To Protect and Confirm: Droidcon NYC 2018

Android P introduces new APIs for biometric authentication and securely authorizing actions on behalf of the user.

Let's take a look at what's changed on the biometric front since Droidcon NYC 2016's "Fingerprint Authentication In Action," and check out the new Protected Confirmation API for authorizing sensitive actions.

Transcript

1. To Protect and Confirm Ben Oberkfell Droidcon NYC 2018
2. New (And New-Ish) Features In Android 9.0 • New Biometrics • BiometricPrompt • Protected Confirmation • Key Attestation
3. New Biometrics • Android 9 de-emphasizes fingerprint, and generalizes the concept of biometric authentication • CDD for Android 9 allows for the inclusion of other biometric methods • Applies equivalent strength metrics to fingerprint
6. False Acceptance Rate • The chance of accepting an outright incorrect input. • The CDD requires that biometric implementations have no worse than 0.002% FAR. • Restated, that’s 2 in 100,000
7. Spoof Acceptance Rate • The likelihood of accepting a previous known good sample (similar to a “replay attack”). • Fingerprint mold • High-res facial photo, face mask • Replaying a voice recording • Iris image on a contact lens
8. Impostor Acceptance Rate • The likelihood of accepting an attempt to mimic a known good input sample • Trying to look like the device owner • Trying to fake tone of voice or accent to sound like the device owner
9. Strong vs Weak Biometrics • Strong biometrics are mechanisms that meet or exceed the 7% SAR/IAR thresholds. • Weak biometrics may unlock a device, but they may not be used to unlock authentication-required keys in the KeyStore. • Weak biometrics are not exposed through the new BiometricPrompt API.
10. https://source.android.com/security/biometric/
11. AOSP 9.0 BiometricPrompt simply delegates to the FingerprintManager
13. Now
14. How to Use It val prompt = BiometricPrompt.Builder(this) .setTitle("Place Your Order") .setSubtitle("Confirm your delivery order") .setDescription("Deliver to 732 Evergreen Terrace? Total: $36.99") .setNegativeButton("D'oh! Cancel", mainExecutor, cancelOnClickListener) .build() // Wrap a signature and ask to unlock the key val signature = Signature.getInstance("SHA256withRSA") signature.initSign(getPrivateKey()) val cryptoObject = BiometricPrompt.CryptoObject(signature) prompt.authenticate(cryptoObject, cancellationSignal, mainExecutor, callback)
15. How to Use It val prompt = BiometricPrompt.Builder(this) .setTitle("Place Your Order") .setSubtitle("Confirm your delivery order") .setDescription("Deliver to 732 Evergreen Terrace? Total: $36.99") .setNegativeButton("D'oh! Cancel", mainExecutor, cancelOnClickListener) .build() // Wrap a signature and ask to unlock the key val signature = Signature.getInstance("SHA256withRSA") signature.initSign(getPrivateKey()) val cryptoObject = BiometricPrompt.CryptoObject(signature) prompt.authenticate(cryptoObject, cancellationSignal, mainExecutor, callback)
16. How to Use It val prompt = BiometricPrompt.Builder(this) .setTitle("Place Your Order") .setSubtitle("Confirm your delivery order") .setDescription("Deliver to 732 Evergreen Terrace? Total: $36.99") .setNegativeButton("D'oh! Cancel", mainExecutor, cancelOnClickListener) .build() // Wrap a signature and ask to unlock the key val signature = Signature.getInstance("SHA256withRSA") signature.initSign(getPrivateKey()) val cryptoObject = BiometricPrompt.CryptoObject(signature) prompt.authenticate(cryptoObject, cancellationSignal, mainExecutor, callback)
17. How to Use It val prompt = BiometricPrompt.Builder(this) .setTitle("Place Your Order") .setSubtitle("Confirm your delivery order") .setDescription("Deliver to 732 Evergreen Terrace? Total: $36.99") .setNegativeButton("D'oh! Cancel", mainExecutor, cancelOnClickListener) .build() // Wrap a signature and ask to unlock the key val signature = Signature.getInstance("SHA256withRSA") signature.initSign(getPrivateKey()) val cryptoObject = BiometricPrompt.CryptoObject(signature) prompt.authenticate(cryptoObject, cancellationSignal, mainExecutor, callback)
18. How to Use It val prompt = BiometricPrompt.Builder(this) .setTitle("Place Your Order") .setSubtitle("Confirm your delivery order") .setDescription("Deliver to 732 Evergreen Terrace? Total: $36.99") .setNegativeButton("D'oh! Cancel", mainExecutor, cancelOnClickListener) .build() // Wrap a signature and ask to unlock the key val signature = Signature.getInstance("SHA256withRSA") signature.initSign(getPrivateKey()) val cryptoObject = BiometricPrompt.CryptoObject(signature) prompt.authenticate(cryptoObject, cancellationSignal, mainExecutor, callback) The executor allows you to control what thread the listener & callback lands on (the getMainExecutor() shortcut is new in API 28)
