Docker Cluster based on Raspberry Pi

$ wget http://downloads.hypriot.com/hypriot-rpi-20150416-201537.img.zip $ unzip hypriot-rpi-20150416-201537.img.zip # insert SD CARD $ diskutil list ... /dev/disk3 #: TYPE NAME SIZE IDENTIFIER 0: FDisk_partition_scheme *31.9 GB disk3 1: Windows_FAT_32 NO NAME 31.9 GB disk3s1 $ diskutil unmountdisk /dev/disk3 $ sudo dd if=hypriot-rpi-20150416-201537.img of=/dev/rdisk3 bs=1M 1220+1 records in 1220+1 records out 1280000000 bytes (1,3 GB) copied, 81,6065 s, 15,7 MB/s # 1,3 GB warten... 80 Sec $ diskutil unmountdisk /dev/disk3 # eject SD card, insert at your pi and boot your pi...

wget https://raw.githubusercontent.com/hypriot/flash/master/$(uname -s)/flas chmod +x flash sudo mv flash /usr/local/bin/flash brew install pv brew install awscli $ flash help ... --config|-c Copy this config file to /boot/occidentalis.txt --hostname|-n Set hostname for this SD image --ssid|-s Set WiFi SSID for this SD image --password|-p Set WiFI password for this SD image ... $ flash --hostname rpi-001 \ http://downloads.hypriot.com/hypriot-rpi-20150416-201537.img.zip

$ ssh root@rpi-001 > mkdir -f .ssh > chmod 700 .ssh > exit $ scp ${HOME}/.ssh/id_rsa.pub root@rpi-001:/root/.ssh/authorized_keys $ ssh root@rpi-001 > chmod 600 .ssh/authorized_keys

# update to current docker version $ wget http://downloads.hypriot.com/docker-hypriot_1.8.1-1_armhf.deb $ dpkg -i docker-hypriot_1.8.1-1_armhf.deb $ service docker restart $ docker version Client: Version: 1.8.1 API version: 1.20 Go version: go1.4.2 Git commit: d12ea79-dirty Built: Thu Aug 13 07:53:24 UTC 2015 OS/Arch: linux/arm Server: Version: 1.8.1 API version: 1.20 Go version: go1.4.2 Git commit: d12ea79-dirty Built: Thu Aug 13 07:53:24 UTC 2015 OS/Arch: linux/arm

$ docker info Containers: 2 Images: 84 Storage Driver: overlay Backing Filesystem: extfs Execution Driver: native-0.2 Logging Driver: json-file Kernel Version: 3.18.11-hypriotos-v7+ Operating System: Raspbian GNU/Linux 7 (wheezy) CPUs: 4 Total Memory: 925.1 MiB Name: black-pearl ID: V57A:JOG4:5GRL:WKXF:BL2H:ZCFS:MGIF:6M3V:XD2I:FS6M:TXGU:6HRF Labels: provider=hypriot

$ docker pull resin/rpi-raspbian:jessie $ docker run --rm -ti resin/rpi-raspbian > cat /etc/os-release PRETTY_NAME="Raspbian GNU/Linux 8 (jessie)" NAME="Raspbian GNU/Linux" VERSION_ID="8" VERSION="8 (jessie)" ID=raspbian ID_LIKE=debian HOME_URL="http://www.raspbian.org/" SUPPORT_URL="http://www.raspbian.org/RaspbianForums" BUG_REPORT_URL="http://www.raspbian.org/RaspbianBugs"

$ docker search hypriot hypriot/rpi-node RPi-compatible Docker Image with Node.js hypriot/rpi-iojs RPi-compatible Docker Image with io.js hypriot/rpi-java RPi-compatible Docker Image with Java hypriot/rpi-python RPi-compatible Docker Image with Python hypriot/rpi-golang hypriot/rpi-busybox-httpd Raspberry Pi compatible Docker Image with ... hypriot/rpi-gpio Dockerized gpio binary of wiringPi for the ... hypriot/rpi-ruby RPi-compatible Docker Image with Ruby hypriot/rpi-hugo Raspberry Pi compatible Docker Image with ... hypriot/rpi-crate RPi-compatible Docker Image with Crate.io hypriot/rpi-drone Raspberry Pi compatible Docker Image with ... hypriot/rpi-alpine-scratch Raspberry Pi compatible Docker Image with ... hypriot/rpi-haproxy Haproxy Dockerfile hypriot/rpi-gogs-raspbian Raspberry Pi compatible Docker Image with ... hypriot/rpi-swarm Raspberry Pi compatible Docker image with ... hypriot/rpi-mysql RPi-compatible Docker Image with Mysql hypriot/rpi-gogs-alpine Raspberry Pi compatible Docker Image with ... gdelpu/rpi-hypriot-node-hapi NodeJs with HapiJs framework hypriot/rpi-nano-httpd Raspberry Pi nano sized HTTP server hypriot/skydns hypriot/rpi-redis hypriot/rpi-skydns

