1. MULTI-THREADING, CONCURRENCY AND ASYNC ON ANDROID @ErikHellman
2. MULTI-TASKING IS REALLY HARD!
3. Consciousness Subconsciousness Everything you’re good at Problem solving
5. RKFBIIRSCBSUSSR
6. RK FBI IRS CBS USSR
7. UNDER THE HOOD…
8. ANDROID MULTI-TASKING Linux Kernel Zygote Task App Task clone() fork()
9. fork() #include <unistd.h>

 void start_new_app() {
 // return process id in parent
 // and 0 in new child
 pid_t new_pid = fork();

 if(new_pid == 0) {
 // Child process init here
 } else {
 // Parent registers new child here
 }
 }
10. JAVA THREADS public void startNewThread() {
 Thread myThread = new Thread(new Runnable() {
 @Override
 public void run() {
 // Do my thing!
 }
 });
 myThread.start();
 }
11. POSIX THREADS #include <pthread.h>

 void *call_from_thread(void *) {
 //do stuff
 return NULL;
 }

 JNIEXPORT void JNICALL
 Java_se_hellsoft_async_Native_start(JNIEnv * env, jobject obj)
 {
 pthread_t t;

 //Launch a thread
 pthread_create(&t, NULL, call_from_thread, NULL);
 } Pointer to function
12. LINUX TASKS // Start new thread
 clone(CLONE_VM | CLONE_FS | CLONE_FILES | CLONE_SIGHAND, 0);

 // Start new process
 clone(SIGCHLD, 0);
13. MULTI-THREADING, CONCURRENCY AND ASYNC OPERATIONS App 1 Main Thread App 1 Main Thread App 1 Main Thread App 1 Main Thread
14. MULTI-THREADING, CONCURRENCY AND ASYNC OPERATIONS App 1 Main Thread App 1 Main Thread App 1 Main Thread App 1 Main Thread Only multi-threading but no concurrency challenges for the developer!
15. MULTI-THREADING Activity IntentService ContentProvider SQLite Database Worker Thread Main Thread
16. MULTI-THREADING Activity IntentService ContentProvider SQLite Database Worker Thread Main Thread Concurrency handled by SQLite
17. CONCURRENCY public class SharedData {
 private long id;
 private String title;
 private String description;

 public String getDescription() {
 return description;
 }

 public void setDescription(String description) {
 this.description = description;
 }

 public long getId() {
 return id;
 }

 public void setId(long id) {
 this.id = id;
 }

 public String getTitle() {
 return title;
 }

 public void setTitle(String title) {
 this.title = title;
 }
 } Main Thread Worker Thread SharedData Write Read
18. CONCURRENCY public class SharedData {
 private long id;
 private String title;
 private String description;

 public synchronized String getDescription() {
 return description;
 }

 public synchronized void setDescription(String description) {
 this.description = description;
 }

 public synchronized long getId() {
 return id;
 }

 public synchronized void setId(long id) {
 this.id = id;
 }

 public synchronized String getTitle() {
 return title;
 }

 public synchronized void setTitle(String title) {
 this.title = title;
 }
 } Main Thread Worker Thread SharedData Write Read
19. IMMUTABLE OBJECTS public class ImmutableSharedData {
 private long id;
 private String title;
 private String description;

 private ImmutableSharedData(String description, long id, String title) {
 this.description = description;
 this.id = id;
 this.title = title;
 }

 public String getDescription() { return description; }

 public long getId() { return id; }

 public String getTitle() { return title; }

 public Builder newBuilder() {
 return new Builder().description(description) .id(id).title(title);
 }
 } public static class Builder {
 private String description = null;
 private long id = 0;
 private String title = null;

 public Builder description(String description) {
 this.description = description;
 return this;
 }

 public Builder id(long id) {
 this.id = id;
 return this;
 }

 public Builder title(String title) {
 this.title = title;
 return this;
 }

 public ImmutableSharedData build() {
 return new SharedData(description, id, title);
 }
 }
20. CONCURRENCY public class DataManager {
 private ImmutableSharedData sharedData;
 private Set<Listener> listeners;

 public DataManager() {
 listeners = Collections.synchronizedSet(new HashSet<>());
 }

 public void updateData(ImmutableSharedData data) {
 sharedData = data;
 for (Listener listener : listeners) {
 listener.onDataChanged(sharedData);
 }
 }

 public void registerListener(Listener listener) {
 listener.onDataChanged(sharedData);
 listeners.add(listener);
 }

 public void unregisterListener(Listener listener) {
 listeners.remove(listener);
 }

