"Running a tight ship": A security model for Docker environments

With the continuing success of the Docker engine containers are increasingly moving from build chains into production environments. So it’s high time to assess the current state of security of one’s container environment. Luckily the Docker eco system is beginning to provide more and more tools to deploy security measures – some of the them being already active per default. At the same time several pitfalls exist that could lead to a vulnerable environment.

The talk aims to present a security model covering multiple layers from building images, to the Docker host and daemon, and up to containers at runtime while focusing on the knobs and levers for building a secure system.

Transcript

1. © 2016 Cassini Consulting Dustin Huptas „Running a tight ship“: A security model for Docker environments Berlin, February 5, 2016
2. Disclaimer This is not a hacker talk and I am not one. I left out networking as it would require a separate talk. There is no silver bullet. At Least not one. https://www.flickr.com/photos/12587661@N06/2300406685
3. 3 06.02.16 Cassini Consulting Cassini consulting #devops #linux#configmgt#security #virtualization#Containers #networking#ipv6 Dustin Huptas @dhpts System Architecture, Networking, Security, Dev‘ingthe Ops
4. READY FOR TAKEOFF?
5. Development of Docker and security since 2013 „Docker containers can haz networking now!“ Remote API Container Breakout PoC Authorization Bypass on Docker Hub Docker Hub Outage CVE-2014- 8178/8179 Challenges Websockets Official Repos / Docker Hub Docker 1.3.3/1.4.0: Security Fixes Docker Security Bench Trusted Registry Content Trust Improvements 2013 2014 2015
6. Development of Docker and security since 2013 „Docker containers can haz networking now!“ Remote API Container Breakout PoC Authorization Bypass on Docker Hub Docker Hub Outage CVE-2014- 8178/8179 Challenges Websockets Official Repos / Docker Hub Docker 1.3.3/1.4.0: Security Fixes Docker Security Bench Trusted Registry Content Trust Improvements 2013 2014 2015 Docker vs. Security Docker and Security
7. Build Chain Registry Docker Host Docker Daemon Push PULL 3 2 1 4
8. Build Chain 1
9. Latest& Greatest PinnedVersions vs.
11. Two ways to create your own base images TAR’ing convert image to tarball docker import <tarball> Install user land in a local directory install OS image in VM and clean up OR appliance-creator debootstrap
12. configuration management? credentials in images? credentials in ENV variables?
13. Only encrypted credentials in (data) containers key/value stores Agent injected ENV credentials
14. Registry 2
18. Content trust and notary Source: https://docs.google.com/document/d/1Xn9kuhICOFj_P37ZWng8LeR_32NAj4Ytm42XAVWuTHw/edit#
19. Content trust and notary Source: https://docs.google.com/document/d/1Xn9kuhICOFj_P37ZWng8LeR_32NAj4Ytm42XAVWuTHw/edit# notary server checks signatures of meta data based on The Update Framework (TUF) signatures of Docker image hashes are verified
20. Content trust and notary Unsigned images Local notary server and signing steps: https://github.com/de-wiring/ix/tree/master/023_registries
21. Content trust and notary Signed images root@debian-jessie:~# env DOCKER_CONTENT_TRUST=1 docker pull dewiring/trustit:latest Pull (1 of 1): dewiring/trustit:latest@sha256:c58ee9f9d1b1a0b59471cac2c089ac995dd559949ee088533fc6f 4a0dcd2719f sha256:c58ee9f9d1b1a0b59471cac2c089ac995dd559949ee088533fc6f4a0dcd2719f: Pulling from dewiring/trustit 2c49f83e0b13: Already exists 4a5e6db8c069: Already exists 88ab9df21bce: Already exists 2c900b53c032: Already exists 8d86df29cb44: Already exists Digest: sha256:c58ee9f9d1b1a0b59471cac2c089ac995dd559949ee088533fc6f4a0dcd2719f Status: Downloaded newer image for dewiring/trustit@sha256:c58ee9f9d1b1a0b59471cac2c089ac995dd559949ee088533fc6f4a0dcd2 719f Tagging dewiring/trustit@sha256:c58ee9f9d1b1a0b59471cac2c089ac995dd559949ee088533fc6f4a0dcd2 719f as dewiring/trustit:latest
22. Docker HOST Local Images 3
23. Hardening the host itself GRSecurity Audit daemon SELinux and AppArmor
24. Docker Daemon 4
25. Docker Daemon § The daemon runs as user root. § The API is extensive with a lot of functionality. § Docker offers authentication but no authorization when using the API. Docker 1.10 just made the authorization plugin feature available. § Having access to the API grants far-reaching capabilities similar to the root account.
26. Isolate the daemon (e.g. SELinux, AppArmor) Enable auditing Define access paths to API
27. [root@localhost ~]# rpm -qa|grep docker docker-1.8.2-1.gitf1db8f2.fc22.x86_64 docker-selinux-1.8.2-1.gitf1db8f2.fc22.x86_64 [root@localhost ~]# ps -efZ|grep docker system_u:system_r:docker_t:s0 root 870 1 0 16:16 ? 00:00:00 /usr/bin/docker -d --selinux-enabled [root@localhost ~]# ps -efZ |grep svirt_lxc_net_t system_u:system_r:svirt_lxc_net_t:s0:c178,c327 root 1074 870 0 16:17 pts/1 00:00:00 /bin/bash
