1. I have a NoSQL Toaster. Why would I want a NoSQL database? Matthew D. Groves @mgroves
2. ©2016 Couchbase Inc. 2 Who am I? • Matthew D. Groves • Developer Advocate for Couchbase • @mgroves on Twitter • Podcast and blog: http://crosscuttingconcerns.com • BS, MBA, Microsoft MVP • “I am not an expert, but I am an enthusiast.” – Alan Stevens
3. ©2016 Couchbase Inc. 3 Tweet something, get a sticker! Use #Couchbase Tweet something interesting you’ve learned. Tweet a picture. I’ve got stickers!
4. ©2016 Couchbase Inc. 4 Couchbase and CouchDB Couchbase is to CouchDB as MySQL is to SQL Server
5. ©2016 Couchbase Inc. 5 SQL is the norm, right? https://commons.wikimedia.org/wiki/File:George_Wendt_at_the_41st_Emmy_Awards_cropped.jpg
6. ~3200 BC: invention of writing in Mesopotamia ~300 BC: Library of Alexandria ~1041 AD: Movable type invented in China 1450: Movable type invented in Europe 1822: Babbage’s paper on the application of difference engines 1943: Colossus, the first programmable digital computer 1957-1960: IBM SABRE, the first commercial use of a database 1970: EF Codd proposes the relational database model 1974: Ingres released 1979: Commercial launch of Oracle database 1988: Object databases appear 1989: Microsoft SQL Server version 1 1991: HTTP v0.9 1995: MySQL’s initial release 2005: CouchDB released 2006: Google’s Big Table paper 2007: Amazon’s Dynamo paper 2008-2009: The NoSQL Cambrian explosion: Riak, MongoDB, Cassandra, Redis 2010: Couchbase arrives on the scene
7. NoSQL isn’t a very useful term https://commons.wikimedia.org/wiki/File:Toaster.jpg
8. ©2016 Couchbase Inc. 8 Easy?
9. ©2016 Couchbase Inc. 9 Scalable? https://commons.wikimedia.org/wiki/File:Dagwood_sandwich.jpg
10. ©2016 Couchbase Inc. 10 Commodity Hardware https://commons.wikimedia.org/wiki/File:Rear_of_rack_at_NERSC_data_center_-_closeup.jpg
11. ©2016 Couchbase Inc. 11 ACID vs BASE? https://commons.wikimedia.org/wiki/File:PH_Scale.svg Atomic Consistent Isolated Durable Basic Availability Soft-state Eventual consistency
12. ©2016 Couchbase Inc. 12 Schema Schemaless https://en.wikipedia.org/wiki/File:Star-schema-example.png
13. ©2016 Couchbase Inc. 13 Normalized Denormalized https://commons.wikimedia.org/wiki/File:Frown.JPG
14. ©2016 Couchbase Inc. 14 First: Why NoSQL? https://www.flickr.com/photos/wonderlane/13067014944
15. ©2016 Couchbase Inc. 15 Perhaps SQL is right for this project
16. ©2016 Couchbase Inc. 16 Scaling can be hard https://commons.wikimedia.org/wiki/File:Sandwiches_Vienna.jpg
17. ©2016 Couchbase Inc. 17 Availability is hard https://www.flickr.com/photos/jeepersmedia/14562425273/ C A P
18. ©2016 Couchbase Inc. 18 Schemas can be hard https://commons.wikimedia.org/wiki/File:MediaWiki_database_schema_1-17_(r82044).svg
19. ©2016 Couchbase Inc. 19 Round pegs, square holes http://www.timesofbook.com/2013/09/blobfish-image-gallery.html#.V6iXwbgrJhE
20. ©2016 Couchbase Inc. 20 Types of NoSQL databases Document Key/Value Columnar Graph
21. ©2016 Couchbase Inc. 21 Document
23. ©2016 Couchbase Inc. 23 What makes it a document database?
