Anomaly Detection. Part 1 – Basics

Rostislav Yavorski
Head of Research, Exactpro

“In this lecture, we will review the definitions and practical examples of outliers and anomalies in different domains: financial fraud detection, medical diagnosis, fault identification, etc.”

AI Testing Talks – Anomaly Detection. 20 May 2022

https://exactpro.com/events/external/ai-testing-talks-anomaly-detection?utm_source=speakerdeck&utm_medium=Refferer&utm_campaign=basics

---

Follow us on
LinkedIn https://www.linkedin.com/company/exactpro-systems-llc
Twitter https://twitter.com/exactpro

Transcript

1. 1 BUILD SOFTWARE TO TEST SOFTWARE
   AI Testing Talks
   BUILD SOFTWARE TO TEST SOFTWARE
   exactpro.com
   Lecture 1.
   Anomaly Detection Basics
   ANOMALY DETECTION FOR AI TESTING
   20 MAY | 10.00 GET | 11.30 SLST
   Rostislav Yavorski
   Head of Research, Exactpro


   View Slide

2. 2 BUILD SOFTWARE TO TEST SOFTWARE
   AI Testing Talks
   Anomaly, also known as outlier or novelty
   ● Data points, events, or observations that
   deviate from normal behaviour
   ● Instances or collections of data that
   occur very rarely in the data set
   ● Observations which appear to be
   inconsistent with the remainder of the
   data
   2


   View Slide

3. 3 BUILD SOFTWARE TO TEST SOFTWARE
   AI Testing Talks
   Challenges in Anomaly Detection
   ● Definition of normal behaviour
   is extremely challenging
   ● Noise data aren’t anomalies
   ● The definition of anomaly
   is domain-specific
   ● Anomalies evolve over time
   ● Getting a set of labeled anomalous
   instances is difficult
   3


   View Slide

4. 4 BUILD SOFTWARE TO TEST SOFTWARE
   AI Testing Talks
   ● To compute the mean or standard deviation
   ● To improve linear regression models for better
   predictions
   ● To boost the performance of machine learning
   algorithms
   Sometimes anomalies are discarded as waste
   4


   View Slide

5. 5 BUILD SOFTWARE TO TEST SOFTWARE
   AI Testing Talks
   Sometimes anomalies are most desirable
   ● fraud detection
   ● fault detection
   ● system health monitoring
   ● event detection in sensor networks
   ● detecting ecosystem disturbances
   ● defect detection in images
   ● medical diagnosis
   ● law enforcement
   ● cyber-security intrusion detection
   5


   View Slide

6. 6 BUILD SOFTWARE TO TEST SOFTWARE
   AI Testing Talks
   #1 Mean and Standard Deviation
   ANOMALY DETECTION FOR AI TESTING
   6


   View Slide

7. 7 BUILD SOFTWARE TO TEST SOFTWARE
   AI Testing Talks
   7


   View Slide

8. 8 BUILD SOFTWARE TO TEST SOFTWARE
   AI Testing Talks
   Name Salary
   Maria 41
   Jose 43
   Ahmed 44
   Anna 45
   Carlos 45
   Patricia 46
   M =
   41 + 43 + 44 + 45 + 45 + 46
   6
   = 44
   σ =
   32 + 12 + 02 + 12 + 12 +
   22
   6
   = 1.4
   8
   Computing Mean and Standard Deviation


   View Slide

9. 9 BUILD SOFTWARE TO TEST SOFTWARE
   AI Testing Talks
   Name Salary
   Maria 41
   Jose 43
   Ahmed 44
   Anna 45
   Carlos 45
   Patricia 46
   M =
   41 + 43 + 44 + 45 + 45 + 46
   6
   = 44
   σ =
   32 + 12 + 02 + 12 + 12 +
   22
   6
   = 1.4
   9
   Computing Mean and Standard Deviation