 public interface Listener {
 void onDataChanged(ImmutableSharedData data);
 }
 }
21. CONCURRENCY public class DataManager {
 private Handler notifier;
 private ImmutableSharedData sharedData;
 private Set<Listener> listeners;

 public DataManager() {
 listeners = Collections.synchronizedSet(new HashSet<>());
 notifier = new Handler(Looper.getMainLooper());
 }

 public void updateData(ImmutableSharedData data) {
 sharedData = data;
 notifier.post(() -> {
 for (Listener listener : listeners) {
 listener.onDataChanged(sharedData);
 }
 });
 }

 public void registerListener(Listener listener) {
 listener.onDataChanged(sharedData);
 listeners.add(listener);
 }

 public void unregisterListener(Listener listener) {
 listeners.remove(listener);
 }

 public interface Listener {
 void onDataChanged(ImmutableSharedData data);
 }
 }
22. CONCURRENCY public class DataManager {
 private Handler notifier;
 private ImmutableSharedData sharedData;
 private Set<Listener> listeners;

 public DataManager() {
 listeners = Collections.synchronizedSet(new HashSet<>());
 notifier = new Handler(Looper.getMainLooper());
 }

 public void updateData(ImmutableSharedData data) {
 sharedData = data;
 notifier.post(() -> {
 for (Listener listener : listeners) {
 listener.onDataChanged(sharedData);
 }
 });
 }

 public void registerListener(Listener listener) {
 listener.onDataChanged(sharedData);
 listeners.add(listener);
 }

 public void unregisterListener(Listener listener) {
 listeners.remove(listener);
 }

 public interface Listener {
 void onDataChanged(ImmutableSharedData data);
 }
 } Getting complicated…
24. THE ASYNC PROBLEM public static class NetworkCallFactory {
 private static ExecutorService executor = Executors.newCachedThreadPool();

 public static <T> void fetchData(String url, NetworkCallback<T> callback) {
 executor.submit(() -> {
 try {
 T result = syncNetworkCall(url);
 callback.onResult(result);
 } catch (Exception e) {
 callback.onError(e);
 }
 });
 }
 }

 public interface NetworkCallback<T> {
 void onResult(T result);
 void onError(Throwable t);
 }
 }
25. THE ASYNC PROBLEM protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 RecyclerView productsList = (RecyclerView) findViewById(R.id.products);
 productsList.setLayoutManager(new LinearLayoutManager(this));
 productsAdapter = new ProductsAdapter();
 NetworkCallFactory.fetchData(DATA_URL,
 new NetworkCallFactory.NetworkCallback<List<Product>>() {
 @Override
 public void onResult(List<Product> result) {
 productsAdapter.setProducts(result);
 }

 @Override
 public void onError(Throwable t) {
 // TODO Error handling
 }
 });
 } Ouch!!
26. THE ASYNC PROBLEM protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 RecyclerView productsList = (RecyclerView) findViewById(R.id.products);
 productsList.setLayoutManager(new LinearLayoutManager(this));
 productsAdapter = new ProductsAdapter();
 NetworkCallFactory.fetchData(DATA_URL,
 new NetworkCallFactory.NetworkCallback<List<Product>>() {
 @Override
 public void onResult(List<Product> result) {
 runOnUiThread(() -> productsAdapter.setProducts(result));
 }

 @Override
 public void onError(Throwable t) {
 // TODO Error handling
 }
 });
 } Might be too late!
27. runOnUiThread() public final void runOnUiThread(Runnable action) {
 if (Thread.currentThread() != mUiThread) {
 mHandler.post(action);
 } else {
 action.run();
 }
 }
28. THE ASYNC PROBLEM NetworkCallFactory.fetchData(DATA_URL,
 new NetworkCallFactory.NetworkCallback<List<Product>>() {
 @Override
 public void onResult(final List<Product> result) {
 runOnUiThread(() -> {
 if (!isDestroyed()) {
 productsAdapter.setProducts(result);
 }
 });
 }

 @Override
 public void onError(Throwable t) {
 // TODO Error handling
 }
 })
29. THE ASYNC PROBLEM NetworkCallFactory.fetchData(DATA_URL,
 new CustomAsyncSample.NetworkCallback<List<Product>>() {
 @Override
 public void onResult(final List<Product> result) {
 runOnUiThread(() -> {
 if (!isDestroyed()) {
 productsAdapter.setProducts(result);
 }
 });
 }

