Rubymotion

Charla de rubymotion para meetup dynlang chile, 2013

Transcript

1. IOS MEETS RUBY Monday, September 2, 13
2. MIGUEL MICHELSON https://github.com/michelson/ https://twitter.com/michelson/ RUBY DEVELOPER @ CONTINUUM Monday, September 2, 13
3. RUBYMOTION introduction Monday, September 2, 13
4. Laurent Sansonetti RUBYMOTION 7 Years at Apple as senior software engineer for iLife and OS X Creator and Mantainer of MacRuby RubyCocoa & Gnome contributor Monday, September 2, 13
5. Monday, September 2, 13
6. RUBY Monday, September 2, 13
7. RUBY Lenguaje OOP Permite metaprogramar sintaxis muy expresiva facil de usar y extender Monday, September 2, 13
8. RUBY https://github.com/cogitator/ruby- implementations/wiki/List-of-Ruby- implementations IRONRUBY / JRUBY / MACRUBY / MRUBY Monday, September 2, 13
9. MRUBY http://mobiruby.org/ FREE! Yuichiro MASUI Monday, September 2, 13
10. XCODE Monday, September 2, 13
11. OBJ-C •Superset de C •OOP •Metodos son mensajes Monday, September 2, 13
12. OBJ-C @interface classname : superclassname { // instance variables } +classMethod1; +(return_type)classMethod2; +(return_type)classMethod3:(param1_type)parameter_varName; -(return_type)Method1:(type1)param1_varName :(type2)param2_varName; -(return_type)Method2: (type1)varName1 otherParameter:(type2)varName2 @end Class Definition .h Monday, September 2, 13
13. OBJ-C Class Implementation @implementation classname +classMethod { // implementation } -instanceMethod { // implementation } @end .m Monday, September 2, 13
14. OBJ-C Method Declaration -(int)method:(int)i { return [self square_root: i]; } int function(int i) { return square_root(i); } C OBJ-C Monday, September 2, 13
15. OBJ-C Object Instanciation MyObject * o = [[MyObject alloc] init]; allocation intialization Monday, September 2, 13
16. OBJ-C Foundation Kit Frameworks NSObject NSString NSNumber NSValue Monday, September 2, 13
17. OBJ-C/COCOA Cocoa/Cocoa Touch object-oriented application programming interface Foundation Kit Application Kit / UIKit CoreData Frameworks Monday, September 2, 13
18. OBJ-C/COCOA object-oriented application programming interface Monday, September 2, 13
19. COCOA-APPS Core Objects allocation Monday, September 2, 13
20. XCODE Hello World http://www.appcoda.com/hello-world-build-your-first-iphone-app/ Monday, September 2, 13
21. XCODE Hello World http://www.appcoda.com/hello-world-build-your-first-iphone-app/ Monday, September 2, 13
22. XCODE Hello World http://www.appcoda.com/hello-world-build-your-first-iphone-app/ Monday, September 2, 13
23. XCODE Hello World http://www.appcoda.com/hello-world-build-your-first-iphone-app/ Monday, September 2, 13
24. XCODE Hello World http://www.appcoda.com/hello-world-build-your-first-iphone-app/ Monday, September 2, 13
25. XCODE Hello World http://www.appcoda.com/hello-world-build-your-first-iphone-app/ UIAlertView *message = [[UIAlertView alloc] initWithTitle:@"Hello World!" message:@"orrait!" delegate:nil cancelButtonTitle:@"OK" otherButtonTitles:nil]; [message show]; Monday, September 2, 13
26. XCODE Hello World http://www.appcoda.com/hello-world-build-your-first-iphone-app/ Monday, September 2, 13
27. XCODE Hello World http://www.appcoda.com/hello-world-build-your-first-iphone-app/ Monday, September 2, 13
28. http://www.pixelresort.com/blog/printsforsale/ Monday, September 2, 13
29. RUBYMOTION introduction Monday, September 2, 13
30. RubyMotion RubyMotion apps are created and later maintained from the terminal command-line. A RubyMotion project is based on the Rake tool and can be configured by editing its Rakefile. Monday, September 2, 13
31. RubyMotion Requirements RubyMotion requires a Mac Install the iOS and OS X SDK Monday, September 2, 13
32. $199 RubyMotion Requirements and... Monday, September 2, 13
33. Rubymotion Hello World Monday, September 2, 13
34. RubyMotion Hello World class AppDelegate def application(application, didFinishLaunchingWithOptions:launchO alert = UIAlertView.new alert.message = "Hello World!" alert.show true end end $ motion create hello_world Monday, September 2, 13
35. RubyMotion Hello World alert = UIAlertView.new alert.message = "Hello World!" alert.show $ motion create hello_world Monday, September 2, 13
36. RubyMotion Hello World Monday, September 2, 13
37. RubyMotion Hello World Use Your ruby development tools Monday, September 2, 13
38. RubyMotion Object Model Ruby Model implemented from Objective-C runtime In RubyMotion, Ruby classes, methods and objects are Objective-C classes Objective-C classes, methods and objects are available in Ruby as if they were native. Monday, September 2, 13
39. RubyMotion Object Model Objective-C and RubyMotion share the same object model infrastructure. Objective-C and RubyMotion APIs can be interchangeable at no additional performance expense. Monday, September 2, 13
