  1. Hacking apps for fun and profit iOS security overview Denis

    Lebedev MobileOptimized 2013 www.linkedin.com/in/dlebedev
  2. Agenda - iOS security overview - A bit of Obj-C

    runtime - Tools for manipulating apps at runtime - Use cases - Recommendations
  3. iOS Apps security - Focus on backend security

  4. iOS Apps security - Focus on backend security

  5. iOS Apps security - Client side - who cares?

  6. Security overview

  7. Memory corruption[1] - the oldest of the vulnerabilities - on

    of the hardest to find and prevent - dog-cat-mouse game
  8. Data execution prevention (DEP) - OS marks certain memory pages

    as ‘non executable’ - processor refuses to execute that pages - used to prevent part of memory corruption cases
  9. Address space layout randomization - randomly shuffles positions of important

    data in memory - finding particular memory location is not trivial* - introduced in iOS 4.3 * evasi0n jailbreak uses arm exception vector layout information to map memory layout
  10. - Apps are run by user ‘mobile’ - Apps must

    be signed by Apple - Each app has unique ID and directory - ‘Sandbox’ restricts app from accessing almost everything - Apps cannot access data from other apps* - Low level ‘attacks’ reduced with ‘sandbox’* General conditions
  11. - encrypted container (128 bit AES algorithm) - SQLite database

    with 4 tables: genp, inet, cert, keys - keychain API performs IPC calls to securityd which handles database access - access control is based on application id - new: applications with the same keychain access group entitlement can access/share the keychain items - simple “WHERE agrp = %s” clause appended to SQL statements Keychain
  12. Keychain protection classes kSecAttrAccessibleWhenUnlocke d (default) Keychain item is accessible

    only after the device is unlocked kSecAttrAccessibleAfterFirstUnl ock Keychain item is accessible only after the first unlock of the device until reboot kSecAttrAccessibleAlways Keychain item is accessible even when the device is locked kSecAttrAccessibleWhenUnlocke dThisDeviceOnly Keychain item is accessible only after the device is unlocked, and the item cannot be migrated between devices. kSecAttrAccessibleAfterFirstUnl ockThisDeviceOnly Keychain item is accessible after the first unlock of the device and the item cannot be migrated between devices. kSecAttrAccessibleAlwaysThisD eviceOnly Keychain item is accessible even when the device is locked and the item cannot be migrated between devices.
  13. NSMutableDictionary  *query  =  [NSMutableDictionary  dictionary]; [query  setObject:(id)kSecClassGenericPassword  forKey: (id)kSecClass]; [query

     setObject:account  forKey:(id)kSecAttrAccount]; [query  setObject:(id)kSecAttrAccessibleWhenUnlocked  forKey: (id)kSecAttrAccessible]; [query  setObject:data  forKey:(id)kSecValueData];   OSStatus  error  =  SecItemAdd((CFDictionaryRef)query,  NULL); Keychain by example
  14. - get physical access to the device - substitute appID

    and get access from other apps - use tools (keychaindump, keychainviewer)[2] Hack keychain
  15. - introduced in iOS 4.0 - CoreData supports it natively

    from iOS 5.0 - same protection classes as for keychain Data protection APIs
  16. Set data protection for custom file NSDictionary  *attrs  =  [NSDictionary

     dictionaryWithObject:   NSFileProtectionComplete  forKey:NSFileProtectionKey]; BOOL  success  =  [self  setAttributes:attrs  ofItemAtPath:<FILE>   error:nil]; It’s also possible with Entitelments.plist
  17. Cryptography - built-in AES support - each file is encrypted

    with its own key, which is encrypted by the filesystem key [3] - fast data wipe by removing ‘master key’
  18. Tools

  19. - get app resources (iExplorer) - list used frameworks (otool)

    - classes/methods list (nm) Without jailbreak curious user can:
  20. otool -L <APPNAME> <APPNAME>: /System/Library/Frameworks/CoreText.framework/CoreText (compatibility version 1.0.0, cu /System/Library/Frameworks/ImageIO.framework/ImageIO