24. JSON XML BSON
26. ©2016 Couchbase Inc. 26 The document database understands the format of the document
27. ©2016 Couchbase Inc. 27 It can do server-side stuff
28. Buckets Documents Views N1QL
29. "ClientProductCode","Title","Quantity" "TShirtCBS","Couchbase logo t-shirt (small)",29 "TShirtCBM","Couchbase logo t-shirt (medium)",72 "TShirtCBL","Couchbase logo t-shirt (large)",34 "TShirtCBXL","Couchbase logo t-shirt (extra large)",12 "StickerCBLogo","Couchbase logo sticker",256 "PenCBLogo","Couchbase logo pen",365
30. class Program { private static IBucket _bucket; static void Main(string[] args) { SetupCouchbase(); LoadStockList(); ClusterHelper.Close(); } private static void SetupCouchbase() { ClientConfiguration config = new ClientConfiguration(); config.Servers = new List<Uri> {new Uri("couchbase://192.168.1.5") }; ClusterHelper.Initialize(config); _bucket = ClusterHelper.GetBucket("default"); } private static void LoadStockList() { var csv = new CsvReader(File.OpenText("swag.csv")); while (csv.Read()) { var record = csv.GetRecord<dynamic>(); var document = new Document<dynamic> { Id = record.ClientProductCode, Content = new { record.Title, record.Quantity } }; _bucket.Insert(document); Console.WriteLine($"Added document '{record.ClientProductCode}'"); } } }
31. private static void SetupCouchbase() { ClientConfiguration config = new ClientConfiguration(); config.Servers = new List<Uri> {new Uri("couchbase://192.168.1.5") }; ClusterHelper.Initialize(config); _bucket = ClusterHelper.GetBucket("default"); }
32. private static void LoadStockList() { var csv = new CsvReader(File.OpenText("swag.csv")); while (csv.Read()) { var record = csv.GetRecord<dynamic>(); var document = new Document<dynamic> { Id = record.ClientProductCode, Content = new { record.Title, record.Quantity } }; _bucket.Insert(document); Console.WriteLine($"Added document '{record.ClientProductCode}'"); } }
34. private static void GetDocument() { var doc = _bucket.Get<dynamic>("StickerCBLogo"); Console.WriteLine($"Document Key: {doc.Id}"); Console.WriteLine($"Title: {doc.Value.title}"); Console.WriteLine($"Quantity: {doc.Value.quantity}"); }
36. ©2016 Couchbase Inc. 36 Typical Document Database Operations • Upsert (aka set) • Inserts document if key doesn’t exist, replaces otherwise • Insert (aka add) • Inserts document, error if it already exists • Update (aka replace) • Updates document, error if it doesn’t exist • Delete • Get
37. ©2016 Couchbase Inc. 37 N1QL SELECT m.* FROM `default` m WHERE META(m).id = ‘StickerCBLogo’ SELECT m.* FROM `default` m WHERE m.quantity > 10
38. Great for Dev Scales Easily Consistently Fast
39. ©2016 Couchbase Inc. 39 Use cases for Document Databases • User profiles • Session stores • Content management • General relational replacement
40. ©2016 Couchbase Inc. 40 Key/Value Database
42. ©2016 Couchbase Inc. 42 Key-Value Databases In-memory caches and distributed data stores
43. ©2016 Couchbase Inc. 43 Doesn’t care what your data is (mostly) KEY1 { type: “json” } KEY2 <data type=“xml”></data> KEY3 Lorem ipsum … 00100101000100101 KEYN https://www.flickr.com/photos/dcmot/23168680069
44. Buckets Key-Value Pairs
45. ©2016 Couchbase Inc. 45 C# Riak private static void DoStuffWithRiak() { var cluster = RiakCluster.FromConfig("riakConfig"); var client = cluster.CreateClient(); var actor = new RiakObject("actors", "James Bond","Sean Connery"); client.Put(actor); var actorBackOut = client.Get("actors", "James Bond"); var str = System.Text.Encoding.UTF8.GetString(actorBackOut.Value.Value); Console.WriteLine($"Value: {str}"); }
47. ©2016 Couchbase Inc. 47 Introducing: Eventual Consistency!
