Media Handling for Animated Sticker in Sticker Maker
Po
April 19, 2024
Transcript
26 slides
-
© LY Corporation Media Handling for Animated Sticker in Sticker
Maker LINEϠϑʔɹApp Dev෦ Sticker Maker App Dev νʔϜ Dev Lead ΆʔɹPo-Hao Chen -
© LY Corporation - Άʔ - Android Engineer - 2020.11
LINE Fukuoka - 2024.01 LINE Yahoo - LINE Client Dev -> LINE Sticker Maker Dev Lead - X: @kuramu1108 - ࠷ۙͷΈ - ࣾһূΕ͕ͪ - Xcode͍ͮΒ͍ 2 Speaker -
© LY Corporation Timeline 5 July 2022 First Animated Sticker
Proposal made Late 2022 Project Kick Off Early 2023 Android Prototype Jan 2024 Android Beta Release Mar 2024 iOS Beta Release Mid-Late 2023 Release Planning Development -
© LY Corporation Challenges and Improvement 6 - In-House APNG
encoder to fulfill LINE Creators Market restriction - Video frame extraction - Customized Camera screen - Customized Gallery screen - Some other stuff - APNG in compose (Not included today) - etc -
© LY Corporation Animated Sticker Guidelines 7 • Loops: 1
– 4 loops per sticker whose combined length does not exceed 4 seconds. • Playback time: Up to 4 seconds per sticker. • PNG frame limits per APNG: Between 5 and 20 frames. • The maximum file size for each image is 300 KB. If submitting all images in a single ZIP file, make sure the ZIP file is 20 MB or less. -
© LY Corporation Solutions 8 - If Created APNG with
full color info (RGBA) the file would be too big - Converting 4 second video to RGBA encode apng of 320 * 270 would over 1MB - Need to encode with indexed color and optimization color palette - Color space is limited -> Color info optimization -
© LY Corporation PNG Spec 11 - http://www.libpng.org/pub/png/spec/1.2/PNG-Contents.html - 90
pages in PDF - In-House customized encoder - Kotlin Encoder - C++ Encoder with NDK - Color palette optimization with dynamic color palette and color quantization -
© LY Corporation Video Frame Extraction and Encode APNG 12
Project Info (Video uri, decoration etc -
© LY Corporation Video Frame Extraction and Encode APNG 13
Project Info (Video uri, decoration etc Color Palette Creation -
© LY Corporation Video Frame Extraction and Encode APNG 14
Project Info (Video uri, decoration etc Extract Critical Video Frames (1/2 of frames) Color Palette Creation -
© LY Corporation Video Frame Extraction and Encode APNG 15
Project Info (Video uri, decoration etc Extract Critical Video Frames (1/2 of frames) Color Palette Creation Apply Transform and decoration -
© LY Corporation Video Frame Extraction and Encode APNG 16
Project Info (Video uri, decoration etc Extract Critical Video Frames (1/2 of frames) Color Palette Creation Apply Transform and decoration Calculate Color Palette -
© LY Corporation Video Frame Extraction and Encode APNG 17
Project Info (Video uri, decoration etc Color Palette Creation -
© LY Corporation Video Frame Extraction and Encode APNG 18
Project Info (Video uri, decoration etc Apply Transform and decoration to Each Frame Color Palette Creation -
© LY Corporation Video Frame Extraction and Encode APNG 19
Project Info (Video uri, decoration etc Apply Transform and decoration to Each Frame Final Encoding with Optimized Palette Color Palette Creation -
© LY Corporation Video Frame Extraction and Encode APNG 20
Project Info (Video uri, decoration etc Apply Transform and decoration to Each Frame Final Encoding with Optimized Palette Color Palette Creation -
© LY Corporation Customized Camera 21 - CameraX - https://developer.android.com/media/camera/
camerax - https://medium.com/@seungbae2/camera2- vs-camerax-a-comparison-of-android- camera-apis-5db2b5ff302e -
© LY Corporation Customized Photo Picker 22 - Android Photo
Picker - Android 11 (API 30)+ - https://developer.android.com/training/ data-storage/shared/photopicker - MediaStore - Flexible apis - https://developer.android.com/training/ data-storage/shared/media -
© LY Corporation - Android Photo Picker - Android 11
(API 30)+ - https://developer.android.com/training/ data-storage/shared/photopicker - MediaStore - Flexible apis - https://developer.android.com/training/ data-storage/shared/media Customized Photo Picker 23 -
© LY Corporation - Android Photo Picker - Android 11
(API 30)+ - https://developer.android.com/training/ data-storage/shared/photopicker - MediaStore - Flexible apis - https://developer.android.com/training/ data-storage/shared/media Customized Photo Picker 24
