


    View Slide

35. At most one at a time
    suspend fun doJob() {
    jobText.append("Job started...\n")
    delay(1000)
    jobText.append("still working...\n")
    delay(1000)
    jobText.append("just a bit more...\n")
    delay(1000)
    jobText.append("Job done!\n")
    }


    View Slide

36. At most one at a time
    // Create an actor that reacts to new events, but only one at a time
    val jobActor = actor(UI) { for (event in channel) doJob() }
    // Trigger new event on cick
    jobButton.setOnClickListener {
    jobActor.offer(Unit)
    }


    View Slide

37. Producer/Consumer


    View Slide

38. Producer
    // Setup producer
    val channel = produce {
    val cursor = queryDatabase()
    cursor.use {
    while (it.moveToNext()) {
    send(cursorToData(it))
    }
    }
    }


    View Slide

39. Consumer
    async(UI) {
    val cat = channel?.receiveOrNull()
    cat?.let {
    catAdapter.cats += it
    catAdapter.notifyItemInserted(catAdapter.cats.lastIndex)
    }
    }


    View Slide

40. Subroutines are special
    cases of ... coroutines.
    — Donald Knuth


    View Slide

41. Thank you for listening!
    Slides available at https://speakerdeck.com/erikhellman/kotlin-
    coroutines-for-android


    View Slide

42. Resources
    • https://kotlinlang.org/docs/reference/coroutines.html
    • https://github.com/Kotlin/kotlinx.coroutines/blob/master/coroutines-
    guide.md
    • https://github.com/Kotlin/kotlinx.coroutines/blob/master/ui/coroutines-
    guide-ui.md
    • https://github.com/Kotlin/kotlin-coroutines/blob/master/kotlin-coroutines-
    informal.md
    • https://github.com/Kotlin/anko/wiki/Anko-Coroutines
    • https://github.com/ErikHellman/KotlinCoroutinesWithAndroid


    View Slide