aptitude install python python-pip git clone https://github.com/docker/compose.git cd compose git checkout 1.4.0 pip install . $ cd /etc/bash-completion.d $ rm docker $ URL_BASE=https://raw.githubusercontent.com/docker $ wget $(URL_BASE)/docker/master/contrib/completion/bash/docker $ wget $(URL_BASE)/compose/master/contrib/completion/bash/docker-compose # login again! $ exit $ ssh root@rpi-001

FROM hypriot/rpi-java MAINTAINER Peter Rossbach <[email protected]> @PRossbach ENV TOMCAT_MINOR_VERSION=8.0.26 \ CATALINA_HOME=/opt/tomcat \ TOMCAT_URL=http://archive.apache.org/dist/tomcat/tomcat-8 RUN DEBIAN_FRONTEND=noninteractive apt-get update \ && apt-get install -y \ curl \ --no-install-recommends \ && rm -rf /var/lib/{apt,dpkg,cache,log}/ ...

... RUN curl -O ${TOMCAT_URL}/v${TOMCAT_MINOR_VERSION}/bin/apache-tomcat-\ ${TOMCAT_MINOR_VERSION}.tar.gz \ && curl ${TOMCAT_URL}/v${TOMCAT_MINOR_VERSION}/bin/apache-tomcat-\ ${TOMCAT_MINOR_VERSION}.tar.gz.md5 | md5sum -c - \ && tar xzf apache-tomcat-*.tar.gz \ && rm apache-tomcat-*.tar.gz* && mv apache-tomcat* ${CATALINA_HOME} \ && rm -rf ${CATALINA_HOME}/webapps/* \ ${CATALINA_HOME}/RELEASE-NOTES ${CATALINA_HOME}/RUNNING.txt \ ${CATALINA_HOME}/bin/*.bat ${CATALINA_HOME}/bin/*.tar.gz WORKDIR /opt/tomcat EXPOSE 8080 EXPOSE 8009 ENTRYPOINT [ "/opt/tomcat/bin/catalina.sh" ] CMD ["run"]

tomcat: build: . volumes: - "./status:/opt/tomcat/webapps/status" docker-compose build docker-compose up -d

$ IP=$(docker inspect --format \ "{{ .NetworkSettings.IPAddress }}" tomcat_tomcat_1) $ curl -sL http://${IP}:8080/status hello Mon Aug 31 09:58:37 UTC 2015 $ docker exec -ti tomcat_tomcat_1 java -version java version "1.7.0_65" OpenJDK Runtime Environment (IcedTea 2.5.3) (7u71-2.5.3-2~deb7u1+rpi1) OpenJDK Zero VM (build 24.65-b04, mixed mode) $ sudo ntpdate -u ptbtime2.ptb.de docker pull infrabricks/tomcat:rpi-8.0.24

FROM resin/rpi-raspbian:jessie MAINTAINER Peter Rossbach <[email protected]> @PRossbach RUN DEBIAN_FRONTEND=noninteractive apt-get update \ && apt-get install -y \ wget pwgen curl openjdk-8-jre \ --no-install-recommends \ && apt-get clean autoclean \ && apt-get autoremove -y \ && rm -rf /var/lib/{apt,dpkg,cache,log}/ WORKDIR /data ENV JAVA_HOME /usr/lib/jvm/java-8-openjdk-armhf ENTRYPOINT [ "/usr/bin/java" ] CMD ["-version"]

