Generate anonymised database with MasKING - 2023.09.21 Euruko Unconference Talk

video: https://youtu.be/oml7dcDo_jo
Generate anonymised database with MasKING - 2023.09.21 Euruko Unconference Talk

repo: https://github.com/kibitan/masking
presentation slide: https://docs.google.com/presentation/d/106kyWEeJ1G2reMKXx2ytKbq6BlvdXV1HZnIrQW442fA

Transcript

1. Generate anonymised database
   with MasKING
   Chikahiro Tokoro Euruko 2023 at Vilnius: Unconference Talk


   View Slide

2. Why do we want anonymised
   database?


   View Slide

3. One day, during the release….


   View Slide

4. One day, during the release….
   the main table was locked
   during database migration😱


   View Slide

5. staging
   (QA)
   production
   local
   (development)
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   0.2 sec 3 sec 1 hour
   the postmortem: check the delivery process


   View Slide

6. If with similar dataset with production...
   staging
   (QA)
   production
   local
   (development)
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   1 hour


   View Slide

7. But, we should not use
   the production dataset
   Let’s use
   anonymised dataset!


   View Slide

8. Use cases:
   ● simulate database migration
   local
   (development)
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   —-
   1 hour


   View Slide

9. Use cases:
   ● SQL performance optimization
   accurate execution plan
   # Time: 2023-09-13T15:45:12.987654Z
   # User@Host: web_app[web_db] @ 10.0.0.2
   # Query_time: 25.987654 Lock_time: 2.345678
   Rows_sent: 50 Rows_examined: 5000
   SET timestamp=1234567890;
   SELECT
   users.id,
   users.username,
   COUNT(posts.id) AS post_count,
   SUM(posts.likes) AS total_likes
   FROM users
   LEFT JOIN posts ON users.id = posts.user_id
   WHERE users.created_at >= '2023-01-01'
   GROUP BY users.id
   HAVING post_count >= 5
   ORDER BY total_likes DESC
   LIMIT 10;
   slow query log


   View Slide

10. Use cases:
    ● make ease to reproduce and fix bugs
    unexpected
    values
    missing
    related record
    duplicated
    records


    View Slide

11. Use cases:
    ● better feature preview
    ● stress test
    ● analyse / Business Intelligence data source
    And… your idea here!


    View Slide

12. https://www.snaplet.dev/
    Founded on 2020


    View Slide

13. https://www.snaplet.dev/
    Founded on 2020


    View Slide

14. How to implement anonymisation process?
    1. copy database and “UPDATE” records
    production
    production
    (copy)
    UPDATE users
    SET name = 'User1',
    email = 'user1@test.com',
    ....
    (most common way)


    View Slide

15. How to implement anonymisation process?
    2. setup replica and database trigger
    production
    production
    (replica)
    CREATE TRIGGER after_user_insert
    AFTER INSERT ON users FOR EACH ROW
    BEGIN
    UPDATE users
    SET username = CONCAT('User', NEW.user_id)
    WHERE user_id = NEW.user_id;
    ...


    View Slide

16. How to implement anonymisation process?
    3. proxy connection and interrupt SQL on the fly
    production
    INSERT INTO users (username, email, ...)
    VALUES ('JohnDoe', 'johndoe@domain.com'
    , ...);
    production
    (copy)
    Connection Proxy
    INSERT INTO users (username, email, ...)
    VALUES ('JohnDoe', 'johndoe@domain.com'
    , ...);
    INSERT INTO users (username, email, ...)
    VALUES ('User1', 'user1@test.com
    ', ...);


    View Slide

17. How to implement anonymisation process?
    4. read database and create anonymised database
    production
    dump
    anonymised
    dump
    production
    (anonymised)
    database
    client
    (second common way)


