Event Streaming Rises

Apache Kafka를 비롯한 분산 로그 기술의 배경에 있는 아이디어들에 대해서: 전통적인 아키텍처에는 어떠한 문제가 있고, Event Streaming이라는 패러다임의 도입은 어떻게 이 문제들을 해결할 수 있는가?
2020년 1월 21일, Furiosa AI 에서 발표.

About the ideas in the background of distributed log technology, e.g., Apache Kafka: the problems of traditional architectures & how event streaming (with Log as a primary programming model) approaches these problems?
Presented at Furiosa AI, a hardware startup developing a high-performance AI inference processor, January 21st, 2020.

Slides: Korean. Presentation: English.

Transcript

1. Event Streaming Rises
   Lee Dongjin | dongjin@apache.org


   View Slide

2. Contents
   ● Background: Modern Enterprise Architecture
   ○ Problems
   ● Event Streaming
   ○ Approaches
   ○ Log
   ● Related Projects
   ● Conclusion


   View Slide

3. Background: Modern Enterprise Architecture
   MS MS
   Application
   Data Integration
   Data Processing


   View Slide

4. Problems: Application Layer
   ● Polyglot Persistence
   ○ ACID Property
   ○ Atomicity or Abortability - but how?
   ● Heterogeneous Distributed Transaction
   ○ cf: Homogeneous Distributed Transaction
   ○ ex: VoltDB, Google Spanner
   ● Limitations of 2PC
   ○ Blocking Protocol
   ○ Not well supported
   Process


   View Slide

5. Problems: Data Integration Layer
   ● ETL: Extract, Transform, Load
   ● Low coverage
   ● Too slow
   ○ Can’t handle real-time data!
   ● Not scalable
   ○ Hard to Extract
   ○ Repeated Load
   ○ Complexity: O(m * n)


   View Slide

6. Problems: Data Processing Layer
   ● All problems in Data Integration Layer
   AND...
   ● Processing Logic = DAG of Processors
   ○ No reliable real-time input / output
   ○ Complex to connect storages
   ■ Schema: Easy to break
   ○ Processor w/ Internal State
   ■ How to recover on failure?
   ● In short: A TOTAL MESS.
   Filter
   Enrich
   Agg


   View Slide

7. Event Streaming
   ● Storage as a Mutable State
   ○ … of final snapshot
   ○ Bound collection of records
   ● Storage as a Sequence of Immutable Events
   ○ … being accumulated
   ○ Unbound collection of immutable events


   View Slide

8. Distributed Transaction w/ Event Streaming (1)
   ● Reactive approach (detects events from & emits events to event store)
   Process
   Event Store
   Storage A Storage B Storage C


   View Slide

9. Distributed Transaction w/ Event Streaming (2)
   ● Process: emits transaction request
   Process
   Event Store
   Storage A Storage B Storage C
   TX 1


   View Slide

10. Distributed Transaction w/ Event Streaming (3)
    ● Storage A: detects transaction request & emits success event on A
    Process
    Event Store
    Storage A Storage B Storage C
    TX 1 TX 1/A


    View Slide

11. Distributed Transaction w/ Event Streaming (4)
    ● Storage B: detects success event on A & emits success event on B
    Process
    Event Store
    Storage A Storage B Storage C
    TX 1 TX 1/A TX 1/B
    …


    View Slide

12. Distributed Transaction w/ Event Streaming (5)
    ● Storage C: detects success event on B & emits success event on C
    Process
    Storage A Storage B Storage C
    TX 1 TX 1/A TX 1/B
    … … … TX 1/C


    View Slide

13. Distributed Transaction w/ Event Streaming (6)
    ● Process: detects success event on C & emits transaction success
    Process
    Storage A Storage B Storage C
    TX 1 TX 1/A TX 1/B
    … … … TX 1/C TX 1
    …