19. How to Use It val prompt = BiometricPrompt.Builder(this) .setTitle("Place Your Order") .setSubtitle("Confirm your delivery order") .setDescription("Deliver to 732 Evergreen Terrace? Total: $36.99") .setNegativeButton("D'oh! Cancel", mainExecutor, cancelOnClickListener) .build() // Wrap a signature and ask to unlock the key val signature = Signature.getInstance("SHA256withRSA") signature.initSign(getPrivateKey()) val cryptoObject = BiometricPrompt.CryptoObject(signature) prompt.authenticate(cryptoObject, cancellationSignal, mainExecutor, callback)
20. Authentication Callback val callback = object : BiometricPrompt.AuthenticationCallback() { override fun onAuthenticationFailed() { //The biometric capture was good, but wrong } override fun onAuthenticationError(errorCode: Int, errString: CharSequence) { //Hard error (terminate the flow) - e.g. too many tries } override fun onAuthenticationHelp(helpCode: Int, helpString: CharSequence) { //Help message, like "your finger moved too fast" } override fun onAuthenticationSucceeded(result: BiometricPrompt.AuthenticationResult) { //Success! Grab the CryptoObject from the result and use it to sign/encrypt/decrypt } }
21. Authentication Callback val callback = object : BiometricPrompt.AuthenticationCallback() { override fun onAuthenticationFailed() { //The biometric capture was good, but wrong } override fun onAuthenticationError(errorCode: Int, errString: CharSequence) { //Hard error (terminate the flow) - e.g. too many tries } override fun onAuthenticationHelp(helpCode: Int, helpString: CharSequence) { //Help message, like "your finger moved too fast" } override fun onAuthenticationSucceeded(result: BiometricPrompt.AuthenticationResult) { //Success! Grab the CryptoObject from the result and use it to sign/encrypt/decrypt } }
22. Authentication Callback val callback = object : BiometricPrompt.AuthenticationCallback() { override fun onAuthenticationFailed() { //The biometric capture was good, but wrong } override fun onAuthenticationError(errorCode: Int, errString: CharSequence) { //Hard error (terminate the flow) - e.g. too many tries } override fun onAuthenticationHelp(helpCode: Int, helpString: CharSequence) { //Help message, like "your finger moved too fast" } override fun onAuthenticationSucceeded(result: BiometricPrompt.AuthenticationResult) { //Success! Grab the CryptoObject from the result and use it to sign/encrypt/decrypt } }
23. Authentication Callback val callback = object : BiometricPrompt.AuthenticationCallback() { override fun onAuthenticationFailed() { //The biometric capture was good, but wrong } override fun onAuthenticationError(errorCode: Int, errString: CharSequence) { //Hard error (terminate the flow) - e.g. too many tries } override fun onAuthenticationHelp(helpCode: Int, helpString: CharSequence) { //Help message, like "your finger moved too fast" } override fun onAuthenticationSucceeded(result: BiometricPrompt.AuthenticationResult) { //Success! Grab the CryptoObject from the result and use it to sign/encrypt/decrypt } }
24. Authentication Callback val callback = object : BiometricPrompt.AuthenticationCallback() { override fun onAuthenticationFailed() { //The biometric capture was good, but wrong } override fun onAuthenticationError(errorCode: Int, errString: CharSequence) { //Hard error (terminate the flow) - e.g. too many tries } override fun onAuthenticationHelp(helpCode: Int, helpString: CharSequence) { //Help message, like "your finger moved too fast" } override fun onAuthenticationSucceeded(result: BiometricPrompt.AuthenticationResult) { //Success! Grab the CryptoObject from the result and use it to sign/encrypt/decrypt } }
25. Support Version • There’s a support library implementation, but it isn’t published yet • androidx.biometric has its own BiometricPrompt compat lib • Presents either the BiometricPrompt system dialog or its own standardized Fingerprint dialog on older devices
26. Improving Trust
27. Enrollment keyPairGenerator.initialize( new KeyGenParameterSpec.Builder(KEY_NAME, PURPOSE_SIGN) .setKeySize(2048) .setDigests(DIGEST_SHA256) .setSignaturePaddings(KeyProperties.SIGNATURE_PADDING_RSA_PKCS1) .setUserAuthenticationRequired(true) .build()); keyPairGenerator.generateKeyPair(); This property ensures that the key cannot be used unless authenticated first
28. Enrollment keyPairGenerator.initialize( new KeyGenParameterSpec.Builder(KEY_NAME, PURPOSE_SIGN) .setKeySize(2048) .setDigests(DIGEST_SHA256) .setSignaturePaddings(KeyProperties.SIGNATURE_PADDING_RSA_PKCS1) .setUserAuthenticationRequired(true) .build()); keyPairGenerator.generateKeyPair(); This property ensures that the key cannot be used unless authenticated first
29. User’s Device Backend
30. User’s Device Backend Username and Password
31. User’s Device Backend Username and Password Session Token
32. User’s Device Backend Username and Password Session Token Generate an authentication- bound keypair
33. User’s Device Backend Username and Password Session Token Generate an authentication- bound keypair Public Key & Device Identifier
