Multi-armed Bandit Optimisation in Clojure

Multi-armed Bandit strategies provide efficient and intuitive models that are often more easily applied to product optimisation than traditional methods.

Through building a sample application, Notflix, we use the Thompson Sampling algorithm to rank videos and select thumbnails to optimise click-throughs.

Transcript

1. Multi-armed Bandit
   Optimisation in Clojure
   @pingles
   Paul Ingles,
   Principal Engineer, uSwitch.com


   View Slide

2. Product optimisation
   cycles are long,
   complex and
   inefficient.


   View Slide

3. View Slide

4. Source: http://danariely.com/the-books/excerpted-from-chapter-1-–-the-truth-about-relativity-2/


   View Slide

5. Source: http://danariely.com/the-books/excerpted-from-chapter-1-–-the-truth-about-relativity-2/


   View Slide

6. View Slide

7. Experiment
   1
   Time
   Experiment
   2
   Experiment
   3
   …


   View Slide

8. Experiment
   1
   Time
   Experiment
   2
   Experiment
   3
   …
   Participants Needed
   Effect


   View Slide

9. Bandit strategies
   can help


   View Slide

10. A product

    for procrastinators

    by a procrastinator


    View Slide

11. View Slide

12. http://notflix.herokuapp.com/


    View Slide

13. Source: Action Movie Kid, https://www.youtube.com/watch?v=SU-ZM3xoYag


    View Slide

14. Source: Action Movie Kid, https://www.youtube.com/watch?v=SU-ZM3xoYag


    View Slide

15. http://notflix.herokuapp.com/


    View Slide

16. The Multi-armed
    Bandit Problem


    View Slide

17. View Slide

18. Exploitation
    Exploration


    View Slide

19. Exploitation
    Exploration
    Source: printablecolouringpages.co.uk


    View Slide

20. Exploitation
    Exploration
    Source: printablecolouringpages.co.uk


    View Slide

21. Exploitation
    Exploration
    Source: printablecolouringpages.co.uk


    View Slide

22. Bandit Model


    View Slide

23. Bandit Model
    Arms: {1, 2, …, K}


    View Slide

24. Bandit Model
    Trials: 1, 2, … T
    Arms: {1, 2, …, K}


    View Slide

25. Bandit Model
    Rewards: {0, 1}
    Trials: 1, 2, … T
    Arms: {1, 2, …, K}


    View Slide

26. K-arms
    K-buttons
    SUBMIT
    SUPPORT HAITI
    Source: A/B Testing, Siroker
    and Koomen, 2013
    K-pages
    Source: A/B Testing, Siroker
    and Koomen, 2013
    “Pierce and Wilfork
    show off their Boston
    accents”
    “Pierce, Wilfork show
    off their bad Boston
    accents”
    Source: http://
    knightlab.northwestern.edu/
    2013/08/15/designing-from-data-how-
    news-organizations-use-ab-testing-to-
    increase-user-engagement/
    K-headlines


    View Slide

27. Bandit Strategy


    View Slide

28. Bandit Strategy
    (defn select-arm [arms]
    …)
    Arm selection


    View Slide

29. Bandit Strategy
    (defn select-arm [arms]
    …)
    Arm selection
    (defn reward [arm x]
    …)
    (defn pulled [arm]
    …)
    Updating arm
    state with
    feedback
    }


    View Slide

30. Bandit Strategy
    (defrecord Arm [name pulls value])
    (defn select-arm [arms]
    …)
    Arm selection
    (defn reward [arm x]
    …)
    (defn pulled [arm]
    …)
    Updating arm
    state with
    feedback
    }


    View Slide

31. Clojure Bandit Algorithms


    View Slide

32. Clojure Bandit Algorithms
    • Epsilon-Greedy


    View Slide

33. Clojure Bandit Algorithms
    • Epsilon-Greedy
    • Thompson Sampling


    View Slide

34. ε-greedy


    View Slide

35. ε-greedy
    ε = epsilon = rate of exploration


    View Slide

36. ε-greedy
    Source: “Bandit Algorithms for Website Optimization”, John Myles White, O’Reilly, 2012
    Explore
    10%
    Exploit
    90%
    Arm k
    Arm 1
    Arm 2
    Arm K
    …
    epsilon = 0.1
    (rate of exploration)


