Código limpio en la UI para Android, mejores prácticas.

Consejos basicos para un codigo mas limpio en tu UI.

Transcript

1. Codigo limpio en tu UI de Android.
2. Hola! Soy Cristian Gomez Desarrollador Android Co-Organizador de Medellin Android meetup @iyubinest
3. “ El codigo limpio puede ser legible por una persona diferente al autor… tiene pruebas… usa nombres adecuados… cuenta con dependencias minimas… tiene un API reducido…
4. Codigo Limpio ▪ Ligibilidad ▪ Pruebas ▪ Nombramiento ▪ Dependencias ▪ API reducido Estás seguro que tu codigo es limpio?
5. Legibilidad
6. No es un gran problema? ▪ Claridad ▪ Consistencia ▪ Proposito ▪ Expresividad
7. Codigo Android ▪ Separa las reglas de negocio de la presentación. ▪ Buenas prácticas? ▪ Como manejar todo el código restante? ▪ Deja de hablar en Android, habla con propósito.
8. class MyActivity extends AppCompatActivity { @OnClick(R.id.button) public void onButtonAction(){ RequestTask task = new RequestTask(); task.exec(); } @OnClick(R.id.button1) public void onButton1Action(){ Reques1tTask task = new Request1Task(); task.exec(); } static class RequestTask() extends AsyncTask {...} static class Request1Task() extends AsyncTask {...} }
9. class LoginActivity extends AppCompatActivity { @OnClick(R.id.login_button) public void onLoginButtonClicked() { String username = usernameField.content(); String password = passwordField.content(); loginAction.auth(username, password).subscribe({ showHomeScreen() }, { showErrorMessage() }); } @OnClick(R.id.login_facebook_button) public void onLoginFacebbokButtonClicked() { facebookAction.auth().subscribe({ showHomeScreen() }, { showErrorMessage() }); } }
10. Pruebas
11. Testing UI ▪ Given/When/Then ▪ Espresso - Flebox layout by Google ▪ Chequeo de Intents ▪ Chequeo de información ▪ Navegacion correcta ▪ Screenshots ▪ Inversión de dependencias - Fabio Collini / Adrian Catalan
12. @RunWith(AndroidJUnit4.class) @MediumTest public class MainActivityTest { @Rule public ActivityTestRule<MainActivity> mActivityRule = new ActivityTestRule<>(MainActivity.class); @Test @FlakyTest public void testAddFlexItem() { MainActivity activity = mActivityRule.getActivity(); FlexboxLayout flexboxLayout = (FlexboxLayout) activity.findViewById(R.id.flexbox_layout); assertNotNull(flexboxLayout); int beforeCount = flexboxLayout.getChildCount(); onView(withId(R.id.add_fab)).perform(click()); assertThat(flexboxLayout.getChildCount(), is(beforeCount + 1)); } }
13. @RunWith(AndroidJUnit4.class) @MediumTest public class MainActivityTest { @Rule public ActivityTestRule<MainActivity> mActivityRule = new ActivityTestRule<>(MainActivity.class); @Test @FlakyTest public void testAddFlexItem() { MainActivity activity = mActivityRule.getActivity(); FlexboxLayout flexboxLayout = (FlexboxLayout) activity.findViewById(R.id.flexbox_layout); assertNotNull(flexboxLayout); int beforeCount = flexboxLayout.getChildCount(); onView(withId(R.id.add_fab)).perform(click()); assertThat(flexboxLayout.getChildCount(), is(beforeCount + 1)); } }
14. @RunWith(AndroidJUnit4.class) @MediumTest public class MainActivityTest { @Rule public ActivityTestRule<MainActivity> mActivityRule = new ActivityTestRule<>(MainActivity.class); @Test @FlakyTest public void testAddFlexItem() { MainActivity activity = mActivityRule.getActivity(); FlexboxLayout flexboxLayout = (FlexboxLayout) activity.findViewById(R.id.flexbox_layout); assertNotNull(flexboxLayout); int beforeCount = flexboxLayout.getChildCount(); onView(withId(R.id.add_fab)).perform(click()); assertThat(flexboxLayout.getChildCount(), is(beforeCount + 1)); } }
15. @RunWith(AndroidJUnit4.class) @MediumTest public class MainActivityTest { @Rule public ActivityTestRule<MainActivity> mActivityRule = new ActivityTestRule<>(MainActivity.class); @Test @FlakyTest public void testAddFlexItem() { MainActivity activity = mActivityRule.getActivity(); FlexboxLayout flexboxLayout = (FlexboxLayout) activity.findViewById(R.id.flexbox_layout); assertNotNull(flexboxLayout); int beforeCount = flexboxLayout.getChildCount(); onView(withId(R.id.add_fab)).perform(click()); assertThat(flexboxLayout.getChildCount(), is(beforeCount + 1)); } }
16. NOMBRES
17. @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); EditText et = (EditText) findViewById(R.id.editText); EditText et2 = (EditText) findViewById(R.id.editText2); Button bt = (Button) findViewById(R.id.button); Button bt2 = (Button) findViewById(R.id.button2); }
