OrionPlanning: Improving Modularization and Checking Consistency on Software Architecture (VISSOFT 2015)

In this presentation, we present OrionPlanning, a prototype tool to assist model transformations at large scale. The tool provides support for model-based operations. These operations are performed in an interactive visualization. The contributions of the tool consist in: (i) providing iterative modifications in the architecture, and (ii) providing an environment for architecture inspection and definition of dependency rules.

Presented at VISSOFT '15

Transcript

1. OrionPlanning: Improving Modularization and Checking Consistency on Software Architecture Gustavo Santos, Nicolas Anquetil, Anne Etien, Stéphane Ducasse, and Marco Tulio Valente
2. Architecture Definition Little adoption in the industry [Pen2010] Important requirements [Mal2013]
 - Iterative Architecting
 - Extensibility
 - Analysis 2
3. OrionPlanning 3
4. Demo
5. Evolution Planning ▪ Define a model as wished ▪ Add modules and dependency rules 10
6. Evolution Planning ▪ Create working versions 10
7. Evolution Planning ▪ Interact with the model 10
8. Evolution Planning ▪ Interact with the model 10
9. Evolution Planning ▪ Create logical modules 10
10. Evolution Planning ▪ Define Dependency Constraints 10
11. Evolution Planning ▪ Dependency Contraint Checking 10
12. Visualization decisions Component-based Dependencies as relationships Colors defining changes and violations 5
13. Conclusions Incremental modification and versioning Extensibility with dependency constraint checking 6
14. Gustavo Santos, Nicolas Anquetil, Anne Etien, Stéphane Ducasse, and Marco Tulio Valente http://gustavojss.github.io/ http://smalltalkhub.com/#!/~GustavoSantos/OrionChangesBrowser OrionPlanning: Improving Modularization and Checking Consistency on Software Architecture
