Paging with Compose without Paging for Compose

Transcript

1. Paging with Compose Without Paging for Compose Po (Po-Hao Chen) App Developmentࣨ Sticker Maker AppνʔϜ
2. Agenda - Sticker Maker and Compose - Paging for Compose - Self-implemented Paging management - Appendix
3. About the Speaker @kuramu1108 • Joined LFK at 2020.11 • Former position: • LINE Wallet Android Dev • Current position: • LINE Sticker Maker Client Dev Lead • Hobby: • Coffee, Camp
4. LINE Sticker Maker LINE ελϯϓϝʔΧʔ • Allow user to create and edit stickers • Allow user to submit sticker package to sell
5. Adopting Jetpack Compose https://tech-verse.me/ja/sessions/16 🤝
6. Screen Including Paging Data /** * Returns 10 item after [key]. * If [key] is null, return the 10 newest item. */ @GET() suspend fun getPackages( key: Long?, ): List<Package> • Displays the user’s submitted sticker package • Display Newest first • No local data • Originally implemented with self-managed paging with Rx
7. The Jetpack paging-compose https://developer.android.com/jetpack/androidx/releases/paging
8. The Jetpack paging-compose https://developer.android.com/topic/libraries/architecture/paging/v3-overview
9. The Jetpack paging-compose https://developer.android.com/topic/libraries/architecture/paging/v3-overview
10. Why Not? https://developer.android.com/topic/libraries/architecture/paging/v3-overview • A bit complicated setup • We need to setup paging data for preview • Need to be exposed as a separate data flow besides the uiState • A bit Overkill
11. PagingState LoadingNextPage FailedToLoadNextPage Loaded (Idle) Trigger load next page Trigger reload Loading success Loading failed
12. State - Implementation sealed class PagingState<T>( val key: Long?, val items: ImmutableList<T>, ) { data class LoadingNextPage<T>( private val currentLoadingKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(currentLoadingKey, _items.toImmutableList()) data class FailedToLoadNewPage<T>( private val failedLoadingKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(failedLoadingKey, _items.toImmutableList()) data class Loaded<T>( private val nextKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(nextKey, _items.toImmutableList()) }
13. State - Implementation sealed class PagingState<T>( val key: Long?, val items: ImmutableList<T>, ) { data class LoadingNextPage<T>( private val currentLoadingKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(currentLoadingKey, _items.toImmutableList()) data class FailedToLoadNewPage<T>( private val failedLoadingKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(failedLoadingKey, _items.toImmutableList()) data class Loaded<T>( private val nextKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(nextKey, _items.toImmutableList()) } Current Items
14. State - Implementation sealed class PagingState<T>( val key: Long?, val items: ImmutableList<T>, ) { data class LoadingNextPage<T>( private val currentLoadingKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(currentLoadingKey, _items.toImmutableList()) data class FailedToLoadNewPage<T>( private val failedLoadingKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(failedLoadingKey, _items.toImmutableList()) data class Loaded<T>( private val nextKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(nextKey, _items.toImmutableList()) }
15. State - Implementation sealed class PagingState<T>( val key: Long?, val items: ImmutableList<T>, ) { data class LoadingNextPage<T>( private val currentLoadingKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(currentLoadingKey, _items.toImmutableList()) data class FailedToLoadNewPage<T>( private val failedLoadingKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(failedLoadingKey, _items.toImmutableList()) data class Loaded<T>( private val nextKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(nextKey, _items.toImmutableList()) }
16. State - Implementation sealed class PagingState<T>( val key: Long?, val items: ImmutableList<T>, ) { data class LoadingNextPage<T>( private val currentLoadingKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(currentLoadingKey, _items.toImmutableList()) data class FailedToLoadNewPage<T>( private val failedLoadingKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(failedLoadingKey, _items.toImmutableList()) data class Loaded<T>( private val nextKey: Long? = null, private val _items: List<T> = emptyList() ) : PagingState<T>(nextKey, _items.toImmutableList()) }
17. UI State sealed class UiState { /** * Main State of the Package Screen. */ data class Main( // ... val stickerPackagePagingState: PagingState<Package> = PagingState.Loaded(), // ... ) : MyPageUiState() }
18. UI Implementation @Composable fun PackageList( pagingState: PagingState<Package>, loadNextPage: (Long) -> Unit, ) { val lazyListState = rememberLazyListState() LazyColumn( state = lazyListState, modifier = Modifier.fillMaxSize(), ) { } }
19. UI Implementation fun PackageList( pagingState: PagingState<Package>, loadNextPage: (Long) -> Unit, ) { val lazyListState = rememberLazyListState() LazyColumn( state = lazyListState, modifier = Modifier.fillMaxSize(), ) { items(pagingState.items) { item -> PackageItem( stickerPackageViewData = item, onItemClicked = onItemClick, ) } } }
20. LazyColumn( state = lazyListState, modifier = Modifier.fillMaxSize(), ) { items(pagingState.items) { item -> PackageItem( stickerPackageViewData = item, onItemClicked = onItemClick, ) } item { PackageListFooter( lazyListState = lazyListState, pagingState = pagingState, loadNextPage = loadNextPage ) } } UI Implementation Only enters the composition when the items reaches its final item
21. UI Implementation @Composable private fun PackageListFooter( lazyListState: LazyListState, pagingState: PagingState<Package>, loadNextPage: (Long) -> Unit, ) { when (pagingState) { is PagingState.Loaded -> { // Start loading next page when footer is reached LaunchedEffect(pagingState.key) { pagingState.key?.let(loadNextPage) } } is PagingState.FailedToLoadNewPage -> { PackageErrorFooter( onReloadClick = { pagingState.key?.let(loadNextPage) } ) LaunchedEffect(pagingState.key) { lazyListState.animateScrollToItem(pagingState.items.size + 1) } } is PagingState.LoadingNextPage -> { PackageLoadingFooter() LaunchedEffect(pagingState.key) { lazyListState.animateScrollToItem(pagingState.items.size + 1) } } } }
22. Conclusion - For more complicated cases or building from scratch, we could consider Jetpack paging - Self implemented paging is easy with the nature of Compose
23. Thank You
24. Appendix Code Snippet - https://gist.github.com/kuramu1108/287e64e1fdf564e31cfff38db2d49b34
