cpp11 - welding R and C++

R and S have a long history of interacting with compiled languages. The Rcpp package has been a widely successful project, however over the years a number of issues and additional C++ features have arisen. Modifying Rcpp to fix or include these would require a great deal of work, or in some cases would be impossible without severely breaking backwards compatibility. cpp11 is a ground up rewrite of C++ bindings to R with different design trade-offs and features. This talk will focus on the new features of cpp11 including:

- Enforcing copy-on-write semantics.
- Improving the safety of using the R API from C++ code.
- Supporting ALTREP objects.
- Using UTF-8 strings everywhere.
- Applying newer C++11 features.

Transcript

1. cpp11
   welding R and C++
    @jimhester_
   Photo by Christopher Burns on Unsplash


   View Slide

2. C++
   very fast
   statically typed
   lots of libraries
   limited safety net
   Photo by Filipa Saldanha on Unsplash


   View Slide

3. View Slide

4. Then why cpp11?
   Photo by Russ Ward on Unsplash


   View Slide

5. Photo by Micah Tindell on Unsplash


   View Slide

6. C++11
   move semantics
   auto pointers
   type traits
   initializer lists
   variadic templates
   user defined literals
   user defined attributes
   Photo by Markus Spiske on Unsplash


   View Slide

7. # Files Lines of code
   Rcpp (1.0.4) 379 74,658
   cpp11 (1.0.0) 19 1,734
   Simpler implementation


   View Slide

8. Rcpp features not in cpp11
   ❌ No modules
   ❌ No sugar
   ❌ Less attributes
   ❌ No automatic random number restoration
   ❌ No roxygen2 comment documentation
   ❌ No interfaces


   View Slide

9. package
   Rcpp
   compile time
   cpp11
   compile time
   Rcpp
   peak
   memory
   cpp11 peak
   memory
   haven 17.42s 7.13s 428MB 204MB
   readr 124.13s 81.08s 969MB 684MB
   roxygen2 17.34s 4.24s 371MB 109MB
   tidyr 14.25s 3.34s 363MB 83MB
   Cheaper compilation


   View Slide

10. header only
    Install pkgA with Rcpp x.y.z
    Later upgrade Rcpp
    pkgA segfaults
    tidyverse/dplyr#2335
    Photo by Yogendra Singh on Unsplash


    View Slide

11. vendor-able
    bring cpp11 to your
    ensure stability
    (miss out on updates)
    cpp_vendor()
    Photo by Humphrey Muleba on Unsplash


    View Slide

12. Protection cost


    View Slide

13. Vector growth


    View Slide

14. ✅ Semantics
    Safety
    Unicode
    ALTREP


    View Slide

15. –R Language Definition (Version 4.0.3)
    “The semantics of invoking a function in R argument are call-by-value.
    (sic). Changing the value of a supplied argument within a function will
    not affect the value of the variable in the calling frame.”


    View Slide

16. sum_vec sum for (val in x) {
    sum }
    sum
    }


    View Slide

17. Rcpp::sourceCpp(code = '#include "Rcpp.h"
    using namespace Rcpp;
    // [[Rcpp::export]]
    int sum_vec_rcpp(IntegerVector x) {
    int sum = 0;
    for (auto val : x) {
    sum = sum + val;
    }
    return sum;
    }')


    View Slide

18. Call-by-value
    x sum_vec(x)
    #> [1] 6
    x
    #> [1] 1 2 3
    sum_vec_rcpp(x)
    #> [1] 6
    x
    #> [1] 1 2 3


    View Slide

19. add_first x[[1]] x
    }
    Call-by-value


    View Slide

20. Rcpp::sourceCpp(code = '#include "Rcpp.h"
    using namespace Rcpp;
    // [[Rcpp::export]]
    IntegerVector add_first_rcpp(IntegerVector x) {
    x[0] = x[0] + 1;
    return x;
    }')
    Call-by-value?