18. @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); EditText et = (EditText) findViewById(R.id.editText); EditText et2 = (EditText) findViewById(R.id.editText2); Button bt = (Button) findViewById(R.id.button); Button bt2 = (Button) findViewById(R.id.button2); }
19. @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.login_activity); EditText usernameField = (EditText) findViewById(R.id.login_username); EditText passwordField = (EditText) findViewById(R.id.login_password); Button loginButton = (Button) findViewById(R.id.login_button); Button facebookButton = (Button) findViewById(R.id.login_facebook_button); }
20. Convenciones ▪ Views vs variables (usernameView vs username as String) ▪ Field, View, Button, Pager, List, Grid, etc. ▪ usernameEditText o usernameTextInputLayout? ▪ Ids con namespaces (login_username, login_button, login_something, etc) Dime tu intención y donde estás actuando...
21. API
22. Eventos ▪ Click ▪ TextWatchers ▪ RxBindings
23. @Override protected void onCreate(Bundle savedInstanceState) { ... usernameField.addTextChangedListener(new TextWatcher() { @Override public void beforeTextChanged(CharSequence s, int start, int count, int after){ username = s.toString(); check(); } ... }); passwordField.addTextChangedListener(new TextWatcher() { @Override public void beforeTextChanged(CharSequence s, int start, int count, int after){ password = s.toString(); check(); } ... }); } private void check() { if(!TextUtils.isEmpty(username) && !TextUtils.isEmpty(password)) loginButton.setEnabled(true); }
24. @Override protected void onCreate(Bundle savedInstanceState) { ... usernameField.onChanged(username -> check(username, passwordField.content())); passwordField.onChanged(password -> check(usernameField.content(), password)); } private void check(String username, String password) { if (!TextUtils.isEmpty(username) && !TextUtils.isEmpty(password)) loginButton.setEnabled(true); }
25. “ Las arquitecturas te ayudan a separar tu lógica de negocio de la presentación, pero, ¿Qué pasa con todo el código de la UI?
26. XML
27. <Button android:id="@+id/login_button" android:text="@string/login_button" android:layout_width="0dp" android:layout_height="wrap_content" style="@style/AppTheme.Login.Button" />
28. 1. Un archivo de recursos por pantalla
29. <resources> <string name="login_username_field">...</string> <string name="login_password_field">...</string> <dimen name="login_title_margin_top">...</dimen> <style name="AppTheme.Login"/> <style name="AppTheme.Login.Field">...</style> <style name="AppTheme.Login.Button" parent="AppTheme.Common.Button">...</style> <style name="AppTheme.Login.Message">...</style> <style name="AppTheme.Login.Title">...</style> </resources>
30. 2. Consistencia de Strings & Ids
31. <Button android:id="@+id/login_button" android:text="@string/login_button" android:layout_width="0dp" android:layout_height="wrap_content" style="@style/AppTheme.Login.Button" />
32. 3. Name spaces
33. <resources> <string name="login_username_field">...</string> <string name="login_password_field">...</string> <dimen name="login_title_margin_top">...</dimen> <style name="AppTheme.Login"/> <style name="AppTheme.Login.Field">...</style> <style name="AppTheme.Login.Button">...</style> <style name="AppTheme.Login.Message">...</style> <style name="AppTheme.Login.Title">...</style> </resources>
34. 4. Custom views
35. public class TextField extends android.support.v7.widget.AppCompatEditText { interface Before { void changed(String s); } interface On { void changed(String s); } interface After { void changed(String s); } private Before before; private On on; private After after; }
36. public class TextField extends android.support.v7.widget.AppCompatEditText { public TextField(Context context, AttributeSet attrs) { super(context, attrs); addTextChangedListener(new TextWatcher() { @Override public void beforeTextChanged(CharSequence s, int start, int count, int after) { if (before != null) before.changed(content()); } @Override public void onTextChanged(CharSequence s, int start, int before, int count) { if (on != null) on.changed(content()); } @Override public void afterTextChanged(Editable s) { if (after != null) after.changed(content()); } }); } }
37. public class TextField extends android.support.v7.widget.AppCompatEditText { public String content() { return getText().toString(); } }
38. Events ▪ RxBinding subscibe/unsubscribe ▪ Custom events ayudan a limpiar tu codigo, liberan la dependencia directa a los cambios de API.
39. Gracias! ! Preguntas? twitter @iyubinest cristianfgr@gmai.com github.com/iyubinest