34. User’s Device Backend Username and Password Session Token Generate an authentication- bound keypair Public Key & Device Identifier Store key with the user’s data
35. User’s Device Backend Username and Password Session Token Generate an authentication- bound keypair Public Key & Device Identifier Store key with the user’s data Device Token
36. User’s Device Backend
37. User’s Device Backend Unlock key with biometric to
 sign device token & nonce
38. User’s Device Backend Unlock key with biometric to
 sign device token & nonce Signed login request
39. User’s Device Backend Unlock key with biometric to
 sign device token & nonce Signed login request Verify signature & nonce
40. User’s Device Backend Unlock key with biometric to
 sign device token & nonce Signed login request Verify signature & nonce Session Token
41. Improving Trust • These authentication methods rely upon trust that the private side of the user’s key is securely stored in the trusted world and gated by the biometric reader • Given rules in the Android CDD, know that biometric-backed keys are handled via trusted hardware • However…
42. Improving Trust Is the key securely generated & stored, on a device with a trusted execution environment? Is the authentication required flag set? Or is it a rando, using curl to post a manually- generated key?
43. Key Attestation • We want proof of characteristics of the enrolled key: • that the key was created and lives in the trusted world • that the key has authentication required • the package name and signing fingerprint of apps authorized to use the key
44. Key Attestation • What if we also want some secondary characteristics of the device? • Verified boot state • OS version • Patch level
45. Key Attestation • The certificate associated with a key includes an extension block that describes key generation parameters and characteristics about where the key lives • This had been done earlier in software, but software implementations can be affected on rooted/compromised devices • For devices that first ship with Android 8.0+, this must be able to happen in trusted hardware
46. Key Attestation • Google has a root certificate for key attestation • OEM vendors burn an intermediate key into the device at the factory, whose certificate is signed by Google & traces back to the key attestation cert • Certificates for keys generated on your device are signed by the intermediate key
47. Key Attestation • The certificates contain a revocation list URL that should be checked when validating • If a device’s intermediate key is revoked, this permanently impacts key attestation for that device and others that share that key • “Devices containing revoked certificates are still at least as trustworthy as those only supporting software attestation.”
48. Key Attestation • Create a key with authentication required, and get its certificate chain • Validate the chain of signatures and confirm the root cert • Validate that the certificate indicates the key has authentication required set and was created in the trusted world Certificate[] certs = getKeyStore().getCertificateChain(KEY_NAME); List<String> encodedCerts = new ArrayList<>(); for (Certificate cert : certs) { encodedCerts.add(Base64.encodeToString(cert.getEncoded(), Base64.NO_WRAP)); } //send these to your backend
49. Challenge • You can prove the key meets your specifications, but you also want to prove the key was created for your purpose • So, you use a challenge string when creating the key • your backend creates the challenge string & delivers to client • client creates its key with this challenge • backend validates challenge along with attestation result
50. Key Generation keyPairGenerator.initialize( new KeyGenParameterSpec.Builder(KEY_NAME, PURPOSE_SIGN) .setKeySize(2048) .setDigests(DIGEST_SHA256) .setSignaturePaddings(KeyProperties.SIGNATURE_PADDING_RSA_PKCS1) .setUserAuthenticationRequired(true) .setAttestationChallenge("HelloWorld".getBytes()) .build()); keyPairGenerator.generateKeyPair();
51. keyPairGenerator.initialize( new KeyGenParameterSpec.Builder(KEY_NAME, PURPOSE_SIGN) .setKeySize(2048) .setDigests(DIGEST_SHA256) .setSignaturePaddings(KeyProperties.SIGNATURE_PADDING_RSA_PKCS1) .setUserAuthenticationRequired(true) .setAttestationChallenge("HelloWorld".getBytes()) .build()); keyPairGenerator.generateKeyPair(); Key Generation
52. User’s Device Backend
53. User’s Device Backend Username and Password
54. User’s Device Backend Username and Password Session Token
55. User’s Device Backend Username and Password Session Token Device Identifier
56. User’s Device Backend Username and Password Session Token Device Identifier Store identifier, generate challenge
57. User’s Device Backend Username and Password Session Token Device Identifier Store identifier, generate challenge Challenge
58. User’s Device Backend Username and Password Session Token Device Identifier Store identifier, generate challenge Challenge Generate keypair with challenge