    View Slide

21. x add_first(x)
    #> [1] 2 2 3
    x
    #> [1] 1 2 3
    add_first_rcpp(x)
    #> [1] 2 2 3
    x
    #> [1] 2 2 3
    Call-by-reference


    View Slide

22. x add_first(x)
    #> [1] 2 2 3
    x
    #> [1] 1 2 3
    add_first_rcpp(x)
    #> [1] 2 2 3
    x
    #> [1] 2 2 3
    Call-by-reference


    View Slide

23. Rcpp::sourceCpp(code = '#include "Rcpp.h"
    using namespace Rcpp;
    // [[Rcpp::export]]
    IntegerVector add_first_rcpp(IntegerVector x) {
    x[0] = x[0] + 1;
    return x;
    }')
    Call-by-reference


    View Slide

24. Rcpp::sourceCpp(code = '#include "Rcpp.h"
    using namespace Rcpp;
    // [[Rcpp::export]]
    IntegerVector add_first_rcpp(IntegerVector x) {
    x[0] = x[0] + 1;
    return x;
    }')
    Call-by-reference


    View Slide

25. Pinnacle
    of success
    Photo by lovely shots on Unsplash


    View Slide

26. Pit of success
    Photo by Eric Muhr on Unsplash


    View Slide

27. cpp11::cpp_function(code = '
    int sum_vec_cpp11(integers x) {
    int sum = 0;
    for (auto val : x) {
    sum = sum + val;
    }
    return sum;
    }
    [[cpp11::register]]
    integers add_one_cpp11(writable::integers x) {
    x[0] = x[0] + 1;
    return x;
    }
    ')


    View Slide

28. cpp11::cpp_function(code = '
    int sum_vec_cpp11(integers x) {
    int sum = 0;
    for (auto val : x) {
    sum = sum + val;
    }
    return sum;
    }
    [[cpp11::register]]
    integers add_one_cpp11(writable::integers x) {
    x[0] = x[0] + 1;
    return x;
    }
    ')


    View Slide

29. cpp11::cpp_function(code = '
    int sum_vec_cpp11(integers x) {
    int sum = 0;
    for (auto val : x) {
    sum = sum + val;
    }
    return sum;
    }
    [[cpp11::register]]
    integers add_one_cpp11(writable::integers x) {
    x[0] = x[0] + 1;
    return x;
    }
    ')


    View Slide

30. cpp11::cpp_function(code = '
    integers add_one_cpp11(integers x) {
    x[0] = x[0] + 1;
    return x;
    }', quiet = FALSE)
    // error: expression is not assignable
    // x[0] = x[0] + 1;
    // ~~~~ ^


    View Slide

31. Call-by-value
    x sum_vec_cpp11(x)
    #> [1] 6
    x
    #> [1] 1 2 3
    add_one_cpp11(x)
    #> [1] 2 2 3
    x
    #> [1] 1 2 3


    View Slide

32. Call-by-value
    x sum_vec_cpp11(x)
    #> [1] 6
    x
    #> [1] 1 2 3
    add_one_cpp11(x)
    #> [1] 2 2 3
    x
    #> [1] 1 2 3


    View Slide

33. Safety
    Photo by Rob Lambert on Unsplash


    View Slide

34. void fun() {
    std::string str("foo");
    Rf_error("something went wrong");
    }
    Memory leak?


    View Slide

35. void fun() {
    char* str = (char*) malloc(1024);
    Rf_error("something went wrong");
    free(str);
    }
    Memory leak


    View Slide

36. void fun() {
    std::string str("foo");
    throw std::runtime_error("something went wrong");
    }
    No memory leak


    View Slide

37. Rcpp::sourceCpp(code = '#include "Rcpp.h"
    std::string fun() {
    std::string str("foo");
    return str;
    }')
    Memory leak


    View Slide

38. SEXP fun() {
    std::string str("foo");
    SEXP x = Rf_allocVector(STRSXP, 1);
    SET_STRING_ELT(x, 0, Rf_mkChar(str.c_str()));
    return x
    }
    Safety
    Memory leak


    View Slide

39. SEXP fun() {
    std::string str("foo");
    SEXP x = Rf_allocVector(STRSXP, 1);
    SET_STRING_ELT(x, 0, Rf_mkChar(str.c_str()));
    return x
    }
    Safety
    Memory leak


    View Slide

40. SEXP fun() {
    std::string str("foo");
    SEXP x = Rf_allocVector(STRSXP, 1);
    SET_STRING_ELT(x, 0, Rf_mkChar(str.c_str()));
    return x
    }
    Safety
    Memory leak


    View Slide

41. –Jim Hester
    “All calls to R API functions can potentially error.”


