MVVM in iOS

Slides from the talk I gave at CocoaHeads Moscow 29.11.13.

Transcript

1. MVVM pattern in iOS development
   Denis Lebedev,
   iOS Hipster @ Wargaming
   !
   mailto: d_lebedev@wargaming.net
   linkedin: http://linkedin.com/in/dlebedev


   View Slide

2. View Slide

3. Agenda
   Wargaming Service Mobile Apps dept.
   MVC
   MVVM
   Development hints
   Reference


   View Slide

4. WARGAMING SERVICE MOBILE APPS


   View Slide

5. SMA department
   We make apps for user engagement
   Quality really matters
   We experiment a lot with new tools & technologies


   View Slide

6. Apps


   View Slide

7. MODEL-VIEW-CONTROLLER


   View Slide

8. MVC Diagram
   View
   Model
   Controller


   View Slide

9. Classical principles
   Loose coupling
   Model is decoupled; view/controller can listen to it’s changes
   View knows about model, can manipulate controller
   Controller knows everything and “does all the things” ©


   View Slide

10. View Controller responsibilities
    Owns & manages view’s state
    Acts as the datasource for tableviews
    Maps model’s properties to view values
    …


    View Slide

11. MASSIVE VIEW CONTROLLER


    View Slide

12. Real world MVC
    Controllers are ‘almost’ not reusable
    Controllers are large
    View is very tight to it’s controller
    Controllers are hard to unit test


    View Slide

13. Solving Massive Controller problems
    Separate object acting as tableview dataSource
    ConverterHelper, ‘MyFancyAttributeToStringHelper’, etc..


    View Slide

14. Testing
    Unit tests of controllers code is pain
    Sort of UI tests (Calabash, KIF) is required


    View Slide

15. Wrapping up
    MVC is not bad at all.


    View Slide

16. Wrapping up
    What can we do for better world?


    View Slide

17. MODEL-VIEW-VIEWMODEL


    View Slide

18. MVVM Diagram
    View/
    ViewController
    ViewModel Model


    View Slide

19. MVVM Diagram
    Wait what? It’s the same!


    View Slide

20. Key differences with MVC
    ViewController owns it’s view model
    View model doesn’t know anything about controller


    View Slide

21. Key differences with MVC
    View/ViewController
    ViewModel
    Model
    ViewController
    View
    Model
    MVC MVVM


    View Slide

22. MVVM Models
    Can represent single domain entity or collection
    Responsible for fetching/storing data


    View Slide

23. MVVM Views
    Cocoa note: MVVM view = view + view controller
    view is stateless
    views/view controllers become smaller


    View Slide

24. MVVM View Models
    encapsulates all view data/properties and binds them to view
    validation logic
    actions


    View Slide

25. ReactiveCocoa
    Functional reactive paradigm in Cocoa world
    Fancy bindings
    Composes of sync/async events of any kind
    Mature, production-ready framework


    View Slide

26. ReactiveCocoa
    RAC(self, title) = RACObserve(self, viewModel.nickname);


    View Slide

27. ReactiveCocoa
    RAC(self, stringType) = [RACObserve(self, model.type)
    map:^id(NSNumber *v) {
    return v.intValue == 0 ? @"zero" : @"non-zero";
    }];


    View Slide

28. Benefits
    We don’t need to to test the UI (actually we should)
    We can implement app logic without any UI
    view model is easy testable
    view model are (almost) platform independent


    View Slide

29. Platform agnostic code
    iPad / iPhone / OS X code sharing
    MVVM + Xamarin = shared Windows / OS X code


    View Slide

30. How we came to MVVM
    Already familiar with ReactiveCocoa
    Strong need in good internal testing
    Fresh project developed from scratch


    View Slide

31. DEVELOPMENT HINTS


    View Slide

32. What actually does view controller?
    Layout
    Animations
    Device rotation
    View transitions
    !
    All sensible state is stored in view model


    View Slide

33. Instantiation
    Every controller has viewModel property
    Some views may have separate view models
    Inject view model to controller during instantiation
    Inject view model’s important properties during instantiation


    View Slide

34. ViewModel interface
    RACSignals as model properties where possible
    RACSignal for data requests
    Model property (NSArray, domain object, etc.)


    View Slide

35. WPAFeaturesViewModel.h
    @interface WPAPlaneFeaturesViewModel : NSObject
    !
    @property (copy, nonatomic) NSArray *planeRows;
    !
    @property (strong, nonatomic, readonly) RACCommand *forwardCommand;
    @property (strong, nonatomic, readonly) RACSignal *forwardHidden;
    !
    @property (strong, nonatomic) RACSignal *nextPlaneTitle;
    !
    - (instancetype)initWithReferencePlane:(WOWPPlane *)plane
    classMates:(NSArray *)planes;
    !
    @end


    View Slide

36. ViewModel for tableviews
    ViewModel has “rows” property of type NSArray
    Row is some NSObject subclass with data very coupled to cell
    Formatters, etc. are applied to row class, not cell
    Controller binds to “rows” and reloads data after property changes


    View Slide

37. WPAPlaneRow.h
    @interface WPAPlaneRow : NSObject
    !
    @property (strong, nonatomic) WPAFeature *feature;
    @property (copy, nonatomic) NSString *value;
    @property (copy, nonatomic) NSString *grade;
    @property (copy, nonatomic) NSString *referenceGrade;
    !
    @end


    View Slide

38. Testing
    State of model can be determined in any moment
    Property change affects view model internal state
    RACCommand changes view model state
    RACSignal pushes new state to subscribers
    ViewModel tests are very obvious and atomic:


    View Slide

39. Real world testing
    Unit tests for view models
    Integration tests (for controllers) with KIF


    View Slide

40. IMPERATIVE VS DECLARATIVE


    View Slide

41. How to be functional and reactive
    Write declarative code instead of imperative
    Describe how properties are related to each other


    View Slide

42. Functional Reactive view model
    Almost all code is in constructor
    Describes how the view should work in terms of commands and
    properties


    View Slide

43. Functional Reactive view model
    The login button can be pressed when username and password aren’t
    blank
    !
    The error should be cleared after 5 seconds it was displayed


    View Slide

44. REFERENCE


    View Slide

45. Functional Reactive view model
    ReactiveCocoa https://github.com/ReactiveCocoa/ReactiveCocoa
    ReactiveViewModel https://github.com/ReactiveCocoa/
    ReactiveViewModel
    !
    FRP on iOS https://leanpub.com/iosfrp
    !
    FunctionalReactivePixels https://github.com/AshFurrow/
    FunctionalReactivePixels
    MVVMExample https://github.com/garnett/MVVMExample