28. root@vagrant-ubuntu-vivid-64:/etc/apparmor.d# apparmor_status apparmor module is loaded. 6 profiles are loaded. 6 profiles are in enforce mode. /sbin/dhclient /usr/lib/NetworkManager/nm-dhcp-client.action /usr/lib/NetworkManager/nm-dhcp-helper /usr/lib/connman/scripts/dhclient-script /usr/sbin/tcpdump docker-default 0 profiles are in complain mode. 2 processes have profiles defined. 2 processes are in enforce mode. /sbin/dhclient (549) docker-default (2923) 0 processes are in complain mode. 0 processes are unconfined but have a profile defined. root@vagrant-ubuntu-vivid-64:/etc/apparmor.d# ps -efZ|grep docker unconfined root 2684 1 0 15:46 ? 00:00:03 /usr/bin/docker -d -H fd:// docker-default root 2923 2684 0 15:52 pts/1 00:00:00 /bin/bash
29. Restricting access to the API? (1) Make Docker API accessible via socket file § Limit permissions of the socket § Make sure no user is part of the Docker group § Access across host boundaries via SSH (2) Allow Docker API via network § TLS certificates, server- and client-side § Distribute public keys § Disable socket (3) Agent-based approach § E.g. via socket or TLS (only on local network interface) § Agent proxies access to API § Agent provides own API to implement authorization socket network agent (4) Authz Plugin § Create one or multiple authorization plugins to the Docker daemon § Available since Docker 1.10 (aka yesterday!) authz
30. ContainerS @runtime 5
31. A few essential steps to improve security for your Docker containers § Don’t run containers as user root (use USER directive in Dockerfile, -u/--user). § Don’t run as --privileged. § Use --volume and --device read-only if possible, use --read-only, if useful. § Only EXPOSE ports that are necessary. § Set up container native logging and monitoring. --userns-remap
32. User Namespaces Capabilities CGroups SELinux & AppArmor Seccomp
33. User Namespaces Capabilities CGroups SELinux & AppArmor Seccomp
34. Testing
35. Docker Security Benchmark § Detailed guide for hardening Docker hosts, daemon, images and containers § Includes test routines § benchmarks.cisecurity.org § Tools for automation are available
36. Automated security checks
37. Automated security checks
38. Automated security checks
39. Hardening remains an important topic – and it’s necessary for containers as well. Docker helps to improve the security level of application processes. "UI for security" Things are work in progress. Luckily things are moving forward.
40. Q & A
41. Recommended reading § http://securedocker.org/news/ § https://news.ycombinator.com/item?id=10927043 § https://github.com/meltwater/secretary § https://github.com/mozilla/sops § https://www.conjur.net § https://www.vaultproject.io § https://github.com/asteris-llc/vaultfs § https://github.com/GDSSecurity/Docker-Secure-Deployment-Guidelines § https://docs.google.com/document/d/1Xn9kuhICOFj_P37ZWng8LeR_32NAj4Ytm42XA VWuTHw § https://github.com/docker/notary § https://docs.docker.com/registry/deploying/ § https://integratedcode.us/2015/10/13/user-namespaces-have-arrived-in-docker/ § https://jaxenter.com/docker-and-security-how-do-they-fit-together-122333.html § https://github.com/de-wiring/docker-selinux-playground/blob/master/docs/README.md § https://github.com/de-wiring/tests-docker-hardening § https://github.com/de-wiring/puppet-docker-hardening
42. Docker security history Challenges § https://blog.docker.com/2013/03/docker-containers-can-haz-networking-now/ § https://blog.docker.com/2013/04/list-of-publicly-available-docker-images/ § https://blog.docker.com/2013/05/new-registry-goes-live/ § https://blog.docker.com/2013/06/docker-0-4-remote-api-build-openstack-integration/ § https://blog.docker.com/2014/06/docker-container-breakout-proof-of-concept-exploit/ § https://groups.google.com/forum/#!msg/docker-dev/F8LLeAZhiYE/RmlGPNcouXAJ § https://blog.docker.com/2014/08/disclosure-of-authorization-bypass-on-the-docker-hub/ § https://groups.google.com/forum/#!topic/docker-user/IrjXTHA6jJc § https://www.docker.com/docker-cve-database(CVE-2014-6407, CVE-2014-6408) § https://blog.docker.com/2015/01/docker-hub-jan-5-outage/ § https://blog.docker.com/2015/10/security-release-docker-1-8-3-1-6-2-cs7/ (CVE-2014-8178, CVE-2014-8179) Improvements § https://blog.docker.com/2013/07/docker-0-5-0-external-volumes-advanced-networking-self-hosted-registry/ § https://blog.docker.com/2013/08/containers-docker-how-secure-are-they/ § https://blog.docker.com/2013/08/websockets-dockerfile-upgrade-better-registry-support-expert-mode-and-more/ § https://blog.docker.com/2013/11/introducing-trusted-builds/ § https://blog.docker.com/2014/02/docker-and-security/ § https://blog.docker.com/2014/06/announcing-docker-hub-and-official-repositories/ § https://blog.docker.com/2014/07/new-dockercon-video-docker-security-renamed-from-docker-and-selinux/ § https://blog.docker.com/2014/10/docker-1-3-signed-images-process-injection-security-options-mac-shared-directories/ § https://blog.docker.com/2014/12/advancing-docker-security-docker-1-4-0-and-1-3-3-releases/ § https://blog.docker.com/2015/03/secured-at-docker-diogo-monica-and-nathan-mccauley/ § https://blog.docker.com/2015/05/understanding-docker-security-and-best-practices/ § https://blog.docker.com/2015/05/docker-security-tools/ § https://blog.docker.com/2015/07/new-tool-v1-registry-docker-trusted-registry-v2-open-source/ § https://blog.docker.com/2015/08/docker-1-8-content-trust-toolbox-registry-orchestration/ § https://blog.docker.com/2015/08/content-trust-docker-1-8/