   View Slide

10. 10 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Name Salary
    Joe the Intern 9
    Maria 41
    Jose 43
    Ahmed 44
    Anna 45
    Carlos 45
    Patricia 46
    M =
    41 + 43 + 44 + 45 + 45 + 46 + 9
    7
    = 39
    σ =
    22 + 42 + 52 + 62 + 62 + 72 + 302
    7
    = 12.3
    10
    Computing Mean and Standard Deviation


    View Slide

11. 11 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Name Salary
    Joe the Intern 9
    Maria 41
    Jose 43
    Ahmed 44
    Anna 45
    Carlos 45
    Patricia 46
    M =
    41 + 43 + 44 + 45 + 45 + 46 + 9
    7
    = 39
    σ =
    22 + 42 + 52 + 62 + 62 + 72 + 302
    7
    = 12.3
    Outlier,
    very rare value
    Meaningless results,
    hardly interpretable
    11
    Computing Mean and Standard Deviation


    View Slide

12. 12 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    #2 Linear Regression
    ANOMALY DETECTION FOR AI TESTING
    12


    View Slide

13. 13 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    https://www.product-pro.com/preparing-for-mass-production/
    13


    View Slide

14. 14 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Units Time
    2 units 14 min
    4 units 19 min
    6 units 30 min
    8 units 38 min
    10 units 44 min
    Time = 4.0 min × Units + 5.3 min
    (k = 4.0 ± 0.3, b = 5.3 ± 1.7)
    Performance Prediction with Linear Regression
    14


    View Slide

15. 15 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Units Time
    2 units 14 min
    4 units 19 min
    6 units 30 min
    8 units 38 min
    10 units 44 min
    Time = 4.0 min × Units + 5.3 min
    (k = 4.0 ± 0.3, b = 5.3 ± 1.7)
    Performance Prediction with Linear Regression
    15
    Prediction error is
    rather small


    View Slide

16. 16 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Units Time
    2 units 14 min
    3 units 41 min
    4 units 19 min
    6 units 30 min
    8 units 38 min
    10 units 44 min Time = 2.7 min × Units + 16.2 min
    (k = 2.7 ± 1.5, b = 16.2 ± 9.0)
    Performance Prediction with Linear Regression
    16


    View Slide

17. 17 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Units Time
    2 units 14 min
    3 units 41 min
    4 units 19 min
    6 units 30 min
    8 units 38 min
    10 units 44 min
    Performance Prediction with Linear Regression
    Inconsistent observation
    Poor prediction
    quality
    17
    Time = 2.7 min × Units + 16.2 min
    (k = 2.7 ± 1.5, b = 16.2 ± 9.0)


    View Slide

18. 18 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    #3 Fraud Detection
    ANOMALY DETECTION FOR AI TESTING
    18


    View Slide

19. 19 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    https://www.zoho.com/books/articles/payment-fraud.html
    19


    View Slide

20. 20 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    A deliberate act aimed at obtaining an unauthorised benefit:
    ● Theft or misappropriation of funds placed in one's trust
    ● Forgery or alteration of documents or computer files
    ● Authorisation of payment for services not performed
    ● Receipt of unearned wages or benefits
    ● Identity theft
    20
    Fraud


    View Slide

21. 21 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Indicators
    ● Excessive number of checking accounts
    ● Frequent changes in banking accounts
    ● Behavioural changes: drugs, alcohol, gambling
    ● Lifestyle changes: expensive cars, jewelry, homes, clothes
    21


    View Slide

22. 22 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Indicators
    ● Excessive number of checking accounts
    ● Frequent changes in banking accounts
    ● Behavioural changes: drugs, alcohol, gambling
    ● Lifestyle changes: expensive cars, jewelry, homes, clothes
    Deviate from normal behaviour
    22


    View Slide

23. 23 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    https://sdk.finance/all-you-need-to-know-about-machine-learning-based-fraud-detection-systems/
    !
    Rule Based
    Machine Learning
    The traditional approach to identifying fraudulent
    activities through known past behaviour
    The machine learning approach models a user’s
    banking patterns and detects anomalous behaviour
    Commits
    Fraudster Fraud Rules Detection
    Human
    Analysis User for
    !
    Performs
    User Transaction ML Model Detection
    Train User for
    Improve