 @Override
 public void onError(Throwable t) {
 // TODO Error handling
 }
 }) Getting complicated…
30. THE ASYNC PROBLEM • Loading should be multi-thread aware (worker + main thread) • Callbacks go on the main thread • Loading should be possible to cancel
31. SINGLE THREADED ASYNC PROBLEM private void showStartPage() {
 FragmentManager fragmentManager = getSupportFragmentManager();
 fragmentManager
 .beginTransaction()
 .replace(R.id.content, StartPageFragment.newInstance())
 .commit();
 }

 public static class StartPageFragment extends Fragment {
 public static StartPageFragment newInstance() {
 return new StartPageFragment();
 }

 public View onCreateView(LayoutInflater inflater, ViewGroup container, Bundle savedInstanceState) {
 return inflater.inflate(R.layout.start_page, container, false);
 }
 }
32. SINGLE THREADED ASYNC PROBLEM public void showSplashAndContinue(ImageView imageView) {
 imageView.setImageResource(R.drawable.splash);
 Handler handler = new Handler();
 handler.postDelayed(() -> showStartPage(), 5000);
 }
33. SINGLE THREADED ASYNC PROBLEM Fatal Exception: java.lang.IllegalStateException: Can not perform this action after onSaveInstanceState at android.support.v4.app.FragmentManagerImpl.checkStateLoss(SourceFile:1493) at android.support.v4.app.FragmentManagerImpl.enqueueAction(SourceFile:1511) at android.support.v4.app.BackStackRecord.commitInternal(SourceFile:638) at android.support.v4.app.BackStackRecord.commit(SourceFile:617)
34. 4 SIMPLE RULES • Start job • Receive result • Cancel job • Cancel result delivery
36. Cancelling a Thread Thread myThread = new Thread() {
 @Override
 public void run() {
 try(InputStream stream = new FileInputStream("/dev/urandom")) {
 byte[] buffer = new byte[32];
 while(stream.read(buffer) != -1) {
 Log.d(TAG, "Read some data!");
 }
 } catch (Throwable t) { Log.e(TAG, "Error when reading!", t); }
 }
 };

 myThread.start();
 SystemClock.sleep(1000);
 myThread.interrupt();
38. –The Java™ Tutorials “An interrupt is an indication to a thread that it should stop what it is doing and do something else. It's up to the programmer to decide exactly how a thread responds to an interrupt, but it is very common for the thread to terminate.” https://docs.oracle.com/javase/tutorial/essential/concurrency/interrupt.html
39. –The Java™ Tutorials “An interrupt is an indication to a thread that it should stop what it is doing and do something else. It's up to the programmer to decide exactly how a thread responds to an interrupt, but it is very common for the thread to terminate.” https://docs.oracle.com/javase/tutorial/essential/concurrency/interrupt.html
40. Cancelling a Thread Thread myThread = new Thread() {
 @Override
 public void run() {
 try(InputStream stream = new FileInputStream("/dev/urandom")) {
 byte[] buffer = new byte[32];
 while(stream.read(buffer) != -1) {
 Log.d(TAG, "Read some data!");
 if(interrupted()) {
 Log.d(TAG, "Got interrupted - cancel reading!");
 return;
 }
 }
 } catch (IOException e) { Log.e(TAG, "Error when reading!", e); }
 }
 };

 myThread.start();
 SystemClock.sleep(1000);
 myThread.interrupt();
41. java.lang.Thread • Can be started only once • Limited support for cancelling • No built-in support for callbacks on other threads • Avoid!
42. Handler, Message, Looper and MessageQueue
43. MessageQueue Message Message Message Message next next next
44. MessageQueue (simplified) public final class MessageQueue { Message mMessages;
 Message next() { synchronized (this) { Message prevMsg = null;
 Message msg = mMessages;
 do {
 prevMsg = msg;
 msg = msg.next;
 } while (msg != null && !msg.isAsynchronous());
 if (msg != null) {
 if (now < msg.when) {
 nextPollTimeoutMillis = (int) Math.min(msg.when - now, Integer.MAX_VALUE);
 } else {
 mBlocked = false;
 if (prevMsg != null) {
 prevMsg.next = msg.next;
 } else {
 mMessages = msg.next;
 }
 msg.next = null;
 return msg;
 }
 } else {
 nextPollTimeoutMillis = -1;
 }
 }
 }

