DyND - Enabling Complex Analytics Across the Language Barrier, PyData London 2016

Transcript

1. DYND: ENABLING COMPLEX ANALYTICS
   ACROSS THE LANGUAGE BARRIER
   IRWIN ZAID, CONTINUUM ANALYTICS


   View Slide

2. Part 1: The What and Why of DyND
   Part 2: DyND Snippets
   DYND: ENABLING COMPLEX ANALYTICS
   ACROSS THE LANGUAGE BARRIER


   View Slide

3. PYDATA LONDON 2016
   What is DyND?
   DyND aims to be a modern library for array-oriented
   computing


   View Slide

4. PYDATA LONDON 2016
   What is DyND?
   ‣ A library, not a language
   ‣ Helps do computation with arrays
   ‣ “Modern” means “uses software engineering practices
   from today, solving problems people have had for a
   while”


   View Slide

5. PYDATA LONDON 2016
   What is DyND really?
   A type system and a callable object that operate
   together with an array container, engineered in C++
   and bound to dynamic languages like Python


   View Slide

6. PYDATA LONDON 2016
   What is DyND not?
   ‣ DyND is not NumPy 2.0

   - NumPy is really good at what it was designed to do: broadcasting

   computation and stride-based manipulation

   - NumPy may not be “replaceable” — Fortran is still pretty widely used
   ‣ DyND is not a JIT for Python

   - See Numba for that
   ‣ DyND is not Boost.MultiArray

   - DyND is dynamic C++, templates are a hidden detail


   View Slide

7. PYDATA LONDON 2016
   It’s 2016. Why write another array library?
   Because there are problems that are not being
   otherwise solved


   View Slide

8. PYDATA LONDON 2016
   It’s 2016. Why write another array library?
   ‣ Example: Missing data

   - Values that may or may not be present

   - The masked arrays of numpy.ma are not sufficient, there is overhead related

   to how the masked array is stored and NumPy is not always consistent

   with how it treats mask arrays

   - Discussed at length in 2011, remains unsolved in 2016


   View Slide

9. PYDATA LONDON 2016
   It’s 2016. Why write another array library?
   ‣ Example: Variable-length strings

   - NumPy can only efficiently represent strings of a predefined length

   - Variable-length strings have to be stored as Python objects


   View Slide

10. PYDATA LONDON 2016
    It’s 2016. Why write another array library?
    ‣ Example: Custom types

    - NumPy dtypes are too primitive

    - How does one represent categorical data? Ragged dimensions? GPU data?

    - Cannot define user overloads on ufuncs, e.g. string concatenation


    View Slide

11. PYDATA LONDON 2016
    It’s 2016. Why write another array library?
    ‣ Example: NumPy without the “Py”

    - Sometimes we don’t want to use Python

    - Why not have a representation of data that can go between several

    languages? (R, Julia, Javascript, …)


    View Slide

12. PYDATA LONDON 2016
    Four Traits of DyND
    ‣ Expressive
    ‣ Generic
    ‣ Extendable
    ‣ Pluggable







    View Slide

13. PYDATA LONDON 2016
    Expressive
    ‣ DyND implements Datashape as its type system

    - A structured data description language, http://datashape.pydata.org

    type
    dimension * dtype



    var * int32

    3 * string

    4 * float64
    Datashape:
    Struct type
    {x: int32, y: string, z: float64}
    Tabular data
    var * {x: int32, y: string, z: float64}


    View Slide

14. PYDATA LONDON 2016
    Generic
    ‣ DyND’s type, callable, and array objects are reference-
    counted smart pointers that dynamically interpret data
    ‣ Types can be parameterized on other types

    - N * T, var[T], option[T]
    ‣ Callables can be transformed (in a functional sense) from
    inner operations to higher-order patterns

    - Define the innermost operation, then build out the behavior you want with

    predefined generic patterns

    - nd::functional::elwise([](int x, int y) { return x + y; });


    View Slide

15. PYDATA LONDON 2016
    Extendable
    ‣ Types and callables are first-class objects that users should
    create directly


    View Slide

16. PYDATA LONDON 2016
    Extendable
    ‣ Types and callables are first-class objects that users should
    create directly


    View Slide

17. PYDATA LONDON 2016
    Pluggable
    ‣ DyND supports plug-in libraries

    - Define custom types and callables (or namespaces thereof) directly
    ‣ Use nd::set(“my_amazing_callable”, f) for a
    custom callable or nd::set(“my_amazing_namespace”,
    {{“my_amazing_callable”, f},
    {“my_other_amazing_callable”, g}}) for a custom
    namespace
    ‣ Callables are dynamically propagated to Python, entirely
    removing the need for any user wrapper code


    View Slide

18. Part 1: The What and Why of DyND
    Part 2: DyND Snippets
    DYND: ENABLING COMPLEX ANALYTICS
    ACROSS THE LANGUAGE BARRIER


    View Slide

19. PYDATA LONDON 2016
    Types
    ‣ Types are instances of simple classes

    - Write a class, get a type
    ‣ Types expose dynamic features to arrays

    - Either properties, like .real or .imag, or behavior, like .conj()
    ‣ Types can be kinds or patterns

    - Int, Scalar, Fixed, or Any; Fixed * T or (N * T, T) -> T


    View Slide

20. PYDATA LONDON 2016
    Metadata and Data
    ‣ Array metadata can describe data other than strided

    - Offset (tuple or struct), indirect (pointer), ragged (variable-sized dimensions)
    ‣ Array data is poolable or allocatable in custom memory
    spaces

    - Variable-sized strings or dimensions; CUDA


    View Slide

21. PYDATA LONDON 2016
    Fundamental Types


    View Slide

22. PYDATA LONDON 2016
    Dimension Types


    View Slide

23. PYDATA LONDON 2016
    Aggregate Types


    View Slide

24. PYDATA LONDON 2016
    Option Type


    View Slide

25. PYDATA LONDON 2016
    Symbolic Types


    View Slide

26. PYDATA LONDON 2016
    Callable and Functionals
    ‣ Share functions alongside data

    - Callables are first-class objects that can be dynamically published
    ‣ Enable user-defined functions with generic patterns

    - Functionals like apply, elwise, reduction, multidispatch, outer, neighborhood,

    and rolling transform one callable into another
    ‣ Built-in callable are overloadable

    - Users can define +, -, *, /, … for custom types


    View Slide

27. PYDATA LONDON 2016
    Elementwise Functional


    View Slide

28. PYDATA LONDON 2016
    Reduction Functional


    View Slide

29. PYDATA LONDON 2016
    Multidispatch Functional


    View Slide

30. PYDATA LONDON 2016
    Option Operations


    View Slide

31. PYDATA LONDON 2016
    JSON Processing


    View Slide

32. PYDATA LONDON 2016
    Thanks to…
    Mark Wiebe Ian Henriksen Stefan Krah
    Irwin Zaid


    View Slide

33. PYDATA LONDON 2016
    Thanks to…


    View Slide

34. PYDATA LONDON 2016
    Get DyND!
    conda install dynd-python -c dynd/channel/dev


    View Slide