    View Slide

14. Distributed Transaction w/ Event Streaming (7)
    ● If failure: for example, Storage B emits failure event on B
    Process
    Storage A Storage B Storage C
    TX 1 TX 1/A TX 1/B … TX 1/C TX 1 …
    TX 2 TX 2/A TX 2/B


    View Slide

15. Distributed Transaction w/ Event Streaming (8)
    ● Process: detects failure event on A, B, or C and emits transaction failure
    Process
    Storage A Storage B Storage C
    TX 1 TX 1/A TX 1/B … TX 1/C TX 1
    TX 2 TX 2/A TX 2/B TX 2


    View Slide

16. Distributed Transaction w/ Event Streaming (9)
    ● Storage A, B or C: detects transaction failure, rollbacks transaction
    Process
    Storage A Storage B Storage C
    TX 1 TX 1/A TX 1/B … TX 1/C TX 1
    TX 2 TX 2/A TX 2/B TX 2


    View Slide

17. Conditions for Event Store
    ● Optimized to write
    ● Ordering guarantee
    ○ Read events in stored order
    ● Subscribable
    ● Scalability & Fault tolerance
    Event Store


    View Slide

18. Log: A data structure (1)
    ● Append-only Data Structure
    ○ Log Sequence No. (=id), Payload
    ○ No update or delete
    ● Provides…
    ○ Optimized to write
    ○ Ordering guarantee
    ○ Logical timestamp
    ■ Independent to physical time


    View Slide

19. Log: A data structure (2)
    ● Not seen, but Everywhere
    ○ At the heart of the data system
    ● From Traditional Databases to Distributed Systems
    ○ A Tool to achieve Atomicity and Durability
    ■ Write Ahead Log (WAL), Commit Log, Transaction Log, Replication Log, ...
    ○ A Storage itself
    ■ Log Structured Merge tree
    ■ LevelDB (by Google), RocksDB (by Facebook)
    ■ Google BigTable, HBase HFile, Cassandra SSTable


    View Slide

20. Log as a Distributed Storage (1)
    ● Log as an application programming model
    ○ Append Only
    ○ Sequential Read w/ Subscribing
    ○ Durable
    ● Log as a Distributed Storage
    ○ Scalability by Partitioning
    ■ Partition Count = Maximum
    Parallelism
    ■ Ordering guarantee only in Partition
    ■ Key for partitioning
    ○ Fault Tolerance by Replication
    ■ Maintains multiple copies of each
    partition


    View Slide

21. Log as a Distributed Storage (2)
    ● Implementations
    ○ Apache Kafka (by Linkedin)
    ○ Apache Bookeeper (by Yahoo! Research)
    ○ Apache Pulsar
    ○ CORFU (by Microsoft Research)
    ○ LogDevice (by Facebook)
    ○ AWS Kinesis, GCP Pub/Sub, Azure Event Hub


    View Slide

22. OLEP: OnLine Event Processing
    ● Advantages
    ○ Scalable Distributed Transaction
    ● Limitations
    ○ Eventual Consistency
    ○ Isolation Level
    ■ Read Committed only
    ■ Snapshot Isolation is under research
    P1
    P2 P3
    t1 t2


    View Slide

23. What type of Streams?
    ● Event Stream
    ○ Accumulates events
    ○ A way to communicate between distributed services
    ■ Mainly microservices
    ○ Key for partition assignment (optional)
    ● Update Stream (AKA Changelog stream)
    ○ Represents modification history of a state
    ○ A way to represent the logical state of a storage
    ■ Including (but not restricted to) databases
    ○ Key for record identity (required)
    Update
    Stream
    Event Stream


    View Slide

24. Update Stream (AKA Changelog Stream) (1)
    ● Example
    Key Value
    k1 v1
    Key Value
    k1 v1
    k2 v2
    Key Value
    k1 v1-1
    k2 v2
    Key Value
    k1 v1-1
    (k2, v2) (k1, v1-1) (k2, null)
    State
    Update Stream


