マネーフォワード クラウドの 基盤プロダクトにおける設計・実装ガイドラインで ID生成機にULIDを推している理由 / Why we recommend ULID in the design and implementation of core products
Presentation Slide for Money Forward Tech Day 2024.
https://techday.moneyforward-dev.jp/2024/
LT: https://techday.moneyforward-dev.jp/2024/sessions/lt-05/
ogawa
September 26, 2024
Transcript
26 slides
-
マネーフォワード クラウドの 基盤プロダクトにおける設計・実装ガイドラインで ID生成機にULIDを推している理由 Why we recommend ULID in the
design and implementation of core products -
• Carrer ◦ 2007: SIer ◦ 2011: SIer(Due to a
merger) ◦ 2017: toG SaaS ◦ 2022.05 -: Money Forward • Workflow Domain Tech Lead • X: @kroyeeg 小川 昌吾 Ogawa Shogo / Ogawan -
ULID = Universally Unique Lexicographically Sortable Identifier • グローバルに一意 •
辞書順にソート可能 • 識別子 ULIDとは What is ULID • Universally Unique • Lexicographically Sortable • Identifier -
仕様の抜粋 • 128ビットデータ • 1msecごとに1.21e+24個のユニーク なキーを持てる • 辞書順ソート可能 • 26文字
• 使用する文字はCrockford base32 ULIDとは What is ULID Excerpt from the specifications • 128-bit data • Capable of having 1.21e+24 unique keys every 1 millisecond • Lexicographically sortable • 26 characters long • Uses Crockford's base32 alphabet -
ULIDとは What is ULID データフォーマット • タイムスタンプとランダムパートで構成 する • 文字列はすべて大文字
(Crockford base32で規定) Data format • Composed of a timestamp and a random part • All characters are uppercase (as specified by Crockford's base32) -
One day, a network failure occurred in the database of
a certain product. We switched the writer instance to recover, but it was not the ideal method. As a result, after the network was restored, the database became double-active, causing a secondary failure. ある日、あるプロダクトのDBでNW障害 が発生 ライターインスタンスを切り替えて復旧し たがやり方がよくなかった この結果、NW復旧後にDBがダブルア クティブになってしまい、2次障害を起こ してしまった。 -
ダブルアクティブになったことで、どちら のDBへアクセスするかがランダムな状 態になった。 さらに、RDBのオートインクリメントIDを 使ってID採番を行っていたため、本来 起こるはずがない「異なる事業者で同一 IDのデータ」ができてしまった。 Due to the
double-active state, the application started accessing both DB instances randomly. Furthermore, because we were using auto-increment IDs in the RDB, we ended up creating data in each instance for different merchants having the same ID, which should never have happened. Table name: users DB instance-A DB instance-B -
こういった経緯からオートインクリメントIDの使用をや めるということになりました Due to these circumstances, we decided to stop
using auto-increment IDs. -
オートインクリメントIDからの乗り換え先候補 Candidates for switching from auto-increment IDs • Snowflake •
ULID • UUID ver4 and others • Snowflake • ULID • UUID ver4 その他 -
ULIDにした理由 The reasons for choosing ULID • The probability of
generating trillions of IDs at the same time without any sign of overlap • The specification is lightweight and clear • Unlikely to have updates to the specification • Timestamp-based IDs are compatible with RDB • IDs can be generated on the application layer • 同一時刻に数兆個のIDを生成してぶ つかる気配のない確率 • 仕様が軽量で明確 • 仕様の更新がなさそう • タイムスタンプベースのIDのため、 RDBと相性が良い • アプリケーションでIDを払い出せる -
ULIDを採用すると決めたら、 あとは実装あるのみ Once the decision is made to adopt ULID,
the only task is to work hard on its implementation -
ライブラリに求めたこと ちなみに、Kotlinです • ULIDを型レベルで生成できる • Maven Centralに上がっている • ランダムパートの仕様を満たしている
ライブラリ選定 Select a library Requirements for the library (p.s. we use Kotlin): • Capable of generating ULID at the type level • Uploaded on Maven Central • Meets the specifications for the random part -
候補 (載せ替え当時) • JonasSchubert/kULID • Aallam/ulid-kotlin • kobil-systems/ulid-kt ULIDのライブラリは更新の必要がほぼな いので、大体最終コミットが5年前とかです
ライブラリ選定 Select a library Candidates (At that time) • JonasSchubert/kULID • Aallam/ulid-kotlin • kobil-systems/ulid-kt ULID libraries generally do not require updates, so the last commit is usually about five years ago -
候補 (載せ替え当時) • JonasSchubert/kULID • Aallam/ulid-kotlin • kobil-systems/ulid-kt ライブラリ選定 Select
a library 上2つが痒いところに手が届かず、 一番下のは機能的には理想だったけど、 Maven Centralに上がってなかった。。。 Candidates (At that time) • JonasSchubert/kULID • Aallam/ulid-kotlin • kobil-systems/ulid-kt The top two options didn't quite meet the needs, and while the bottom one was functionally ideal, it wasn't available on Maven Central... -
結局自作しました • ULIDを型レベルで生成できる • Maven Centralに上がっている • ランダムパートの仕様を満たしている
ライブラリ選定 Select a library I ended up creating it myself. • Capable of generating ULID at the type level • Uploaded on Maven Central • Meets the specifications for the random part -
• 当時のテストデータがランダムデータに対して アサーションしてないので、 ULIDを1つずつ割 り当てる地獄(まだ一部残っている) • ID系のメンバー変数をULID型に置き換えな いといけない(単に置き換えるのがめんどい)
• At the time, the test data did not assert against random data, so there was the tedious task of assigning ULIDs one by one (some of which still remain) • Member variables related to IDs had to be replaced with ULID types (simply replacing them was tedious) ULIDへの移行で大変だったこと Problems faced during the transition to ULID -
• 当時のテストデータがランダムデータに対して アサーションしてないので、 ULIDを1つずつ割 り当てる地獄(まだ一部残っている) • ID系のメンバー変数をULID型に置き換えな いといけない(単に置き換えるのがめんどい)
• At the time, the test data did not assert against random data, so there was the tedious task of assigning ULIDs one by one (some of which still remain) • Member variables related to IDs had to be replaced with ULID types (simply replacing them was tedious) ULIDへの移行で大変だったこと Problems faced during the transition to ULID • テストデータはランダムで生成して具体的な値 を自分たちでは一切書かないでテストしてれ ば楽だった。 • 例えLongでもID抽象型を付けておけば良 かった • It would have been easier if the test data was generated randomly and we tested without writing specific values ourselves. • For example, even with Long, it would have been better to have an abstract ID type in place. -
• IDをDBに依存しない形に実装すれ ば、不用意に異なるデータと紐づくこと はなくなる • ULIDは単方向増加でRDBとの相性が よい • アプリでID生成をすることで、バックエ
ンドの処理性能が上がる • 移行はめんどいので、最初から使うと 良いよ(心の声) まとめ Conclusion • If the ID is made independent of the database, it will no longer inadvertently be associated with different data. • ULID is monotonically increasing, which makes them well-suited for compatibility with RDB. • Generating IDs in the app improved backend processing performance. • Migration is a hassle, so it's better to use it from the start (from the bottom of my heart).