    View Slide

37. (defrecord Arm [name pulls value])


    View Slide

38. (defrecord Arm [name pulls value])
    (defn select-arm [epsilon arms]
    (if (> (rand) epsilon)
    (exploit :value arms)
    (rand-nth arms)))


    View Slide

39. (defrecord Arm [name pulls value])
    (defn select-arm [epsilon arms]
    (if (> (rand) epsilon)
    (exploit :value arms)
    (rand-nth arms)))


    (defn exploit [k arms]
    (first (sort-by k > arms)))


    View Slide

40. (defrecord Arm [name pulls value])
    (defn select-arm [epsilon arms]
    (if (> (rand) epsilon)
    (exploit :value arms)
    (rand-nth arms)))
    user=> (def arms [(Arm. :arm1 2 0)
    (Arm. :arm2 2 1)])
    user=> (select-arm 1.0 arms)
    #user.Arm{:name :arm1, :pulls 2, :value 0}
    user=> (select-arm 0.0 arms)
    #user.Arm{:name :arm2, :pulls 2, :value 1}


    (defn exploit [k arms]
    (first (sort-by k > arms)))


    View Slide

41. user=> (def arms [(Arm. :arm1 0 0)
    (Arm. :arm2 0 0)])
    user=> (def selected-arm (select-arm 0.1 arms))
    #user.Arm{:name :arm1, :pulls 0, :value 0}
    user=> (-> selected-arm
    (pulled)
    ;; time passes
    (reward 1))
    #user.Arm{:name :arm1, :pulls 1, :value 1}


    View Slide

42. user=> (def arms [(Arm. :arm1 0 0)
    (Arm. :arm2 0 0)])
    user=> (def selected-arm (select-arm 0.1 arms))
    #user.Arm{:name :arm1, :pulls 0, :value 0}
    user=> (-> selected-arm
    (pulled)
    ;; time passes
    (reward 1))
    #user.Arm{:name :arm1, :pulls 1, :value 1}
    Increment pulls
    counter
    Increment value
    counter


    View Slide

43. ε-greedy Behaviour


    View Slide

44. ε-greedy Behaviour
    (bernoulli-bandit {:arm1 0.1
    :arm2 0.1
    :arm3 0.1
    :arm4 0.1
    :arm5 0.9}


    View Slide

45. ε-greedy Behaviour
    0.00
    0.25
    0.50
    0.75
    1.00
    0 100 200 300 400 500
    Time
    Pr(selected = optimal−arm)
    algo
    epsilon.greedy 0.2
    epsilon.greedy−0.1
    Epsilon = 0.1
    Epsilon = 0.2


    View Slide

46. Thompson
    Sampling
    aka Bayesian Bandit


    View Slide

47. Arm k’s hidden true probability
    of reward
    θk
    [0,1]
    Arm Model


    View Slide

48. Arm Model
    0.50
    0.75
    1.00
    1.25
    1.50
    0.00 0.25 0.50 0.75 1.00
    θk
    pulls = 0
    rewards = 0


    View Slide

49. 0.0
    0.5
    1.0
    1.5
    2.0
    0.00 0.25 0.50 0.75 1.00
    Arm Model
    pulls = 1
    rewards = 0
    θk


    View Slide

50. 0
    1
    2
    0.00 0.25 0.50 0.75 1.00
    Arm Model
    pulls = 10
    rewards = 4
    θk


    View Slide

51. 0
    5
    10
    15
    20
    25
    0.00 0.25 0.50 0.75 1.00
    Arm Model
    pulls = 1000
    rewards = 400
    θk


