is so complicated • Only Google & Netflix have the scale to need it • You need a dedicated team to manage it • I’m happy with [chef/ansible/terraform] ♂
of software workloads ♻ • Lifecycle • Stateful, Stateless, Batch • Provision of storage • Distribution across computing nodes • Networking & access from the outside world • Security, Policies & Access Control • Declaration of how to run workloads in the cloud
the desired state of the system. ◦ Analogous to an instance of a resource in the system ◦ They must have a Kind, Group and Version ◦ They are persisted in etcd. apiVersion: networking.k8s.io/v1beta1 kind: Ingress Group Version
docker ps CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES 8c315a54ed41 albertoimpl/myapp "java -jar /opt/myap…" 12 seconds ago Up 11 seconds 0.0.0.0:8080->8080/tcp cranky_khayyam
{ begin: name := fmt.Sprintf("%s_%s", left[rand. Intn(len(left))], right[rand. Intn(len(right))]) if name == "boring_wozniak" /* Steve Wozniak is not boring */ { goto begin } if retry > 0 { name = fmt.Sprintf("%s%d", name, rand.Intn(10)) } return name } https://github.com/moby/moby/blob/master/pkg/namesgenerator/names-generator.go#L844
REPOSITORY TAG IMAGE ID CREATED SIZE albertoimpl/myapp latest 6d69e5b15226 4 seconds ago 142MB openjdk 8 e8d00769c8a8 6 days ago 488MB gcr.io/distroless/java 8 2ee039e7a421 49 years ago 125MB
REPOSITORY TAG IMAGE ID CREATED SIZE albertoimpl/myapp latest 8314b5c99ec7 4 minutes ago 107MB openjdk 8 e8d00769c8a8 6 days ago 488MB adoptopenjdk/openjdk8 alpine-slim a3562aa0b991 4 months ago 90.2MB
images REPOSITORY TAG IMAGE ID CREATED SIZE gcr.io/distroless/java 8 2ee039e7a421 49 years ago 125MB myapp-jib 0.0.1-SNAPSHOT 272b59084a4c 49 years ago 142MB
original and most used registry, free for public, paid for private. • GRC/ACR/ECR Are the biggest cloud providers registries, if you are using their hosted kubernetes container services, you should use their registries. • Harbor Open Source registry part of the CNCF. On premise registry. Vulnerability Scanner.
Use a managed service from your cloud provider of choice • Otherwise use an on-prem distribution (OpenShift, PKS, Rancher etc) • For the brave and curious - kubeadm • If you want to really understand how it fits together - Kubernetes the hard way by Kelsey Hightower
cluster-info Kubernetes master is running at https://127.0.0.1:60694 KubeDNS is running at https://127.0.0.1:60694/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.
STATUS AGE default Active 56s kube-node-lease Active 60s kube-public Active 60s kube-system Active 60s Namespaces provide a scope for names and it's a way to divide cluster resources.
