REST

An introduction to REST (Representational State Transfer)

Transcript

4. Back to basics   Plain HTTP   GET, PUT, DELETE   XML, JSON or XHTML data
5. Time for some examples •  iTunes top 10 songs –  http://ax.itunes.apple.com/WebObjects/MZStoreServices.woa/ws/RSS/topsongs/limit=10/xml •  Twitter –  http://twitter.com/statuses/user_timeline/7355792.atom –  http://twitter.com/statuses/user_timeline/7355792.json –  http://twitter.com/friends/ids.json?user_id=7355792 •  Google Maps –  http://maps.google.com/staticmap?center=40.714728,-73.998672&zoom=12&size=400x400
6. How RESTful is it?   Are all plain HTTP APIs REST?   Most services that claim to be REST are actually not   There are some rules to follow
7. “Design depends largely on constraints.” — Charles Eames
8. Roy Fielding Attribution: Paul Downey http://blog.whatfettle.com
9. Principles of REST •  Give every “thing” an ID •  Use a standard set of methods •  Link things together •  Communicate statelessly
10. Addressability   Resources must be addressable   Everything that matters should have its own URI
11. Uniform Interface   Well defined set of operations   GET, PUT, DELETE, POST   Well defined semantics   GET does not kill kittens   PUT and DELETE are idempotent   POST is unsafe   A client knows exactly what it can do with a resource
12. Imagine the web without links
13. Without linking Server Client GET http://bjarlestam.com/slides [slide1, slide2, slide3, slide4] GET http://bjarlestam.com/slides/getSlide?id=slide1
14. With linking Server Client GET http://bjarlestam.com/slides [ http://bjarlestam.com/slides/slide1, http://bjarlestam.com/slides/slide2, http://bjarlestam.com/slides/slide3, http://bjarlestam.com/slides/slide4 ] GET http://bjarlestam.com/slides/slide1
15. Why is it better to link the resources?
16. Link your resources •  No out of band info needed •  No separate discovery mechanism
17. Statelessness
18. Imagine Google being stateful
19. http://www.google.com/search?q=rest&page=first http://www.google.com/search?q=rest&page=next http://www.google.com/search?q=rest&page=next Stateful
20. http://www.google.com/search?q=rest http://www.google.com/search?q=rest&start=10 http://www.google.com/search?q=rest&start=20 Stateless
21. What makes the stateless Google better than the stateful?
22. Statelessness •  Better scaling –  No session storage on server –  Any server in a cluster can handle any request –  All the result pages can safely be cached •  More reliable –  A client can safely re-send a request •  Better resource reuse –  All the result pages can safely be linked to
23. Caching
24. Client Proxy Cache Client Client Server Proxy Cache Client Reverse Proxy Cache Client Cache Client Cache Client Cache Client Cache
25. “The best requests are those that not even reach me.” - Anonymous overloaded Server
26. Caching   GET can be cached while POST can't (safely)   Specify max-age –  Use max-age cache control header   Split data according to freshness requirement   Separate private and public data –  Use private and public cache control header   Support conditional GET –  Get if modified since –  E-tags
27. Media Types •  A resource can have different representations –  Ex: an image can be available as gif or jpeg •  Media types can be negotiated with HTTP –  Client can send Accept headers •  Prefer media types that lets you link resources –  Atom –  XHTML+Microformats
28. Some benefits of REST   Faster response time (caching)   Reduced server load (caching)   Improved server scalability (no session state)   Client software can be reused (uniform interface)   No separate resource discovery needed (hyperlinks)   Easy to serve different types of content such as images, videos, xl-sheets etc.
29. “I think most people just make the mistake that it should be simple to design simple things. In reality, the effort required to design something is inversely proportional to the simplicity of the result.” - Roy Fielding
30. True! Unless someone else has already done the thinking for you
31. JAX-RS •  Simple URL mappings •  Simple media type specification •  Simple Cache-control header handling •  Simple HTTP response code handling •  Support when building URLs •  The REST is up to you :-)
32. JAX-RS Hello World @Path("/helloworld") public class HelloWorld { @GET @Produces("text/plain") public String sayHello() { return new String("Hello World!"); } }
33. @Path("/slides") public class SlideResource { Map<Slide> slides; @GET @Path("{id}") @Produces("text/html") public String getSlideAsHtml(@PathParam("id") String slideId) { return slides.get(slideId).getAsHtml(); } ... } JAX-RS
34. @Path("/slides") public class SlideResource { Map<Slide> slides; ... @PUT @Path("{id}") @Consumes("application/json") public String save(@PathParam("id") String slideId, String content) { slides.put(slideId, new Slide(content)); return "slide with id " + slideId + " stored"; } } JAX-RS
35. Describing the interface   REST services should be self-descriptive   Client can use HTTP OPTIONS command   Content-type headers   Links let the client navigate the API   In theory no description language should be needed   There are some description languages though   WADL   WSDL2.0
36. PUT or POST?   New resources could be created by either PUT or POST   Use PUT to create or edit a resource at a known URL   Use POST to create a resource and let the server decide the URL
37. For the interested
38. For the interested   Roy Fieldings PhD dissertation, see ch 5 –  http://www.ics.uci.edu/~fielding/pubs/dissertation/top.htm   Roy Fieldings blog –  http://roy.gbiv.com/untangled/   Mark Hadleys blog –  http://weblogs.java.net/blog/mhadley/   Mark Nottinghams blog –  http://www.mnot.net   Stefan Tilkovs blog –  http://www.innoq.com/blog/st/