    View Slide

52. Thompson Sampling
    0
    2
    4
    6
    8
    0.00 0.25 0.50 0.75 1.00
    θk
    pulls = 100

    rewards = 40
    pulls = 10
    rewards = 6


    View Slide

53. Thompson Sampling
    0
    2
    4
    6
    8
    0.00 0.25 0.50 0.75 1.00
    θk
    pulls = 100

    rewards = 40
    pulls = 10
    rewards = 6
    0.41


    View Slide

54. Thompson Sampling
    0
    2
    4
    6
    8
    0.00 0.25 0.50 0.75 1.00
    θk
    pulls = 100

    rewards = 40
    pulls = 10
    rewards = 6
    0.41 0.57


    View Slide

55. Thompson Sampling
    (use 'incanter.distributions)
    (defn estimate-value
    [{:keys [pulls value] :as arm}]
    (let [prior 1.0
    alpha (+ prior value)
    beta (+ prior (- pulls value))]
    (assoc arm
    :theta (draw (beta-distribution alpha beta)))))
    (defn select-arm [arms]
    (exploit :theta (map estimate-value arms)))


    View Slide

56. Thompson Sampling
    (use 'incanter.distributions)
    (defn estimate-value
    [{:keys [pulls value] :as arm}]
    (let [prior 1.0
    alpha (+ prior value)
    beta (+ prior (- pulls value))]
    (assoc arm
    :theta (draw (beta-distribution alpha beta)))))
    (defn select-arm [arms]
    (exploit :theta (map estimate-value arms)))
    user=> (select-arm [(Arm. :blue 10 6) (Arm. :red 100 40)])
    #user.Arm{:name :blue, :pulls 10, :value 6, :theta 0.4978…}


    View Slide

57. Thompson Sampling Behaviour
    (bernoulli-bandit {:arm1 0.1
    :arm2 0.1
    :arm3 0.1
    :arm4 0.1
    :arm5 0.9}


    View Slide

58. Strategy Accuracy
    0.00
    0.25
    0.50
    0.75
    1.00
    0 100 200 300 400 500
    Time
    Pr(selected = optimal−arm)
    algo
    epsilon.greedy 0.2
    epsilon.greedy−0.1
    thompson.sampling
    Epsilon = 0.1
    Epsilon = 0.2
    Thompson


    View Slide

59. Thompson Sampling
    • Smoothly balances explore/exploit
    tradeoff.
    • Optimal convergence: logarithmic
    regret
    • We can use it to Rank


    View Slide

60. Ranking with
    Thompson Sampling
    (defn rank [k arms]
    (sort-by k > arms))
    user=> (def arms [(Arm. :blue 10 6)
    (Arm. :red 100 40)])
    user=> (rank :theta (map estimate-value arms))
    (#user.Arm{:name :red, :pulls 100, :value 40, :theta 0.3979…}
    #user.Arm{:name :blue, :pulls 10, :value 6, :theta 0.2789…})


    View Slide

61. Ranking with
    Thompson Sampling
    (defn rank [k arms]
    (sort-by k > arms))
    user=> (def arms [(Arm. :blue 10 6)
    (Arm. :red 100 40)])
    user=> (rank :theta (map estimate-value arms))
    (#user.Arm{:name :red, :pulls 100, :value 40, :theta 0.3979…}
    #user.Arm{:name :blue, :pulls 10, :value 6, :theta 0.2789…})
    SWEEEEEEETTT


    View Slide

62. [bandit/bandit-core "0.2.1-SNAPSHOT"]
    https://github.com/pingles/bandit


    View Slide

63. View Slide

64. Ranking
    1.
    2.
    3.


    View Slide

65. Ranking
    1.
    2.
    3.
    Video Rank
    Bandit


    View Slide

66. Ranking
    1.
    2.
    3.
    Video Rank
    Bandit
    Rank Bandit
    Arms


    View Slide

67. Ranking
    1.
    2.
    3.
    Video Rank
    Bandit
    Rank Bandit
    Arms
    Thumbnail
    Bandit
    Thumbnail
    Bandit
    Thumbnail
    Bandit


    View Slide

68. Ranking
    1.
    2.
    3.
    Portal Video

    Thumbnail Bandit Arms
    Video Rank
    Bandit
    Rank Bandit
    Arms
    Thumbnail
    Bandit
    Thumbnail
    Bandit
    Thumbnail
    Bandit