59. User’s Device Backend Username and Password Session Token Device Identifier Store identifier, generate challenge Challenge Generate keypair with challenge Public Key & Certificate Chain
60. User’s Device Backend Username and Password Session Token Device Identifier Store identifier, generate challenge Challenge Generate keypair with challenge Public Key & Certificate Chain Validate key & certificates
61. User’s Device Backend Username and Password Session Token Device Identifier Store identifier, generate challenge Challenge Generate keypair with challenge Public Key & Certificate Chain Validate key & certificates Device Token
62. Certificate Validation • Use an ASN.1 parser library to parse the extension data from the certificate • Java: BouncyCastle • JS: asn1js • Python: asn1crypto • Go: encoding/asn1
63. Certificate Validation • Google has an example of the Android-specific implementation details, using BouncyCastle • https://github.com/googlesamples/android-key- attestation • The Google-provided schema specifies how the data in the cert is represented • https://developer.android.com/training/articles/security- key-attestation
64. The Attestation Schema https://developer.android.com/training/articles/security-key-attestation
65. The Attestation Schema https://developer.android.com/training/articles/security-key-attestation
66. Protected Confirmation
67. Protected Confirmation • Provides an API for displaying user prompts for confirmation • Offers high level of confidence that the user confirmed the details on the prompt, even if a device was rooted or compromised • Useful for high-stakes situations like financial transactions, or controlling medical devices • To be available on supported devices that ship with Android 9.0
68. How It Works • Trusted Execution Environment takes control and presents a prompt to validate the transaction • The information on the prompt is signed and sent back to your server for validation https://www.youtube.com/watch?v=r54roADX2MI
69. Key Generation keyPairGenerator.initialize( new KeyGenParameterSpec.Builder(KEY_NAME, PURPOSE_SIGN) .setKeySize(2048) .setDigests(DIGEST_SHA256) .setSignaturePaddings(KeyProperties.SIGNATURE_PADDING_RSA_PKCS1) .setAttestationChallenge("CHALLENGE_FROM_BACKEND".getBytes()) .setUserConfirmationRequired(true) .build()); keyPairGenerator.generateKeyPair();
70. Key Generation keyPairGenerator.initialize( new KeyGenParameterSpec.Builder(KEY_NAME, PURPOSE_SIGN) .setKeySize(2048) .setDigests(DIGEST_SHA256) .setSignaturePaddings(KeyProperties.SIGNATURE_PADDING_RSA_PKCS1) .setAttestationChallenge("CHALLENGE_FROM_BACKEND".getBytes()) .setUserConfirmationRequired(true) .build()); keyPairGenerator.generateKeyPair(); Use Key Attestation to confirm the challenge and confirmation flag when enrolling the key
71. Issuing the Prompt // nonce should come from your backend as a replay-protection // token val nonce = 8676309; val dialog = ConfirmationPrompt.Builder(this) .setPromptText("Send $100 to Ben") .setExtraData(("Send $100 to Ben:$nonce").toByteArray()) .build() dialog.presentPrompt(executor, callback)
72. Handling the Result val callback = object : ConfirmationCallback() { override fun onConfirmed(dataThatWasConfirmed: ByteArray?) { super.onConfirmed(dataThatWasConfirmed) signDataWithConfirmationKeyAndSendIt(dataThatWasConfirmed) } } The key we created with the confirmation flag can only be used to sign the data passed into this callback.
73. Handling the Result • The data returned to the callback is a CBOR (http://cbor.io) data structure that has several key/value pairs: • promptText: the data that was displayed to the user • extraData: the data that was passed as “extra” in the prompt (a good place to encode the prompted data AND the nonce together) • You sign and send to your service • Service should validate that both pieces of data are as expected.
74. Handling the Result • If the data validates, as does the signature, you know: • The data was signed with a key having the confirmation tag • The confirmation tag implies the data was confirmed, or else it wouldn’t have been accepted for signing • The nonce validation implies the data is not a replay
75. Wrapping Up • BiometricPrompt • https://developer.android.com/reference/android/hardware/biometrics/ BiometricPrompt • androidx.biometric (soon, or look in the AndroidX source repo today) • Key Attestation • https://developer.android.com/training/articles/security-key-attestation • Protected Confirmation • https://developer.android.com/training/articles/security-android-protected- confirmation
76. Other Resources • Android Fingerprint Authentication In Action (Droidcon NYC 2016) • https://github.com/benoberkfell/android-fingerprint-demo • Advanced Fingerprint (Øredev 2017) • https://vimeo.com/243345710 • https://github.com/benoberkfell/CryptoDiary • Fragmented Podcast #74 • http://fragmentedpodcast.com/2017/02/