    View Slide

18. How to implement anonymisation process?
    4.
    data leak
    risk
    Medium
    Low
    Low
    effort
    Medium
    High
    Medium
    Low
    config
    High
    Medium
    Low
    Low
    time gap
    realtime
    realtime
    Medium
    Long
    performance
    regression
    No
    Yes
    No
    No
    2. DB trigger
    3. DB proxy
    read &
    create
    1. copy &
    UPDATE High


    View Slide

19. How to implement anonymisation process?
    4.
    data leak
    risk
    Medium
    Low
    Low
    effort
    Medium
    High
    Medium
    Low
    config
    High
    Medium
    Low
    Low
    time gap
    realtime
    realtime
    Medium
    Long
    performance
    regression
    No
    Yes
    No
    No
    2. DB trigger
    3. DB proxy
    read &
    create
    1. copy &
    UPDATE High


    View Slide

20. https://github.com/kibitan/masking


    View Slide

21. Usage
    anonymized+1@example.com
    anonymized+2@example.com
    anonymized+3@example.com
    …
    users:
    email: anonymized+%{n}@example.com


    View Slide

22. Usage

    $ mysql --complete-insert DB_NAME | masking | mysql ANONYMIZED_DB_NAME


    View Slide

23. Generate anonymised database with MasKING - Demo - YouTube
    Demo


    View Slide

24. Generate anonymised database with MasKING - Demo - YouTube
    Demo
    masking.yml


    View Slide

25. Generate anonymised database with MasKING - Demo - YouTube
    Demo


    View Slide

26. Generate anonymised database with MasKING - Demo - YouTube
    Demo


    View Slide

27. Design Concepts


    View Slide

28. Design Concept: KISS ~ Keep it simple, stupid! ~
    “Do one thing, and do it well”
    Unix philosophy
    ❌ Database connection
    ❌ File handling
    ✅ Standard input/output


    View Slide

29. Design Concept: No external dependency
    No gems dependencies, use only standard libraries


    View Slide

30. Design Concept: Quality


    View Slide

31. Design Concept: Quality - metrics


    View Slide

32. Design Concept: Quality - Acceptance test
    setup
    test
    assertion
    docker-compose.yml
    acceptance/run_test.sh


    View Slide

33. Design Concept: Quality - Acceptance test on CI


    View Slide

34. How to implement?


    View Slide

35. users:
    name: Anonymized Name
    email: anonymized+%{n}@example.com
    masking.yml
    dump.sql anonymised_dump.sql
    masking


    View Slide

36. Domains: uncertainties
    Mapping
    configuration
    ?
    Parse/Rebuild
    SQL


    View Slide

37. Domains: uncertainties
    Mapping
    configuration
    Parse/Rebuild
    SQL
    Introduction to Test-Driven Development (TDD) with Classic TDD Example | Khalil Stemmler


    View Slide

38. ① Outside-in
    Mapping
    configuration
    stdin
    ① Outside-in
    ② Inside-out
    Parse/Rebuild
    SQL
    ③ Inside-out
    Domains: finding architecture/models
    Output
    Line
    Input
    Line
    stdout
    Processor
    ⑤ Outside-in ⑤ Outside-in
    ④ Inside-out


    View Slide

39. How to parse dump?


    View Slide

40. sample_dump.sql
    setup database
    define table schema
    insert data



    View Slide

41. https://dev.mysql.com/doc/refman/8.0/en/mysqldump.html


    View Slide

42. setup database
    define table schema
    insert data
    sample_dump_with_complete-insert_option.sql


    View Slide

43. setup database
    define table schema
    insert data
    sample_dump_with_complete-insert_option.sql


    View Slide

44. How to parse SQL?


    View Slide

45. https://github.com/kibitan/masking/blob/main/lib/masking/insert_statement.rb
    dynamically make
    regular expression object
    ?
    ?
    ?
    VALUE_REGEXP x 3


    View Slide

46. https://github.com/kibitan/masking/blob/main/lib/masking/insert_statement.rb
    dynamically make
    regular expression object
    ?
    ?
    ?
    VALUE_REGEXP x 3


