  1. Alice & Bob
    CodeConnexx
    8-9 november 2013, Maastricht
    Public key cryptography 101
    1

    View Slide

  2. An introduction
    2

    View Slide

  3. 3
    Without this there would be
    no internet as we know today
    (really)

    View Slide

  4. example “encryption” algorithms
    4
    http://www.flickr.com/photos/dpwk/1714014449/in/[email protected]/

    View Slide

  5. ciphertext:
    3, 15, 4, 5
    “algorithm”:
    A = 1, B = 2, C = 3, ...., Z = 26
    =
    C O D E
    5

    View Slide

  6. 6
    ciphertext:
            
    =
    W I N G D I N G S

    View Slide

  7. “algorithm”:
    c = (m + k) mod 26
    7
    Message: C O D E
    Ciphertext (key=1): D P E F
    Ciphertext (key=2): E Q F G
    Ciphertext (key=-1): B M C D
    Ciphertext (key=0): C O D E
    Ciphertext (key=26): C O D E
    Ciphertext (key=52): C O D E
    http://upload.wikimedia.org/wikipedia/commons/thumb/2/2b/Caesar3.svg

    View Slide

  8. ➡ Key is too easy to guess.
    ➡ Key has to be send to Bob.
    ➡ Deterministic.
    ➡ Prone to frequency analysis.
    8

    View Slide

  9. ➡ ‘E’ is used 12.7% of the times in english texts.
    ➡ The ‘Z’ only 0.074%.
    ➡ ‘E’ is used 17.4% of the times in german
    texts, the ‘Q’ only 0.022%
    9

    View Slide

  10. gl 7291 i owioa okddilnk ylgm hiu uflm mk cwgukl bs i
    dgegmiws okywm jkw i owgdf mvfs ngnl'm okddgm. mvfuf dfl
    cwkdcmes fuoicfn jwkd i dixgdyd-ufoywgms umkoainf mk mvf
    eku ilqfefu ylnfwqwkyln. mknis, umgee hilmfn bs mvf
    qkrfwldflm, mvfs uywrgrf iu ukengfwu kj jkwmylf. gj sky virf i
    cwkbefd, gj lk klf feuf oil vfec iln gj sky oil jgln mvfd., disbf sky
    oil vgwf, mvf i- mfid.
    10
    Intercepted message:

    View Slide

  11. 11
    Let’s analyze:

    View Slide

  12. 12

    View Slide

  13. 13

    View Slide

  14. In 1972 a crack commando unit was sent to prison by a
    military court for a crime they didn't commit. These men
    promptly escaped from a maximum-security stockade to the
    Los Angeles underground. Today, still wanted by the
    government, they survive as soldiers of fortune. If you have a
    problem, if no one else can help and if you can find them,
    maybe you can hire, The A- Team.
    14
    http://gutenberg.spiegel.de/buch/3664/4
    Decrypted message:

    View Slide

  15. Determinism and the ability to apply
    frequency analysis are “bad things”
    15

    View Slide

  16. ➡ Previous examples were symmetrical encryptions.
    ➡ Same key is used for both encryption and decryption.
    ➡ Good symmetrical encryptions: AES, Blowfish, (3)DES.
    ➡ They are fast and secure.
    16

    View Slide

  17. Q: How does Alice send over the message +
    key securely to Bob? Everybody’s listening!
    17

    View Slide

  18. Another encryption system:
    Asymmetrical encryption or public key encryption.
    18

    View Slide

  19. public key - available for everybody.
    19
    KEYPAIR
    private key - For your eyes only!

    View Slide

  20. It is NOT possible to decrypt the message
    with same key that is used to encrypt.
    20

    View Slide

  21. 21
    Use public key to encrypt: private key to decrypt
    OR
    private key to encrypt: public key to decrypt.

    View Slide

  22. 22
    Encryption
    Signing

    View Slide

  23. 23
    Awesome! So why not using asymmetrical
    encryption for everything??

    View Slide

  24. 24
    It’s too slow!

    View Slide

  25. Symmetrical
    ✓ quick.
    ✓ not resource intensive.
    ✓ encryption only
    ✓ useful for small and large
    messages.
    ✗ need to send over the key
    to the other side.
    Asymmetrical
    ✓ no need to send over the
    (whole) key.
    ✓ can be used for encryption and
    signing.
    ✗ very resource intensive.
    ✗ only useful for small messages.
    25

    View Slide

  26. 26
    Q: How does Alice send over the message + key
    securely to Bob? Everybody’s listening!
    A: Use symmetrical encryption for the (large)
    message and encrypt the key used with an
    asymmetrical encryption method.

    View Slide

  27. ➡ Alice generates a random string:
    ➡ “monkeypooh”
    ➡ Alice encrypts this string with Bobs
    PUBLIC key => “sdfafkjasdgaag”
    27

    View Slide

  28. 28
    “sdfafkjasdgaag”
    ???
    (slow) public key encryption

    View Slide

  29. ➡ Bob received “sdfafkjasdgaag”
    ➡ Bob decrypts the message with his
    PRIVATE key => “monkeypooh”
    29

    View Slide

  30. 30
    ???
    (fast) symmetrical encryption using key “monkeypooh”
    1001001010111
    omglolbbq! haha hacker noobs!