FROM resin/rpi-raspbian:jessie MAINTAINER Peter Rossbach <[email protected]> @PRossbach RUN DEBIAN_FRONTEND=noninteractive \ echo "deb http://ppa.launchpad.net/webupd8team/java/ubuntu precise main" \ | tee -a /etc/apt/sources.list \ && echo "deb-src http://ppa.launchpad.net/webupd8team/java/ubuntu precise main" \ | tee -a /etc/apt/sources.list \ && apt-key adv --keyserver keyserver.ubuntu.com \ --recv-keys EEA14886 && apt-get update \ && echo oracle-java8-installer shared/accepted-oracle-license-v1-1 \ select true | debconf-set-selections \ && apt-get install -y oracle-java8-installer wget pwgen curl oracle-java8-installer \ --no-install-recommends \ && rm /usr/lib/jvm/java-8-oracle/src.zip \ && apt-get clean autoclean \ && apt-get autoremove -y \ && rm -rf /var/lib/{apt,dpkg,cache,log}/ RUN locale-gen en_US.UTF-8 ENV LANG en_US.UTF-8 ENV LC_CTYPE en_US.UTF-8 WORKDIR /data ENV JAVA_HOME /usr/lib/jvm/java-8-oracle ENTRYPOINT [ "/usr/bin/java" ] CMD ["-version"]

$ docker run --cap-add SYS_RAWIO --device /dev/mem # or more ... $ docker run --privileged

tomcat1: image: tomcat_tomcat volumes: - "./status:/opt/tomcat/webapps/status" tomcat2: image: tomcat_tomcat volumes: - "./status:/opt/tomcat/webapps/status" haproxy: image: hypriot/rpi-haproxy volumes: - "./haproxy:/haproxy-override" links: - tomcat1 - tomcat2 ports: - "8080:80" - "7070:70"

global log 127.0.0.1 local0 log 127.0.0.1 local1 notice defaults log global mode http option httplog option dontlognull timeout connect 5000 timeout client 10000 timeout server 10000 listen stats :70 stats enable stats uri / ...

... frontend balancer bind 0.0.0.0:80 mode http default_backend tc_backends backend tc_backends mode http option forwardfor # http-request set-header X-Forwarded-Port %[dst_port] balance roundrobin server tomcat1 tomcat1:8080 check server tomcat2 tomcat2:8080 check # option httpchk OPTIONS * HTTP/1.1\r\nHost:\ localhost option httpchk GET /status/index.jsp http-check expect status 200

$ wget http://downloads.hypriot.com/docker-machine_0.4.0-dev_darwin-amd64 $ chmod +x docker-machine_0.4.0-dev_darwin-amd64 $ ln -sf docker-machine_0.4.0-dev_darwin-amd64 docker-machine $ export PATH=$(pwd):$PATH

$ docker-machine create -d hypriot \ --hypriot-ip-address=192.168.178.109 \ rpi-001 # Update to newest docker engine! $ ssh [email protected] > wget http://downloads.hypriot.com/docker-hypriot_1.8.1-1_armhf.deb > dpkg -i docker-hypriot_1.8.1-1_armhf.deb > service docker restart > exit

$ cd ~/bin $ docker-machine ls INFO[0000] Creating CA: /Users/peter/.docker/machine/certs/ca.pem INFO[0001] Creating client certificate: /Users/peter/.docker/machine/certs/c NAME ACTIVE DRIVER STATE URL $ ls -a .docker/machine/certs ca-key.pem ca.pem cert.pem key.pem server-key.pem server.pem

$ docker-machine ls NAME ACTIVE DRIVER STATE URL rpi-master virtualbox Running tcp://192.168.99.100:2376 (master) rpi-001 * hypriot Running tcp://192.168.99.109:2376 $ docker-machine config rpi-001 --tlsverify --tlscacert="/Users/peter/.docker/machine/machines/rpi-001/ca.pem" --tlscert="/Users/peter/.docke $ docker $(docker-machine config rpi-001) ps $ docker $(docker-machine config rpi-001) run \ --rm hypriot/rpi-alpine-scratch /bin/sh -c "echo hello machine \$(hostname)" Unable to find image 'hypriot/rpi-alpine-scratch:latest' locally hypriot/rpi-alpine-scratch:latest: The image you are pulling has been verified 511136ea3c5a: Pull complete df7546f9f060: Pull complete ea13149945cb: Pull complete 4986bf8c1536: Pull complete Status: Downloaded newer image for busybox:latest hello machine 117ade53e1d6 $ docker $(docker-machine config rpi-001) images REPOSITORY TAG IMAGE ID CREATED VIRTUAL SIZE hypriot/rpi-alpine-scratch latest 9566b98023b5 8 weeks ago 4.971 MB