    (compatibility version 1.0.0, curre /System/Library/Frameworks/QuartzCore.framework/QuartzCore (compatibility version 1.2 /System/Library/Frameworks/SystemConfiguration.framework/SystemConfiguration (compat version 499.0.0) /usr/lib/libxml2.2.dylib (compatibility version 10.0.0, current version 10.8.0) /System/Library/Frameworks/Security.framework/Security (compatibility version 1.0.0, curren /System/Library/Frameworks//CoreData.framework/CoreData (compatibility version 1.0.0, c /System/Library/Frameworks/UIKit.framework/UIKit (compatibility version 1.0.0, current ver /System/Library/Frameworks/Foundation.framework/Foundation (compatibility version 300.0 /System/Library/Frameworks/CoreGraphics.framework/CoreGraphics (compatibility version /usr/lib/libobjc.A.dylib (compatibility version 1.0.0, current version 227.0.0) /usr/lib/libSystem.dylib (compatibility version 1.0.0, current version 125.0.0)
  21. nm -U <APPNAME> > file.txt 00040860 t -[WABaseProfileHeader itemsTable] 00040980

    t -[WABaseProfileHeader nicknameLabel] 00040980 - 01 0000 FUN -[WABaseProfileHeader nicknameLabel] 00040360 t -[WABaseProfileHeader onClanButtonTap:] 00040360 - 01 0000 FUN -[WABaseProfileHeader onClanButtonTap:] 000402d0 t -[WABaseProfileHeader onCompareButtonTap:] 000402d0 - 01 0000 FUN -[WABaseProfileHeader onCompareButtonTap:] 00040610 t -[WABaseProfileHeader roleLabel] 00040610 - 01 0000 FUN -[WABaseProfileHeader roleLabel] *Xcode does not strip symbols by default [5]
  22. None
  23. - Remove apple limitations - Install cool geeky software Jailbreak

  24. None
  25. Static analysis - clutch - decrypt app container - class-dump-z

    - dump classes
  26. Dynamic analysis

  27. Viva Obj-C Runtime!

  28. #import  <objc/runtime.h>   #import  <objc/message.h> //.... void  Swizzle(Class  c,  SEL

     orig,  SEL  new) {        Method  origMethod  =  class_getInstanceMethod(c,  orig);        Method  newMethod  =  class_getInstanceMethod(c,  new);        if(class_addMethod(c,  orig,  method_getImplementation(newMethod),   method_getTypeEncoding(newMethod)))                class_replaceMethod(c,  new,  method_getImplementation(origMethod),   method_getTypeEncoding(origMethod));        else        method_exchangeImplementations(origMethod,  newMethod); } * Original implementation is not called
  29. DLIntrospection [6] (lldb)  po  [[UIDevice  class]  properties] (lldb)  po  [[UIDevice

     class]  instanceMethods] ... -­‐  (BOOL)isMediaPicker, -­‐  (void)setIsMediaPicker:(BOOL)arg0  , -­‐  (id)systemVersion, -­‐  (void)_unregisterForSystemSounds:(id)arg0  , -­‐  (void)_registerForSystemSounds:(id)arg0 ... @property  (nonatomic,  assign,  readonly)  BOOL  _useSheetRotation, @property  (nonatomic,  copy)  @?  afterAppearanceBlock, ... @property  (nonatomic,  assign)  {CGSize=ff}  contentSizeForViewInPopover, @property  (nonatomic,  assign,  getter=isInAnimatedVCTransition)  BOOL   inAnimatedVCTransition, @property  (nonatomic,  assign,  readonly)  BOOL  inExplicitAppearanceTransition Dump classes info from within the app:
  30. DLRuntimePatcher    [UIResponder  listenToAllInstanceMethods:^(NSObject  *obj,  SEL  selector)  {

