  1. High Altitude
    Adventures
    @jasonmadigan
    http://jasonmadigan.com
    Monday 19 August 13

    View Slide

  2. Background
    • Software Engineering type
    • Day Job
    • FeedHenry
    • Spare Time
    • Hacking (github.com/jasonmadigan)
    • iOS Apps
    • Irish Weather
    • Matchy
    • Bit of a Space nerd
    Monday 19 August 13

    View Slide

  3. Browsing Reddit One Day...
    “How hard could it
    be?”
    Monday 19 August 13

    View Slide

  4. The Plan (1)
    Lifting Gas - Hydrogen €76 + Rental
    A cheap Android smartphone
    Parachute
    Weather Balloon
    Monday 19 August 13

    View Slide

  5. The Plan (1)
    A cheap Android smartphone
    Parachute
    Weather Balloon
    Monday 19 August 13

    View Slide

  6. The Plan (2)
    Lifting Gas - Helium €170 + Rental
    Arduino + GPS + Siemens TC35 + NTX2
    Parachute
    Weather Balloon
    Monday 19 August 13

    View Slide

  7. So, what goes where?
    Balloon
    1000g Hwoyee
    48” Spherachute
    8ltr Polystyrene Box
    Monday 19 August 13

    View Slide

  8. So, what goes where?
    Balloon
    1000g Hwoyee
    48” Spherachute
    8ltr Polystyrene Box
    Monday 19 August 13

    View Slide

  9. What’s in the box?
    Arduino Mega
    Siemens TC35
    NTX2
    MTK3339
    Veho Muvi HD
    (Not Pictured!)
    Monday 19 August 13

    View Slide

  10. Payload Details
    Monday 19 August 13

    View Slide

  11. Arduino Mega
    • 4 Hardware Serial Ports
    • Software Serial ports introduce
    problems!
    • Processes GPS data from the
    MTK3339
    • Processes incoming AT commands
    read from the GSM TC35 modem
    for sending/receiving SMS
    • Controls telemetry transmission via
    RTTY sent via NTX2
    Monday 19 August 13

    View Slide

  12. MTK3339
    • Low power (20mW)
    • On-board data logging
    • Works above 18km
    • COCOM limits
    • 1900km/h && > 18000m - turn off
    • No intercontinental ballistic missiles,
    please
    • Actually worked up to 3.7km. Once.
    Monday 19 August 13

    View Slide

  13. Radiometrix NTX2
    • Low power transmitter UHF
    (10mW)
    • Free/unlicensed to use at low
    power in the UK & Ireland*
    • UKHAS use these since
    they’re easy to use
    • Used to transmit RTTY
    (Radioteletype) telemetry
    periodically
    * Table 5 - http://www.comreg.ie/_fileupload/publications/odtr0062r.pdf
    Monday 19 August 13

    View Slide

  14. Xexun TK102
    • Redundancy!
    • Cheap GPS Tracker with GSM (€30)
    • Terrible
    • Doesn’t work when it’s upside
    down
    • Randomly stops responding
    • Has failed to work on two HAB
    missions
    • I should probably throw it out.
    Remind me to throw it out.
    Monday 19 August 13

    View Slide

  15. Veho Muvi HD
    • Full HD video capture (1080p)
    • Wide angle lens
    • Rugged, similar to a Go Pro, and a
    bit cheaper (€130)
    Monday 19 August 13

    View Slide

  16. Siemens TC35
    • GSM module with a
    serial (RS232) interface
    • Works with an Arduino
    • Low(ish) power 120mW
    while idle, can spike to
    ~700mW when sending/
    receiving SMS
    Monday 19 August 13

    View Slide

  17. How it all works
    • Redundant communications system
    • GSM (via TC35)
    • SMS processing - I can call or text “where”,
    and it will text me back its location
    • UHF (via NTX2)
    • Transmits periodic RTTY for decoding on the
    ground (dl-fldigi)
    • Cheap GPS tracker
    Monday 19 August 13

    View Slide

  18. Bugs!
    • There were/are many
    • My favourite - Arduino serial interupts
    • Originally using an Uno
    • 1 hardware serial port (I needed 2)
    • Software serial ports
    • I have data, I interrupt
    • Oh you were transmitting? Sorry about
    that.
    Monday 19 August 13

    View Slide

  19. Launching!
    • Legals
    • IAA - “No”
    • CAA - “Sure”
    • Picked a remote site
    with little tree cover
    an a wide-open space
    Monday 19 August 13

    View Slide

  20. Launch Day
    • Oh crap the antenna broke
    • Oh crap the voltage sensor
    snapped off
    • Oh crap we forgot to put in
    the video camera
    • Oh crap I forgot to close
    the Helium valve before
    disconnecting the regulator
    Monday 19 August 13

    View Slide

  21. Launched!
    Monday 19 August 13

    View Slide

  22. The Chase
    Monday 19 August 13

    View Slide

  23. Oops
    • Checked the predictor, started heading
    north towards Coleraine
    • “Odd, it’s altitude seems to be stuck at
    3.7km”
    • GPS never regained a lock until it landed
    • We could hear the Payload via UHF Radio
    for the whole chase
    Monday 19 August 13

    View Slide

  24. Silence
    • Shortly after regaining GSM coverage, the
    Radio went silent.
    • TC35 & GPS Tracker still working, so
    frantically called them
    • Eventually the main tracker told us its
    location
    Monday 19 August 13

    View Slide

  25. Recovery
    Monday 19 August 13

    View Slide

  26. Some Videos
    Monday 19 August 13

    View Slide

  27. Thanks!
    Monday 19 August 13

    View Slide
