大規模コンピューティングを支える Kubernetes のネットワーク 第4回分散システム集会 @honahuku
自己紹介 Honahuku(ほなふく) 第4回分散システム集会 • 7月からGKEを使った広告の部 署に異動に • 梅雨で頭が痛いが頑張る • 好きな色の折りたたみ傘を見つ
けてうきうき • オフィスの近くで食べた「食べる 豚汁」が美味しかった • 次の土曜日は三重にセキュリ ティ・ミニキャンプのチューター として行ってきます 最近のトピック
分散システムとは(短縮版)
第4回分散システム集会 • 複数ノードにおいて処理を分散して行うもの(ほなふくが勝手に 定義) • ジョブ型とコンテナ型(ほなふくが勝手に定義) • ユーザーからのリクエストを受け付けるか • k8s
は web リクエストを受け付けることが多い 分散システムとは [1] Slurm Workload Manager [2] Slurm Workload Manager
kubernetes のネットワーク
第4回分散システム集会 • インターネットから Nodeにトラフィック が流れてくる • どのマシンでも同じよ うにコンテナが動いて ほしい •
→ Pod は Node と 独立したネットワーク を持ち、 Pod ごとに IP が振られる k8s でのユーザーリクエストの処理 [3] Pod へのトラフィック
外からのトラフィックは直接 Node に送信される?
第4回分散システム集会 • Pod は揮発する ◦ Node の調子が悪くなったときに別 の Node に退避したい
• Service は Pod に対するアクセスを 抽象化する ◦ 外からのトラフィック以外にもクラス タ内の他のリソースから Pod にアク セスすることもある • Pod とは独立したネットワークを持ち、 Service ごとに IP が振られる Service という概念 [3] Service と Pod
(Service は) Pod と独立した ネットワークを持つ??
第4回分散システム集会 Node と Service と Pod [4] k8s のネットワーク
k8s の中ではめちゃくちゃ ネットワークが分離されている (overlay network)
誰が提供するのこれ
\\ CNI // (Container Network Interface)
第4回分散システム集会 CNI [5] k8s と CNI
第4回分散システム集会 CNI
なるほどわからん
第4回分散システム集会 • CNI は k8s 以外でも使える ◦ Linux コンテナ向けのネットワークの仕様とライブ ラリ
• CNIの k8s 向け実装は Network Plugin と呼ばれ る[10] • k8s では overlay network を提供する[11] ◦ Pod へ IP を振ったり ◦ Service へ IP を振ったりする • VXLAN や IP-in-IP で動いてる [5] CNI
第4回分散システム集会 • Service は実態として kube-proxy というやつがいい 感じにしている ◦ ノードに流れてきた Pod
向けのトラフィックを Pod に流す • kube-proxy はクラスタの外から CNI plugin までを 繋いでいる • ネットワークを抽象化(≒仮想化)することによって k8s のコンポーネントがネットワークを k8s の API とかの仕 組み上でいじれるようになってる ◦ 代わりにオーバーヘッドもある[4] CNI plugin と Service
まとめ
第4回分散システム集会 • overlay network により Pod 間 や Service 間
で NAT をせずに疎通できる(他にも色々やってくれる) • これは CNI Plugin により提供される • overlay network までのトラフィックは kube-proxy が繋ぎこむ まとめ [7] [8]
参考文献
参考文献 第4回分散システム集会 • [1] Slurm Workload Manager https://slurm.schedmd.com/ • [2]
Kubernetes https://kubernetes.io/ • [3] ネットワークの概要 https://cloud.google.com/kubernetes-engine/docs/concepts/network-overview • [4] コンテナネイティブロードバランシングの話 / A story about container native load balancing https://speakerdeck.com/inductor/a-story-about-container-native-load-balancing • [5] Assessing Container Network Interface Plugins: Functionality, Performance, and Scalability https://doi.org/10.1109/TNSM.2020.3047545 • [6]久々に社内勉強会で発表するので資料を公開します https://blog.inductor.me/entry/container-native-load-balancing • [7]Kubernetes Components https://kubernetes.io/docs/concepts/overview/components/ • [8]CNI - the Container Network Interface https://github.com/containernetworking/cni • [9]ふくねっと Vol.1 https://booth.pm/ja/items/5399365 • [10]Network Plugins https://kubernetes.io/docs/concepts/extend-kubernetes/compute-storage-net/ne twork-plugins/ • [11]The Kubernetes network model https://kubernetes.io/docs/concepts/services-networking/#the-kubernetes-netwo rk-model