48. ©2016 Couchbase Inc. 48 Eventual Consistency https://www.flickr.com/photos/scottchene/7046992749 https://commons.wikimedia.org/wiki/File:Timothy_Dalton_1987.jpg https://commons.wikimedia.org/wiki/File:Sir_Roger_Moore_crop.jpg
49. ©2016 Couchbase Inc. 49 There can be only one! https://en.wikipedia.org/wiki/File:Highlander_film_Connor_MacLeod.jpg
50. ©2016 Couchbase Inc. 50 So, fix it https://www.flickr.com/photos/94086507@N00/84368105
51. Scales Well Highly Available Data Agnostic Maybe some extra work
52. ©2016 Couchbase Inc. 52 Use Cases for K/V • Data variability • Object caching • Session storage • Large object storage
53. ©2016 Couchbase Inc. 53 Columnar
55. Keyspaces Column Families Rows Columns
56. ©2016 Couchbase Inc. 56 Keyspace
57. ©2016 Couchbase Inc. 57 Column Family
58. CREATE KEYSPACE mykeyspace WITH replication = { 'class': 'SimpleStrategy', 'replication_factor': '1'}; CREATE TABLE users (firstname text, lastname text, age int, email text, city text, PRIMARY KEY (lastname));
59. private static void DoStuffWithDataStax() { var cluster = Cluster.Builder().AddContactPoint("127.0.0.1").Build(); var session = cluster.Connect("mykeyspace"); session.Execute("insert into users (lastname, age, city, email, firstname) values ('Jones', 35, 'Austin', 'bob@example.com', 'Bob')"); var userBackOut = session.Execute("select * from users where lastname='Jones'").First(); Console.WriteLine($"{userBackOut["firstname"]} {userBackOut["age"]}"); }
61. Impedance Mismatch Scales Well (Ops Headache) Suited to Analytics
62. ©2016 Couchbase Inc. 62 Use cases for Columnar •Metering data •Really big data •Analytics
63. ©2016 Couchbase Inc. 63 Convergence!
64. ©2016 Couchbase Inc. 64 Graph https://commons.wikimedia.org/wiki/File:The_protein_interaction_network_of_Treponema_pallidum.png
65. ©2016 Couchbase Inc. 65 Leonhard Euler
66. ©2016 Couchbase Inc. 66 7 Bridges of Königsberg
68. ©2016 Couchbase Inc. 68 Use cases for Graph databases • Social networks / dating sites • Fraud detection • Parcel routing • Shopping recommendations
69. ©2016 Couchbase Inc. 69 Say what? Relational Document Key/Value Columnar Graph Object others…
70. ©2016 Couchbase Inc. 70 Box arrow box arrow Web Logic SQL Riak Couchbase More Logic Mobile
71. ©2016 Couchbase Inc. 71 Couchbase, everybody!
72. ©2016 Couchbase Inc. 72 Couchbase Days Join us for Couchbase Day on September 22 in Schaumburg, Illinois. This FREE day-long educational event will feature a combination of hands-on workshops and presentations on Couchbase Server.  Hyatt Place Chicago Schaumburg  September 22nd, 8:30a – 4p  http://www.couchbase.com/nosql- resources/events/2016/september/couchbase-day-schaumburg  http://info.couchbase.com/Couchbase_Day_Schaumburg_Register_web.html  http://tinyurl.com/cbdaychicago
73. ©2016 Couchbase Inc. 73 Where do you find us? • developer.couchbase.com • blog.couchbase.com • @couchbasedev or @couchbase or #couchbase • forums.couchbase.com • stackoverflow.com/questions/tagged/couchbase • @mgroves is me!