    View Slide

42. Pit of success
    Photo by Kelly Sikkema on Unsplash


    View Slide

43. SEXP fun() {
    std::string str("foo");
    cpp11::unwind_protect([&] {
    SEXP x = Rf_allocVector(STRSXP, 1);
    SET_STRING_ELT(x, 0, Rf_mkChar(str.c_str()));
    });
    return x
    }
    No memory leak


    View Slide

44. SEXP fun() {
    std::string str("foo");
    cpp11::unwind_protect([&] {
    SEXP x = Rf_allocVector(STRSXP, 1);
    SET_STRING_ELT(x, 0, Rf_mkChar(str.c_str()));
    });
    return x
    }
    No memory leak


    View Slide

45. SEXP fun() {
    std::string str("foo");
    SEXP x = cpp11::safe[Rf_allocVector](STRSXP, 1);
    SET_STRING_ELT(x, 0, cpp11::safe[Rf_mkChar](str.c_str()));
    return x
    }
    No memory leak


    View Slide

46. SEXP fun() {
    std::string str("foo");
    SEXP x = cpp11::safe[Rf_allocVector](STRSXP, 1);
    SET_STRING_ELT(x, 0, cpp11::safe[Rf_mkChar](str.c_str()));
    return x
    }
    No memory leak


    View Slide

47. SEXP fun() {
    std::string str("foo");
    SEXP x = cpp11::safe[Rf_allocVector](STRSXP, 1);
    SET_STRING_ELT(x, 0, cpp11::safe[Rf_mkChar](str.c_str()));
    return x
    }
    No memory leak


    View Slide

48. Unicode
    Photo by Henry & Co. on Unsplash


    View Slide

49. Getting unicode right is HARD!


    View Slide

50. Getting unicode right is HARD!


    View Slide

51. Getting unicode right is HARD!


    View Slide

52. Getting unicode right is HARD!


    View Slide

53. Rcpp::sourceCpp(code = '
    #include "Rcpp.h"
    // [[Rcpp::export]]
    std::string do_nothing_rcpp(std::string x) {
    return x;
    }')


    View Slide

54. x Encoding(x) do_nothing_rcpp(x)
    #> [1] "façile"


    View Slide

55. x do_nothing_rcpp(x)
    #> [1] "façile"


    View Slide

56. Pit of success
    Photo by Tim Gouw on Unsplash


    View Slide

57. - utf8everywhere.org, Pavel Radzivilovsky, Yakov Galka and Slava Novgorodov
    “(UTF-8) should be the default choice of encoding for storing text
    strings in memory or on disk, for communication and all other uses.
    (this) improves performance, reduces complexity of software and helps
    prevent many Unicode-related bugs.”


    View Slide

58. – https://cpp11.r-lib.org/articles/motivations.html
    “text coming from R is always translated into UTF-8.
    text coming from C++ is always marked as UTF-8."


    View Slide

59. cpp11::cpp_source(code = '
    #include
    [[cpp11::register]]
    std::string do_nothing_cpp(std::string x) {
    return x;
    }')


    View Slide

60. SEXP f(SEXP x) {
    std::string str;
    str.reserve(Rf_xlength(STRING_ELT(x, 0)));
    void* vmax = vmaxget();
    str.assign(Rf_translateCharUTF8(STRING_ELT(x, 0)));
    vmaxset(vmax);
    api.do_stuff(str);
    }
    To C++


    View Slide

61. From C++
    SEXP f(SEXP x) {
    std::string data = api.get_data();
    return Rf_ScalarString(Rf_mkCharLenCE(data.c_str(),
    data.size(), CE_UTF8));
    }


    View Slide

62. x Encoding(x) do_nothing_cpp(x)
    #> [1] "façile"


    View Slide

63. x do_nothing_cpp(x)
    #> [1] "façile"


    View Slide

64. ALTREP
    Alternative representation
    R 3.5+
    Where's the data?
    Used in base R
    Used in
    Photo by Danilo Santos on Unsplash


    View Slide

65. View Slide

66. ALTREP aware
    sum_vec sum for (val in x) {
    sum }
    sum
    }
    x sum_vec(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @105a00cf8 13 INTSXP g0c0
    [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

67. ALTREP aware
    sum_vec sum for (val in x) {
    sum }
    sum
    }
    x sum_vec(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @105a00cf8 13 INTSXP g0c0
    [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

68. ALTREP aware
    sum_vec sum for (val in x) {
    sum }
    sum
    }
    x sum_vec(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @105a00cf8 13 INTSXP g0c0
    [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

