End-to-End-Anwendungen mit ASP.NET Web API, SignalR & Angular 2 In
Action Christian Weyer @christianweyer Principal Consultant & CTO

Action Thinktecture AG - http://thinktecture.com § Microsoft MVP for ASP.NET § Google GDE for Web Technologies § Focus on cross-platform solutions – end-to-end § [email protected] § @christianweyer Christian Weyer 2

Action Modern applications 3

Action Cross-Platform == Reach Mobile-First != Mobile-only 5

Action Lightweight architectures 5

Action § Web / REST APIs § Node.js: Express or Restify § Java: Jersey § .NET: ASP.NET Web API § Push Services § Platform level § APNS, FCM, WNS § Application level § Node.js: socket.io § Java: Atmospehere § .NET: ASP.NET SignalR Target architecture: Services, everywhere 6

Action 7

Action Angular 2 8

Action § Client-side single page applications (SPA) § Features § Consequently component-based § Metadata-driven § Tooling ecosystem § Focus on proven pattern and separation of concerns § Components, views, view models § Services and dependency injection Angular 2 9

Action § Modules § Components § Directives § Services § Router Angular 2 – Central Artifacts 10

Action Components in TypeScript 11 @Component({ selector: 'my-app', template: '<h1>My Angular 2 App</h1>' }) export class AppComponent { }

Action Component ‚Controller‘ 12 export class AppComponent implements OnInit { constructor() { } ... }

Action § Directives add behavior to a DOM element • Component can consist of directives § A component is a directive with a view Component vs. Directive 13 @Directive({ selector: '[x-large]' }) export class XLargeDirective { constructor(public el: ElementRef) { this.el.nativeElement.style.fontSize = 'x-large'; } } <span x-large>Extra Large Text</span>

Action Services 14 export class MyService { constructor() { } public GetMyData() {…} }

Action Dependency Injection 15 @Injectable() export class MyService { constructor(private _otherService: OtherService) { } public GetMyData() { this._otherService.doSomething(); } }

Action § Modularity system § Every Angular app has at least one module • Root module, conventionally named AppModule § Most apps have many more feature modules Modules @NgModule({ imports: [ BrowserModule ], providers: [ Logger ], declarations: [ AppComponent ], exports: [ AppComponent ], bootstrap: [ AppComponent ] }) export class AppModule { } 16

Action Bootstrapping an Application – ng 2 17 @Component({ selector: 'my-app', viewTemplate: '<div>This app is called {{ title }}</div>' }) // needs to be in AppModule class AppComponent { this.title = 'My super app'; } import ... from 'angular'; import {AppModule} from 'appModule'; platformBrowserDynamic().bootstrapModule(AppModule); <html> <body> <my-app></my-app> </body> import ... from 'angular'; import {AppModuleNgFactory} from 'appModuleNgFactory'; platformBrowser().bootstrapModuleFactory(AppModuleNgFactory); AOT

Action § Routing configuration Routing 18 export const APP_ROUTING: ModuleWithProviders = RouterModule.forRoot(appRootRoutes); export const GAMES_ROUTING: ModuleWithProviders = RouterModule.forChild(gameRoutes); const appRootRoutes: Routes = [ { path: 'login', component: LoginComponent, name: 'Login' }, { path: 'list', component: DataList, name: 'List' } ]; const gameRoutes: Routes = [ { path: 'games', component: GamesRootComponent, children: [{ path: 'all', component: GameListComponent }] } ];

Action § Module imports Routing @NgModule({ imports: [ BrowserModule, APP_ROUTING ], providers: [ Logger ], declarations: [ AppComponent ], exports: [ AppComponent ], bootstrap: [ AppComponent ] }) export class AppModule { } 19

Action § Routing placeholder in view Routing <div class="content-wrapper" style="min-height: 100%;"> <section class="content scrolling-module"> <router-outlet></router-outlet> </section> </div> 20

Action § Data flows into a component via inputs § Data flows out of a component via outputs Data Flow & Component Public API 21

Action § In Angular 2 no need to call $scope.$apply § Magic resides inside special library named zone.js • Overrides all standard browser APIs that are considered asynchronous • Injects its own implementation & uses it to monitor start and completion of any asynchronous activity § Async • Events: user events like click, change, input, submit • XMLHttpRequests: e.g. fetching data from REST API • Timers: setTimeout(), setInterval() Change Detection with Zones 22