    View Slide

  31. 31
    Hybrid Encryption

    View Slide

  32. Hybrid
    ✓ quick
    ✓ not resource intensive
    ✓ useful for small and large messages
    ✓ safely exchange key data
    32

    View Slide

  33. 33
    Signing

    View Slide

  34. 34
    ➡ Maybe even more important than
    encryption?
    ➡ Signing is authenticating that a message is
    actually send by the sender and is not
    compromised in any way.

    View Slide

  35. ➡ Bob creates a message:
    “i don’t like mondays”.
    ➡ Bob creates a md5() from this message:
    “b54c7cf4312cd6e2c37fd3f1ec681116”
    ➡ Bob encrypts this MD5 with his PRIVATE
    key => “43tt34tqegadsgadsgA”
    35

    View Slide

  36. 36
    “i don’t like mondays”
    “43tt34tqegadsgadsgA”

    View Slide

  37. ➡ Alice decrypts the hash with Bob’s
    PUBLIC key:
    “b54c7cf4312cd6e2c37fd3f1ec681116”
    ➡ Alice creates a md5() from the message =>
    “b54c7cf4312cd6e2c37fd3f1ec681116”
    ➡ Alice checks if both hashes match.
    37

    View Slide

  38. ➡ Can’t change message, because encrypted
    hash would not match.
    ➡ Can’t change hash, because only Bob’s
    private key can encrypt.
    38

    View Slide

  39. 39
    Great,.. but not really convinced...

    View Slide

  40. 40
    How many of you are actually using this
    encryption and signing in practice??

    View Slide

  41. 41
    100%

    View Slide

  42. 42

    View Slide

  43. 43

    View Slide

  44. ➡ When we go to a HTTPS website, we are
    establishing a symmetrical encryption.
    ➡ We use asymmetrical encryption to
    exchange the (random) key used.
    ➡ The public key we need to use is found in
    the SSL-certificate.
    44

    View Slide

  45. 45
    How do we know that the site is actually
    run by the ones we think they are?

    View Slide

  46. 46
    PRIVATE
    COMMUNICATION
    ENDPOINT
    AUTHENTICATION

    View Slide

  47. ➡ It is signed (by somebody else) that states:
    this certificate / URL truly belongs to them.
    ➡ Signed by their PRIVATE key, so we can use
    their PUBLIC key to check the signature.
    47

    View Slide

  48. ➡ (Root) Certificate Authorities
    ➡ They are automatically built into your
    browser / OS and you will automatically
    trust them.
    48

    View Slide

  49. 49
    http://mxr.mozilla.org/mozilla-central/source/security/nss/lib/ckfw/builtins/certdata.txt
    185

    View Slide

  50. ➡ We are forced to trust companies that
    make a living on selling as many certificates
    as possible..
    ➡ It’s a flawed system, but the best we have :(
    50

    View Slide

  51. 51
    ➡ But, we can fix pretty much everything else!

    View Slide

  52. 52
    ➡ Email: privately communicate between you
    and somebody else.
    ➡ Making sure your email isn’t tampered with
    and actually comes from you.
    ➡ Enigmail / gpgsuite
    ➡ Pretty easy to setup and use

    View Slide

  53. 53
    ➡ Every time you commit something to version
    control / github, you sign it with your key!
    ➡ Download new software (yum, apt, packagist)

    View Slide

  54. 54
    lots of ppl with keys lots of implementations
    not many ppl with keys no implementations
    no implementations not many ppl with keys

    View Slide

  55. 55
    Here’s another problem:
    ➡ Everybody can create a key
    ➡ And everybody can pretend to be anyone else

    View Slide

  56. 56
    ➡ We use a system called: web-of-trust

    View Slide

  57. 57

    View Slide

  58. ➡ How do we create the web-of-trust?
    58

    View Slide

  59. ➡ Every time you meet a person in real life.
    ➡ key signing parties on meetups,
    conferences, places where enough people
    come together.
    ➡ No need for a computer / laptop. Only
    your key (fingerprint) and something that
    identifies you being you (driving license, ID
    etc)
    59

    View Slide

  60. 60
    http://chemnitzer.linux-tage.de/2009/service/pgp_en.html

    View Slide

  61. 61

    View Slide

  62. ➡ Add GPG/PGP extension to your email
    client (enigmail / gpgsuite etc).
    ➡ Create a keypair.
    ➡ Use!
    ➡ Worry about the web-of-trust later!
    62

    View Slide

  63. ➡ PKE enables us to (automatically) enrich
    your content with security and/or privacy.
    ➡ It’s still hard to implement, but it’s getting
    better and easier.
    ➡ (e-)mail was hard too!
    ➡ We *need* it.
    63

    View Slide

  64. http://farm1.static.flickr.com/73/163450213_18478d3aa6_d.jpg 64

    View Slide

  65. 65
    Find me on twitter: @jaytaph
    Find me for development and training: www.noxlogic.nl
    Find me on email: [email protected]
    Find me for blogs: www.adayinthelifeof.nl
    http://joind.in/9608