69. Not ALTREP aware
    // [[Rcpp::export]]
    int sum_vec_rcpp(IntegerVector x) {
    int sum = 0;
    for (auto val : x) {
    sum = sum + val;
    }
    return sum;
    }
    x sum_vec_rcpp(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @10600fe40 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (expanded)
    lobstr::obj_sizes(x)
    #> 40,728 B


    View Slide

70. Not ALTREP aware
    // [[Rcpp::export]]
    int sum_vec_rcpp(IntegerVector x) {
    int sum = 0;
    for (auto val : x) {
    sum = sum + val;
    }
    return sum;
    }
    x sum_vec_rcpp(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @10600fe40 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (expanded)
    lobstr::obj_sizes(x)
    #> 40,728 B


    View Slide

71. Not ALTREP aware
    // [[Rcpp::export]]
    int sum_vec_rcpp(IntegerVector x) {
    int sum = 0;
    for (auto val : x) {
    sum = sum + val;
    }
    return sum;
    }
    x sum_vec_rcpp(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @10600fe40 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (expanded)
    lobstr::obj_sizes(x)
    #> 40,728 B


    View Slide

72. Not ALTREP aware
    // [[Rcpp::export]]
    int sum_vec_rcpp(IntegerVector x) {
    int sum = 0;
    for (auto val : x) {
    sum = sum + val;
    }
    return sum;
    }
    x sum_vec_rcpp(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @10600fe40 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (expanded)
    lobstr::obj_sizes(x)
    #> 40,728 B


    View Slide

73. Not ALTREP aware
    SEXP sum_vec_c(SEXP x) {
    int sum = 0;
    int* p = INTEGER(x);
    for (R_xlen_t i = 0; i < Rf_xlength(x); ++i) {
    sum = sum + p[i];
    }
    return Rf_ScalarInteger(sum);
    }
    x sum_vec_c(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @1351f7858 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (expanded)
    lobstr::obj_sizes(x)
    #> 40,728 B


    View Slide

74. Not ALTREP aware
    SEXP sum_vec_c(SEXP x) {
    int sum = 0;
    int* p = INTEGER(x);
    for (R_xlen_t i = 0; i < Rf_xlength(x); ++i) {
    sum = sum + p[i];
    }
    return Rf_ScalarInteger(sum);
    }
    x sum_vec_c(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @1351f7858 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (expanded)
    lobstr::obj_sizes(x)
    #> 40,728 B


    View Slide

75. Not ALTREP aware
    SEXP sum_vec_c(SEXP x) {
    int sum = 0;
    int* p = INTEGER(x);
    for (R_xlen_t i = 0; i < Rf_xlength(x); ++i) {
    sum = sum + p[i];
    }
    return Rf_ScalarInteger(sum);
    }
    x sum_vec_c(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @1351f7858 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (expanded)
    lobstr::obj_sizes(x)
    #> 40,728 B


    View Slide

76. Not ALTREP aware
    SEXP sum_vec_c(SEXP x) {
    int sum = 0;
    int* p = INTEGER(x);
    for (R_xlen_t i = 0; i < Rf_xlength(x); ++i) {
    sum = sum + p[i];
    }
    return Rf_ScalarInteger(sum);
    }
    x sum_vec_c(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @1351f7858 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (expanded)
    lobstr::obj_sizes(x)
    #> 40,728 B


    View Slide

77. ALTREP aware
    SEXP sum_vec_c2(SEXP x) {
    int sum = 0;
    for (R_xlen_t i = 0; i < Rf_xlength(x); ++i) {
    sum = sum + INTEGER_ELT(x, i);
    }
    return Rf_ScalarInteger(sum);
    }
    x sum_vec_c2(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @103e50f80 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

78. ALTREP aware
    SEXP sum_vec_c2(SEXP x) {
    int sum = 0;
    for (R_xlen_t i = 0; i < Rf_xlength(x); ++i) {
    sum = sum + INTEGER_ELT(x, i);
    }
    return Rf_ScalarInteger(sum);
    }
    x sum_vec_c2(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @103e50f80 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

79. ALTREP aware
    SEXP sum_vec_c2(SEXP x) {
    int sum = 0;
    for (R_xlen_t i = 0; i < Rf_xlength(x); ++i) {
    sum = sum + INTEGER_ELT(x, i);
    }
    return Rf_ScalarInteger(sum);
    }
    x sum_vec_c2(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @103e50f80 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