pod/myapp created % k get pods NAME READY STATUS RESTARTS AGE myapp 0/1 ImagePullBackOff 0 1m % k get pods NAME READY STATUS RESTARTS AGE myapp 1/1 Running 0 1m
Pods and a policy to access them. The main types are: • ClusterIP: Exposes only inside the cluster. • NodePort: Exposes a port through the node to the world. • LoadBalancer: Exposes the Service externally using a cloud provider’s load balancer. Service
service/service-myapp-jib created % k get services NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 92m service-myapp-jib NodePort 10.111.36.24 <none> 8080:31106/TCP 6s % k port-forward service/service-myapp-jib 8080:8080 Forwarding from 127.0.0.1:8080 -> 8080 Forwarding from [::1]:8080 -> 8080 % curl localhost:8080 Hello, All
replicaset.apps/myapp created % k get po,rs NAME READY STATUS RESTARTS AGE pod/myapp 1/1 Running 0 101m pod/myapp-lbb82 1/1 Running 0 43s pod/myapp-m82tv 1/1 Running 0 43s NAME DESIRED CURRENT READY AGE replicaset.extensions/myapp 3 3 3 43s
"myapp" deleted % k get po,svc,rs NAME READY STATUS RESTARTS AGE pod/myapp-l5tfq 1/1 Running 0 18s pod/myapp-lbb82 1/1 Running 0 4m35s pod/myapp-m82tv 1/1 Running 0 4m35s NAME DESIRED CURRENT READY AGE replicaset.extensions/myapp 3 3 3 4m35s
READY STATUS RESTARTS AGE pod/myapp-l5tfq 1/1 Running 0 4m11s pod/myapp-lbb82 1/1 Running 0 8m28s pod/myapp-m82tv 1/1 Running 0 8m28s NAME DESIRED CURRENT READY AGE replicaset.extensions/myapp 3 3 3 8m28s NAME READY UP-TO-DATE AVAILABLE AGE deployment.extensions/myapp 3/3 3 3 2s
✓ Okteto manifest (okteto.yml) created % okteto up Deployment app-okteto doesn't exist in namespace default. Do you want to create a new one? [y/n]: y ✓ Development environment activated ✓ Files synchronized Namespace: default Name: app-okteto Forward: 8080 -> 8080 8088 -> 8088
Robust and secure - uses cloud load balancer service ⚠ Will incur more costs from cloud providers ⚠ Vendor specific configuration ⚠ Less configurable than Ingress ⚠ LoadBalancer not available in on-prem k8s (needs metal-lb, a 3rd party LoadBalancer implementation)
Registry Applicatio n Container ReplicaSet Deployment Service Ingress Pod Application Container Image Registry Application Container ReplicaSet Deployment Service Ingress
ingress.networking.k8s.io/provider-ingress created % k get svc,ingress NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE service/kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 3d1h service/service-myapp-provider NodePort 10.107.90.53 <none> 8080:31230/TCP 2d21h NAME HOSTS ADDRESS PORTS AGE ingress.extensions/provider-ingress provider.test.app.com 107.178.254.228 80 75s % curl 107.178.254.228/customers ["Laura","Bella","Olga"]
sh # cat config/DB_PASSWORD supersecret • Encrypting the data on rest: https://kubernetes.io/docs/tasks/administer-cluster/encrypt-data/ • Using Sealed Secrets that allow us to encrypt everything on git: https://github.com/bitnami-labs/sealed-secrets • Using Vault to store them: https://github.com/coreos/vault-operator
really help us here • Ingress can provide course-grained auth for a service • Implement an OAuth2 or Openid Connect flow ◦ On Prem: Hydra, Dex, UAA ◦ Cloud: Google, Github etc • Istio can secure communication between pods using mTLS & policy rules
humans • ServiceAccounts identify a process • Roles describe an action against a resource eg create Pod • RoleBinding describes a set of Users or ServiceAccounts that a Role applies to • Namespaces are a logical grouping of resources User: Jon Can create & read Resource: Pod Namespace: prod Resource: Pod / BookingApp ServiceAccount: DevPods Can read Resource: Secret / DevSecret
dons/fluentd-elasticsearch % k apply -f . service/elasticsearch-logging created serviceaccount/elasticsearch-logging created clusterrole.rbac.authorization.k8s.io/elasticsearch-logging created clusterrolebinding.rbac.authorization.k8s.io/elasticsearch-logging created statefulset.apps/elasticsearch-logging created configmap/fluentd-es-config-v0.2.0 created serviceaccount/fluentd-es created clusterrole.rbac.authorization.k8s.io/fluentd-es created clusterrolebinding.rbac.authorization.k8s.io/fluentd-es created daemonset.apps/fluentd-es-v2.7.0 created deployment.apps/kibana-logging created service/kibana-logging created
management: endpoints: web: exposure: include: "prometheus,info,health" % curl localhost:8001/actuator/prometheus # HELP jvm_memory_committed_bytes The amount of memory in bytes that is committed for the Java virtual machine to use # TYPE jvm_memory_committed_bytes gauge jvm_memory_committed_bytes{area="heap",id="PS Survivor Space",} 1.2582912E7
1. See https://thenewstack.io/kubernetes-design-and-development-explained/ Describe Desired State Operator Control Plane Persist Desired State Controller Watch for changes of interest Ensure cluster is in desired state