$ docker-machine ssh rpi-001 Linux rpi-001 3.18.11-hypriotos-v7+ #2 SMP PREEMPT Sun Apr 12 16:34:20 UTC 2 The programs included with the Debian GNU/Linux system are free software; the exact distribution terms for each program are described in the individual files in /usr/share/doc/*/copyright. Debian GNU/Linux comes with ABSOLUTELY NO WARRANTY, to the extent permitted by applicable law. Last login: Mon Aug 31 12:47:02 2015 from heisenberg-2.fritz.box HypriotOS: root@rpi-001 in ~

docker-machine help create

$ docker pull swarm # docker pull hypriot/rpi-swarm $ docker run --rm swarm create <SWARM_TOKEN> $ docker run -d -p 3376:2376 swarm manage \ <TLS CONFIG> token://<SWARM_TOKEN> $ docker run -d swarm join \ --addr=<node_ip:2376> token://<cluster_id>

# TOKEN=$(docker run --rm -ti swarm create) $ docker-machine create -d hypriot \ --hypriot-ip-address=192.168.178.94 \ --swarm \ --swarm-image "hypriot/rpi-swarm" \ --swarm-discovery token://${TOKEN} \ rpi-master $ ssh [email protected] > wget http://downloads.hypriot.com/docker-hypriot_1.8.1-1_armhf.deb > dpkg -i docker-hypriot_1.8.1-1_armhf.deb > service docker restart > exit

$ ssh root@rpi-001 $ docker pull hypriot/rpi-golang $ mkdir -p swarm $ docker run -ti -v $(pwd)/swarm:/app hypriot/rpi-golang $ go get -d github.com/docker/swarm $ go get github.com/tools/godep $ cd $GOPATH/src/github.com/docker/swarm $ CGO_ENABLED=0 GOOS=linux godep go build -a -tags netgo -ldflags '-w' . $ cp swarm /app/swarm # if work.. $ exit

$ cat >Dockerfile <<EOF FROM hypriot/rpi-alpine-scratch MAINTAINER Peter Rossbach [email protected] COPY swarm /swarm RUN apk update \ && apk add ca-certificates \ && rm -rf /var/cache/apk/* \ && ln -s /lib/ld-musl-armhf.so.1 /lib/ld-linux-armhf.so.3 ENV SWARM_HOST :2375 EXPOSE 2375 VOLUME /.swarm ENTRYPOINT ["/swarm"] CMD ["--help"] EOF $ docker build -t infrabricks/rpi-swarm:0.4.0 . $ docker run -ti --rm infrabricks/rpi-swarm:0.4.0

docker run -m 256m ... docker run -c 1 ... docker run -p 80:80 ...

$ eval $(docker-machine env rpi-master) $ docker run -c 1 -p 9082:8080 -d infrabricks/tomcat:rpi-8.0.24 35d50a29ed0fde780c0826ef16ff24d2582609f877ee092c780d9aeb6f27fc75 $ docker ps CONTAINER ID IMAGE COMMAND CREATED \ STATUS PORTS NAMES 35d50a29ed0f infrabricks/tomcat:rpi-8.0.24 "catalina.sh run" 16 minutes ago\ Up Less than a second 192.168.33.89:9082->8080/tcp \ rpi-001/insane_brattain $ docker run -c 1 -p 9083:8080 -d infrabricks/tomcat:rpi-8.0.24 f5bc6a274e82426df98eaca5e88fb01f43e03455dfebdb9ee4a3b00a7eab202e $ docker ps CONTAINER ID IMAGE COMMAND CREATED\ STATUS PORTS NAMES f5bc6a274e82 infrabricks/tomcat:rpi-8.0.24 "catalina.sh run" 16 minutes ago\ Up Less than a second 192.168.33.90:9083->8080/tcp \ rpi-002/stupefied_albattani 35d50a29ed0f infrabricks/tomcat:rpi-8.0.24 "catalina.sh run" 17 minutes ago\ Up Less than a second 192.168.33.89:9082->8080/tcp \ rpi-001/insane_brattain ...

