Gutter margin in Writer page styles

LibreOffice Conference 2021, Virtual

Transcript

1. Gutter margin in
   Writer page styles
   By Miklos Vajna
   Software Engineer at Collabora Productivity
   2021-09-24


   View Slide

2. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 2 / 20
   About Miklos
   From Hungary
   ●
   More details:
   https://www.collaboraoffice.com/about-us/
   Google Summer of Code 2010 / 2011
   ●
   Rewrite of the Writer RTF import/export
   Then a full-time LibreOffice developer for SUSE
   Now a contractor at Collabora


   View Slide

3. Gutter margin in
   Writer page styles


   View Slide

4. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 4 / 20
   Motivation
   One of the missing last section properties which are
   in each & every Word document
   ●
   Use-case: book
   ●
   Binding consumes a known amount of space on
   the left
   ●
   Want to have equal amount of remaining
   horizontal space on the left & on the right after
   that
   ●
   Can be also at the top, also RTL is to be considered
   (via wikipedia.org)


   View Slide

5. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 5 / 20
   User interface


   View Slide

6. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 6 / 20
   New / correct render result
   (more details)


   View Slide

7. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 7 / 20
   Reference render result


   View Slide

8. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 8 / 20
   Old / incorrect render result


   View Slide

9. Second round:
   RTL support


   View Slide

10. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 10 / 20
    User interface
    & layout
    (more details)


    View Slide

11. How is this
    implemented?


    View Slide

12. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 12 / 20
    Document model
    Internal C++ core representation:
    ●
    Writer document: SwDoc
    ●
    Writer page styles: SwPageDesc
    ●
    Page style properties: SfxItemSet
    ●
    Other margins are handled by SvxLRSpaceItem
    ●
    New: SvxLRSpaceItem::m_nGutterMargin
    ●
    New: SvxLRSpaceItem::m_nRightGutterMargin
    ●
    Two members are needed for mirrored page styles
    (via wikipedia.org)


    View Slide

13. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 13 / 20
    UNO API
    Public, stable representation:
    ●
    Writer document: com.sun.star.text.TextDocument
    ●
    Writer page styles: com.sun.star.style.PageStyle
    ●
    Other margins are named like LeftMargin, RightMargin
    ●
    New property: GutterMargin
    ●
    New property: RtlGutter
    ●
    Second property is inferred from the writing direction for ODT,
    set explicitly by the Word formats
    (via wikipedia.org)


    View Slide

14. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 14 / 20
    Layout
    Just an increased left margin… except:
    ●
    Take page border into account (gutter + left margin is outside the
    border, except for the border spacing
    ●
    Mirrored page margins
    ●
    RTL
    ●
    On the left or on the right


    View Slide

15. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 15 / 20
    Filters
    ODF and the rest:
    ●
    A new ODF extension: loext:margin-gutter="…">
    ●
    Proposal at https://issues.oasis-open.org/browse/OFFICE-4105
    ●
    Position is just a per-document setting: GutterAtTop=false
    ●
    Similar serialization and parsing for DOCX, DOC and RTF


    View Slide

16. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 16 / 20
    User interface
    Not just a spin-button:
    ●
    Combo box for the position
    ●
    Preview widget accurately takes gutter
    space into account


    View Slide

17. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 17 / 20
    Testing
    At various levels:
    ●
    Layout is covered in CppunitTest_sw_core_layout
    ●
    Also the mirrored margins case
    ●
    DOCX filter is covered in CppunitTest_sw_ooxmlexport
    ●
    The “from page” margin case and the “from text” one
    ●
    ODT filter is covered in CppunitTest_sw_odfexport
    ●
    DOC filter is covered in CppunitTest_sw_ww8export
    ●
    RTF filter is covered in CppunitTest_sw_rtfexport
    ●
    And then all the same for the “from top” case
    ●
    And then all the same for the RTL case
    (via wikipedia.org)


    View Slide

18. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 18 / 20
    Help content
    The content that ends up on https://help.libreoffice.org/:


    View Slide

19. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 19 / 20
    Thanks
    Collabora is an open source consulting and product company
    ●
    What we do and share with the community has to be paid by
    someone
    There is an exception to every rule
    ●
    Most of this work was done as a Collabora Hackweek project


    View Slide

20. Collabora Productivity LibreOffice Conference 2021, Virtual | Miklos Vajna 20 / 20
    Summary
    Writer now has full support for gutter margins
    ●
    Not only not loosing this formatting setting
    ●
    Also rendering it properly
    ●
    Integrates correctly with the rest of the layout: borders,
    mirroring, RTL
    ●
    Imports from / exports to all major file formats
    Thanks for listening! :-)
    ●
    Slides: https://people.collabora.com/~vmiklos/slides/
