Building Modular and Reactive Android Applications

Transcript

1. Building Modular and Reactive Android Applications Mouna Cheikhna @monac1
4. Structure
7. + AsyncTask =
8. + AsyncTask =
9. Modularity Dagger 2 & MVP
10. Modularity: Dagger 2
12. Dagger 2
13. Dagger 2 • A compile-time dependency injection framework for Java and Android.
14. Dagger 2 • A compile-time dependency injection framework for Java and Android. • An adaptation of Square’s version and now maintained by Google.
15. Dagger 2 • A compile-time dependency injection framework for Java and Android. • An adaptation of Square’s version and now maintained by Google. • Dagger 2 aims to address many of the development and performance issues that have plagued reflection-based solutions.
17. Dagger API
18. Dagger API public @interface Component {
 Class<?>[] modules() default {};
 Class<?>[] dependencies() default {};
 }
 public @interface Subcomponent {
 Class<?>[] modules() default {};
 }

 public @interface Module {
 }
19. Dagger API
20. Dagger API public @interface Provides {
 }

 public @interface MapKey {
 boolean unwrapValue() default true;
 }

 public interface Lazy<T> {
 T get();
 }
22. Component dependencies
23. Component dependencies @Singleton @Component(modules = { AppModule.class, ApiModule.class })
 public interface AppComponent {

 void injectApplication(MyApp app);
 Application application();

 @ApplicationContext
 Context provideApplicationContext();
 }
24. Component dependencies
25. Component dependencies public class SearchView extends LinearLayout {
 @ScopeSingleton(SearchComponent.class)
 @Component(dependencies = AppComponent.class)
 public interface SearchComponent extends BaseComponent {
 void inject(SearchView searchView);
 @ApplicationContext
 Context provideApplicationContext();
 }
 }
27. Singleton
28. Singleton @Module
 Class DripCoffeeModule {
 @Provides @Singleton
 CoffeeMaker provideCoffeeMaker () {
 return new CoffeeMaker();
 }
 }

 //or
 @Singleton
 class CoffeeMaker {
 //...
 }

 @Component(modules = DripCoffeeModule.class)
 @Singleton
 interface CoffeeShopComponent {
 CoffeeMaker maker();
 }
30. Scoping
31. Scoping @Scope
 @Retention(RUNTIME)
 public @interface ActivityScope {
 } @Module
 public Module ActivityModule {
 @Provides @ActivityScope
 public Activity provideActivity () {
 return mainActivity;
 }
 // Provide other activity dependencies
 }

 @ActivityScope
 @Component(dependencies = AppComponent.class, modules = {ActivityModule.class})
 public interface MainActivityComponent extends AppGraph {
 void inject(MainActivity mainActivity);
 }

32. Scoping
33. Scoping public class MainActivity {
 @Override
 protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);

 DaggerMainActivityComponent.builder()
 .appComponent(MyApp.get(this).getComponent())
 .activityModule(new ActivityModule(this))
 .build().inject(this);
 }
 }

35. MapKey
36. MapKey @MapKey(unwrapValue = true)
 public @interface TaskIdentifier {
 TaskKey value();
 }

 @Provides(type = MAP)
 @TaskIdentifier(TAKE_PHOTO)
 BaseTask provideTakePhotoTask(@ApplicationContext Context context) {
 return new TakePhotoTask(context);
 }

 @Provides(type = MAP)
 @TaskIdentifier(PREVIEW)
 BaseTask providePreviewTask(@ApplicationContext Context context) {
 return new PreviewTask(context);
 }