    View Slide

25. Update Stream (AKA Changelog Stream) (2)
    ● Stream-Table Duality
    ○ Table → Stream
    ■ All states (including storages) can be represented as a form of update stream
    ○ Stream → Table
    ■ … and Vice Versa
    ■ State as a Materialized View w/ timestamp
    ● Examples
    ○ Replication Log
    ○ CDC (Change Data Capture) feature like Oracle GoldenGate


    View Slide

26. Data Integration with Update Stream (1)
    ● Example: replicating MySQL
    Mysql (original)
    Mysql (replicated)
    Mysql (w/ Index)
    BigQuery
    Changelog


    View Slide

27. Data Integration with Update Stream (2)
    ● Extract once
    ○ w/ Predefined Schema
    ○ w/ Cleansing
    ● Transform as many times you need
    ● Load per storage type
    ● Advantages: Scalable & Real-time!
    Original Storage
    Changelog
    Stream
    Derived Stream
    Destination Storages


    View Slide

28. ● In event-streaming world, the schema of events stored in Log works as a
    contract between different microservices or teams.
    ○ … dislike to RPC world, where API works as a Contract in RPC.
    ● Each devops team that publishes event stream takes the responsibility of
    maintaining the stream Clean and Forward-compatible.
    ● Example: A dedicated service to register, document, evolve, and validate
    schemas
    ○ https://issues.apache.org/jira/browse/AVRO-1124
    Schema as a Contract


    View Slide

29. Machine Replication Principle
    ● “Updating state deterministically based on
    an ordered events”
    ● “A processor with internal state can be
    serialized into changelog, and vice versa.”
    Processor
    w/ State


    View Slide

30. Real-time Data Processing Model w/ Log
    ● Data Processing Task
    ○ A Dag of Processors
    ○ Read from Log, Write to Log
    ● Processor
    ○ Stateless Processor
    ○ Stateful Processor
    ■ Fault Tolerance w/ Internal State
    Changelog
    ■ Crash: Can recover from Changelog!
    Filter
    Enrich
    Aggre
    gation


    View Slide

31. Data Processing Architecture (1)
    ● Lambda Architecture


    View Slide

32. Data Processing Architecture (2)
    ● Kappa Architecture


    View Slide

33. Related Projects: Extract and Load (1)
    ● Kafka Connect
    ○ De-facto Standard
    ○ Supports both of Table → Stream and Stream → Table
    ○ Provides ‘Extract and Load’ functionality (w/ little Transformation)
    ● Brooklin (by Linkedin)
    ○ Provides a generic bridge between heterogeneous Streaming / Storage Systems
    ■ Table → Table, Table → Stream, Stream → Table, Stream → Stream
    ○ Deployed as a dedicated system
    ○ Open-sourced in 2019


    View Slide

34. Related Projects: Extract and Load (2)
    ● Debezium
    ○ Focuses CDC only (Table → Stream)
    ○ Supports MySQL, PostgreSQL, Oracle, SQL Server, MongoDB, Cassandra, ...
    ○ Deployed as Kafka Connect plugin or Embedded Engine
    ● DBLog (by Netflix)
    ○ Focuses CDC only (Table → Stream)
    ○ Supports MySQL and PostgreSQL
    ○ Deployed as a dedicated system
    ○ Planning to be open-sourced in 2020


    View Slide

35. Related Projects: Processing Framework
    ● Approaches
    ○ Real-time MapReduce
    ○ Event-Driven Microservices


    View Slide

36. Related Projects: Processing Framework
    ● Real-time MapReduce
    ○ Spark
    ○ Flink
    ● Event-Driven Microservices
    ○ Kafka Streams
    ○ ksqlDB
    ■ “Streaming application as a Query”


    View Slide

37. Conclusion (1)
    ● Event streaming is a paradigm shift in storing & processing data.
    ● Log is a primary programming model for Event streaming.