    View Slide

24. 24 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    https://sdk.finance/all-you-need-to-know-about-machine-learning-based-fraud-detection-systems/
    !
    Rule Based
    Machine Learning
    The traditional approach to identifying fraudulent
    activities through known past behaviour
    The machine learning approach models a user’s
    banking patterns and detects anomalous behaviour
    Commits
    Fraudster Fraud Rules Detection
    Human
    Analysis User for
    !
    Performs
    User Transaction ML Model Detection
    Train User for
    Improve


    View Slide

25. 25 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    #4 Medical Diagnosis
    ANOMALY DETECTION FOR AI TESTING
    25


    View Slide

26. 26 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    26


    View Slide

27. 27 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Anomaly detection captures
    unique characteristics
    of the physiological data
    that could offer information
    about the patient
    Medical Diagnosis
    27


    View Slide

28. 28 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Loftus, Tyler J., et al. "Opportunities for machine learning to improve surgical ward safety." The American Journal of Surgery 220.4 (2020): 905-913.
    28
    Physiological
    data
    Ward
    admission
    Streaming
    electronic
    health records
    Early risk stratification
    guides initial
    triage to ward vs.
    intensive care unit
    Efficient, automated,
    wireless data acquisition
    making
    Wearables
    Machine
    learning
    Clinical
    assessment
    Early
    recovery
    Decompensation
    Rapid
    response
    Delayed
    recovery
    Rehabilitation
    Discharge
    home
    Accurate phenotyping,
    augmented
    decision-making
    Early recognition
    Cardiac
    arrest
    Automated alerts,
    augmented
    decision-making, early
    intervention


    View Slide

29. 29 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    #5 Fault Detection
    ANOMALY DETECTION FOR AI TESTING
    29


    View Slide

30. 30 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    https://climatix-group.com/wp-content/uploads/2020/01/HVAC-cotractor-Leeds-1.jpg
    30


    View Slide

31. 31 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Fault Detection
    Monitoring a system identifying
    when a fault has occurred and
    pinpointing the type of fault and its
    location.
    https://camatsystem.com/
    31


    View Slide

32. 32 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    A. DESCRIPTIVE ANALYTICS. Detect whether an item is
    functioning well or not by comparing the information received
    from it with historical data.
    B. DIAGNOSTIC ANALYTICS. Identify the causes of the fault. This
    process should consider trends in health history and operational
    context.
    C. PREDICTIVE ANALYTICS. Predict the state of the item within the
    future to detect any possible fault beforehand.
    D. PRESCRIPTIVE ANALYTICS. Elaborate maintenance
    plans considering the previous predictions to cut back fault.
    Fault Management Systems
    https://www.cloudmantra.net/blog/fault-detection-using-machine-learning-techniques/
    32
    MANAGER SYSTEM
    MONITORING
    FAULT DETECTION FAULT PREDICTION
    ROOT CASE
    ANALYSIS
    FAULT PREVENTION
    AND RECOVERY


    View Slide

33. 33 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Conclusion
    ANOMALY DETECTION FOR AI TESTING
    33


    View Slide

34. 34 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    Terms
    34
    An outlier is a data point that differs significantly
    from other observations.
    Anomalies are patterns in data that do not conform
    to a well-defined notion of normal behaviour.


    View Slide

35. 35 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    ● Definition of normal behaviour
    is extremely challenging
    ● Noise data aren’t anomalies
    ● The definition of anomaly
    is domain-specific
    ● Anomalies evolve over time
    ● Getting a checklist of all possible anomalies is difficult
    35
    Challenges in Anomaly Detection


    View Slide

36. 36 BUILD SOFTWARE TO TEST SOFTWARE
    AI Testing Talks
    AI Testing Talks
    Thank You!
