Watson & PHP Inventory Integration Clark Everetts, Rogue Wave Software

So, who is this guy? • Clark Everetts • Rogue Wave Software (acquired Zend 2015) • PHP since 2005 • Zend Certified Engineer • Professional Services Consultant • Architecture & Performance Audits • PHP, Zend Framework Training • Zend Server • App Development, Best Practices • Many moons ago: missile launch control, space station embedded software • [email protected] • @clarkphp on Twitter • +ClarkEveretts on Google+

The Premise – My end goal • Can you find how much of your inventory is on hand or allocated? • Which product lines your customers are buying, and in what volume? • Hands-free? • How can Watson services help you: • understand how much stock is available • who is buying and selling it • spot trends • Key concepts and points: • speech-to-text • text-to-speech • interactive application on IBM i • powered by Watson in the cloud • data residing on your IBM i

© 2017 Rogue Wave Software, Inc. All Rights Reserved. 4
Machine Learning Use-Case: Code Quality Higher quality libraries are • Easier to understand • Easier to maintain • Easier to test • Get updated sooner • Bugfixes • New features • Don’t break as easily or as often • Greater interest/participation from dev team and users *Campbell County Kentucky Public Library

© 2017 Rogue Wave Software, Inc. All Rights Reserved. 5
Code Quality: Cognitive vs. Static Analysis • PHPLOC – size metrics, complexity, dependencies, structure – https://github.com/sebastianbergmann/phploc • Copy/Paste Detector – finds duplicated code (exact dups) – https://github.com/sebastianbergmann/phpcpd • PHP Depend - – https://pdepend.org/ • PHP Mess Detector – https://phpmd.org/ • Phan – https://github.com/phan/phan • Exakat – https://www.exakat.io/ • PHPMetrics – http://www.phpmetrics.org/

BIRT Sample Database BIRT – Business Intelligence Reporting Tools Eclipse Project, has an interesting sample database Classic marine, car, truck, and train models. DB Tables: Offices Employees Customers Orders Payments Order Details Products Product Lines

#COMMONF17 BIRT Database Schema

IBM Bluemix Cloud https://console.bluemix.net/ (login with IBM id) Stay informed!! https://www.ibm.com/blogs/bluemix/

IBM Cloud Catalog Categories Infrastructure Compute Storage Network Security Containers VMware Platform Boilerplates APIs Application Services Blockchain Cloud Foundry Apps Data & Analytics DevOps Finance Functions Integrate Internet of Things Mobile Network Security Storage Watson

IBM Cloud Catalog: Watson

Choosing the right services • Several related / overlapping services • Need good understanding • Application • functionality, scope, breadth, depth • Nature of data • static / dynamic • structure /contents • size • Watson services • what each provides, & doesn’t • setup, (re)training, update • initial and ongoing cost

IBM Cloud Catalog: Watson

Challenges • Unstructured speech to structured db queries • Correctly parsing the resulting text • Building correct SQL query from text • Knowing when not to attempt a query Question: “Who are my customers?” Appropriate Query: Select customerName from Customers join Employees on salesrepEmployeeNumber = employeeNumber where salesrepEmployeeNumber = X; • Intention, Context, Memory • Q1. Who are my customers? (company name or point of contact) • Q2. Where are they located? (city, state, province, sales region, country?) • Q3. Who has not ordered in three months? “my” (authenticated user?), “they” (results of Q1), “who” (results of Q1, not Q2)

Text-to-Speech: Overview • Quickly converts written text to natural-sounding speech • Voice-driven and screenless interfaces • Anywhere where audio is the preferred method of output • home automation solutions • assistance tools for the vision-impaired • reading text and email messages aloud to drivers • video script narration and voice over • reading-based educational tools

Text-to-Speech: Features • HTTP and WebSocket interfaces • SSML (Speech Synthesis Markup Language) • Audio formats • Ogg format with Opus or Vorbis codec • Waveform Audio File Format (WAV) • Free Lossless Audio Codec (FLAC) • MP3 (Motion Picture Experts Group, or MPEG) • Web Media (WebM) with the Opus or Vorbis codec • Linear 16-bit Pulse-Code Modulation (PCM) • mu-law (u-law) • basic audio • Languages • English, French, German, Italian, Japanese, Spanish, and Brazilian Portuguese

Text-to-Speech: Features (cont’d) • Voices - • one male or female voice, sometimes both, for each language • US and UK English and Castilian, Latin American, North American Spanish • uses appropriate cadence and intonation • Expressiveness • Add’l SSML element to indicate a speaking style • GoodNews, Apology, Uncertainty • currently US English Allison voice only • Voice transformation • pitch, rate, timbre • built-in transformations for “young” and “soft” • Customization of pronunciation • International Phonetic Alphabet (IPA) • IBM Symbolic Phonetic Representation (SPR) • Text-to-speech demo https://text-to-speech- demo.mybluemix.net/