    View Slide

38. Conclusion (2)
    ● Log as a primary programming model
    ○ … provides an excellent abstraction for a wide range of problems
    ● Application
    ○ Distributed Heterogeneous Transaction
    ● Data Integration
    ○ Scalable ETL w/ great coverage in real-time
    ● Data Processing
    ○ Stateful processor w/ fault tolerance


    View Slide

39. Conclusion (3)
    ● Traditional concepts in enterprise application are changing
    ○ No boundaries, No orders anymore
    ○ “All processes are just a kind of processor w/ state store interconnected via Log.”


    View Slide

40. … And one more thing (1)
    Distributed Application Database
    Distributed Log Log
    Changelog stream → State Table updates → Materialized
    View
    State per access pattern Table with Index
    State to Changelog Stream Table to Transaction Log
    Log to Log processing WAL to Transaction Log
    processing


    View Slide

41. … And one more thing (2)
    “Any sufficiently advanced distributed
    application is indistinguishable from database.”


    View Slide

42. Questions?


    View Slide

43. References (1)
    ● Jay Kreps, ‘The Log: What every software engineer should know about real-time data's unifying
    abstraction’, Linkedin Engineering, 2013
    ○ https://engineering.linkedin.com/distributed-systems/log-what-every-software-engineer-should-
    know-about-real-time-datas-unifying
    ● Adam Jacobs, ‘The Pathologies of Big Data’, acmqueue volume 7, issue 6, 2009
    ○ https://queue.acm.org/detail.cfm?id=1563874
    ● Martin Kleppmann et al, ‘Online Event Processing’, acmqueue volume 17, issue 1, 2019
    ○ https://queue.acm.org/detail.cfm?id=3321612
    ● O’Neil et al, ‘The log-structured merge-tree (LSM-tree)’, Acta Informatica volume 33, 1996
    ○ https://dl.acm.org/doi/10.1007/s002360050048


    View Slide

44. References (2)
    ● Jeffrey Dean et al, ‘Bigtable: A Distributed Storage System for Structured Data’, Usenix, 2006
    ○ https://research.google/pubs/pub27898/
    ● Jay Kreps, ‘I ♥ Logs: Apache Kafka, Stream Processing, and Real-time Data’, Stanford Seminar, 2014
    ○ https://www.youtube.com/watch?v=SU8LaHLh6Ng
    ● Jay Kreps, ‘Questioning Lambda Architecture’, oreilly.com, 2014
    ○ https://www.oreilly.com/radar/questioning-the-lambda-architecture/
    ● Matthias J. Sax et al, 'Streams and Tables: Two Sides of the Same Coin', Proceedings of the
    international workshop on Real-time business intelligence and Analytics, 2018
    ○ https://dl.acm.org/doi/10.1145/3242153.3242155


    View Slide

45. References (3)
    ● Martin Kleppmann and Jay Kreps, ‘Kafka, Samza and the Unix philosophy of distributed data’, IEEE
    Data Engineering Bulletin 38, 2015
    ○ https://martin.kleppmann.com/2015/12/15/stream-processing-data-engineering-bulletin.html
    ● Haruna Isah et al, ‘A Survey of Distributed Data Stream Processing Frameworks’, IEEE Access volume
    7, 2019
    ○ https://ieeexplore.ieee.org/document/8864052
    ● Samarth Shetty, ‘Streaming Data Pipelines with Brooklin’, Linkedin Engineering, 2017
    ○ https://engineering.linkedin.com/blog/2017/10/streaming-data-pipelines-with-brooklin
    ● Celia Kung, ‘Open Sourcing Brooklin: Near Real-Time Data Streaming at Scale’, Linkedin Engineering,
    2019
    ○ https://engineering.linkedin.com/blog/2019/brooklin-open-source


    View Slide

46. References (4)
    ● Andreas Andreakis and Ioannis Papapanagiotou, ‘DBLog: A Generic Change-Data-Capture
    Framework’, Netflix Technology, 2019
    ○ https://netflixtechblog.com/dblog-a-generic-change-data-capture-framework-69351fb9099b
    ● Jay Kreps, ‘Introducing ksqlDB’, Confluent, 2019
    ○ https://ksqldb.io/


    View Slide