80. ALTREP aware
    SEXP sum_vec_c3(SEXP x) {
    int sum = 0;
    int buf[1024];
    R_xlen_t i = 0;
    R_xlen_t n = Rf_xlength(x);
    while(i < n - 1024) {
    INTEGER_GET_REGION(x, i, 1024, buf);
    for (R_xlen_t j = 0; j < 1024; ++j) {
    sum = sum + buf[j];
    }
    i += 1024;
    }
    R_xlen_t extra = n - i;
    INTEGER_GET_REGION(x, i, extra, buf);
    for (R_xlen_t j = 0; j < extra; ++j) {
    sum = sum + buf[j];
    }
    return Rf_ScalarInteger(sum);
    }
    }
    x sum_vec_c3(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @1342a4be0 13 INTSXP g0c0
    #> [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

81. ALTREP aware
    SEXP sum_vec_c3(SEXP x) {
    int sum = 0;
    int buf[1024];
    R_xlen_t i = 0;
    R_xlen_t n = Rf_xlength(x);
    while(i < n - 1024) {
    INTEGER_GET_REGION(x, i, 1024, buf);
    for (R_xlen_t j = 0; j < 1024; ++j) {
    sum = sum + buf[j];
    }
    i += 1024;
    }
    R_xlen_t extra = n - i;
    INTEGER_GET_REGION(x, i, extra, buf);
    for (R_xlen_t j = 0; j < extra; ++j) {
    sum = sum + buf[j];
    }
    return Rf_ScalarInteger(sum);
    }
    }
    x sum_vec_c3(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @1342a4be0 13 INTSXP g0c0
    #> [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

82. ALTREP aware
    SEXP sum_vec_c3(SEXP x) {
    int sum = 0;
    int buf[1024];
    R_xlen_t i = 0;
    R_xlen_t n = Rf_xlength(x);
    while(i < n - 1024) {
    INTEGER_GET_REGION(x, i, 1024, buf);
    for (R_xlen_t j = 0; j < 1024; ++j) {
    sum = sum + buf[j];
    }
    i += 1024;
    }
    R_xlen_t extra = n - i;
    INTEGER_GET_REGION(x, i, extra, buf);
    for (R_xlen_t j = 0; j < extra; ++j) {
    sum = sum + buf[j];
    }
    return Rf_ScalarInteger(sum);
    }
    }
    x sum_vec_c3(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @1342a4be0 13 INTSXP g0c0
    #> [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

83. ALTREP aware
    SEXP sum_vec_c3(SEXP x) {
    int sum = 0;
    int buf[1024];
    R_xlen_t i = 0;
    R_xlen_t n = Rf_xlength(x);
    while(i < n - 1024) {
    INTEGER_GET_REGION(x, i, 1024, buf);
    for (R_xlen_t j = 0; j < 1024; ++j) {
    sum = sum + buf[j];
    }
    i += 1024;
    }
    R_xlen_t extra = n - i;
    INTEGER_GET_REGION(x, i, extra, buf);
    for (R_xlen_t j = 0; j < extra; ++j) {
    sum = sum + buf[j];
    }
    return Rf_ScalarInteger(sum);
    }
    }
    x sum_vec_c3(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @1342a4be0 13 INTSXP g0c0
    #> [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

84. function time
    sum_vec_c 374µs
    sum_vec_c2 625µs
    sum_vec_c3 186µs


    View Slide

85. Pit of success
    Photo by Christian Bowen on Unsplash


    View Slide

86. ALTREP aware
    int sum_vec_cpp11(integers x) {
    int sum = 0;
    for (auto val : x) {
    sum = sum + val;
    }
    return sum;
    }
    x sum_vec_cpp11(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @134b695f0 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

87. ALTREP aware
    int sum_vec_cpp11(integers x) {
    int sum = 0;
    for (auto val : x) {
    sum = sum + val;
    }
    return sum;
    }
    x sum_vec_cpp11(x)
    #> [1] 50005000
    .Internal(inspect(x))
    #> @134b695f0 13 INTSXP g0c0 [REF(65535)] 1 : 10000 (compact)
    lobstr::obj_sizes(x)
    #> 680 B


    View Slide

88. ✅ Semantics
    Safety
    Unicode
    ALTREP
    cpp11.r-lib.org
    C++11
    simple(r)
    cheaper
    | compilation
    | appending
    | protection
    header only
    vendor-able
     @jimhester_


    View Slide
