Orestes Carracedo_Google Assistant's Smart Home API in practice_Codemotion Madrid 2019

24-25 September, 2019

Google Assistant’s Smart Home API in practice Orestes Carracedo 24-25
September, 2019

@OrestesCA #CodemotionMadrid19

@OrestesCA #CodemotionMadrid19 vigo

@OrestesCA #CodemotionMadrid19 ESP8266 WeMos / LOLIN D1

@OrestesCA #CodemotionMadrid19 AdaFruit’s NeoPixels WeMos / LOLIN D1

@OrestesCA #CodemotionMadrid19 Hardware Software

@OrestesCA #CodemotionMadrid19 • Easy to test in isolation • Easy
to test without Internet curl -X POST http://192.168.43.231/state \ -H 'Content-Type: application/json' \ -d '{ "on": true }' IoT device API Client HTTP

@OrestesCA #CodemotionMadrid19 Google Home/Mobile device The Google Assistant — Actions
on Google —

@OrestesCA #CodemotionMadrid19 Madrid Flip Flop Madrid

@OrestesCA #CodemotionMadrid19 • •

@OrestesCA #CodemotionMadrid19 • • • • • •

@OrestesCA #CodemotionMadrid19 • • • • • • • •
• • turn the temperature up set the light color red

@OrestesCA #CodemotionMadrid19 turn off light off one Home Graph Provider

@OrestesCA #CodemotionMadrid19 Provider Intent

@OrestesCA #CodemotionMadrid19 Provider

@OrestesCA #CodemotionMadrid19 • • • •

@OrestesCA #CodemotionMadrid19 • user • { "requestId": "ff36a3cc-ec34-11e6-b1a0-64510650abcf", "inputs": [{
"intent": "action.devices.QUERY", } ] }

@OrestesCA #CodemotionMadrid19 IoT project Actions on Google Provider Integration HTTP
HTTP

@OrestesCA #CodemotionMadrid19 smart-home

@OrestesCA #CodemotionMadrid19 login token

@OrestesCA #CodemotionMadrid19 • • •

@OrestesCA #CodemotionMadrid19 user id

@OrestesCA #CodemotionMadrid19 roomHint

@OrestesCA #CodemotionMadrid19 { "requestId": "ff36a3cc-ec34-11e6-b1a0-64510650abcf", "inputs": [{ "intent": "action.devices.SYNC" }]
}

@OrestesCA #CodemotionMadrid19 { "devices": [ { "id": "light-one", "type": "action.devices.types.LIGHT",
"traits": [ "action.devices.traits.OnOff", "action.devices.traits.Brightness", "action.devices.traits.ColorSetting" ], "name": { "name": "RGB LED one", "nicknames": [ "RGB LED one" ] }, "attributes": { "colorModel": "rgb", "commandOnlyColorSetting": true }, ...

@OrestesCA #CodemotionMadrid19 • • turn the temperature up set the
light color red

@OrestesCA #CodemotionMadrid19 … "intent": "action.devices.EXECUTE", "payload": { "commands": [ {
"devices": [ { "customData": {}, "id": "light-one" } ], "execution": [ { "command": "action.devices.commands.BrightnessAbsolute", "params": { "brightness": 97 } } ]

@OrestesCA #CodemotionMadrid19 response: { "requestId": "14264271937916360852", "payload": { "commands": [
{ "ids": [ "light-one" ], "status": "SUCCESS" } ] } }

@OrestesCA #CodemotionMadrid19 authExpired deviceNotFound

@OrestesCA #CodemotionMadrid19 body: { "inputs": [ { "intent": "action.devices.QUERY", "payload":
{ "devices": [ { "id": "light-one" } ] } } ], "requestId": "10851261056524166135" }

@OrestesCA #CodemotionMadrid19 response: { "requestId": "10851261056524166135", "payload": { "agentUserId": "user-123",
"devices": { "light-one": { "online": true, "on": true, "brightness": 80, "color": { "name": "apricot", "spectrumRGB": 16502449 } } } } }

@OrestesCA #CodemotionMadrid19 https://homegraph.googleapis.com/v1/devices:requestSync

@OrestesCA #CodemotionMadrid19 API Key curl -X POST \ -H "Content-Type:
application/json" \ -d "{agent_user_id: \"user-123\"}" \ "https://homegraph.googleapis.com/v1/devices:requestS ync?key=AIzaSyD8CdkTXJhUSQzOeGBf8NxDqFFQq_w6rfE"

@OrestesCA #CodemotionMadrid19 Service Account https://homegraph.googleapis.com/v1/devices:reportStateAndNotification

@OrestesCA #CodemotionMadrid19 • User interaction outside of Actions on Google
• • •

@OrestesCA #CodemotionMadrid19 • •