    View Slide

69. Implementing Notflix: State
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

70. Implementing Notflix: State
    (def videos {"chilli" {:url “http://youtube.com/?v=1"}
    "portal" {:url “http://youtube.com/?v=2"}})
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

71. Implementing Notflix: State
    (def videos {"chilli" {:url “http://youtube.com/?v=1"}
    "portal" {:url “http://youtube.com/?v=2"}})
    (defn initialise-bandits []
    {:video-rank (bandit.arms/bandit "chilli" "portal" "coconut")
    "chilli" (bandit.arms/bandit "chilli1.png" "chilli2.png" …)
    "coconut" (bandit.arms/bandit "coconut1.png" "coconut2.png" …)
    "portal" (bandit.arms/bandit "portal1.png" "portal2.png" …)})
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

72. Implementing Notflix: State
    (def videos {"chilli" {:url “http://youtube.com/?v=1"}
    "portal" {:url “http://youtube.com/?v=2"}})
    (defn initialise-bandits []
    {:video-rank (bandit.arms/bandit "chilli" "portal" "coconut")
    "chilli" (bandit.arms/bandit "chilli1.png" "chilli2.png" …)
    "coconut" (bandit.arms/bandit "coconut1.png" "coconut2.png" …)
    "portal" (bandit.arms/bandit "portal1.png" "portal2.png" …)})
    (defn -main []
    (dosync
    (alter bandits merge (initialise-bandits))))
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

73. Implementing Notflix: Drawing Arms
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

74. (defn rank-arms [bandit-id]
    (->> (get @bandits bandit-id)
    (vals) ; #Arm{:name “video1” …}
    ; #Arm{:name “video2” …}
    (map bandit.algo.bayes/estimate-value)
    (bandit.arms/rank :theta)))
    Implementing Notflix: Drawing Arms
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

75. (defn rank-arms [bandit-id]
    (->> (get @bandits bandit-id)
    (vals) ; #Arm{:name “video1” …}
    ; #Arm{:name “video2” …}
    (map bandit.algo.bayes/estimate-value)
    (bandit.arms/rank :theta)))
    (defn select-arm [bandit-id]
    (first (rank-arms bandit-id)))
    Implementing Notflix: Drawing Arms
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

76. Implementing Notflix: Arm Feedback
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

77. (defn pulled-arm! [bandit-id arm-label]
    (alter bandits
    (update-in [bandit-id arm-label] bandit.arms/pulled)))
    Implementing Notflix: Arm Feedback
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

78. (defn pulled-arm! [bandit-id arm-label]
    (alter bandits
    (update-in [bandit-id arm-label] bandit.arms/pulled)))
    (defn pulled-all-arms! [bandit-id]
    (alter bandits
    update-in [bandit-id] (fmap bandit.arms/pulled)))
    Implementing Notflix: Arm Feedback
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

79. (defn pulled-arm! [bandit-id arm-label]
    (alter bandits
    (update-in [bandit-id arm-label] bandit.arms/pulled)))
    (defn pulled-all-arms! [bandit-id]
    (alter bandits
    update-in [bandit-id] (fmap bandit.arms/pulled)))
    (defn reward-arm! [bandit-id arm-label]
    (alter bandits
    update-in [bandit-id arm-label] #(bandit.algo.bayes/reward % 1)))
    Implementing Notflix: Arm Feedback
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

80. (defroutes notflix-routes
    (GET "/" []
    (dosync
    (let [ranked-labels (map :name (rank-arms :video-rank))]
    (pulled-all-arms! :video-rank)
    (videos-page-html ranked-labels))))
    (POST “/reward/:video-name/:thumb-name“ [video-name thumb-name]
    (dosync
    (reward-arm! video-name thumb-name)
    (reward-arm! :video-rank video-name)
    (redirect-after-post "/"))))
    Implementing Notflix: Web App
    (def videos {"chilli" {:url “http://youtube.com/?v=1"}
    "portal" {:url “http://youtube.com/?v=2"}})
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}


