15-437 Files

Handling Files Thierry Sans

MIME Types

MIME types MIME (Multipurpose Internet Mail Extensions)  is also known
as the content type ➡ Deﬁne the format of a document exchanged on internet   (IETF standard) http://www.iana.org/assignments/media-types/index.html

Examples of MIME types • text/html • text/css • text/javascript
• image/jpeg - image/gif - image/svg - image/png (and so on) • application/pdf • application/json

Example of how images are retrieved <html>! <body>! <img src=images/bart.jpg/>!
</body>! </html> GET hello/bart/ http://localhost/HelloYou/ http://www.example.com//hello/bart/ GET images/bart.jpg MIME : text/html MIME : image/jpg

Client Side Uploading a ﬁle

Upload FORM <form enctype="multipart/form-data" action="{% url 'add' %}" method="post">! <input
id="upload" type="file" name="file"/>! <input type="text" name="name"/>! <input type="text" name="website"/>! </form>! <a id="publishButton">Publish</div> WebDirectory/templates/WebDirectory/index.html this form handles multiple formats of data the URL to submit the form uploading ﬁles must be done through a POST request

Submitting the form with Javascript $(document).ready(function(){! $("#publishButton").click(function(){! $("form").submit();! });! });
WebDirectory/static/WebDirectory/js/script.js

Using drag’n drop ... ... that’s your homework 4 :)

Server Side Saving and serving uploaded ﬁles

Saving uploaded ﬁles Controller def add(request):! ... Database img mime
path image/png path image/jpg The image path and the mime type are stored in the database POST add/ uploads The image is stored in the upload directory Image

Conﬁguring Django about where to upload ﬁles # Absolute filesystem
path to the directory that will hold user-uploaded files.! # Example: "/home/media/media.lawrence.com/media/"! MEDIA_ROOT = os.path.join(BASE_DIR, 'uploads/') tsans/settings.py

The model class Entry(models.Model):! # image = models.CharField(max_length=200)! name =
models.CharField(max_length=200)! webpage = models.URLField(max_length=200)  ! class Image(models.Model):! ! entry = models.ForeignKey(Entry, unique=True)! image = models.ImageField(upload_to='WebDirectory')! mimeType = models.CharField(max_length=20) WebDirectory/models.py where to store uploaded files use FileField for generic files We need to record the MIME type (see serving uploaded file) entry foreign key

Migrating the WebDirectory database $ python manage.py makemigrations WebDirectory! $
python manage.py migrate

Controller - saving uploaded ﬁles from django.views.decorators.csrf import csrf_exempt! !
@csrf_exempt! def add(request):! e = Entry(name = request.POST['name'],\! webpage = request.POST['website'])! e.save()  ! i = Image(entry = e,\! image = request.FILES['file'],\! mimeType=request.FILES['file'].content_type)! i.save()  ! return HttpResponseRedirect(reverse('index'))! WebDirectory/views.py get the ﬁle from the HTTP request Not secure but we will talk about security later get the MIME type

Controller - serving uploaded files • How to serve these
uploaded files? • Should we serve them as static files?

Why not serving uploaded files as static files? Because we
want to control • who can access these files • when to serve these files • how to serve these files

A good way to serve uploaded files Have a method
to control (controller) the file - getImage Reference the image using an identifier • automatically generated hash code • or database entry id (primary key in the database)

How to deﬁne getImage Controller def getimage(request,imageid):! ... GET getimage/345/
uploads Retrieve the image from the upload directory  (this is done automatically by Django) Database img mime path image/png path image/jpg Get the image path and mime type from the database based on its id Return a HTTP response of the corresponding mime type Image

Controller - serving uploaded ﬁles urlpatterns = patterns('',! url(r'^$', views.index,
name='index'),! url(r'^add/$', views.add, name='add'),! url(r'^getimage/(?P<image_id>\d+)/$',\! views.getImage,\! name='getImage'),! ) WebDirectory/urls.py

Controller - serving uploaded ﬁles def getImage(request,image_id):! i = Image.objects.get(id=image_id)!
return HttpResponse(i.image.read(), content_type=i.mimeType)! ! def index(request):! ! image_list = Image.objects.all()! return render(request,’WebDirectory/index.html’,\  {'image_list': image_list}) WebDirectory/views.py get the ﬁle from the database return an HTTP response of the corresponding MIME type

Updating the image URL in the template WebDirectory/templates/WebDirectory/index.html ...! <div
id="directory">! {% if image_list %}! {% for image in image_list %}! <div class="entry">! <div class="image"><img src="{% url 'getImage' image.id %}"/>! </div>! <div class=“name">{{image.entry.name}}</div>! <div class="website">! <a href=“{{image.entry.webpage}}”>  ! ! ! {{image.entry.name}}'s website  ! ! </a>! ...
