3D Web – Babylon.js for Your Web App

Modern business applications are anything but boring. Data needs to be visualized understandably and appealingly. Web graphics engines like BabylonJS help us do just that. They enable 2D, 3D, virtual, and augmented reality content to be presented comprehensibly. Thus, among other things, digital concepts can be visualized, configured, and tested – cross-platform and performant. In this session, Max Schulte shows how you can integrate BabylonJS and Angular in an exemplary way, so that both technologies can unfold their full potential in tandem. Learn by live coding how to integrate a graphics engine yourself and achieve your goals.

Transcript

1. 3D Web – Babylon.js for Your Web App Session Max Schulte @MaxOSchulte Engineer / Consultant
2. Forms Over Data 3D Web – Babylon.js for Your Web App Session
3. h"p://gleborgne.github.io/molvwr/#1GCN https://kitchenplanner.ikea.com/jp/UI/Pages/VPUI.htm Session
4. http://build.aritcohomelifts.com/?ct1=0&sc=RAL9006&dc=RAL9006&f=bolon_gradient&dw=designwall_skyline&s gt=tinted&ch1=2225 3D-Engine Talk Session
5. Max Marschall max.marschall@thinktecture.com https://www.thinktecture.com/max-marschall @MaxOSchulte • Consultant at Thinktecture AG. • Specialised in Angular, Ionic and BabylonJS 3D Web – Babylon.js for Your Web App Session
6. An app that … § combines Angular and BabylonJS § is interactive § works on different platforms and devices § uses native hardware (WebGL) https://github.com/thinktecture/webinar-3d- visualisierung-babylonjs-angular DEMO Demo Example App Try now! https://qrgo.page.link/15 mwG 3D Web – Babylon.js for Your Web App Session
7. 3D Web – Babylon.js for Your Web App Session
8. • Cross platform • Any device • Code once run everywhere • On location & remote planning and editing • Shareable with a simple URL • Easy integration web technology Web 3D benefits over native 3D 3D Web – Babylon.js for Your Web App Session
9. Web-Na;ve TypeScript 3D Web – Babylon.js for Your Web App Session
10. • Open source project supported by Microsoft • Framework optimized for web • WebGL hardware acceleration • Complete 3D-Engine • Currently V4.x • V5 • WebGPU support • Snapshot Rendering Babylon.js 3D Web – Babylon.js for Your Web App Session
11. Can I Use - WebGL v1 26.10.2022 • CAN I USE SCREENSHOT + DATE Babylon.js https://caniuse.com/#feat=webgl 3D Web – Babylon.js for Your Web App Session
12. Can I Use - WebGL v2 23.06.2022 • CAN I USE SCREENSHOT + DATE Babylon.js https://caniuse.com/#feat=webgl2 3D Web – Babylon.js for Your Web App Session
13. Can I Use - WebGPU 23.06.2022 Babylon.js h"ps://caniuse.com/#feat=webgpu 3D Web – Babylon.js for Your Web App Session
14. Clarifying keywords • GameObject (TransformNode) à Logical objects • Can hold visual objects and much more • The root of all possible things • Mesh à Visual objects • Scene (Stage) à holds all information • Engine à renders the Scene Babylon.js Babylonjs.com 3D Web – Babylon.js for Your Web App Session
15. Playground h"ps://www.babylonjs-playground.com/#TAZ2CB BabylonJS 3D Web – Babylon.js for Your Web App Session
16. BabylonJS - Angular Angular • UI • Application lifecycle • Services, Contexts, Components • NgZone (ZoneJS) • DOM Integra;on BabylonJS • 3D • Engine lifecycle • Scene • Event-based system • Scene Graph 3D Web – Babylon.js for Your Web App Session
17. Application Angular Components Directives Service BabylonJS Scene Engine Objects Browser Rendering Engine feed instructions update model Web APIs render 3D content WebGL (WebGPU) OS API Hardware View render HTML trigger function Architecture Overview (simplified) 3D Web – Babylon.js for Your Web App Session
18. 3D Web – Babylon.js for Your Web App Session LIVE CODING
19. Lifecycle • Different steps executed by the render loop • Static execution order • Move from “manipulate it now” to “I instruct you to manipulate it at the correct time” mindset • see: Angular’s changeDetectorRef.markForCheck • Syncs the “state” with the “view” (physics not included) Babylon.js 3D Web – Babylon.js for Your Web App Session
20. Two Different Lifecycles Angular • DOM • Event Integration Babylon.js • Loop à e.g. dispose on next iteration • Different timings can cause synchronization problems à Lifecycles should be separated à No dependency from BabylonJS to the Angular lifecycle / change detection cycle à “Add box to scene” becomes “Add box on next iteration” 3D Web – Babylon.js for Your Web App Session
21. Change Detec5on Angular • NgZone (ZoneJS) • Checks on every event Integration BabylonJS • Event-based communication • Events on every frame (60 FPS!) • Exclude BabylonJS from the NgZone à ngZone.runOutsideAngular( … ); • Stop zone.js to observe animation frame requests à (window as any).__Zone_disable_requestAnimationFrame = true; 3D Web – Babylon.js for Your Web App Session
22. Clear responsibilities • Separate contexts • Lifecycle hooks • Naming • Extend exisdng BabylonJS classes • Scene • Mesh • TransformNode • Don’t mix (a mesh must not be a component) My integration key points 3D Web – Babylon.js for Your Web App Session
23. Level of immersiveness 3D AR VR Sweet spot Nintendo Oculus Rift S 3D Web – Babylon.js for Your Web App Session
24. WebAR + Tracking (Development) In Future https://medium.com/@babylonjs/babylon-ar-7823ab4a80c1 • Display and edit • Real size • Rotate and scale to posidon • Integrate into the real world • Web-nadve 3D Web – Babylon.js for Your Web App Workshop
25. https://www.thinktecture.com/de/cheatsheet/angular-babylonjs BabylonJS Cheat Sheet 3D Web – Babylon.js for Your Web App Session
26. Summary Try now! h7ps://qrgo.page.link/15 mwG 1. Extend your data visualization 2. 3D integration is different 3. On your everyday devices max. marschall@thinktecture.com https://www.thinktecture.com/max-marschall @MaxOSchulte