lsb_release -a DOCKER_OPTS="--label region=de-berlin \ --label storage=ssd-vdi \ --label role=loadbalancer" docker -d ${DOCKER_OPTS} --label stage=prod docker run -e "constraint:provider==hypriot" ... docker run -e "constraint:storagedriver==aufs" ... docker run -e "constraint:region==de-berlin" ... docker run -e "constraint:node!=rpi-master" ... constraint:node==/rpi-00[12]/ constraint:node!=app* constraint:node==/(?i)rpi-001/

docker run -d -p 80:80 --name front nginx docker run -e "affinity:container==front" logger docker run -e "affinity:image==redis" redis docker run -d -p 80:80 --label com.example.type=frontend nginx docker run -d -e affinity:com.example.type==frontend logger docker run -d --name redis1 -e affinity:image==~redis redis docker run -d --name redis2 -e constraint:region==~us* redis docker run -d --name redis5 -e affinity:container!=~redis* redis

--volumes-from=dependency --link=dependency:alias network stack: --net=container:dependency

DOT=XYZ docker pull swarm SWARM_TOKEN=$(docker run --rm swarm create) echo $SWARM_TOKEN >token.txt docker-machine create \ --driver digitalocean \ --digitalocean-region fra1 \ --digitalocean-size 1gb \ --digitalocean-access-token $DOT \ --digitalocean-private-networking \ --swarm \ --swarm-master \ --swarm-discovery token://$SWARM_TOKEN \ --engine-label zone=prod \ --engine-label swarm=master \ swarm-master

docker-machine create \ --driver digitalocean \ --digitalocean-region fra1 \ --digitalocean-size 1gb \ --digitalocean-access-token $DOT \ --digitalocean-private-networking \ --swarm \ --swarm-discovery token://$SWARM_TOKEN \ --engine-label zone=prod \ --engine-label swarm=node \ swarm-node-001

$ ssh root@rpi-master $ git clone https://github.com/hypriot/rpi-consul $ cd rpi-consul $ make $ cd .. $ mkdir -p orchestration $ cat >docker-compose.yml <<EOF consul: image: hypriot/rpi-consul ports: - "8400:8400" - "8500:8500" - "8600:53/udp" volumes: - "./config:/config" - "./data:/data" environment: GOMAXPROCS: 2 command: agent -server -config-dir=/config -data-dir=/data -client=0.0.0.0 -ui-dir=/web EOF

mkdir -p config cat >config/consul.json <<EOF { "datacenter": "rpi", "data_dir": "/data", "ui_dir": "/web-ui", "client_addr": "0.0.0.0", "ports": { "dns": 53 }, "recursor": "8.8.8.8", "disable_update_check": true, "check_update_interval": "0s" } EOF docker-compose up -d

FROM hypriot/rpi-alpine-scratch ENTRYPOINT ["/bin/registrator"] RUN apk update \ && apk add build-base go git mercurial \ && mkdir -p /go/src/github.com/gliderlabs && cd /go/src/github.com/glide && git clone https://github.com/gliderlabs/registrator \ && cd registrator \ && export GOPATH=/go \ && go get \ && go build -ldflags "-X main.Version $(cat VERSION)" -o /bin/registrato && rm -rf /go \ && apk del --purge build-base go git mercurial

tomcat: image: infrabricks/tomcat:rpi-8.0.24 ports: - "8080" volumes: - tomcat-users.xml:/opt/tomcat/conf/tomcat-users.xml environment: - constraint:zone==dev - constraint:swarm==node SERVICE_8080_NAME: status-http SERVICE_REGION: bee42.1 SERVICE_8080_CHECK_HTTP: /status/ping.jsp SERVICE_8080_CHECK_INTERVAL: 30s

status: image: infrabricks/status tomcatblue: extends: file: common.yml service: tomcat volumes_from: - status environment: SERVICE_TAGS: tomcat,blue

status: image: infrabricks/status tomcatgreen: extends: file: common.yml service: tomcat volumes_from: - status environment: SERVICE_TAGS: tomcat,green

$ docker run -d -p 8000:80 rossbachp/docker-rpi:iot-2015 $ open http://<docker host>:8000/docker-rpi