45. Looper (simplified) public final class Looper {
 final MessageQueue mQueue;
 final Thread mThread;
 private Looper(boolean quitAllowed) {
 mQueue = new MessageQueue(quitAllowed);
 mThread = Thread.currentThread();
 } public static void loop() { final Looper me = myLooper();
 final MessageQueue queue = me.mQueue;
 for (;;) {
 Message msg = queue.next(); // might block msg.target.dispatchMessage(msg);
 } }
46. HandlerThread private Handler createBackgroundHandler(Handler.Callback callback) {
 HandlerThread handlerThread = new HandlerThread("bg-thread");
 handlerThread.start();
 return new Handler(handlerThread.getLooper(), callback);
 }
47. MessageQueue, Looper and Handlers Looper MessageQueue Handler Handler Handler Handler
48. MessageQueue and Looper Runnable Message onReceive() Handler Handler onClick() Handler
49. Timeouts with Handler @Override
 protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 RecyclerView productsList = (RecyclerView) findViewById(R.id.products);
 productsList.setLayoutManager(new LinearLayoutManager(this));
 productsAdapter = new ProductsAdapter();

 uiHandler = new Handler(Looper.getMainLooper(), this);
 swipeRefreshLayout = (SwipeRefreshLayout) findViewById(R.id.swipe_refresh_layout);
 swipeRefreshLayout.setOnRefreshListener(this::performNetworkSync);
 }
50. Timeouts with Handler private void performNetworkSync() {
 swipeRefreshLayout.setRefreshing(true);
 uiHandler.sendEmptyMessageDelayed(MSG_TIMEOUT, REFRESH_TIMEOUT_MS) syncNetworkData(new NetworkCallback() {
 public void onData(List<Product> data) {
 uiHandler.obtainMessage(MSG_PRODUCTS_UPDATED, data)
 .sendToTarget();

 uiHandler.removeMessages(MSG_TIMEOUT);
 }
 }); }
51. Timeouts with Handler @Override
 public boolean handleMessage(Message msg) {
 switch (msg.what) {
 case MSG_TIMEOUT:
 swipeRefreshLayout.setRefreshing(false);
 Snackbar.make(findViewById(R.id.content),
 "Timeout when loading data", Snackbar.LENGTH_LONG)
 .setAction("Retry", v -> performNetworkSync())
 .show();
 break;
 case MSG_PRODUCTS_UPDATED:
 swipeRefreshLayout.setRefreshing(false);
 productsAdapter.setProducts((List<Product>) msg.obj);
 break; }
 return true;
 }
52. Cancelling with Handler // Remove all messages with what == 123
 handler.removeMessages(123);
 // Remove messages with what 123 and carrying someObject
 handler.removeMessages(123, someObject);
 // Remove message containing this runnable
 handler.removeCallbacks(runnable);
 // Remove message containing this runnable and carrying someObject
 handler.removeCallbacks(runnable, someObject);
 // Remove all messages
 handler.removeCallbacksAndMessages(null);
53. android.os.Handler • Message-based async utility • Thread safe • Reusable • Cancel scheduled messages • Still needs manual cancel flag • Useful for repeated processing tasks
54. AsyncTask
55. android.os.AsyncTask private Result postResult(Result result) {
 Message message = getHandler().obtainMessage(MESSAGE_POST_RESULT,
 new AsyncTaskResult<Result>(this, result));
 message.sendToTarget();
 return result;
 } private static Handler getHandler() {
 synchronized (AsyncTask.class) {
 if (sHandler == null) {
 sHandler = new InternalHandler();
 }
 return sHandler;
 }
 }
56. android.os.AsyncTask private static class InternalHandler extends Handler {
 public InternalHandler() {
 super(Looper.getMainLooper());
 }

 public void handleMessage(Message msg) {
 AsyncTaskResult<?> result = (AsyncTaskResult<?>) msg.obj;
 switch (msg.what) {
 case MESSAGE_POST_RESULT:
 // There is only one result
 result.mTask.finish(result.mData[0]);
 break;
 case MESSAGE_POST_PROGRESS:
 result.mTask.onProgressUpdate(result.mData);
 break;
 }
 }
 }
57. android.os.AsyncTask private void finish(Result result) {
 if (isCancelled()) {
 onCancelled(result);
 } else {
 onPostExecute(result);
 }
 mStatus = Status.FINISHED;
 }
 public final boolean cancel(boolean mayInterruptIfRunning) {
 mCancelled.set(true);
 return mFuture.cancel(mayInterruptIfRunning);
 }
58. android.os.AsyncTask protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 setContentView(R.layout.activity_async_task_sample);
 myTask = new AsyncTask<Void, Void, String>() {
 protected String doInBackground(Void... params) {
 SystemClock.sleep(5000);
 return "Result!";
 }