Text-to-Speech: Initial Test <?php namespace ClarkPhp\WatsonDemo; use GuzzleHttp\Client; use Zend\Diactoros\Request; use Zend\Diactoros\Uri; use Zend\Diactoros\Response; require __DIR__ . '/../vendor/autoload.php'; require __DIR__ . '/../src/classic-models.php'; call_user_func(function () { $config = getConfig()['text-to-speech']; $client = new Client(); $request = (new Request()) ->withUri((new Uri("{$config['uri']}/synthesize")) ->withQuery('voice=en-US_AllisonVoice')) ->withMethod('POST') ->withAddedHeader('Authorization', 'Basic ' . base64_encode("{$config['username']}:{$config['password']}")) ->withAddedHeader('Content-Type', 'application/json') ->withAddedHeader('Accept', $config['mime_type']);

Text-to-Speech: Initial Test (cont’d) $request->getBody()->write( json_encode(['text' => 'Customer requested special shipment. The instructions were passed along to the warehouse.']) ); $response = $client->send($request); // send to Watson // send audio output back to web browser header("Content-Type: {$config['mime_type']}"); header('Content-Disposition: inline; filename=result.ogg'); header('Content_Length: ' . strlen($response->getBody())); print $response->getBody(); });

Application Configuration <?php return [ 'text-to-speech' => [ 'mime_type' => 'audio/ogg;codecs=opus', 'uri' => 'https://stream.watsonplatform.net/text-to-speech/api/v1/', ], 'speech-to-text' => [ 'mime_type' => 'audio/ogg;codecs=opus', 'uri' => 'https://stream.watsonplatform.net/speech-to-text/api/v1', ], 'db' => [ 'I71EDU' => [ 'options' => [ 'autocommit' => DB2_AUTOCOMMIT_OFF, 'DB2_ATTR_CASE' => DB2_CASE_NATURAL, 'cursor' => DB2_FORWARD_ONLY, 'i5_lib' => 'CLARK', 'i5_naming' => DB2_I5_NAMING_OFF, 'i5_query_optimize' => DB2_ALL_IO, ], ], ], ];

Credentials Configuration <?php return [ 'text-to-speech' => [ 'username' => ‘a-big-long-obfuscated-hash', 'password' => ‘a-secret-hash' ], 'speech-to-text' => [ 'username' => ' another-obfuscated-hash', 'password' => ' another-secret-hash' ], 'db' => [ 'I71EDU' => [ 'userprofile' => ‘my-user-name', 'password' => ‘my-password' ], ], ]; Keep auth credentials out of source code repository by putting them in a separate file, and mark that file to be ignore by version control.

Merged Configuration function getConfig() { return array_merge_recursive( require_once __DIR__ . '/../config/config.php', require_once __DIR__ . '/../config/credentials.php' ); } Calling the above yields the following merged configuration: [ 'text-to-speech' => [ 'mime_type' => 'audio/ogg;codecs=opus', 'uri' => 'https://stream.watsonplatform.net/text-to-speech/api/v1/', 'username' => ‘a-big-long-obfuscated-hash', 'password' => ‘a-secret-hash‘ ], 'speech-to-text' => […], 'db' => […] ]

Text-to-Speech: Product Description call_user_func(function () { $config = getConfig(); $db = getDbConnection($config); $productDesc = getRandomProductDescription($db); $client = new Client(); $request = (new Request()) ->withUri((new Uri("{$config['text-to-speech']['uri']}/synthesize"))- >withQuery('voice=en-US_AllisonVoice')) ->withMethod('POST') ->withAddedHeader( 'Authorization', 'Basic ' . base64_encode("{$config['text-to- speech']['username']}:{$config['text-to-speech']['password']}") )->withAddedHeader('Content-Type', 'application/json') ->withAddedHeader('Accept', $config['text-to-speech']['mime_type']);

Text-to-Speech: Product Description (cont’d) $request->getBody()->write( json_encode(['text' => $productDesc ?: 'I was unable to access any product description.']) ); $response = $client->send($request); header("Content-Type: {$config['text-to-speech']['mime_type']}"); header('Content-Disposition: inline; filename=result.ogg'); header('Content_Length: ' . strlen($response->getBody())); print $response->getBody(); });

Quick Demo

Speech-to-Text: Overview • Converts human voice into the written word • Potential uses • voice control of embedded systems • transcription of meetings and conference calls • dictation • Combines information about grammar and language structure with knowledge of the composition of the audio signal to generate a transcription • Languages: US and UK English, Japanese, Arabic, Mandarin, Portuguese, Spanish, French, Localized version available in Japan via SoftBank • Metadata object in JSON response • confidence score (per word), start/end time (per word), and alternate hypotheses / N-Best (per phrase), word alternatives per (sequential) time intervals • Keyword Spotting (beta) • search for keywords in audio stream. Begin/end times, confidence score for each instance of the keyword found

Speech-to-Text: Overview (cont’d) • Mobile SDKs (beta) for iOS and Android • Optional metadata in JSON response includes • confidence score (per word), start/end time (per word), alternate hypotheses / N-Best (per phrase). alternatives per (sequential) time interval • Keyword search in audio stream • beginning and end times • confidence score for each instance found • currently available at no additional charge

