Best Practices for Building Multi-Region, Active-Active Serverless Applications

As presented in re:Invent 2018

In this session, we walk through building and deploying a global-scale, multi-region, active-active serverless backend using Amazon Route 53 to route the traffic among AWS Regions, Amazon API Gateway, and AWS Lambda for the backend, and Amazon DynamoDB global tables for handling data storage at a global scale. We provide a demo and a hands-on coding opportunity.

Transcript

1. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Best Practices for Building Multi-region, Active-active Serverless Application Adrian Hornsby Technical Evangelist Amazon Web Services S R V 4 2 5
2. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Breakout repeats Wednesday Best Practices for Building Multi-Region, Active-Active Serverless Applications 2:30 PM - Venetian, Level 2, Venetian H Friday Best Practices for Building Multi-Region, Active-Active Serverless Applications 10:00 AM - Mirage, Antigua A
3. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Before we get started, let’s take a look at some fundamentals.
4. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. About availability Availability Downtime per year 99% (2-nines) 3 days 15 hours 99.9% (3-nines) 8 hours 45 minutes 99.99% (4-nines) 52 minutes 99.999% (5-nines) 5 minutes 99.9999% (6-nines) 31 seconds
5. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Availability in parallel A = 1 – (1 – Ax)2 Part X Part X
6. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Availability in parallel Component Availability Downtime X 99% (2-nines) 3 days 15 hours Two X in parallel 99.99% (4-nines) 52 minutes Three X in parallel 99.9999% (6-nines) 31 seconds
7. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Component redundancy increases availability significantly!
8. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. 19 Geographic Regions 57 Availability Zones (AZs) 4 regions and 12 more Availability Zones announced
9. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. AWS Region and availability zones Region Availability zone a Availability zone b Availability zone c data center data center data center data center data center data center data center data center data center
10. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Multi-AZ architecture Region Availability zone a Availability zone b Availability zone c Application Application Application
11. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Multi-region Region Availability zone a Availability zone b Availability zone c Application Region Availability zone a Availability zone b Availability zone c Application Application Application Application Application
12. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Serverless components Region Availability zone a Availability zone b Availability zone c Serverless Components
13. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. No servers to provision or manage Scales with usage Never pay for idle Availability and fault tolerance built in Why serverless components??
14. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Why build a multi-region active-active architecture?
15. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Improve availability and disaster recovery Applications in US West Applications in US East Users from San Francisco Users from New York Service 1 Service 2 Service 3 Service 4 Service 1 Service 2 Service 3 Service 4
16. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Improve latency for end-users ~300ms ~140ms
17. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Netflix 2013
18. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Netflix 2016
19. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Prerequisits to building a multi-region architecture.
20. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. CAP Theorem Consistency Availability Partition Tolerance Data is consistent. All nodes see the same state. Every request is non-failing. Service still responds as expected if some nodes crash. Distributed System In the presence of a network partition, you must choose between consistency and availability!
21. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Embrase eventual consistency … if no new updates are made to a given data item, eventually all accesses to that item will return the last updated value. Availability An eventually consistent system can return any value before it converges!! https://en.wikipedia.org/wiki/Eventual_consistency Distributed System Every request is non-failing.
22. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Secure and reliable global network
23. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
24. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
25. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Global routing
26. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Latency based routing Region Region Application Application
27. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Geo-based routing Region us-east-1 Region us-west-2 Application Application
28. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Weighted round robin routing Region us-east-1 Region us-west-2 Application Application
29. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. DNS failover Region us-east-1 Region us-west-2 Application Application
30. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Shallow health check Instance Cache node Email database Cluster Are you healthy? yes
31. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Shallow health check Instance Cache node Email database Cluster Are you healthy? yes
32. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Deep health check Instance Cache node Email database Cluster Are you healthy? yes Are you healthy? yes yes yes yes
33. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Deep health check Instance Cache node Email database Cluster Are you healthy? no Are you healthy? no yes yes yes
34. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region us-east-1 Region us-west-2 https://globalddb.adhorn.me Regional API Endpoint Custom Domain Name Regional API Endpoint Custom Domain Name API Gateway
35. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Build high performance, globally distributed applications Low latency reads & writes to locally available tables Disaster proof with multi-region redundancy Easy to set up and no application rewrites required Globally dispersed users Replica (N. America) Replica (Europe) Replica (Asia) Global App Global Table Amazon DynamoDB Global Tables Fully managed, multi-master, multi-region database
36. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Amazon S3 cross-region replication Bucket with objects Bucket with objects
37. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Multi-region multi-vpc connectivity Region Region VPC VPC VPC VPC VPC VPC Peering Amazon Backbone Peering https://aws.amazon.com/answers/networking/aws-multiple-region-multi-vpc-connectivity/
38. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Testing multi-region architecture.
39. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. GameDay at Amazon https://www.youtube.com/watch?v=zoz0ZjfrQ9s
40. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Chaos engineering https://github.com/Netflix/SimianArmy
41. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
42. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region us-east-1 Region us-west-2 Global Table https://globalddb.adhorn.me
43. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region us-east-1 Region us-west-2 Global Table
44. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region us-east-1 Region us-west-2 Global Table
45. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region us-east-1 Region us-west-2 Global Table
46. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Region us-east-1 Region us-west-2 Global Table https://globalddb.adhorn.me Voilà!
53. Route53: Traffic Policy
54. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Health checks with Route 53
55. Thank you! © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Adrian Hornsby @adhorn