40. RubyMotion Object Model Monday, September 2, 13
41. RubyMotion Objective-C Messages [string drawAtPoint:point withFont:font]; variable variable variable Monday, September 2, 13
42. RubyMotion Objective-C Messages [string drawAtPoint:point withFont:font]; Message keyword Message keyword Monday, September 2, 13
43. RubyMotion Send messages from RubyMotion to Obj-C string.drawAtPoint(point, withFont:font) Monday, September 2, 13
44. RubyMotion Dispatch Messages manually string.send(:'drawAtPoint:withFont:', point, font) Monday, September 2, 13
45. RubyMotion view.hidden = true unless view.hidden? Monday, September 2, 13
46. RubyMotion Monday, September 2, 13
47. RubyMotion Interfacing with C Basic Types Basic C types cannot be created from Ruby directly, but are automatically converted from and to equivalent Ruby types. Monday, September 2, 13
48. RubyMotion Structs pt = CGPoint.new pt.x = 100 pt.y = 200 'Hello'.drawAtPoint(pt, withFont: font) #It is possible to pass the field values directly to the constructor. pt = CGPoint.new(100, 200) 'Hello'.drawAtPoint(pt, withFont: font) #RubyMotion will also accept arrays as a convenience. #They must contain the same number and type of objects expected in the structure. 'Hello'.drawAtPoint([100, 200], withFont: font) C structures are mapped to classes in RubyMotion. Monday, September 2, 13
49. RubyMotion Pointers rect_ptr = Pointer.new(CGRect.type) rect_ptr = Pointer.new(:int) C type pointer Structure pointers Monday, September 2, 13
50. RubyMotion OBJ-C VS RUBYMOTION obj.method parameter [obj method:parameter] Monday, September 2, 13
51. RubyMotion OBJ-C VS RUBYMOTION arr = ["uno", "dos", "tres"] NSMutableArray *myColors; myColors = [NSMutableArray arrayWithObjects: @"Red", @"Green", @"Blue", @"Yellow", nil]; Monday, September 2, 13
52. RubyMotion OBJ-C VS RUBYMOTION dict = {key: "value", key2: "dos", key3: "tres"} NSDictionary *dict = [NSDictionary dictionaryWithObjectsAndKeys: @"value1", @"key1", @"value2", @"key2", nil]; Monday, September 2, 13
53. RubyMotion OBJ-C VS RUBYMOTION “Hello” + “world” NSString *string = [NSString stringWithFormat:@"%@%@", @"Hello", @"World"]; NSLog(@"%@", string); Monday, September 2, 13
54. RubyMotion OBJ-C VS RUBYMOTION 10 + “string” int numero = 10; NSString = @string" bah NSString *string = @"string" NSString *stringConcat = [NSString stringWithFormat:@"%s - %i",string, numero]; Monday, September 2, 13
55. RubyMotion OBJ-C VS RUBYMOTION //XYZPerson.h" @interface Person : NSObject @property NSString *firstName; @property NSString *lastName; @end //XYZPerson.m" #import "XYZPerson.h" @implementation XYZPerson - (void)fullName { NSLog(@"Hello, World!"); } @end class Person attr_accessor :first_name, :last_name def hello_world "#{@first_name} #{@last_name}" end end Monday, September 2, 13
56. RubyMotion APP Configuration Motion::Project::App.setup do |app| # Use `rake config' to see complete project settings. app.name = 'delaymachine' app.device_family = :iphone app.icons = ["nucleardevilhorns.jpg"] app.frameworks += ['CoreImage', 'QuartzCore'] .... end Monday, September 2, 13
57. RubyMotion Vendorize app.vendor_project('vendor/pd-for-ios/libpd', :xcode, :xcodeproj => 'libpd.xcodeproj', :target => 'libpd-ios', :headers_dir => 'objc' ) app.vendor_project('vendor/dccontrols', :static) Monday, September 2, 13
58. RubyMotion app.pods do pod 'NanoStore' #, '~> 2.1.4' #pod 'NUI' pod 'SVProgressHUD' pod 'SDWebImage' end CocoaPods Monday, September 2, 13
59. RubyMotion Bundler source "https://rubygems.org" gem "motion-cocoapods" gem 'bubble-wrap' gem "ProMotion" #gem "formotion" #gem "nitron" #gem "teacup" #gem "nano-store" #gem "elevate", "~> 0.5.0" #gem 'motion-config-vars' #gem "motion-hpple" group :development do gem 'guard-shell', :require=>false end Monday, September 2, 13
60. RubyMotion Metaprogramming class_eval instance_eval alias_method send define_singleton_method module_eval const_get const_set Monday, September 2, 13
61. RubyMotion Test describe "Application 'rubymotion-libpd'" do before do @app = UIApplication.sharedApplication end it "has one window" do @app.windows.size.should == 1 end end Monday, September 2, 13
62. RubyMotion BubbleWrap Device Camera HTTP EM Monday, September 2, 13
63. RubyMotion Promotion class AppDelegate < PM::Delegate def on_load(app, options) open RootScreen.new(nav_bar: true) end end class RootScreen < PM::Screen title "Root Screen" def push_new_screen open NewScreen end end class NewScreen < PM::TableScreen title "Table Screen" def table_data [{ cells: [ { title: "About this app", action: :tapped_about }, { title: "Log out", action: :log_out } ] }] end end Monday, September 2, 13
64. DEMO Monday, September 2, 13
65. RubyMotion DANKE! https://github.com/michelson/ https://twitter.com/michelson/ Monday, September 2, 13
