1. Kubernetes on OpenStack on Kubernetes with Magnum and Kolla Kyle bai R&D @ inwinSTACK www.inwinstack.com www.openstack.org Gene Kuo AUC @ OpenStack Kubernetes Day
2. About Us 郭靖 & 黃蓉⽩白仁 Job R&D@ inwinSTACK kairen(kyle.b@inwinstack.com) https://kairen.github.io/ Love Buttocks Coffee Good! Previously worked on iOS and Cloud-native team at NUTC imac as team leader. OpenStack and Kubernetes Contributor, Kubernetes Certified Administrator. Job Student @ NCTU AUC @ OpenStack He is working in the different field from his major as below: • OpenStack Active User Contributor. • Former OpenStack Foundation Intern. • Organizer at OpenStack Taiwan User Group. • Contact me for gene@openstack.org
3. Agenda Today We will talk about K8s on OpenStack on K8s 10min 15min 15min OpenStack & Kubernetes Let’s Go OpenStack on K8s Bonus
4. OpenStack & Kubernetes
5. What is OpenStack? • OpenStack software controls large pools of compute, storage, and networking resources throughout a datacenter, managed through a dashboard or via the OpenStack API. • It’s a collection of projects that collectively form a multi-tenant cloud operating system. • OpenStack is a free and open-source. Deployments 1000+ Projects 50+ Contributors 13161+
7. What is OpenStack Not? • Easy to deploy • Easy to scale • Easy to provide high availability • Easy to upgrade • Easy to manage
8. What is Kubernetes? • Kubernetes is an open-source platform for automating deployment, scaling, and operations of application containers across clusters of hosts, providing container-centric infrastructure. • Easy to deploy, scale, manage, …,etc. • CNCF Project. Stars 25,830+ Commits 52,905+ Contributors 1,331+
9. What is Kubernetes Not? • Multi-tenancy • Multi-cluster • Good at supporting complex networking topology. • Part of a large established ecosystem, running many production workloads.
10. OpenStack on Kubernetes
11. OpenStack on Kubernetes Deploy and manage OpenStack on Kubernetes.
12. The Infrastructure Sandwich • Bare metal, Virtual machine and Container. • Auto-scale the Kubernetes Cluster. • Helm-based Application deployment on Kubernetes. • Multi-tenancy environment. • Manage multiple Kubernetes cluster.
13. What is Kolla? Kolla provides production-ready containers and deployment tools for operating OpenStack clouds that are scalable, fast, reliable, and upgradable using community best practices.
14. What is Kolla-Kubernetes? Kolla-Kubernetes is a community driven deliverable of the OpenStack Kolla project that delivers complete lifecycle management, often referred to as day-2 operations, of OpenStack services running on a Kubernetes underlay.
15. Terminology = + + + +
16. This work is progressing quickly Using Kubernetes v1.6+ Primatives: • Using Kubernetes Helm Charts. • Services are tagged to nodes. • Agents become Daemon sets. • Databases using Stateful sets. • Multiple container sources.
17. Why Kolla-Kubernetes? • OpenStack just another application. • Natural evolution for Kolla. • Benefits: • Abstraction layer for hardware. • Orchestrate and manage a complex application. • Additions to Kolla-Kubernetes: • Fernet tokens as default keystone token mechanism. • Support Ironic. • Support Prometheus.
18. Kolla-K8s Architecture
19. What's new in Pike? • Dynamic volume provisioning • Kolla-Kubernetes by default uses Ceph for stateful storage. • With Kubernetes 1.5+, support was added for Ceph and dynamic volume provisioning as requested by claims made against the API server. • Service level package using Kubernetes entrypoint. • Image pull policy can now be set for all containers. • Helm chart to bring up OpenStack deployment. • mariadb, rabbitmq, memcached, keystone, glance, cinder, neutron, nova and horizon. This compute kit uses iscsi/lvm as a backend for cinder volume.
20. https://www.youtube.com/watch?v=rHCCUP2odd8
21. K8s on OpenStack on K8s
22. K8s on OpenStack on K8s
23. What is Magnum? Magnum is an OpenStack project which offers container orchestration engines for deploying and managing containers as first class resources in OpenStack.
24. Terminology • COE: Container Orchestration Engine to manage containers. Examples: Kubernetes, Docker Swarm, Apache Mesos, DCOS. • Cluster/Bay: A construct in which Magnum launches COE.
25. Terminology • ClusterTemplate/BayModel: Template for creating clusters. Includes image, COE. • Native Client: Use native clients at COE level or at container level to interact with clusters. Ex: kubectl, docker, zun.
26. Why Magnum? • Abstractions for Clusters • Multi-tenancy for containers. • Reusing OpenStack Components like Keystone, Heat, Glance, Neutron, …, etc. • Multiple COEs side by side • Server Type: VM, Bare Metal.
27. Magnum Architecture
28. What's new in Pike? • Kubernetes clusters now Include the kubernetes dashboard. • Monitoring stack based on cAdvisor, node-exporter, Prometheus and Grafana. • Restriction of the access of Magnum’s trustID so that it doesn’t have unrestricted access to every service in OpenStack project. • DC/OS supported.
29. https://www.youtube.com/watch?v=uLcjdushn6g
30. Bonus
31. What is Kuryr? Kuryr is a Docker network plugin that uses Neutron to provide networking services to Docker containers. It provides containerized images for the common Neutron plugins. Run both OpenStack VMs and Kubernetes Pods on the same Neutron network https://github.com/openstack/kuryr
32. Kuryr Architecture
33. What is Stackube? Stackube is a Kubernetes-centric OpenStack distro. It uses Kubernetes, instead of Nova, as the compute fabric controller, to provision containers as the compute instance, along with other OpenStack services (e.g. Cinder, Neutron). It supports multiple container runtime technologies, e.g. Docker, Hyper, and offers built-in soft / hard multi-tenancy (depending on the container runtime used). Integrate OpenStack projects with Kubernetes for multi-tenancy. https://github.com/openstack/stackube
34. Stackube Architecture
35. What is KubeSpray? KubeSpray is an incubated Kubernetes community project for deploying K8s clusters on premises or in the cloud. https://github.com/kubernetes-incubator/kubespray
36. KubeSpray Architecture
37. Features • Can be deployed on AWS, GCE, Azure, OpenStack or Baremetal. • High availability cluster Support. • Composable (Choice of the network plugin for instance). • Support most popular Linux distributions. • Continuous integration tests. • Support kubeadm deployment.
38. 38 有任何問題與想法，可以⼀一起討論唷。 Thank You!!