Action § Angular heavily builds on observables • Observable object represents a push-based collection • Leverages RxJS § Angular 2 has a native HTTP service • Can use any HTTP functionality like the Fetch API in modern browsers • Returns observable streams Observables & HTTP 23

Action § Event bindings § Property bindings § Local variables Template Syntax 24

Action Template Syntax 25 @Component({ selector: 'name-change', templateUrl: 'name-change.html' }) export class NameChange { constructor() { this.name = ''; } changeName(newName) { this.name = newName; } } <div> My name is {{ name }} </div> <div> <input #newname type="text"> <button (click)="changeName(newname.value)" [disabled]="newname.value == 'CW'"> Change Name </button> </div>

Action § One-time bindings by default • Simplification and performance § Two-way binding is syntactic sugar • ng-model uses combination of property and event binding Two-Way Bindings 26

Action Two-Way Binding Explained 27 <input [value]="name"> <p>Hello {{name}}</p> <input [value]="name" (input)="name = $event.target.value"> <p>Hello {{name}}</p> <input [ng-model]="name" (ng-model)="name = $event"> <p>Hello {{name}}</p> <input [(ng-model)]="name"> <p>Hello {{name}}</p>

Action § In real projects we have a build process § Tools like gulp.js make life easier • Transpilation • Concatenation • Minification • and so on… § Angular 2 is agnostic to actual underlying build process § Angular CLI tool: https://cli.angular.io/ • Based on Webpack Build Process 28

Action § View encapsulation § Forms in depth § Animations § AOT § Universal Angular § … and more ... More Topics 29

Action Going native on the client 30

Action § Toolkit and framework for building native application shells for our web apps § Make ‘app apps’ from ‘web apps’ J § Uses native web view components to host the original web app locally § Provides framework and APIs via plugins to interact with underlying native platforms § CLI tools for automating project creation & build § We always need the native SDKs (e.g. iOS, Android, Windows) § Access to native platforms via plugins Mobile apps with Cordova 31 JS HTML CSS Native wrapper Deploy to devices

Action § Create real desktop applications from HTML5 code base § Similar to Cordova’s base idea: from web app to app app § Target Windows desktop, macOS, and Linux § Marriage of Chromium and Node.js § Independent of installed browsers on target machines § Does not need native SDKs to build final artifact § Access to native platform features § Electron API § Node modules ecosystem § Auto-updating and platform deployment available Desktop applications with Electron 32

Action ASP.NET Web API 33

Action § ASP.NET Web API technology stack • Based on OWIN § Derive from ApiController § Implement your actions • Actions map to HTTP methods • Prefix method name with desired HTTP method – e.g. PostComment • Use [HttpGet/Post/Put/Delete] if you prefer a different name • Supports async with Task<T> § Actions expose explicit DTO data, HttpResponseMessage or JsonValue / dynamic Implementing a Web API 34

Action § Several hosting options, e.g. • ASP.NET Web Application (IIS) • Self-host server option (console application, Windows service, etc.) § HttpConfiguration defines behavior § OWIN as base for hosting Web API, SignalR etc. Hosting 35

Action § Maps a URL space to your Web API controllers • {controller} + “Controller” § Can be tailored using actions, default values and route constraints • Like more RPC-ish behavior § Alternative: attribute-based routing • Defines routes with .NET attributes Routing 36

Action § “First class experience” for using HTTP • exposing HTTP as an application protocol in its full glory and not hiding it § Use of HttpRequestMessage and HttpResponseMessage • way of giving direct access to the HTTP protocol, without parsing and encoding complexity § Use IHttpActionResult • Better testability; pre-defined action results Working with HTTP 37

Action § Model binding can “shred” the request and bind it to individual parameters § Values are taken from the URL (route variables, query parameters) or from the body § MediaTypeFormatters are used to deserialize the request body based on the content type • XML, JSON, form-url-encoded supported out of the box § Request data is validated as it is bound to the parameters Model Binding & Formatters 38

Action § Response format is determined based on HTTP content negotiation § Request Accept header expresses desired format(s) § Server selects a format for the response based on the request and the available MediaTypeFormatters § Help/documentation page optionally available at /help § Use Swagger for open documentation standard Content Negotiation 39

Action ASP.NET SignalR 40

Action § ‘Push Services’ are really not an official pattern • Aka Observer pattern § Model a service that • accepts incoming connections from callers • is able to push data down to callers • abstracts from communication nitty-gritty details § Realize Publish-Subscribe semantics • Based on standard web technologies with reach in mind • With maximum reach into any device, platform Push Services Pattern 41 Push Service Consumer Send data External event (Database) External event (Message queue) External event (Other actor) Notify [data]