               NSLog(@"%@  called:  '%@'",  obj,  NSStringFromSelector(selector));        }  includePrivate:NO]; [TestA  complementInstanceMethod:@selector(foo)  byCalling:^(NSObject  *obj){        NSLog(@"%@  concrete  method  intercepted  %@",  obj,          NSStringFromSelector(@selector(foo)));    }]; Add additional behavior to the method: Intercept all UIResponder methods
  31. Action What happens? Intercept messages get into internal app logic

    Send messages to existing objects Mutate app internal state Swizzle method implementations Runtime for hacking
  32. On-the-fly manipulations

  33. Cycript cy#  var  a  =  [NSMutableArray  arrayWithCapacity:4] cy#  a  instanceof

     Array true cy#  [a  class] "NSCFArray" - Mix of Objective-C and javascript - Possibility to write Mac/iOS Apps - Hook into existing processes
  34. iPhone:~$  ps  -­‐ax  |  grep  YourApp iPhone:~$  cycript  -­‐p  PID

    #cy  UIApp.keyWindow.rootViewController  =   [[OtherViewController  alloc]  init]; Demo
  35. Inject code via static library

  36. MobileSubstrate - MobileHooker Is used to hook and replace existing

    functions    MSHookFunction(CFShow,  replaced_CFShow,  &original_CFShow); De facto framework for developing iOS(Android!) extensions - MobileLoader dynamically loads code in running iOS process using DYLD_INSERT_LIBRARIES environment variable /Library/MobileSubstrate/DynamicLibraries/ *Use theos tool for convenience[7]
  37. Substrate filters allow inject code in specific places: Filter  =

     {    Bundles  =  (com.apple.UIKit); }; - into bundle - int class - into specific process
  38. Example: change iOS colors %hook UIColor - (UIColor *)initWithRed:(CGFloat)red green:(CGFloat)green

    blue: (CGFloat)blue alpha:(CGFloat)alpha { id color = %orig(1.0, 1.0, 0, 1); return color; } %end
  39. Use Cases

  40. Unlock premium features - (BOOL)isFeatureXAvailabe { return YES }; Evaluate

    encryption logic by tracing program flow - log all objc_msgSend - Combine results with static code analysis
  41. GDB (gdb) exec-file /var/mobile/Applications/<APP- EXECUTABLE> Reading symbols for shared libraries

    . done (gdb) attach <PID> ... (gdb) break objc_msgSend Breakpoint 1 at 0x134cff42e (gdb) commands ... >printf “-[%s %s]\n”, (char *)class_getName($r0),$r1 >c >end (gdb) c Continuing. -[UIStatusBarServer _receivedStatusBarData:actions] -[UIStatusBar _didRecieveStatusBarData:withActions:] ...
  42. What do we want to see? [myCipher  decryptDataWithSecret],  args:<__NSCFConstantString  0x1235xe

     >
  43. What do we want to see? [myCipher  decryptDataWithSecret],  args:<__NSCFConstantString  0x1235xe

     > Constant key is used: potential vulnerability is discovered.
  44. Getting profit from runtime exploiting - Unlock premium content -

    Discover encryption vulnerabilities - Bypass client-side restrictions - Execution of hidden functionality - Dump copyrighted data - Many many other not-so-obvious things
  45. Recommendations

  46. Protect user data - use https - encrypt sql (SQLcipher)

    - store private user data in Keychain - use file protection APIs
  47. - minimum logic on client side - use C code

    for additional obfuscation - verify In-App purchases - do not save significant info in plists/plain text - encrypt your app’s resources (artworks, sound, etc.) - check if phone is jailbroken (and act accordingly) - turn off NSLog :) Protect yourself
  48. Questions?

  49. 1. http://www.isg.rhul.ac.uk/sullivan/pubs/raid-2012.pdf 2. https://code.google.com/p/iphone-dataprotection/downloads/list http:// 3. http://images.apple.com/iphone/business/docs/iOS_Security_Oct12.pdf 4. resources.infosecinstitute.com/iphone-penetration-testing-3/ 5.

    http://www.bdunagan.com/2010/05/15/symbolification-shipping-symbols/ 6. https://github.com/garnett 7. http://iphonedevwiki.net/index.php/Theos/Getting_Started Links
