Organizing Metrics: Hierarchical or Tagged?

Talk given at the London DevOps Exchange about how to organize hundreds of thousands of metric time series.

Transcript

1. Organizing Metrics:
   Hierarchical or Tagged?
   Paul Dix
   CEO of InfluxDB
   paul@influxdb.com
   @pauldix


   View Slide

2. Organizing Metrics?


   View Slide

3. Necessary when you
   have thousands, tens,
   hundreds, or millions


   View Slide

4. Discovery
   What metrics do I have?


   View Slide

5. Merging and
   Aggregating
   Combine these and give me a result


   View Slide

6. View Slide

7. Hierarchy


   View Slide

8. Artifact of Whisper’s
   implementation


   View Slide

9. Series are round robin
   files on disk organized in
   directories (hierarchy)


   View Slide

10. Meta data encoded in
    series name


    View Slide

11. View Slide

12. Tagged?


    View Slide

13. OpenTSDB Metrics
    mysql.bytes_received \
    !
    1287333217 327810227706 \
    !
    schema=foo host=db1


    View Slide

14. mysql.bytes_received \
    !
    1287333217 327810227706 \
    !
    schema=foo host=db1
    Name


    View Slide

15. mysql.bytes_received \
    !
    1287333217 327810227706 \
    !
    schema=foo host=db1
    Tags


    View Slide

16. Single Level Hierarchy
    + Tags


    View Slide

17. Hierarchy: names


    View Slide

18. Tags


    View Slide

19. Meta data encoded in
    series name and tags


    View Slide

20. View Slide

21. Data
    [
    {
    "name": "cpu",
    "columns": ["time", "value", "host"],
    "points": [
    [1395168540, 56.7, "foo.influxdb.com"],
    [1395168540, 43.9, "bar.influxdb.com"]
    ]
    }
    ]


    View Slide

22. Flat


    View Slide

23. list series


    View Slide

24. list series /.*dc\.USWest/


    View Slide

25. select percentile(90, value)
    from merge(/cpu_wait.*dc\.USWest.*/)
    group by time(10m)
    where time > now() - 4h


    View Slide

26. Doesn’t scale well to
    millions of series!


    View Slide

27. select percentile(90, value)
    from cpu_wait
    group by time(10m)
    where time > now() - 4h and
    dataCenter = ‘USWest’


    View Slide

28. Doesn’t scale well to
    thousands of hosts!


    View Slide

29. We have to pick a
    method


    View Slide

30. Hierarchy vs. Tags?


    View Slide

31. Religious Debate?


    View Slide

32. Emacs vs. Vim


    View Slide

33. i.e. debates that can’t
    be solved


    View Slide

34. Scientific Debate?


    View Slide

35. acceleration due to
    gravity


    View Slide

36. Things that have a
    clear testable answer


    View Slide

37. Hierarchy vs. Tags a
    bit of both?


    View Slide

38. Tags are vastly
    superior to hierarchies


    View Slide

39. What questions can
    you ask?


    View Slide

40. What sensors do I
    have?
    CPU Idle, network in bytes, memory used, redis key
    count, etc.


    View Slide

41. OpenTSDB
    names


    View Slide

42. cpu_wait
    network_in_bytes
    network_out_bytes
    …


    View Slide

43. Graphite
    traverse hierarchy


    View Slide

44. app.foo.dc.uswest.host.servera.cpu_wait
    app.foo.dc.uswest.host.servera.network_in_bytes
    app.foo.dc.uswest.host.servera.network_out_bytes
    …


    View Slide

45. app.foo.dc.uswest.host.servera.cpu_wait
    app.foo.dc.uswest.host.servera.network_in_bytes
    app.foo.dc.uswest.host.servera.network_out_bytes
    …
    Sensor at the end


    View Slide

46. What values do I have
    on dimension X?
    hosts, data centers, services, applications


    View Slide

47. OpenTSDB
    traverse one level and tags


    View Slide

48. redis_connections
    response_times.90
    …


    View Slide

49. app.foo.dc.uswest.host.servera.cpu_wait
    app.foo.dc.uswest.host.servera.network_in_bytes
    app.foo.dc.uswest.host.servera.network_out_bytes
    …


    View Slide

50. Show me all time
    series for X
    dashboard for MySQL, dashboard for host


    View Slide

51. Computations
    percentiles across sets of hosts, data centers, services


    View Slide

52. Pure tagging


    View Slide

53. {!
    "Name": "CPU Wait",!
    "Host": "serverA.influxdb.com",!
    "Data Center": "US West"!
    }!


    View Slide

54. {!
    "Name": "CPU Wait",!
    "Host": "serverA.influxdb.com",!
    "Data Center": "US West"!
    }!
    Readable Names!


    View Slide

55. {!
    "Name": “Redis Connections",!
    "Host": "serverA.influxdb.com",!
    "Data Center": "US West"!
    }!
    Queryable!
    Which hosts have redis connections?


    View Slide

56. {!
    "Name": "Erorrs",!
    "Host": "serverA.influxdb.com",!
    "Data Center": "US West",!
    "Application": "My super rad app"!
    }!
    Queryable!
    What names (sensors) do I have for My super rad app?


    View Slide

57. Queryable!
    What names (sensors) do I have at 1h precision?
    {!
    "Name": "Erorrs",!
    "Host": "serverA.influxdb.com",!
    "Data Center": "US West",!
    "Application": "My super rad app",!
    "Precision": "1h"!
    }!


    View Slide

58. Computation
    select percentile(90)!
    from ("Name": "CPU Wait", "Data Center": "US West")!
    group by time(10m)!
    where time > now() - 6h!


    View Slide

59. Hierarchy on the fly
    What tags co-occur with a given tag?


    View Slide

60. Faceted Serch


    View Slide

61. Given “Host” and “Data
    Center” what other tags
    are there?


    View Slide

62. "Data Center" = "US West"
    !
    "Name": 2153
    "Host": 256
    "Service": 20
    "Precision": 10
    "Application": 4


    View Slide

63. Need to be able to
    add dimensions/tags


    View Slide

64. Need to support a
    large number of tags
    Both for a single data point and over all


    View Slide

65. Pure tagging gives you
    much more power than
    hierarchies


    View Slide

66. Can be combinatorial
    OpenTSDB hot spots, etc


    View Slide

67. Need to be able to define
    indexing behavior for
    tags


    View Slide

68. Can it work?


    View Slide

69. This is part of what
    InfluxDB is working on
    Feedback welcome!
    http://influxdb.com/community.html
    @InfluxDB


    View Slide