Action § Periodic Polling § Long Polling • HTTP Streaming / Comet Technical Approaches for Push 42

Action § Poll, but don’t respond untill there’s data § Server holds on to the HTTP request until there is data to return § (Re-)Poll after data received or after the connection times out § Consumes server threads & connection resources Long Polling 43 Server Client

Action § Periodic Polling § Long Polling § Forever Frame § Server-Sent Events (SSE) § Web Sockets • Only with Windows 8/Server 2012 • Network considerations § Alright, let’s just write code for any technology & technique! • For any server and any client platform? Technical Approaches for Push 44

Action § SignalR is • a server-side framework to write push services • a set of client libraries to make push service communication easy to use on any platform • optimized for asynchronous processing § Abstracts from the different techniques to implement pushing data • Mental model is a persistent connection • Volatile, non-durable § ‘Signal’, anyone? • Sending data to a signal. E.g. represented by a connection ID § Part of the ASP.NET brand, but not tied into ASP.NET runtime and APIs ASP.NET SignalR as a Solution 45

Action § Extensible framework & pipeline • Based on interfaces & DI § Two programming models • Persistent connections • Hubs § Hubs offer a pre-defined application-level protocol in an RPC-ish style • Easy-to-get-going means for 80/20 situations ASP.NET SignalR Development 46

Action § Hubs are classes to implement push services in SignalR • Abstraction on top of persistent connection • Convention-over-configuration § Hubs provide a higher level RPC framework • Perfect for different types of messages to send between server and client § Hub conventions • Public methods are callable from the outside • Send messages to clients by invoking client-side methods § Simple steps to get going • Write hub class • Add route in host process • Done Hubs Concept 47

Action § Hub name reflected into external API • [HubName] can alias name § Return simple type, complex type or Task § Complex objects and arrays of objects automatically serialized/deserialized to/from JSON • Default is JSON.NET § Context holds connection- and request-specific information • ConnectionId • Request • Headers • RequestCookies • QueryString • User Programming Model 48

Action § Clients property as dispatching point to send messages to clients § Holds dynamic properties and methods § Target method with parameters is dynamically ‘injected’ into code path, serialized, and embedded into response Pushing Data: Clients 49 public void SendMessage(string message) { var msg = string.Format("{0}: {1}", Context.ConnectionId, message); Clients.All.newMessage(msg); }

Action § Consumers can be classic client applications or other services/hubs § SignalR provides a variety of client libraries § Microsoft SignalR team • .NET 4.0+ • WinRT • Windows Phone 8 • Silverlight 5 • jQuery • C++ § Community • iOS native • iOS, Android via Xamarin Hub Consumers 50

Action § HTML5-based applications often use jQuery § JSON-based wire protocol makes it easy to integrate with JavaScript § SignalR jQuery plugin offers two approaches • Proxy-based with generated proxy • Without proxy but ‘late binding’ jQuery Client 51

Action § Late binding approach § Simple steps to get going • Create hubConnection • Derived from $.connection • Get dynamic proxy • Wire up events based on method/event handler name via on • Start & invoke methods based on method name via invoke § Same connection-related event handlers § Cross-domain support same as with static proxy jQuery without Proxy File 52 var connection = $.hubConnection(); var proxy = connection.createHubProxy('chat'); proxy.on('newMessage', onNewMessage); connection.start(); proxy.invoke('sendMessage', $('#message').val());

Action § Client NuGet package contains binaries for all supported .NET flavors § Mental model resembles proxy-less JavaScript approach § Simple steps to get going • Create HubConnection • Create hub proxy via CreateHubProxy • Wire up event handlers via On • Start connection with Start • Call methods via Invoke .NET Client 53 var hubConnection = new HubConnection("http://localhost/services"); var chat = hubConnection.CreateHubProxy("chat"); chat.On<string>("newMessage", …); hubConnection.Start().Wait(); …

Action § Hosting sits on top of OWIN • IAppBuilder API § Simple steps to get going • Define startup class with IAppBuilder method signature • Map hubs onto IAppBuilder (routing) Hosting 54

Action § Demo application § https://github.com/thinktecture/apisummit-2016-angular2-webapi § Contact § [email protected] § @christianweyer Thank you! 55

Action § Christian Weyer über leichtgewichtige Architekturen und Angular 2 § https://entwickler.de/online/web/service-architektur-angular-2-302663.html Xamarin, Angular oder Cordova? Erstmal die passende Service-Architektur! 56