 protected void onPostExecute(String result) {
 super.onPostExecute(result);
 ((TextView) findViewById(R.id.result)).setText(result);
 }

 protected void onCancelled() {
 super.onCancelled();
 ((TextView) findViewById(R.id.result)).setText("Cancelled!");
 }
 };
 }
59. android.os.AsyncTask protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 setContentView(R.layout.activity_async_task_sample);
 myTask = new AsyncTask<Void, Void, String>() {
 protected String doInBackground(Void... params) {
 SystemClock.sleep(5000);
 return "Result!";
 }

 protected void onPostExecute(String result) {
 super.onPostExecute(result);
 ((TextView) findViewById(R.id.result)).setText(result);
 }

 protected void onCancelled() {
 super.onCancelled();
 ((TextView) findViewById(R.id.result)).setText("Cancelled!");
 }
 };
 } Don’t try to modify the UI in onCancel()!
60. AsyncTask with Progress public class AsyncTaskWithProgress
 extends AsyncTask<String, AsyncTaskWithProgress.State, String> {

 public enum State {
 Started, Loading, Updating, Completed, Failed
 }
 protected String doInBackground(String... params) {
 try {
 publishProgress(State.Started);
 SystemClock.sleep(1000);
 publishProgress(State.Loading);
 SystemClock.sleep(1000);
 publishProgress(State.Updating);
 SystemClock.sleep(1000);
 publishProgress(State.Completed);
 return "Done!";
 } catch (Exception e) {
 publishProgress(State.Failed);
 return "Failed!";
 }
 }
 }
61. android.os.AsyncTask • Can only be started once • Callbacks to the main-thread • Avoid touching UI in onCancelled()! • Be vary of Context/Activity references - use cancel()! • Use only for short-lived calls (seconds)!
62. Loaders
63. Loaders public static class DataListLoader extends AsyncTaskLoader<List<Data>> {
 private List<Data> loadedData;

 public DataListLoader(Context context) { super(context); }

 protected void onStartLoading() {
 super.onStartLoading();
 if(loadedData == null) {
 forceLoad();
 } else {
 deliverResult(loadedData);
 }
 }
64. Loaders public List<Data> loadInBackground() {
 List<Data> newData = new ArrayList<>();
 SystemClock.sleep(2000);
 return newData;
 }

 public void deliverResult(List<Data> data) {
 loadedData = data;
 super.deliverResult(data);
 }
 }
65. Loaders • Not multi-threaded by default • Strange start behaviour • Main advantage: Possible to maintain data between config changes • Not suitable for network calls!
66. IntentService
67. IntentServiceSample public class IntentServiceSample extends IntentService {
 public IntentServiceSample() { super(“name"); }

 protected void onHandleIntent(Intent intent) {
 try {
 ProductResource productResource = RetrofitHelper.getProductResource();
 // Synchronous call since we're on a background thread
 Response<List<Product>> response = productResource.getProducts().execute();
 List<Product> products = response.body();
 writeListToDataBase(products);
 } catch (IOException e) {
 // Error handling
 }
 }

 private void writeListToDataBase(List<Product> products) {
 // Insert into database, synchronously...
 }
 }
68. IntentService (simplified) public abstract class IntentService extends Service {
 private final class ServiceHandler extends Handler {
 public ServiceHandler(Looper looper) { super(looper); }

 public void handleMessage(Message msg) {
 onHandleIntent((Intent)msg.obj);
 stopSelf(msg.arg1);
 }
 }
 public void onCreate() {
 super.onCreate();
 HandlerThread thread = new HandlerThread("IntentService[" + mName + "]");
 thread.start();

 mServiceLooper = thread.getLooper();
 mServiceHandler = new ServiceHandler(mServiceLooper);
 } public void onStart(@Nullable Intent intent, int startId) {
 Message msg = mServiceHandler.obtainMessage();
 msg.arg1 = startId;
 msg.obj = intent;
 mServiceHandler.sendMessage(msg);
 } }
69. IntentService • Single queue of background tasks • For long-running background calls (network synchronization etc.) • Callback is complicated - avoid! • Useful for fire-and-forget tasks • Not possible to cancel
70. RxJava Changes Everything… (not really)
71. SUPPORT ANNOTATIONS • @MainThread - Method must only be called from main thread • @WorkerThread - Method must not be called from main thread • @AnyThread - Method can be called from any thread
72. 4 SIMPLE RULES + 1 • Start job • Receive result • Cancel job • Cancel result delivery • Don’t re-invent the wheel!
73. BE THE KITTEN!