37. MapKey
38. MapKey @Provides @Singleton
 public TasksMap provideTasksMap(Map<TaskKey, Provider<Task>> tasks) {
 return new TasksMap(tasks);
 } public class TasksRunner {
 @Inject TasksMap tasksStore;
 }
40. Lazy
41. Lazy //Example: Shared Preferences
 @Inject Lazy<SharedPreferences> lazySharedPrefs;
 void onSaveBtnClicked() {
 lazySharedPrefs.get()
 .edit().putString("status", "lazy...")
 .apply();
 }
 //Example: Picasso
 @Inject Lazy<Picasso> lazyPicasso;
 private Bitmap loadBitmap(Uri uri) {
 if (uri == null) return null;
 return lazyPicasso.get()
 .load(uri).get();
 }
42. Modularity: MVP
44. MVP
45. MVP
47. MVP: Decouple UI from dependencies
48. public class SearchView extends LinearLayout implements SearchScreen {
 @ScopeSingleton(SearchComponent.class)
 @Component(dependencies = AppComponent.class)
 public interface SearchComponent extends BaseComponent {
 void inject(SearchView searchView);
 }
 @Inject SearchPresenter searchPresenter;
 private void init(Context context) {
 DaggerSearchView_SearchComponent.builder()
 .appComponent(MyApp.get(getContext()).getComponent())
 .build().inject(this);

 }

 @OnClick(R.id.search_btn) public void search() {
 searchPresenter.search(searchEditText.getText().toString())
 .subscribe(adapter);
 }
 } MVP: Decouple UI from dependencies
50. MVP: Decouple UI from dependencies
51. MVP: Decouple UI from dependencies public interface SearchScreen extends PresenterScreen {
 //main methods used in this screen
 void search();
 }

 @ScopeSingleton(SearchComponent.class)
 public class SearchPresenter extends BasePresenter<SearchScreen> {
 private SearchApi api;

 @Inject
 public SearchPresenter(SearchApi api) {
 this.api = api;
 }

 public Observable<List<Result>> search(String query) {
 return api.search(query);
 }
 }
53. Modularity: Tips
55. Tip 1: Separate Debug behavior from Release Behavior.
56. Tip 1: Separate debug behavior from release
57. Tip 1: Separate debug behavior from release //in Main folder @Module
 public class ApiModule {
 @Provides @Singleton @ApiClient
 OkHttpClient provideApiClient(OkHttpClient client, List<Interceptor> networkInterceptors) {
 OkHttpClient okClient = client.clone();
 okClient.networkInterceptors().addAll(networkInterceptors);
 return okClient;
 }
 } }
 //In debug flavor
 @Module
 public class DebugApiModule {
 @Provides @Singleton List<Interceptor> provideNetworkInterceptors() {
 return Arrays.asList(new StethoInterceptor(), new LoggingInterceptor());
 }
 }

 @Component(modules = { ApiModule.class, DebugApiModule.class,... })
 public interface AppComponent {
 //...
 }


58. Tip 1: Separate debug behavior from release
59. Tip 1: Separate debug behavior from release //In release flavor
 @Module
 public class ReleaseApiModule {
 @Provides @Singleton
 List<Interceptor> provideNetworkInterceptors() {
 return Arrays.asList(new AnalyticsInterceptor());
 }
 }

 @Component(modules = {ApiModule.class, ReleaseApiModule.class,...})
 public interface AppComponent {
 //...
 } and each app in each flavor use its component and is set in the manifest.
60. Tip 2: Decouple Intent results from Activity/Fragment
61. Tip 2: Decouple Intent results from Activity/Fragment
62. Tip 2: Decouple Intent results from Activity/Fragment public final class ActivityResults {
 private final List<ActivityListener> activityListeners = new CopyOnWriteArrayList<>();

 public void onActivityResult(int requestCode, int resultCode, Intent data) {
 if (!activityListeners.isEmpty()) {
 for (ActivityListener activityListener : activityListeners) {
 activityListener.onActivityResult(requestCode, resultCode, data);
 }
 } }

 public void addListener(ActivityListener activityListener) {
 activityListeners.add(activityListener);
 }

 public void removeListener(ActivityListener activityListener) {
 activityListeners.remove(activityListener);
 }
 }