    View Slide

47. $ mysqldump --complete-insert production_db | masking > anonymised_dump.sql
    /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/insert_statement.rb:15:in `block in initialize':
    Masking::Error::InsertStatementParseError (Masking::Error::InsertStatementParseError)
    from :90:in `tap'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/insert_statement.rb:14:in `initialize'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/data_mask_processor.rb:12:in `new'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/data_mask_processor.rb:12:in `initialize'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/sql_dump_line.rb:13:in `new'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/sql_dump_line.rb:13:in `mask'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking.rb:23:in `block in run'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking.rb:22:in `each_line'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking.rb:22:in `run'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking.rb:10:in `run'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/cli.rb:17:in `run'
    from exe/masking:10:in `'
    let’s try with production data!


    View Slide

48. $ mysqldump --complete-insert production_db | masking > anonymised_dump.sql
    /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/insert_statement.rb:15:in `block in initialize':
    Masking::Error::InsertStatementParseError (Masking::Error::InsertStatementParseError)
    from :90:in `tap'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/insert_statement.rb:14:in `initialize'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/data_mask_processor.rb:12:in `new'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/data_mask_processor.rb:12:in `initialize'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/sql_dump_line.rb:13:in `new'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/sql_dump_line.rb:13:in `mask'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking.rb:23:in `block in run'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking.rb:22:in `each_line'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking.rb:22:in `run'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking.rb:10:in `run'
    from /Users/kibitan/repo/github.com/kibitan/masking/lib/masking/cli.rb:17:in `run'
    from exe/masking:10:in `'
    let’s try with production data!


    View Slide

49. the journey to ready for production data
    https://github.com/kibitan/masking/commit/792e73b7d316fac1fa6694d74b6adcfee19dccc4


    View Slide

50. https://github.com/kibitan/masking/commit/8ca7fdad2c52d3af5e6c56faadc08e8768500108
    the journey to ready for production data


    View Slide

51. https://github.com/kibitan/masking/commit/04515ec0f9c8a5457c10b8224b488b90c90c6aa2
    the journey to ready for production data


    View Slide

52. https://github.com/kibitan/masking/pull/3
    the journey to ready for production data


    View Slide

53. $ mysqldump --complete-insert production_db | masking > anonymised_dump.sql
    $ mysql anonymised_db < anonymised_dump.sql
    ERROR 1064 (42000) at line 547659: You have an error in your SQL
    syntax; check the manual that corresponds to your MySQL server
    version for the right syntax to use near 'smelati’),' at line 547659
    the journey to ready for production data


    View Slide

54. (‘ab’,1),(’cd’,2),(’ef’,3);
    the journey to ready for production data


    View Slide

55. (‘ab’,1),(’cd’,2),(’ef’,3);
    ‘ab’,1,’cd’,2,’ef’,3;
    same with
    CSV!!!
    the journey to ready for production data


    View Slide

56. https://www.clear-code.com/blog/2018/12/25.html
    the journey to ready for production data


    View Slide

57. 2.even? 3.even?
    4.even?
    concat with next
    4.even?
    the journey to ready for production data


    View Slide

58. https://github.com/kibitan/masking/pull/5
    the journey to ready for production data


    View Slide

59. https://github.com/kibitan/masking/pull/5
    the journey to ready for production data


    View Slide

60. View Slide

61. what’s next?
    ● support random/fake data
    ● parse table schema
    ● performance optimization
    ○ type validation for config
    ○ working without “--complete-insert” option


    View Slide

62. what’s next?: for PostgreSQL
    https://github.com/kibitan/pgmasking


    View Slide

63. Thank you!
    Any feedback is welcome!
    https://github.com/kibitan/masking
    Chikahiro
    x/twitter: @chikahirotokoro
    https://chikahirotokoro.com


    View Slide
