1. Code Pipeline, Code Build, ECR, ECS, Auto Scaling AWSで構築する Docker環境CI/CD
3. ONLY FIVEインフラ
4. Dockerの CI/CD環境
5. Code Pipeline Code Build ECS Github Integration ECR Push Images Update Task Definition Build Test Push Build docker images. Run tests. Push docker images to ECR. Architecture
7. Code Build ECS Github Integration
8. IAM リソース権限管理 Code Build ECS Github Integration
10. version: 0.2 phases: install: runtime-versions: docker: 18 pre_build: commands: - aws --version - $(aws ecr get-login --region $AWS_DEFAULT_REGION --no-include-email) - REPOSITORY_URI=000000000000.dkr.ecr.ap-northeast-1.amazonaws.com/example.com/app - COMMIT_HASH=$(echo $CODEBUILD_RESOLVED_SOURCE_VERSION | cut -c 1-7) - IMAGE_TAG=${COMMIT_HASH:=latest} build: commands: - docker-compose -f docker-compose.prd.yml build - docker-compose -f docker-compose.prd.yml run app rails test - docker tag app REPOSITORY_URI:$IMAGE_TAG post_build: commands: - docker push $REPOSITORY_URI:$IMAGE_TAG - printf '[{"name":"app","imageUri":"%s"}]' $REPOSITORY_URI:$IMAGE_TAG > imagedefinitions.json artifacts: files: imagedefinitions.json AWS CLIのログインや変数の セットアップ PRE BUILD Dockerイメージのビルドとテス トの実行 BUILD ECRのレポジトリにビルドした イメージをプッシュ POST BUILD
11. Docker Dockerベースなのでビルド設定は compose buildするだけ
12. メモリ Build Server Spec メモリ メモリ メモリ
14. Rails Container Nginx Container Auto Scaling Group EC2 Instance
15. Rails Nginx Rails Nginx Load Balancer ALB
18. Code Pipeline Code Build ECS Github Integration ECR Push Images Update Task Definition Build Test Push Build docker images. Run tests. Push docker images to ECR. Architecture
21. 早いサイクルでリリース 今まで CI/CD
22. 今後の”時間” に投資する
23. CREDITS: This presentation template was created by Slidesgo, including icons by Flaticon, and infographics & images by Freepik THANKS Do you have any questions? keiji.namba@post-urban.co 070-1877-9900 https://post-urban.co