 public interface ActivityListener {
 void onActivityResult(int requestCode, int resultCode, Intent data);
 }
63. Tip 2: Decouple Intent results from Activity/Fragment
64. Tip 2: Decouple Intent results from Activity/Fragment @Module
 public class MyAppModule {
 @Provides @Singleton
 ActivityResults provideActivityResults() {
 return new ActivityResults();
 }
 }

 public class MyActivity { @Inject ActivityResults activityResults;
 @Override
 protected void onActivityResult(int requestCode, int resultCode, Intent data) {
 super.onActivityResult(requestCode, resultCode, data);
 activityResults.onActivityResult(requestCode, resultCode, data); }
 }


65. Tip 2: Decouple Intent results from Activity/Fragment
66. Tip 2: Decouple Intent results from Activity/Fragment public final class MyImageView extends ImageView implements ActivityResults.Listener {
 @Inject ActivityResults activityResults;
 public MyImageView(Context context) {
 super(context);
 }

 protected void onAttachedToWindow() {
 super.onAttachedToWindow();
 this.activityResults.addListener(this);
 }

 protected void onDetachedFromWindow() {
 super.onDetachedFromWindow();.
 this.activityResults.removeListener(this);
 }

 public void onActivityResult(int req, int res, Intent intent) {
 /* react to the intent result inside the component */
 } }
67. Tip 3: Scope object only while they are needed
68. Tip 3: Scope object only while they are needed @ScopeSingleton(MyView.MyComponent.class)
 public class MyPresenter extends BasePresenter<MyScreen> {
 @Inject HeavyCache heavyCache;
 //...
 }

 public class MyView extends LinearLayout implements MyScreen {
 //...
 @ScopeSingleton(MyComponent.class)
 @Component(modules = { MyHeavyCacheModule.class })
 public interface MyComponent {
 void inject(MyView view);
 }
 }
70. Reactive
71. Reactive RxJava & Rx Libraries
72. RxJava
73. RxJava • A library for composing asynchronous and event- based programs using observable sequences.
74. RxJava API
75. RxJava API
77. Subjects
78. Subjects • A bridge or proxy that acts both as an observer and as an Observable. • A subject is an observer so it can subscribe to one or more observables, and an observable so it can pass through the items it observes by reemitting them, and it can also emit new items. • Multiple Types: PublishSubject, BehaviorSubject, ReplaySubject.
80. Reactive: Tips
81. Tip 1: Use Retrolambda
82. Tip 1: Use Retrolambda
83. Tip 1: Use Retrolambda new Func1<String, Integer>() {
 @Override public Integer call(String s) {
 return s.length();
 }
 }


 //equivalent to
 s -> s.length()
84. Tip 2: Decouple dependencies using subjects
85. Tip 2: Decouple dependencies using subjects
86. Tip 2: Decouple dependencies using subjects Example: When a component depends on an activity state public enum ActivityState {CREATE, START, RESUME, STOP, DESTROY}

 @Module
 public final class MyActivityModule {
 @Provides @Singleton
 BehaviorSubject<ActivityState> provideActivityStateSubject() { return BehaviorSubject.create();
 }

 @Provides @Singleton
 Observable<ActivityState> provideActivityStateObservable( BehaviorSubject<ActivityState> subject) {
 return subject;
 }
 }

