  1. Time series & monitoring with InfluxDB & the TICK stack

    Paul Dix paul@influxdb.com @pauldix
  2. Modern engine for metrics & events (time series data)

  3. What is time series data?

  4. Stock trades and quotes

  5. Metrics

  6. Analytics

  7. Events

  8. Sensor data

  9. Two kinds of time series data…

  10. Regular time series t0 t1 t2 t3 t4 t6 t7

    Samples at regular intervals
  11. Irregular time series t0 t1 t2 t3 t4 t6 t7

    Events whenever they come in
  12. Working with Time Series collect, store, visualize, process

  13. Products Built on the Open-Source “TICK stack”

  14. Store: • OSS - MIT License • Written in Go

    • SQL-ish query language • Time Series Merge Tree storage engine & inverted index • Retention Policies • Continuous Queries
  15. API - 2 endpoints

  16. API - 2 endpoints /write?db=mydb&rp=foo Write: HTTP POST

  17. API - 2 endpoints /write?db=mydb&rp=foo /query?db=mydb&rp=foo Write: HTTP POST Read:

    HTTP GET
  18. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 network,direction=in,host=server01,region=us-west value=23422.0

    1422568543702900257 BODY:
  19. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 network,direction=in,host=server01,region=us-west value=23422.0

    1422568543702900257 BODY: Line Protocol
  20. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 network,direction=in,host=server01,region=us-west value=23422.0

    1422568543702900257 BODY: Measurement name
  21. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 network,direction=in,host=server01,region=us-west value=23422.0

    1422568543702900257 BODY: Tags (should be sorted by key, value)
  22. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 network,direction=in,host=server01,region=us-west value=23422.0

    1422568543702900257 BODY: Tags (values are always strings)
  23. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 network,direction=in,host=server01,region=us-west value=23422.0

    1422568543702900257 BODY: Fields
  24. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 some_measurement value=23422.0,context=“asdf

    jkl” 1422568543702900257 BODY: Unlimited Fields
  25. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 some_measurement value=23422

    1422568543702900257 BODY: Fields (types: int64, float64, string, bool)
  26. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 network,direction=in,host=server01,region=us-west value=0.0

    1422568543702900257 BODY: Fields (floats must have decimal)
  27. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 network,direction=in,host=server01,region=us-west value=0.0

    1422568543702900257 BODY: Fields (types must remain consistent)
  28. Writing Data /write?db=mydb&rp=foo cpu_load,host=server01,region=us-west value=0.64 cpu_load,host=server02,region=us-west value=0.55 1422568543702900257 network,direction=in,host=server01,region=us-west value=0.0

    1422568543702900257 BODY: Timestamp (nanosecond epoch)
  29. Influx CLI

  30. Create a database CREATE DATABASE foo

  31. Create a retention policy CREATE RETENTION POLICY <rp-name> ON <db-name>

    DURATION <duration> REPLICATION <n> [DEFAULT]
  32. Create a retention policy CREATE RETENTION POLICY <rp-name> ON <db-name>

    DURATION <duration> REPLICATION <n> [DEFAULT] CREATE RETENTION POLICY high_precision ON mydb DURATION 7d REPLICATION 3 DEFAULT
  33. Create a retention policy CREATE RETENTION POLICY <rp-name> ON <db-name>

    DURATION <duration> REPLICATION <n> [DEFAULT] CREATE RETENTION POLICY high_precision ON mydb DURATION 7d REPLICATION 3 DEFAULT Writes will go into this RP unless otherwise specified
  34. Discovery

  35. Inverted index of measurements and tags

  36. Discovery SHOW MEASUREMENTs

  37. Discovery SHOW MEASUREMENTs SHOW MEASUREMENTS where host = 'serverA'

  38. Discovery SHOW MEASUREMENTs SHOW MEASUREMENTS where host = 'serverA' SHOW

    TAG KEYS
  39. Discovery SHOW MEASUREMENTs SHOW MEASUREMENTS where host = 'serverA' SHOW

    TAG KEYS SHOW TAG KEYS from CPU
  40. Discovery SHOW MEASUREMENTs SHOW MEASUREMENTS where host = 'serverA' SHOW

    TAG KEYS SHOW TAG KEYS from CPU SHOW TAG VALUES from CPU WITH KEY = 'region'
  41. Discovery SHOW MEASUREMENTs SHOW MEASUREMENTS where host = 'serverA' SHOW

    TAG KEYS SHOW TAG KEYS from CPU SHOW TAG VALUES from CPU WITH KEY = 'region' SHOW SERIES
  42. Discovery SHOW MEASUREMENTs SHOW MEASUREMENTS where host = 'serverA' SHOW

    TAG KEYS SHOW TAG KEYS from CPU SHOW TAG VALUES from CPU WITH KEY = 'region' SHOW SERIES SHOW SERIES where service = 'redis'
  43. Queries

  44. SQL-ish select * from some_series where time > now() -

    1h
  45. Aggregates select percentile(90, value) from cpu where time > now()

    - 1d group by time(10m)
  46. Aggregates select percentile(90, value) from cpu where time > now()

    - 1d group by time(10m), region Group by a tag
  47. Where against Regex (field) select value from some_log_series where value

    =~ /.*ERROR.*/ and time > "2014-03-01" and time < "2014-03-03"
  48. Where against Regex (tag) select value from some_log_series where host

    =~ /.*asdf.*/ and time > "2014-03-01" and time < “2014-03-03" group by host
  49. Functions min max percentile first last stddev mean count sum

    median distinct count(distinct) difference moving_average
  50. Continuous queries CREATE CONTINUOUS QUERY "10m_event_count" ON mydb BEGIN SELECT

    count(value) INTO "6_months".events FROM events GROUP BY time(10m) END;
  51. Collect: • OSS - MIT License • Written in Go

    • Agent deployed across infrastructure • Input plugins - system, docker, postgres, mysql, cassandra, elastic, hadoop, redis, nginx, apache, etc. • Output plugins - InfluxDB, Graphite, Kafka, etc.
  52. Visualize: • OSS - AGPL License • Written in Go,

    React, dygraph • UI for administering TICK stack • Ad-hoc exploration and visualization • Create monitoring and alerting rules in Kapacitor • Query builder, TICK script editor, and more
  53. None
  54. None
  55. None
  56. None
  57. Process: • OSS - MIT License • Written in Go

    • Process, monitor, alert, act/execute • TICK script • Streaming & Batch • Store data back into InfluxDB • User Defined Functions • Service Discovery & Pull
  58. Thank you. Paul Dix paul@influxdb.com @pauldix