    View Slide

81. (defroutes notflix-routes
    (GET "/" []
    (dosync
    (let [ranked-labels (map :name (rank-arms :video-rank))]
    (pulled-all-arms! :video-rank)
    (videos-page-html ranked-labels))))
    (POST “/reward/:video-name/:thumb-name“ [video-name thumb-name]
    (dosync
    (reward-arm! video-name thumb-name)
    (reward-arm! :video-rank video-name)
    (redirect-after-post "/"))))
    Implementing Notflix: Web App
    (def videos {"chilli" {:url “http://youtube.com/?v=1"}
    "portal" {:url “http://youtube.com/?v=2"}})
    (def bandits (ref nil))
    ; {:video-rank {“chilli” #Arm{:pulls …
    ; “portal” #Arm{:pulls …
    ; “chilli” …}
    (defn videos-page-html [video-names]
    (for [video-name video-names]
    (html ...
    (dosync
    (let [video-url (:url (get videos video-name))
    thumb-name (:name (select-arm video-name))]
    (pulled-arm! video-name thumb-name)
    [:a {:href video-url} [:img {:src thumb-name}]])))))


    View Slide

82. Algorithm Performance: Video Ranking Bandit


    View Slide

83. 0
    2
    4
    6
    0.00 0.25 0.50 0.75 1.00
    Pr(click)
    pdf
    θk
    Algorithm Performance: Video Ranking Bandit


    View Slide

84. 0
    2
    4
    6
    0.00 0.25 0.50 0.75 1.00
    Pr(click)
    pdf
    θk
    Algorithm Performance: Video Ranking Bandit
    “hero of the coconut pain”


    View Slide

85. 0
    2
    4
    6
    0.00 0.25 0.50 0.75 1.00
    Pr(click)
    pdf
    θk
    Algorithm Performance: Video Ranking Bandit
    “1000 danes eat 1000 chillis”
    “hero of the coconut pain”


    View Slide

86. 0
    2
    4
    6
    0.00 0.25 0.50 0.75 1.00
    Pr(click)
    pdf
    θk
    Algorithm Performance: Video Ranking Bandit
    “3 year-old with a portal gun”
    “1000 danes eat 1000 chillis”
    “hero of the coconut pain”


    View Slide

87. Algorithm Performance: Portal Thumbnail Bandit


    View Slide

88. Algorithm Performance: Portal Thumbnail Bandit
    θk
    0
    1
    2
    3
    4
    0.00 0.25 0.50 0.75 1.00
    Pr(click)
    pdf


    View Slide

89. Algorithm Performance: Portal Thumbnail Bandit
    θk
    0
    1
    2
    3
    4
    0.00 0.25 0.50 0.75 1.00
    Pr(click)
    pdf


    View Slide

90. Algorithm Performance: Portal Thumbnail Bandit
    θk
    0
    1
    2
    3
    4
    0.00 0.25 0.50 0.75 1.00
    Pr(click)
    pdf


    View Slide

91. Algorithm Performance: Portal Thumbnail Bandit
    θk
    0
    1
    2
    3
    4
    0.00 0.25 0.50 0.75 1.00
    Pr(click)
    pdf


    View Slide

92. http://notflix.herokuapp.com/


    View Slide

93. =
    1.Ariely, D, 2010, “Predictably Irrational”, Harper Perennial
    2.Kahneman, D, 2011, “Thinking Fast and Slow”, Farrar, Straus and Giroux
    3.Myles White, J, 2012, “Bandit Algorithms for Website Optimization”, O’Reilly.
    4.Scott, S, 2010, “A modern Bayesian look at the multi-armed bandit”
    5.http://tdunning.blogspot.co.uk/2012/02/bayesian-bandits.html
    6.http://www.chrisstucchio.com/blog/2013/bayesian_bandit.html
    7.http://www.chrisstucchio.com/blog/2013/bayesian_analysis_conversion_rates.html
    8.Siroker and Koomen, 2013, “A/B Testing”, Wiley
    @pingles
    https://github.com/pingles/bandit


    View Slide