87. Tip 2: Decouple dependencies using subjects
88. Tip 2: Decouple dependencies using subjects public class MyActivity {
 @Inject BehaviorSubject<ActivityState> activityStateSubject;
 protected void onCreate(Bundle bundle) {
 activityStateSubject.onNext(ActivityState.CREATE);
 }

 protected void onDestroy() {
 super.onDestroy();
 this.activityStateSubject.onNext(ActivityState.DESTROY);
 }
 }

 public class MyView extends LinearLayout {
 @Inject Observable<ActivityState> activityStateObservable;
 void load() {
 this.activityStateObservable
 .filter(state -> state == ActivityState.STOP)
 .subscribe( /* do only when activity stops */);
 }
 }
89. Tip 3: Use SqlBrite to interact with the database
90. Tip 3: Use SqlBrite to interact with the database
91. Tip 3: Use SqlBrite to interact with the database Sqlbrite : wrapper around SQLiteOpenHelper which introduces reactive stream semantics to SQL operations : @Override
 protected void onResume() {
 super.onResume();
 sqlBrite = SqlBrite.create();
 BriteContentResolver resolver = sqlBrite.wrapContentProvider(getContentResolver());
 subscription = resolver.createQuery(DB_URI, Users.COLUMNS, null, null, null, true)
 .mapToList(MainActivity::cursorToUser)
 .subscribe(adapter::setUsers); }
92. Tip 4: Use takeUntil to watch terminal situations
93. Tip 4: Use takeUntil to watch terminal situations
94. Tip 4: Use takeUntil to watch terminal situations Example: Stop fetching sensible data when the user has signed out : @Retention(RetentionPolicy.RUNTIME)
 @Qualifier
 public @interface SignOut {}
 @SignOut @Provides @Singleton
 PublishSubject<Void> provideSignOutSubject() {
 return PublishSubject.create();
 }

 @SignOut @Provides @Singleton
 Observable<Void> provideSignOutObservable(@SignOut PublishSubject<Void> subject){
 return subject;
 }

 public MyDrawerView extends DrawerView { @Inject @SignOut PublishSubject<Void> signOutSubject;
 void onSignoutClick() {
 this.signOut.onNext(null);
 }
 }

95. Tip 4: Use takeUntil to watch terminal situations
96. Tip 4: Use takeUntil to watch terminal situations public PaymentView extends LinearLayout {
 @Inject @SignOut Observable<Void> signOut;
 void confirmPayment () {
 api.confirmPayment(request)
 .takeUntil(this.signOut)
 .subscribe(/*display confirmation*/)
 }
 } public MessageView extends LinearLayout {
 @Inject @SignOut Observable<Void> signOut;
 void displayMessages() {
 messagesObservable .flatMap(/*...*/)
 .takeUntil(this.signOut)
 .subscribe(/* display messages */);
 }
 }

97. Tip 5: Reactive Sync
98. Tip 5: Reactive Sync
99. Tip 5: Reactive Sync Example using RxBinding: sync changes of an input text and a recyclerview :
100. Tip 5: Reactive Sync Example using RxBinding: sync changes of an input text and a recyclerview :
101. Tip 5: Reactive Sync Example using RxBinding: sync changes of an input text and a recyclerview : Observable<CharSequence> descriptionChanges = RxTextView.textChanges(descriptionField);
 Observable<MyAdapter> adapterObservable = RxRecyclerViewAdapter.dataChanges(adapter);
 Observable.combineLatest(
 descriptionChanges, adapterObservable)
 (charSequence,tasksAdapter) -> true)
 .subscribe(b -> {
 startSync(getCurrentContent());
 });
102. Other tips
103. Other tips • Don’t Break the Rx chain (use compose). • Remember to always unsubscribe (use CompositeSubscription or RxLifecycle)
104. Resources • Rx Resources list: https://github.com/chemouna/Rx-Resources • Cyclejs: http://cycle.js.org/ • HarryPotterBooks (MVP): https://github.com/chemouna/ HarryPotterBooks • U2020: https://github.com/JakeWharton/u2020 • Foursquare client (Kotlin & MVP): https://github.com/chemouna/Nearby • RxBinding: https://github.com/JakeWharton/RxBinding • RxPreference: https://github.com/f2prateek/rx-preferences • SqlBrite: https://github.com/square/sqlbrite • RxRelay: https://github.com/JakeWharton/RxRelay
105. Thank you Questions ?