Speech-to-Text: Available Interfaces • WebSocket • single version of recognize method for transcribing audio • easy implementation, low latency, high throughput over a full- duplex connection • HTTP REST • HTTP POST versions of recognize method for transcribing audio with or without establishing a session with the service • Accept input audio via • request body • multipart form data consisting of one or more audio files • Can establish and maintain sessions with the service • Obtain information about supported languages and models

Speech-to-Text: Available Interfaces • Asynchronous HTTP • Provides a non-blocking POST recognitions method • Additional methods let you register a callback URL, to which the service sends job status and optional results or to check the status of jobs and retrieve results manually • Uses HMAC-SHA1 signatures based on a user-specified secret to provide authentication and data integrity for callback notifications

Speech-to-Text: First Attempt What I said: Hello! This is Clark Everetts with Rogue Wave Software. I’m unable to take your call at the moment, but if you leave your name, telephone number, and a brief message, I’ll return your call as soon as possible. Thank-you! What I got: hello this is or ever will when software mama unable to halt the moment but if you leave your home telephone number and message of return your call as soon as possible and

Speech-to-Text: Alternatives “ … as soon as possible and “ (selected with highest confidence of 0.628) “ … as soon as possible “ “ … as soon as possible are “ "alternatives": [ { "timestamps": [ [ "hello", 0.13, 0.56 ], [ "this", 0.59, 0.76 ], [ "is", 0.76, 0.98 ], [ "or", 1.02, 1.3 ], [ "ever", 1.33, 1.64 ],

Speech-to-Text test: Code <?php namespace ClarkPhp\WatsonDemo; use GuzzleHttp\Client; use Zend\Diactoros\Request; use Zend\Diactoros\Uri; use Zend\Diactoros\Response; require __DIR__ . '/../vendor/autoload.php'; require __DIR__ . '/../src/classic-models.php'; /** * Self-called anon. function to create its own scope and keep global namespace clean. */ call_user_func(function () { $config = getConfig(); $config = $config['speech-to-text']; $client = new Client();

Speech-to-Text test: Code (cont’d) $request = (new Request()) ->withUri((new Uri("{$config['uri']}/recognize")) ->withQuery('timestamps=true&max_alternatives=3&inactivity_timeout=1')) ->withMethod('POST') ->withAddedHeader('Authorization', 'Basic ' . base64_encode("{$config['username']}:{$config['password']}")) ->withAddedHeader('Content-Type', 'audio/flac') ->withAddedHeader('Accept', 'application/json'); $request->getBody() ->write(file_get_contents(__DIR__ . '/../docs/telephone-greeting.flac')); $response = $client->send($request); print('<pre>'); printf("Response status: %d (%s)\n", $response->getStatusCode(), $response->getReasonPhrase() ); printf("Headers:\n"); foreach ($response->getHeaders() as $header => $values) { printf(" %s: %s\n", $header, implode(', ', $values)); } printf("Message:\n%s\n", $response->getBody()); print '</pre>'; });

Watson Conversation: Overview • Natural language interface backend for any application • Natural conversation flows between your applications and users • Automate interactions with end users • Common applications • virtual agents • chat bots • Trainable through web application, import of CSV files, or web API

Conversation: Where to get help

Watson Conversation: Intents • Purpose or goal expressed in a customer's input • answering a question • placing an order • processing a bill payment • cancelling a process • turning something on • turning something off • Watson recognizes the intent expressed in input • Uses intent to choose appropriate dialog flow for responding to it

Watson Conversation: Intents (cont’d) • Train Watson with minimum of five example statements • More is better • Best case: real user statements or questions for examples of intent • Not necessary for examples to work with the same aspect of your system; the important thing is they express intent • Example: finding the location of something (#location intent) • Customers, Employees, and Offices have locations • Employees are associated with Office location. • Where is customer Atelier graphique? • Where is customer Dragon Souveniers located? • What city is customer Diecast Classics headquartered in? • Customer Herkku Gifts is located where? • The location of William Patterson is where? • Find Mary Patterson? • What is the location of Julie Firrelli?

Watson Conversation: Entities • Represent a class of object or a data type relevant to a user's purpose • Recognizes entities mentioned in the user's input • Conversation service uses entities to choose the specific actions to take to fulfill an intent. • Entities clarify a user's intent. • Different entity values trigger different responses for the same intent. • Entities for which there is a location: • Employees • Diane Murphy • Mary Patterson, … • Customers • Technics Stores Inc. • Herkku Gifts…

Conversation Dialog Flow

Conversation Dialog Flow (cont’d)

Testing Conversation Flow

Where to go from here? • Next Phase • Improve recognition of Speech-to-Text • Using spotted key words, parse text files and build SQL queries? • Add more to Conversation instance, for workflow and context, and “flow” to appropriate action, driving appropriate DB2 queries • Use API to build and modify Conversation Dialog • Follow-on research • Natural Language Processing • Trend analysis, perhaps unexpected correlations (probably need more realistic data and a much larger data set) • Other Watson services

THANK-YOU! [email protected] @clarkphp +ClarkEveretts Stay in touch! Your feedback is invaluable. Source code at https://github.com/clarkphp/watson-classic-models
